Greek Architecture

1
Greek Architecture
2
Gods and temples are not easily instituted, and
to establish them rightly is the work of a
mighty intellect. -Plato
The site should be a spot seen far and wide,
which gives due elevation to virtue and towers
over the neighborhood. -Aristotle
3
Architectural Diagrams
Temple of Hera II, Paestum
Ground Plan
Section
Elevation
4
Temple of Aphaia, Aegina, 490 BCE
5
Architectural Systems
Post and Lintel
Corbel
Arch
6
Evolution of the Greek Temple
Mortuary precinct of Djoser, Saqqara, Egypt, Old
Kingdom, c. 2775 BCE
engaged columnsfluting
7
peripertal
8
Part of a Greek Temple
(opisthodomos)
Pronaos (Porch)
Naos (Cella)
Colonnade (Peristyle)
9
Elevation of a Greek Temple Orders of Classical
Architecture
10
Pediment
Frieze
Capital
11
Metope
Triglyph
12
Evolution of Peripertal Temple
Archaic Temple of Hera I, Paestum, 550 BCE
Early Classical Temple of Aphaia, Aegina, 490 BCE
13
Archaic
Temple of Hera I, Paestum, 550 BCE
Early Classical
Temple of Aphaia, Aegina, 490 BCE
Temple of Hera II, Paestum, 460 BCE
High Classical
Parthenon, Athens, 448-432 BCE
14
Evolution of Ratios in Ground Plan
12
13
612
1021
616
(613)(715)
817
Parthenon
x 2x 1
15
Evolution of Ratios in Elevation
Temple of Hera II
Parthenon
Temple of Hera I
