Strong-field physics revealed through time-domain spectroscopy

1
Strong-field physics revealed through time-domain
spectroscopy
Grad student Li Fang now at LCLS Funding NSF-A
MO
George N. Gibson University of Connecticut Departm
ent of Physics
November 18, 2009 Stevens Institute of
Technology Hoboken, New Jersey
2
Motivation

• Vibrational motion in pump-probe experiments
  reveals the role of electronically excited
  intermediate states.
• This raises questions about how the intermediate
  states are populated. Also, we can study how
  they couple to the final states that we detect.
• We observe inner-orbital ionization, which has
  important consequences for HHG and quantum
  tomography of molecular orbitals.

3
Pump-probe experiment with fixed wavelengths.
In these experiments we used a standard TiSapphir
e laser 800 nm 23 fs pulse duration 1 kHz rep.
rate
Probe
Pump
4
Pump-probe spectroscopy on I22
Enhanced Excitation
Enhanced Ionization at Rc
Internuclear separation of dissociating molecule
5
Lots of vibrational structure in pump-probe
experiments
6
Vibrational structure

• Depends on
• wavelength (400 to 800 nm).
• relative intensity of pump and probe.
• polarization of pump and probe.
• dissociation channel.
• We learn something different from each signal.
• Will try to cover several examples of vibrational
  excitation.

7
I2 pump-probe data
8
(2,0) vibrational signal

• Amplitude of vibrations so large that we can
  measure changes in KER, besides the signal
  strength.
• Know final state want to identify intermediate
  state.

9
I2 potential energy curves
10
Simulation of A state
11
Simulation results
From simulations - Vibrational period-
Wavepacket structure- (2,0) state
12
What about the dynamics?

• How is the A-state populated?
• I2 ? I2 ? (I2) - resonant excitation?
• I2 ? (I2) directly innershell ionization?
• No resonant transition from X to A state in I2.

13
From polarization studies

• The A state is only produced with the field
  perpendicular to the molecular axis. This is
  opposite to most other examples of strong field
  ionization in molecules.
• The A state only ionizes to the (2,0)
  state!?Usually, there is a branching ratio
  between the (1,1) and (2,0) states, but what is
  the orbital structure of (2,0)?
• Ionization of A to (2,0) stronger with parallel
  polarization.

14
Implications for HHG and QT

• We can readily see ionization from orbitals
  besides the HOMO.
• Admixture of HOMO-1 depends on angle.
• Could be a major problem for quantum tomography,
  although this could explain some anomalous
  results.

15
(2,0) potential curve retrieval
It appears that I22 has a truly bound potential
well, as opposed to the quasi-bound ground state
curves. This is an excimer-like system bound
in the excited state, dissociating in the ground
state. Perhaps, we can form a UV laser out of
this.
16
Wavelength-dependent pump probe scheme

• Change inner and outer turning points of the
  wave packet by tuning the coupling wavelength.
• Femtosecond laser pulses
• Pump pulse variable wavelength. (517 nm, 560 nm
  and 600 nm.) Probe pulse 800 nm.

17
I2 spectrum vibrations in signal strength and
kinetic energy release (KER) for different pump
pulse wavelength 517nm, 560 nm and 600 nm
18
Simulation trapped population in the (2,0)
potential well
The (2,0) potential curve measured from the A
state of I2 in our previous work
PRA 73, 023418 (2006)
19
I2 In dissociation channels
20
Neutral ground state vibrations in I2

• Oscillations in the data appear to come from the
  X state of neutral I2.
• Measured the vibrational frequency and the
  revival time.

21
Revival structure

• Vibrational frequencyMeasured 211.0?0.7
  cm-1Known 215.1 cm-1 Finite temp 210.3 cm-1

22
Raman scattering/Bond softening

• Raman transitions are made possible through
  coupling to an excited electronic state. This
  coupling also gives rise to bond softening, which
  is well known to occur in H2.

23
Lochfrass

• New mechanism for vibrational excitation
  LochfrassR-dependent ionization distorts the
  ground state wavefunction creating vibrational
  motion.

• Seen by Ergler et al. PRL 97, 103004 (2006) in
  D2.

24
Lochfrass vs. Bond softening

• Can distinguish these two effects through the
  phase of the signal.

• ?LF ?
• ?BS ?/2.

25
Iodine vs. Deuterium

• Iodine better resolved 23 fs pulse/155 fs
  period 0.15 (iodine) 7 fs pulse/11 fs period
  0.64 (deuterium)
• Iodine signal huge

• DS/Save 0.10

• DS/Save 0.60

26
Variations in kinetic energy

• Amplitude of the motions is so large we can see
  variations in KER or ltRgt.

27
Temperature effects

• Deuterium vibrationally cold at room
  temperatureIodine vibrationally hot at room
  temperature
• Coherent control is supposed to get worse at high
  temperatures!!! But, we see a huge effect.
• Intensity dependence also unusual
• We fit ltRgt DRcos(wtj) RaveAs intensity
  increases, DR increases, Rave decreases.

28
Intensity dependence

• Also, for Lochfrass signal strength should
  decrease with increasing intensity, as is seen.

29

• But, Rave ? temperature

T decreases while DR increases!!!
30
We have an incoherent sea of thermally populated
vibrational states in which we ionize a coherent
hole

• So, we need a density matrix approach.

31
Density matrix for a 2-level model

• For a thermal system
• where p1(T) and p2(T) are the Boltzmann factors.
  This cannot be written as a superposition of
  state vectors.

32
Time evolution of r

• We can write
• These we can evolve in time.

33
Coherent interaction use p/2 pulse for maximum
coherence

• Off diagonal terms have opposite phases. This
  means that as the temperature increases, p1 and
  p2 will tend to cancel out and the coherence will
  decrease.

34
R-dependent ionization assume only the right
well ionizes.

• yf (yg ye)/2
• Trace(r) ½ due to ionization

What about excited state?
NO TEMPERATUREDEPENDENCE!
35
Expectation value of R, ltRgt
The expectation values are p/2 out of phase for
the two interactions as expected.
36
Comparison of two interactions

• Coherent interactions
• Off diagonal terms are imaginary.
• Off diagonal terms of upper and lower states have
  opposite signs and tend to cancel out.

• R-dependent ionization
• Off-diagonal terms are real.
• No sign change, so population in the upper state
  not a problem.

Motion produced by coherent interactions and
Lochfrass are p/2 out of phase.
37
Real (many level) molecular system

• Include electronic coupling to excited state.
• Use I(R) based on ADK rates. Probably not a good
  approximation but it gives R dependence.
• Include n 0 - 14

38
Generalize equations
39
Same conclusions

• For bond-softening
• Off-diagonal terms are imaginary and opposite in
  sign to next higher state. r12(1) ? -r12(2)
• DR decreases and ltngt increases with temperature.
• For Lochfrass
• Off diagonal terms are real and have the same
  sign. r12(1) ? r12(2)
• DR increases and ltngt decreases with temperature.

40

• Excitation from Lochfrass will always yield real
  off diagonal elements with the same sign for
  excitation and deexcitation f(R) is the survival
  probablility

41
DR and ltngt
42
Density matrix elements
43
Conclusions

• Coherent reversible interactions
• Off-diagonal elements are imaginary
• Excitation from one state to another is
  out-of-phase with the reverse process leading to
  a loss of coherence at high temperature
• Cooling not possible
• Irreversible dissipative interactions
• Off-diagonal elements are real
• Excitation and de-excitation are in phase leading
  to enhanced coherence at high temperature
• Cooling is possible

44
Conclusions

• Excitation of the A-state of I2 through
  inner-orbital ionization
• Excitation of the B-state of I2 to populate the
  bound region of (2,0) state of I22
• Vibrational excitation through tunneling
  ionization.

45
Laser System

• TiSapphire 800 nm Oscillator
• Multipass Amplifier
• 750 ?J pulses _at_ 1 KHz
• Transform Limited, 25 fs pulses
• Can double to 400 nm
• Have a pump-probe setup

46
Ion Time-of-Flight Spectrometer
47
Phase lag
48
Ionization geometry
49
Ionization geometry
50
I2 pump-probe data
