Title: U.S. Environmental Protection Agency


1
U.S. Environmental Protection Agency
  • Using Contaminant Information in Evaluating Water
    Contamination Threats and Incidents

2
Course Overview
  • This course is divided into ten parts
  • Part 1 Course Goals and Definitions
  • Part 2 Contaminants of Concern and Overview of
    Toxicology,
  • (Primarily as related to Chemical
    Contaminants)
  • Part 3 Characteristics and Properties of
    Chemicals as they
  • Relate to Water Systems Contamination
  • Part 4 Properties and Characteristics
    Pathogens
  • Part 5 Properties and Characteristics
    Radiochemical Agents
  • Part 6 Gathering and Managing Contaminant
    Information
  • Part 7 Data Use for Consequence Analysis
  • Part 8 Example Contamination Scenario
  • Part 9 Action Items and Learning Tools
  • Part 10 Appendix (Example Scenarios for other
    Contaminants)
  • Please click on the links above to go to that
    part of
  • the presentation

3
Part 1 Course Goals and Definitions
Return to Course Overview Slide
4
Course Goal
  • Integrate existing water security knowledge,
    information, resources and tools into a training
    to provide for a more effective and efficient
    response to contamination threats and incidents

Return to Course Overview Slide
5
Course Goal
  • Gain a basic understanding of the following
  • Basic toxicology
  • Contaminants of concern
  • Types of contaminant properties / characteristics
  • Understand the process involved in researching
    and analyzing contaminants of concern, including
  • Identifying appropriate sources of information
  • Using data to assess potential threat and
    consequences to public
    health

Return to Course Overview Slide
6
Definitions
  • Routine Threats and Incidents
  • An actual occurrence in which hazards or threats
    result in a harmful, dangerous, or otherwise
    unwanted outcome
  • Hoaxes
  • Security breaches
  • September 11, 2001
  • Anthrax-contaminated mail
  • National Special Security Events (NSSE)
  • A significant event or designated special event
    requiring security
  • Presidential Inauguration
  • State of the Union Address
  • National conventions
  • Olympics
  • International summit conferences

Return to Course Overview Slide
7
Part 2 Contaminants of Concern and Overview of
Toxicology (Primarily as Related to Chemical
Contaminants)
Return to Course Overview Slide
8
What are the Priority Drinking Water Contaminants?
  • More than 200 contaminants identified as posing a
    threat to drinking water systems, based on
  • Health effects (toxicity or infectivity)
  • Ability to be dispersed through distribution
    system
  • Six main categories of contaminants
  • Inorganic chemicals (e.g., cyanide)
  • Organic chemicals (e.g., pesticides)
  • Schedule 1 Chemical Warfare Agents (e.g., sulfur
    mustard)
  • Biotoxins (e.g., ricin)
  • Pathogens (e.g., Bacillus anthracis Anthrax)
  • Radiochemicals (e.g., Cesium-137)

Return to Course Overview Slide
9
Toxicity Data
  • What is it?
  • A measure of the degree to which a substance can
    elicit a deleterious effect (including death) in
    a given organism
  • Why is it important?
  • Toxicity is directly related to the public health
    outcome of a threat
  • Many chemicals are more toxic via exposure routes
    other than ingestion
  • The public can be exposed to drinking water
    contaminants via showering (inhalation), bathing
    (dermal contact), as well as ingestion
  • Different types (acute, chronic) depending on
    chemical, concentration, and exposure route
  • Basic tenet of toxicology
  • Dosis facit venenum
  • The dose makes the poison (Paracelus)

Return to Course Overview Slide
10
Basic Toxicology
  • Acute, Sub-Acute
  • Immediate or almost immediate adverse health
    effects from exposure to a substance (for water
    contaminants, usually within a day)
  • Chronic, Sub-Chronic
  • Adverse health effects resulting from long-term
    or repeated (chronic, gt10 of lifespan) exposure
    to a substance over a period of time
  • Can occur at low levels that have no ACUTE
    effects
  • Chronic health effects can be as severe as acute
    effects, but take much longer to manifest
  • Lethal, Sub-Lethal
  • Causes death immediately or over a short period
    of time
  • Sub-lethal is not quite lethal less than lethal

Return to Course Overview Slide
11
Exposure Routes
  • Definition
  • The route through which a chemical, physical, or
    biological agent may enter the body
  • Dermal Route
  • Agent is absorbed directly through the skin
  • Inhalation Route
  • Agent enters through the respiratory tract or
    lungs
  • Oral Ingestion Route
  • Agent enters through the mouth and digestive
    system

Return to Course Overview Slide
12
Exposure Routes (cont.)
  • Other Routes
  • Ocular (through the eyes)
  • Mucous membranes
  • Direct entry into the bloodstream through cuts or
    open sores

Return to Course Overview Slide
13
Drinking Water and Exposure Routes
  • Drinking water use provides opportunities for
    exposure through all of these routes
  • Drinking and Cooking
  • Ingestion
  • Dermal
  • Bathing and Showering
  • Inhalation
  • Ocular
  • Mucus membranes
  • Maintenance and Recreation
  • Inhalation (Watering vegetable gardens)
  • Dermal, Inadvertent ingestion (Swimming and
    wading pools)
  • Direct entry through cuts or open sores
  • Inadvertent ingestion
  • Dermal

Return to Course Overview Slide
14
Toxicity Measures
  • Some toxicity measurements are more applicable
    than others in assessing the concentration at
    which a contaminant will have acute or immediate
    impacts, while others will have more chronic,
    long-term impacts
  • Assessing acute or immediate impacts of
    contaminant
  • Lethal dose 50 (LD50), infectious dose 50 (ID50),
    or lethal concentration 50 (LC50)
  • No observed adverse effect level (NOAEL)
  • Lowest observed adverse effect level (LOAEL)
  • Assessing chronic, or long-term impacts of
    contaminant
  • Maximum contaminant level (MCL)
  • Maximum contaminant level goal (MCLG)

Return to Course Overview Slide
15
Toxicity Measures (cont.)
  • Impacts will vary and may be based on acute or
    chronic levels
  • Health advisory (HA)
  • Reference dose (RfD)

Return to Course Overview Slide
16
MCLs and MCLGs
  • Maximum Contaminant Level (MCL)
  • The highest level of a contaminant that is
    allowed in drinking water
  • Only established for regulated contaminants
  • Enforceable standards
  • Based on lifetime exposure risk (typically for an
    end point, such as cancer)
  • Maximum Contaminant Level Goals (MCLGs)
  • Level of a contaminant in drinking water below
    which there is no known or expected risk to
    health
  • Allow for a margin of safety and are
    non-enforceable public health goals
  • The MCLG for some contaminants is zero, which
    means there is no safe level for the contaminant

Return to Course Overview Slide
17
Drinking Water Health Advisories (HAs)
  • Estimate of acceptable drinking water levels for
    a chemical substance based on health effects
    information
  • HAs are not a legally enforceable Federal
    standard, but serve as technical guidance to
    assist federal, state, and local officials
  • Developed for specific exposure durations
  • Developed by EPAs Office of Water to provide
    guidance on non-regulated water contaminants and
    for emergency contamination events

Return to Course Overview Slide
18
Drinking Water Health Advisories (HAs) (cont.)
  • 1-Day HA
  • The concentration of a chemical in drinking water
    that is not expected to cause any adverse
    noncarcinogenic effects for up to 1 day of
    exposure. The 1-day HA is normally designed to
    protect a 10-kg child consuming 1 L of water per
    day
  • 10-Day HA
  • The concentration of a chemical in drinking water
    that is not expected to cause any adverse
    noncarcinogenic effects for up to 10 days of
    exposure. The 10-day HA is also normally designed
    to protect a 10-kg child consuming 1 L of water
    per day

Return to Course Overview Slide
19
Drinking Water Health Advisories (HAs) (cont.)
  • Lifetime HA
  • The concentration of a chemical in drinking water
    that is not expected to cause any adverse
    noncarcinogenic effects for a lifetime of
    exposure
  • Based on exposure of a 70-kg adult consuming 2L
    of water per day
  • The Lifetime HA for Group C carcinogens (i.e.,
    possible human carcinogen) includes an adjustment
    for possible carcinogenicity
  • HAs are a concentration
  • They can be compared to the concentration of what
    was found in the contaminated water
  • HAs function as benchmark
  • If a contaminant is found in the water at a
    concentration higher than the HA, then people
    might suffer adverse health effects from drinking
    the contaminated water

Return to Course Overview Slide
20
Effect Levels
  • No Observable Adverse Effect Level (NOAEL)
  • Highest exposure level at which there are no
    biologically significant increases in the
    frequency or severity of adverse effect between
    the exposed population and its appropriate
    control
  • Some effects may be produced at this level, but
    they are not considered adverse or precursors of
    adverse effects
  • In short concentrations below the NOAEL are
    generally considered safe, even when exposure is
    chronic
  • Lowest Observable Adverse Effect Level (LOAEL)
  • Lowest exposure level at which there are
    biologically significant increases in frequency
    or severity of adverse effects between the
    exposed population and its appropriate control
    group

Return to Course Overview Slide
21
Reference Dose (RfD)
  • Estimate of a daily exposure to the human
    population that is likely to be without an
    appreciable risk of deleterious effects during a
    lifetime.
  • Uncertainty may span an order of magnitude
  • Generally expressed in units of milligrams per
    kilogram of body weight per day (mg/kg/day)
  • Useful as a reference point from which to gauge
    the potential effects of the chemical at other
    doses.
  • Doses less than the RfD are not likely to be
    associated with adverse health risks

Return to Course Overview Slide
22
Reference Dose (RfD) (cont.)
  • As the frequency and/or magnitude of the
    exposures exceeding the RfD increase, the
    probability of adverse effects in a human
    population increases
  • However, all doses below the RfD may not be
    acceptable (or risk-free) and all doses in
    excess of the RfD may not be unacceptable (or
    result in adverse effects)

Return to Course Overview Slide
23
LD50, LC50, and ID50
  • Lethal dose 50 (LD50)
  • Dose of a chemical required to kill 50 of the
    experimental subjects (e.g., rats, mice,
    cockroaches)
  • Standard measurement of acute toxicity for
    chemicals stated in milligrams (mg) of
    contaminant per kilogram (kg) of body weight
  • Applies to ingestion and dermal exposure routes

Return to Course Overview Slide
24
LD50, LC50, and ID50 (cont.)
  • Lethal concentration 50 (LC50)
  • Two types, depending on situation
  • Human inhalation (also called LCt) measured in
    milligrams per cubic meter of air in a given time
    period (t)
  • Environmental exposure by aquatic organisms,
    measured in mg/L of water
  • Often human data are not available, and animal
    models are used
  • Infectious dose 50 (ID50)
  • Number of infectious pathogens required to
    produce infection or disease in 50 of the
    experimental subjects

Return to Course Overview Slide
25
LD50, LC50, and ID50 (cont.)
  • The lower the dose or concentration, the more
    toxic or infectious the contaminant
  • A contaminant with an LD50 value of 10 mg/kg is
    10 times more toxic than one with an LD50 of 100
    mg/kg
  • One limitation of animal models in determining
    what LD50, LC50, or ID50 of a human population
    may be that different animal species may have
    significantly different susceptibilities to
    certain contaminants than humans

Return to Course Overview Slide
26
LD50, LC50, and ID50 (cont.)
  • LD50, LC50, or ID50 are published for a variety
    of exposure routes, and only values for the same
    route are comparable
  • It is important to remember that the public can
    be exposed through all these routes (e.g. via
    showering (inhalation), bathing (dermal contact),
    as well as ingestion)

Return to Course Overview Slide
27
Related Acute Toxicity Measures
  • Other Lethal Doses (LDs)
  • Amount at which the contaminant is an LD to X
    percent of the population (e.g., LD10)
  • Lethal DoseLO (LDLO) The lowest published lethal
    dose of a chemical via a particular exposure
    route
  • The dose may greatly exceed the true lethal dose
    because it is often determined from a single
    individual and circumstance (e.g., an individual
    commits suicide by ingesting an entire can of
    poison the LDLO is based on what they consumed,
    not the MINIMUM lethal dose)

Return to Course Overview Slide
28
Other Toxicity Measurements
  • Cell Death 50 (CD50)
  • The dose of a contaminant required to produce
    death in 50 of cells in study
  • Convulsive Dose 50 (CD50)
  • Median convulsive dose
  • Chronic Dose 50 (CD50)
  • Chronic dose resulting in chronic effects within
    50 of the test population
  • Minimal Risk Levels (MRLs)
  • Estimate of the daily human exposure to a
    hazardous substance that is likely to be without
    appreciable risk of adverse non-cancer health
    effects over a specified duration of exposure

Return to Course Overview Slide
29
Toxicity Calculations
  • MCLs and MCLGs can be compared directly to
    drinking water concentrations to determine if
    there will be NO potential effect
  • The reverse is not necessarily true
  • Complex risk calculations are required to
    determine the extent of any potential effect
  • For other toxicity values, calculations must be
    performed to determine if the concentration level
    in water poses a threat

Return to Course Overview Slide
30
Toxicity Calculations (cont.)
  • Example Comparison of an oral LD50 with the
    concentration of the contaminant in water
  • C concentration (activity for radionuclides) of
    contaminant in water
  • V average volume of water consumed by an
    individual
  • W average weight of individual consuming water
  • D individuals contaminant dose
  • The contaminant dose can be compared to the LD50
  • If the calculated dose is higher than the LD50,
    health effects in the population could be severe
    and widespread
  • If the calculated does is lower than the LD50,
    comparisons to LOAEL and NOAEL should be made to
    determine if some effects may still occur these
    risk calculations may be complex

Return to Course Overview Slide
31
Toxicity Measurements
  • Many assumptions about exposure are made when
    performing these types of calculations that may
    limit their usefulness
  • Average volume consumed may not reflect volumes
    actually consumed by an individual
  • Average weights do not reflect actual individual
    weights in a population may be necessary to do
    calculations at multiple weights
  • Even if concentrations are below LD50 some
    adverse effects may occur
  • Common practice is to assume the exposure is to a
    70kg human
  • May need to do perform calculations for sensitive
    populations (e.g. daycare center, or retirement
    facility, or hospital)

Return to Course Overview Slide
32
Part 3 Characteristics and Properties of
Chemicals as they Relate to Water Systems
Contamination
Return to Course Overview Slide
33
Chemical Contaminants Overview
  • Many potential chemical contaminants are widely
    available and vary greatly in their health
    effects (e.g., their acute toxicity)
  • Detecting some of these contaminants in water
    presents special challenges detection of others
    is routine
  • Drinking water distribution systems may spread
    the contaminant over vast distances, although
    changes to the contaminated water may occur
    within the distribution system
  • Various physical and chemical properties of the
    contaminants affect their ability to efficiently
    contaminate and persist in water systems

Return to Course Overview Slide
34
Chemical Contaminants Overview (cont.)
  • Generally grouped into the following categories
  • Inorganic chemicals (e.g., cyanide)
  • Organic chemicals (e.g., pesticides)
  • Schedule 1 Chemical Weapons (e.g., sulfur
    mustard)
  • Biotoxins (e.g., ricin)
  • Radiochemicals (e.g., Cesium-137)

Return to Course Overview Slide
35
Chemical Contaminants Overview (cont.)
  • Chemical Weapons (CW) defined in the Chemical
    Weapons Convention (www.cwc.gov) includes toxic
    chemicals covered by a listing known as
    Schedules, including their precursors
  • Schedule 1 contains chemicals that have been
    developed, produced, stockpiled, or used as CW or
    chemicals that are precursors (any chemical
    reactant that takes part at any stage in the
    production of a toxic chemical regardless of
    method) Schedule 1 chemicals have no large-scale
    industrial purpose
  • Schedule 2 contains chemicals that pose a
    significant risk to the objectives of the CWC or
    are CW precursors, and have no legitimate
    industrial use
  • Schedule 3 contains "dual-use" chemicalschemicals
    that have been developed, produced, stockpiled,
    or used as CW or are CW precursors, but are
    produced in large quantities for legitimate
    (non-CW) uses

Return to Course Overview Slide
36
Chemical Contaminants Overview (cont.)
  • CW are popularly grouped into five categories
  • Nerve (e.g., VX, Sarin)
  • Blister (e.g., distilled mustard, nitrogen
    mustard, sulfur mustard)
  • Choking (e.g., chlorine)
  • Blood (e.g., hydrogen cyanide)
  • Vomiting (e.g., adamsite)
  • Some generalities can be made
  • Many are not stable in water
  • Many are difficult to obtain
  • Many are gases

Return to Course Overview Slide
37
Chemical Contaminants Overview (cont.)
  • Several Schedule 3 chemicals are found in water
    as a result of disinfection (e.g., chloropicrin,
    cyanogen chloride, etc.)
  • Water may not be the best delivery mechanism for
    CWs
  • Properties of CWs are evaluated like other
    chemicals

Return to Course Overview Slide
38
Chemical Contaminants Overview (cont.)
  • Biotoxin A toxin naturally produced by a
    microorganism, plant, or animal
  • Examples
  • Ricin toxin that is derived from castor plant
    beans, Ricinus communis
  • Microcystins toxins produced by blue-green
    algae
  • Some have very low lethal dose relative to most
    contaminants however, some are less toxic than
    more common man-made organic chemicals
  • Although biotoxins may be used in an aerosol
    attack, they also represent a concern for food
    and water contamination
  • Properties evaluated like other chemicals
  • Biotoxins are also organic chemicals

Return to Course Overview Slide
39
Chemical Identity
  • Chemicals can be uniquely identified by their
    Chemical Abstract Registry Number, often called
    CAS
  • In finding properties of chemicals, the CAS is
    often helpful because many chemicals go by a lot
    of other names
  • CAS numbers can be in chemical catalogs,
    databases, and Material Safety Data Sheets (MSDS)
  • Illustration The CAS for glyphosate is
    1071-83-6

Return to Course Overview Slide
40
Chemical Detection
  • The ability to detect a chemical contaminant in
    water is often an important step in the
    investigation of contamination
  • As used here, detection falls into two
    categories
  • Sensory Perception
  • Chemical Analysis

Return to Course Overview Slide
41
Chemical Detection (cont.)
  • Sensory perception usually occurs when the
    drinking water customer complains that the water
    looks, smells, and/or tastes unusual, but may or
    may not prevent the customer from drinking the
    water
  • Some contaminants may have distinctive odors or
    tastes, although perception of these by customers
    can vary dramatically
  • Is not always a sign of intentional contamination
    because some water systems are prone to
    complaints, particularly at certain times of year
  • NEVER INTENTIONALLY SMELL or TASTE a suspected
    sample
  • Example A customer complains of an almond smell
    to the water
  • Hydrogen cyanide may smell like almonds
  • On closer inspection, the odor is determined to
    be a new almond scented shampoo

Return to Course Overview Slide
42
Chemical Detection (cont.)
  • Compliance monitoring for regulated chemical
    contaminants will most likely not detect the
    presence of many of the potential chemical
    agents compliance monitoring for some chemicals
    is sometimes only required a few times a year
  • Water quality laboratories are often capable of
    analyzing water for many regulated chemicals of
    concern. Special techniques are required for
    confirming some Schedule 1 CW and biotoxins.
  • Early warning or rapid field detection is not
    available for many contaminants of concern
  • Changes in baseline water quality parameters
    (e.g., pH, turbidity, residual chlorine) may or
    may not indicate the presence of a chemical
    contaminant

Return to Course Overview Slide
43
Fate and Transport of a Chemical within a
Drinking Water System
  • The fate of a chemical as it moves through a
    water system to the tap depends on the nature of
    the particular water system and also on
    properties of the contaminant
  • Predictions are often complicated and rely on
  • - Accuracy of physical and chemical property data
    in the literature
  • Knowledge of the individual drinking water system

Return to Course Overview Slide
44
Drinking Water System
Return to Course Overview Slide
45
Portion of Drinking Water Distribution System
  • Understanding the behavior or water and
    contaminants in a distribution system is a
    complex task

Return to Course Overview Slide
46
Contaminant Properties
  • The next few slides will describe several
    contaminants properties
  • Solubility
  • Detectability (of the contaminant in water)
  • Treatability (at the water treatment plant)
  • Stability (of the contaminant in the distribution
    system)
  • Along with a description of property, well look
    at
  • How does the property help assess the threat
  • What limitations about the property may be
    important
  • Illustration about the propertys relevance to a
    water system

Return to Course Overview Slide
47
Contaminant Property Solubility
  • What is solubility?
  • The ability of a certain amount of chemical to
    dissolve in a certain amount of a given solvent
  • For example, one gram of sodium chloride
    dissolves in 2.8 mL of water at room temperature
  • How does this information help assess the threat?
  • Solubility must be compared to the concentration
    of concern in water (i.e., a highly toxic, less
    soluble chemical may be soluble enough to pose a
    health threat) low solubility does not
    automatically imply low threat
  • Some chemicals, which are soluble in water, need
    to be dispersed (e.g., by stirring) in order to
    dissolve
  • Some insoluble chemicals can still be effectively
    dispersed in water, although it presents a
    greater technical challenge (e.g., insoluble
    metals may need to be dissolved in acid and then
    added to water)

Return to Course Overview Slide
48
Contaminant Property Solubility (cont.)
  • What limitations in solubility information should
    you be aware of?
  • Solubility data are based on pure chemicals and
    sometimes solubility is described using words
    such as very, sparingly, slightly, which is
    not very helpful, especially for highly toxic
    chemicals
  • Factors influenced by conditions in the
    distribution system affect solubility (e.g.,
    temperature, pH, TDS concentration)
  • For contaminants added at high concentrations
    that exceed solubility, a layer of contaminant
    may be found on top or at the bottom of the water
    depending if the contaminants density (mass per
    unit volume) is less or more than water (e.g.,
    oil floats on water)
  • The absence of a contaminant film on top (or
    bottom) of the water does not necessarily mean
    that no contamination is present, but that the
    contaminant is present but below its solubility
    limit

Return to Course Overview Slide
49
Contaminant Property Solubility (cont.)
  • Illustration
  • Someone adds a 10 kg (10,000,000 mg) of a
    contaminant to a 1,000,000 L water tank
  • The LC50 of the liquid is 2000 mg/L to a water
    tank
  • Solubility data indicates the solubility is 0.1
    mg/L
  • Where will the contaminant be (in the water or at
    the bottom of the tank)?
  • One source for solubility data says that a
    particular contaminant is practically insoluble
  • The LC50 of the contaminant is 30 mg/L
  • How does the toxicity compare with the
    solubility?

Return to Course Overview Slide
50
Contaminant Property Treatability
  • What is treatability?
  • Ability of water treatment technologies (e.g.,
    chlorination, sand filtration, activated carbon,
    etc.) to remove a contaminant or reduce its
    concentration in the water
  • How does this information help assess the threat?
  • The existing plant may be treating the water in
    such a way that contamination is removed or
    mitigated rapidly, resulting in fewer long term
    consequences
  • Also relevant to remediation in the case of
    contamination

Return to Course Overview Slide
51
Contaminant Property Treatability (cont.)
  • What limitations in this information should you
    be aware of?
  • Efficacy of a particular process for a particular
    contaminant depends on the treatment technologies
    conditions at the plant
  • Treatment data may be unavailable for many
    contaminants
  • Literature has inconsistent data for some
    contaminants-possibly due to difference in
    treatment conditions
  • Applies generally to contamination added to the
    system before the treatment plant. However,
    water treatment plants add residual disinfectant
    before the water leaves the plant and enters the
    distribution system
  • Illustration
  • Someone adds a quantity of a particular pesticide
    to the source water of the treatment plant
  • The treatment plant uses activated carbon, which
    the literature indicates effectively removes the
    contaminant

Return to Course Overview Slide
52
Contaminant Property Stability
  • What is stability?
  • The ability of a contaminant to withstand
    degradation, which can reduce the toxicity or
    infectivity of a contaminant
  • With the distribution system, primarily a
    function of processes such as hydrolysis,
    volatilization, reactivity, adsorption
  • Biodegradation (degradation of the contaminant by
    microorganisms) may be important in the source
    water
  • How does this information help assess the threat?
  • When available, degradation rate data may be used
    to estimate the half-life of a contaminant in a
    water system half-life is the time is takes for
    half of the contaminant to degrade
  • A chemical with a short half-life in a drinking
    water system may not persist long enough to have
    significant effects on the public
  • A chemical with a longer half-life in a drinking
    water system may persist for sufficient time to
    have significant effects on the public

Return to Course Overview Slide
53
Contaminant Properties Stability (cont.)
  • What limitations in this information should you
    be aware of?
  • Stability data are based on pure chemicals, and
    depending on the stability process, the data may
    not be available for the chemical dissolved in
    water.
  • For instance, reactivity data are sometimes given
    for the undissolved compound, which can differ
    markedly from the compounds behavior in water
  • Estimates of half-life are not available for some
    contaminants
  • Environmental fate and transport predictions rely
    on the accuracy of physical and chemical property
    data in the literature
  • Due to the complexity of drinking water
    distribution systems, the amount of time that
    contaminated water can remain in the distribution
    system varies tremendously by location, even
    within the same distribution system it can be an
    extremely complex task to apply degradation rates
    when trying to estimate how much contaminant the
    public has been exposed to

Return to Course Overview Slide
54
Stability Related Process Hydrolysis
  • What is hydrolysis?
  • A reaction that occurs between a chemical and the
    water itself, often resulting in permanent
    degradation of the original chemical
  • How does this information help assess the threat?
  • Hydrolysis may produce byproducts that are less
    toxic than the parent chemical, thus, hydrolysis
    sometimes, but not always, greatly reduces the
    toxicity of contaminated water
  • Contaminants, especially highly toxic ones, that
    are resistant to hydrolysis may be of greater
    concern due to their persistence in water
  • What limitations in this information should you
    be aware of?
  • Hydrolysis rate is pH and temperature dependent
  • Hydrolysis rate data are not available for all
    contaminants or are not available for pHs and
    temperatures of interest

Return to Course Overview Slide
55
Stability Related Properties Hydrolysis (cont.)
  • Illustration
  • The half-life of a certain pesticide is listed as
    2 days
  • This means that after two days, the concentration
    of the contaminant will by 1/2, but will still be
    present
  • The half-life of a particular chemical weapon is
    around 8 minutes at room temperature
  • Within an hour or two, the concentration is
    reduced to essentially zero

Return to Course Overview Slide
56
Stability Related Process Volatilization
  • What is volatilization from water?
  • The process through which a contaminant dissolved
    in the water enters the gas phase (i.e., the air
    above the water)
  • Henrys Law constants are essentially determined
    from the equilibrium ratio of the concentration
    in the air to the concentration in the water
  • Vapor density is the density of a gas relative to
    air
  • How does this information help assess the threat?
  • Henrys Law constants provide an indication of
    whether the chemical is likely to move from an
    aqueous phase into gas phase (e.g., contaminated
    water to the air)
  • Vapor density provides an indication of how
    quickly a contaminant could dissipate
  • May help predict risk due to inhalation

Return to Course Overview Slide
57
Stability Related Properties Volatilization
(cont.)
  • What limitations in this information should you
    be aware of?
  • Henrys Law Constant assume equilibrium
    conditions, but volatilization is not an
    equilibrium process
  • Applies to small concentrations
  • Temperature dependent
  • In water under specific conditions (e.g., pH),
    some contaminants may co-exist in both volatile
    and non-volatile forms, which affects the amount
    of volatile contaminant
  • Illustration
  • The dimensionless Henrys Law constant for
    benzene is 0.25
  • This means that concentration in the water is 4
    times in the air.
  • At drinking water pHs, sodium cyanide is present
    as hydrogen cyanide, which can volatilize from
    the water

Return to Course Overview Slide
58
Stability Related Process Reactivity
  • What is reactivity?
  • Reaction between a contaminant and another
    substance
  • For water systems, a principal reaction of
    interest occurs between an oxidant and the
    contaminant of concern
  • One oxidant frequently found in finished drinking
    water is chlorine
  • How does this information help assess the threat?
  • The oxidation of a chemical contaminant
    frequently, but not always, decreases the
    toxicity of the water
  • Reaction rates for different contaminants can
    vary dramatically from instantaneous to nearly
    imperceptible
  • What limitations in this information should you
    be aware of?
  • Oxidation is dependent on temperature and pH
  • The presence and concentration of other
    substances in the water may significantly affect
    the oxidation rate

Return to Course Overview Slide
59
Stability Related Process Reactivity(cont.)
  • Illustration
  • A certain pesticide is known to react rapidly
    with chlorine
  • You measure the chlorine residual at a tap and
    find there is a large one
  • It is less likely that the pesticide is present
    at that tap
  • Contamination with a chlorine sensitive
    contaminant is suspected, so you measure the
    chlorine residual at a tap
  • You find very little
  • Does this indicate contamination?
  • Maybe notsome parts of the distribution system
    have far less residual than was added at the
    plant due to natural chlorine decay
  • In arsenic treatment of water systems, oxidation
    changes the chemical form of arsenic, and is
    known to frequently reduce toxicity and ease of
    removal

Return to Course Overview Slide
60
Stability Related Properties Adsorption
  • What is adsorption?
  • A measure of the tendency of a chemical to
    partition out of the water into a substance with
    an organic-like phase (e.g., certain sediments,
    some water system pipes and components, etc.)
  • The octanol-water partition coefficient (KOW) may
    be an indicator. KOW is the concentration of the
    contaminant in octanol divided by the
    concentration in water after the contaminant
    equilibrates between the two solvents
  • How does this information help assess the threat?
  • Related to the fate of a chemical in the water
    system
  • May provide an indication of the chemicals
    persistence in the water system (e.g., need for
    remediation of the system)
  • A compound with a higher KOW may be more likely
    to persistently contaminate drinking water system
    components than a contaminant with a lower one.
    A slow release of the contaminant from the water
    system components could taint the water until
    enough water has passed through for sufficient
    desorption of the contaminant.

61
Stability Related Properties Adsorption (cont.)
  • What limitations in this information should you
    be aware of?
  • The reliability of KOW as a predictor is highly
    dependent on both the chemical and the material
    to which the chemical is partitioning. Not all
    materials have an organic-like phase that behaves
    like octanol.
  • This dependency may be unknown (e.g., given the
    wide variety of pipe materials in use)
  • Temperature-dependent
  • Valid only under equilibrium conditions
  • Illustration
  • Hydrogen cyanide has a KOW of 0.5. An organic
    pesticide has a KOW of 1.3. Which is more likely
    to persist in the pipes, leading to a slow
    release in the water over time?
  • Information gathered revealed that the pipes in
    that part of town were made of a material to
    which neither contaminant measurably adsorbed.

62
Part 4 Properties and Characteristics Pathogens

Return to Course Overview Slide
63
Pathogens Overview
  • Disease-causing organisms that may result in
    illness or death
  • May be referred to as bioterrorism agents,
    replicating agents, select agents, pathogens,
    microorganisms, microbes
  • Large quantities may be grown from small initial
    cultures
  • Unique ability to multiply in the body over time
    and increase their effect
  • May be referred to by disease or by organism
    name
  • Salmonella typhi is the causative agent for
    typhoid fever
  • Vibrio cholerae is the causative agent for
    cholera
  • Yersinia pestis is the causative agent for plague

Return to Course Overview Slide
64
Pathogens Overview (cont.)
  • Classified (for our purposes) into three
    categories
  • Bacteria (including rickettsia and
    rickettsia-like organisms)
  • Viruses
  • Protozoa

Escherichia coli bacteria
Return to Course Overview Slide
65
Bacteria
  • Single-celled, prokaryotic (non-nucleated)
  • Relatively easy to grow, may not require host
    cells for growth growth media often simple
  • 0.1 - 10Fm in size
  • Some are easily disinfected by chlorination,
    certain species produce spores that are stable in
    some environmental matrices for weeks or longer
    also some may propagate in a water system

Return to Course Overview Slide
66
Bacteria (cont.)
  • Organisms may be susceptible to antibiotics
  • Examples
  • Bacillus anthracis (anthrax)
  • Burkholderia pseudomallei (melioidosis)
  • Yersinia pestis (plague)
  • E. coli O157H7 (hemorrhagic colitis)

Return to Course Overview Slide
67
Viruses
  • Obligate intracellular parasites containing
    either DNA or RNA with a protein coat. May also
    have a lipid envelope
  • Unable to replicate or metabolize without a host
    cell
  • Grown in cell cultures, embryonated eggs, or
    animals
  • 0.01 - 0.1Fm in size
  • Stability is estimated at less than a day to
    weeks for some, unknown for others
  • Antibiotics have no effect
  • Examples
  • Variola (smallpox)
  • Caliciviruses (e.g., Norwalkvirus)
  • Hepatitis viruses (e.g., Hepatitis A)

Return to Course Overview Slide
68
Protozoa
  • Single-celled, eukaryotic (containing a nucleus),
    organisms 0.8 - 70Fm in size
  • Protozoa of concern are parasites. There are
    other non-protozoan parasites, some of which may
    be of concern
  • Some produce cysts (or oocysts) that are very
    stable
  • May be susceptible to specialized antibiotics
    (e.g., Nitazoxanide)
  • Examples
  • Cryptosporidium parvum (cryptosporidiosis)
  • Toxoplasma gondii (toxoplasmosis)
  • Entamoeba histolytica (amebic dysentery)

Return to Course Overview Slide
69
Fate and Transport and Health Effects
  • Fate and Transport
  • Many pathogens are stable in water long enough to
    pose a threat
  • In suspension in water, rather than in solution
  • Exposure routes may include ingestion,
    inhalation, and/or dermal contact
  • Health Effects
  • Small volumes of infectious material can
    potentially infect large numbers of people
  • May not cause immediate symptoms due to
    incubation period in host
  • Symptoms may be vague/ambiguous (e.g., flu-like
    symptoms), delaying diagnosis

Return to Course Overview Slide
70
Other Properties Infectivity
  • What is infectivity?
  • A measure of the ability of a microorganism to
    establish itself in a host species and begin to
    multiply
  • May be expressed as an ID50 value (the number of
    organisms needed to infect 50 percent of the
    exposed hosts in a given time period)
  • How does this information help assess the threat?
  • Introduction of pathogen with a low ID50 value
    may be a significant threat, even when low levels
    or concentrations are present
  • Introduction of pathogen with very high ID50
    value may require high concentration of organisms
    to have the same impact

Return to Course Overview Slide
71
Other Properties Infectivity (cont.)
  • What are the limitations of infectious dose
    information?
  • Knowledge of the source of the estimate is
    crucial to understanding the significance of this
    number
  • ID50 values may be derived from estimates made at
    outbreaks, or from animal models (rather than
    human dosing studies).
  • Variation in reported and actual ID50 may also
    arise from strain, culture conditions, host
    factors, etc.
  • ID50 values should include information on the
    route of infection. ID50 values for ingestion and
    inhalation may differ by several orders of
    magnitude
  • Doses lower than the ID50 may cause illness, and
    this relationship may not be linear
  • Some studies report the Minimum Infectious
    Dose, which may vary greatly from the ID50
  • Many pathogen detection methods do not provide
    information on infectivity

Return to Course Overview Slide
72
Other Properties Incubation Period
  • What is incubation period?
  • The time between exposure and the appearance of
    symptoms
  • How does this information help assess the threat?
  • Pathogens with longer incubation times may no
    longer be viable or present in the water system
    at or after the onset of symptoms
  • If there is a continuous source of a pathogen,
    then a longer incubation period may allow more
    individuals to be exposed
  • What limitations in this information should you
    be aware of?
  • Actual incubation period will depend on the
    following conditions
  • Initial dose
  • Virulence of the organism (severity of disease
    produced)
  • Rate of replication of the organism
  • Health of the host (e.g., immunocompromised)

Return to Course Overview Slide
73
Other Properties Virulence
  • What is virulence?
  • Virulence is a measure of the ability of an
    organism to cause severe disease or death
  • One measure of virulence is the mortality rate.
    This is generally calculated as the number of
    deaths per thousand.
  • How does this information help assess the threat?
  • Diseases with higher mortality rates may be of
    greater consequence to homeland security
  • What limitations in this information should you
    be aware of?
  • Medical treatment may affect the mortality rate,
    so mortality may be reported with both treated
    and untreated rates
  • Mortality rates are dependant on correctly
    identifying underlying cases, so the case
    definition used in generating the mortality rate
    will be highly significant

Return to Course Overview Slide
74
Other Properties Communicability
  • What is communicability?
  • Transmission of disease from person to person
    the property of being contagious
  • How does this information help assess the threat?
  • Even though stop-use notices to public may
    prevent new infections for non-communicable
    diseases, new infections may continue to occur
    for communicable pathogens via secondary
    transmission
  • What limitations in this information should you
    be aware of?
  • Degree of communicability may depend on the
    strain of organism released
  • Good sanitation practices can prevent the spread
    of many communicable diseases

Return to Course Overview Slide
75
Other Properties Stability
  • What is stability?
  • An assessment of the organisms susceptibility to
    various environmental factors while in the
    distribution system, including
  • Temperature, pH
  • Osmotic pressure caused by differences in
    chemical concentrations inside and outside the
    pathogen
  • Residual chlorine
  • How does this information help assess the threat?
  • Stable organisms with environmentally resistant
    life stages (such as anthrax spores and
    Cryptosporidium spp. oocysts) may survive longer
    in the distribution system
  • Some organisms may be more susceptible to
    residual chlorine levels or osmotic pressure,
    reducing the possibility of transmission

Return to Course Overview Slide
76
Other Properties Stability (cont.)
  • What limitations in this information should you
    be aware of?
  • Data on organism stability may result from
    studies using different organism strains or
    system conditions than are present any specific
    distribution system

Salmonella typhi
Return to Course Overview Slide
77
Other Properties Treatability
  • What is treatability?
  • Assessment of removal or inactivation of an
    organism by various treatment processes
  • How does this information help assess the threat?
  • Determination of effectiveness of treatment at
    the water treatment plant during event if
    organism is added to source water
  • Determination of chlorine residual effectiveness
    in distribution system during event if organism
    is added after treatment
  • Evaluate the effectiveness of various options to
    decontaminate the system
  • What limitations in this information should you
    be aware of?
  • Data on organism treatability may result from
    studies using different strains or conditions

Return to Course Overview Slide
78
Challenges for Detection
  • Most pathogens of concern will not be detected
    during monitoring for routine contaminants or
    indicators (e.g., total coliforms)
  • Analytical results may not be indicative of
    virulence or infectivity
  • Water concentration techniques can be used prior
    to analysis but overall analytical sensitivity
    may be below the concentration of concern for
    some contaminants
  • Most onsite drinking water utility laboratories
    are currently capable of monitoring for indicator
    organisms, some of these laboratories can
    conduct assays for some common waterborne
    pathogens however, capability and capacity for
    many specific pathogens must be expanded

Return to Course Overview Slide
79
Challenges for Detection (cont.)
  • The Select Agent Program (SAP) limits
    confirmatory analysis for a list of Select
    Agent pathogens (e.g., Bacillus anthracis) to
    approved labs. Failure to comply with the SAP
    can result in lengthy jail terms or heavy fines.
  • Many of the SAP approved labs conducting
    confirmatory testing of Select Agent samples are
    part of Laboratory Response Network (LRN)

Return to Course Overview Slide
80
Part 5Properties and CharacteristicsRadiochem
ical Agents
Return to Course Overview Slide
81
Radiochemical Agents Overview
  • Two general types
  • Naturally occurring (e.g., radium, uranium and
    thorium)
  • Man-made produced exclusively by nuclear
    reactors, accelerators, cyclotrons, or nuclear
    weapons
  • Neutron capture products in nuclear fuel rod
    assemblies, such as plutonium-239 (239 Pu) and
    americium-241 (241Am)
  • Fission products that accumulate in fuel rod
    assemblies or produced by nuclear detonations,
    such as cesium-137 (137Cs), and strontium-90
    (90Sr) or corrosion/wear product activation such
    as cobalt-60 (60Co)
  • Accelerator produced medical radioisotopes, such
    as iodine-123 (123I) or cobalt-57 (57Co)

Return to Course Overview Slide
82
Radiochemical Agents Overview (cont.)
  • Can be categorized by the type of radiation an
    unstable isotope emits
  • Alpha radiation Particle emitted from the
    nucleus of an atom consisting of two neutrons and
    two protons (same as a helium atom nucleus)
  • Beta radiation Particle emitted from the nucleus
    of an atom consisting of an electron or positron
  • Gamma radiation Emission from the nucleus of an
    atom consisting of a high energy photon (gamma
    photon)

Return to Course Overview Slide
83
Radiochemical Agents Overview (cont.)
  • Radiochemical agents may fall into one or
    multiple radiation categories
  • 90Sr is a beta emitter
  • 137Cs and 60Co are both beta and gamma emitters
  • 235U and 239Pu are both alpha and gamma emitters
  • Sources of radiochemical agents
  • Oil exploration equipment
  • Mining and milling sites for uranium, and rare
    earth ores
  • Power generation equipment
  • Weapons production, maintenance and disposal
  • Food and medical irradiators
  • Industrial radiography

Return to Course Overview Slide
84
Radiochemical Agents Overview (cont.)
  • Small quantities widely used in many activities
  • Medical
  • Food industry
  • Laboratory/scientific research

Return to Course Overview Slide
85
Fate and Transport and Health Effects
  • Fate and transport
  • Most will remain in solution
  • Many are highly absorbable into biologic systems
    (e.g., 90Sr, uranium, tritium)
  • Concentrations will likely be uniform in the
    distribution system
  • Health effects
  • If exposure is at low levels but for a long
    duration, or is at a high, but non-fatal level
    for a short duration, the general long-term
    health effect is induction of cancers
  • However, extremely high doses in short-term
    exposure events cause cellular damage that may be
    significant enough to result in death

Return to Course Overview Slide
86
Fate and Transport and Health Effects (cont.)
  • Health effects, cont.
  • Many radioactive agents are organ-specific
  • Iodine-129 129I uptake in the thyroid gland
  • Uranium uptake and toxicity in kidneys
  • For contaminated water, the most significant
    health risk is ingestion water can significantly
    attenuate (shield) alpha and beta radiation (but
    only minimally attenuate gamma radiation),
    reducing the threat of direct exposure

Return to Course Overview Slide
87
Other Properties Toxicity
  • What is toxicity?
  • How poisonous or harmful a substance is in
    specified amounts
  • How does this information help assess the threat?
  • Some radioisotopes may result in both chemical-
    and radiation-induced toxicity
  • Chemical toxicity often is of greater concern
    (e.g., uranium)
  • LD50 much higher than MCLs (for the regulated
    analytes)
  • However, a single alpha particle may induce a
    mutational event
  • What limitations in this information should you
    be aware of?
  • Toxicity studies for radiochemical contaminants
    may not cover all chemical species
  • Most radiation exposure limits are based on
    dosimetric models combined with radiation
    dose-response models, rather than empirical
    studies

Return to Course Overview Slide
88
Other Properties Speciation
  • What is speciation?
  • The types of chemical compounds in which a
    radioactive contaminant may occur, such as a
    salt, oxide, hydroxide, or organometallic
    complex, etc.
  • How does this information help assess the threat?
  • Can identify forms of radioactive species that
    may be in solution
  • Different species will have different properties
    relevant to chemical fate and transport and
    health effects
  • What limitations in this information should you
    be aware of?
  • Can be used only to estimate the actual threat of
    the contaminant of concern

Return to Course Overview Slide
89
Other Properties Solubility
  • What is solubility?
  • The amount of a solid that can be dissolved in a
    solvent (water)
  • How does this information help assess the threat?
  • Can be used to assess the exposure risk
  • Radiochemical compounds with relatively high
    solubility may be more of a
Write a Comment
User Comments (0)
About PowerShow.com
