OPTIMAL CONTRIBUTION OF DISTRIBUTED GENERATION

• IN MEDIUM VOLTAGE GRIDS
• DURING A FAULT,
• NOW AND IN THE FUTURE

Alliander S. van Loon, F. Volberda, F.
Provoost Enexis J. Morren Session 3 0092
2
Introduction

• Distribution System Operators (DSO) within The
  Netherlands

Session 3 0092
3
Introduction

• Increasing DG in MV-grids
• Connected by step-up transformer
• Direct connection

MV
LV
Gen
Gen
Session 3 0092
4
Introduction

• Conflicts
• Selective tripping ? time grading (gt300ms)
• Voltage dips ? unwanted disconnection of DG
• No support grid codes (MV and lt 5 MVA)
• E.ON grid code FRTHV-grids, lt150 ms

Session 3 0092
5
Introduction

• Is there a need for smarter protection schemes in
  MV-grids?

Session 3 0092
6
Present protection scheme

• A voltage dip / frequency change ? disconnect DG
• More DG ? more power lost
• Over-/under- voltage ? damage to equipment

Session 3 0092
7
Present protection scheme
150/10 kV substation

• Example
• 2 phase fault
• DG protection
• DSO protection

21
27
27
27
G1
G2
G3
Undervoltage
27
Distance relay
21
Session 3 0092
8
Present protection scheme
DG disconnect
Fault

• Example
• Duration fault 1060 ms

Network protection
Session 3 0092
9
Present protection scheme

• Example
• Power swing HV/MV transformer

12 MW
-6 MW
Session 3 0092
10
Expectations DSO

• Stability
• Reliability
• Fully selective protection scheme
• Safety of personnel
• Security of supply
• Prevent damage to equipment
• Worst case
• Under- and/or over-voltage

Session 3 0092
11
Smarter grids

• A smart grid needs a smart protection

Change grid Influence grid Cost
Scenario 1 Low Low Low
Scenario 2 High Medium High
Scenario 3 Medium Medium Medium
Session 3 0092
12
Conclusions

• Increasing DG ? new protection scheme
• Fast disconnection of faults
• Shorter voltage dips
• Prepare the MV-grid now for future grids
• Change protection of dedicated feeders
• Allow contribution of large DG

Session 3 0092
13
A smart grid needs a smart protection!
E M C2
Energy Measurement Control Communication
Session 3 0092
14
Scenario 1
DG must stay connected
DG must disconnect
Session 3 0092
15
Scenario 1
HV/MV substation
Undervoltage
27
27
27
27
G1
G2
G3
Non-dedicated feeders
Dedicated feeders
Session 3 0092
16
Scenario 2
DG must stay connected
DG must disconnect
Session 3 0092
17
Scenario 2
HV/MV substation
87
Undervoltage
27
27
27
27
Differential
87
G1
G2
G3
LOM
LOM
LOM
Loss of mains
LOM
Bi-directional
Non-dedicated feeders
Dedicated feeders
Session 3 0092
18
Scenario 3
HV/MV substation
87
Undervoltage
27
27
27
27
Differential
87
G1
G2
G3
LOM
LOM
Loss of mains
LOM
Bi-directional
Non-dedicated feeders
Dedicated feeders
Session 3 0092
