Topic 4: Discrete Random Variables and Probability Distributions

1
Topic 4 Discrete Random Variables and
Probability Distributions

• CEE 11 Spring 2002
• Dr. Amelia Regan

These notes draw liberally from the class text,
Probability and Statistics for Engineering and
the Sciences by Jay L. Devore, Duxbury 1995 (4th
edition)
2
Definition

• For a given sample space S of some experiment, A
  random variable is any rule that associates a
  number with each outcome in S
• Random variables may take on finite or infinite
  values
• Examples 0,1, the number of sequential tosses
  of a coin in which the outcome head is observed

• A set is discrete either if it consists of a
  finite number of elements or if its elements may
  be listed in sequence so that there is a first
  element, a second element, a third element, and
  so on, in the list
• A random variable is said to be discrete if its
  set of possible values is a discrete set.

3
Definition

• The probability distribution or probability mass
  function (pmf) of a discrete random variable is
  defined for every number x by

• The cumulative distribution function (cdf) F(x)
  of a discrete rv X with pmf p(X) is defined for
  every number x by

4
Examples
5
Definition

• Let X be a discrete rv with set of possible
  values D and pmf p(x). The expected value or
  mean value of X, denoted E(x) or mx is given by

• If the rv X has a set of possible values D and
  pmf p(x), then the expected value of any function
  h(X), denoted by Eh(x) or mh(x) is computed by
• Note according to Ross(1988) p. 255 this is
  known as the law of the unconscious statistician

6
Example

• Let X be a discrete rv with the following pmf and
  corresponding cdf

• Now let h(x) x22

7
Class exercise

• Let X be a discrete rv with the following pmf
• Calculate the cdf of X

• Calculate the E(X)

• Now let h(x) 3x3-100 -- Calculate h(x)

8
Definition

• For linear functions of x we have simple rules

9
Variance of a random variable

• If X is a random variable with mean m, then the
  variance of X denoted by Var(X) is defined by

• Recall that we previously defined the variance of
  a population as the average of the squared
  deviations from the mean. The expected value is
  nothing other than the average or mean so this
  form corresponds exactly to the one we used
  earlier.

10
Variance of a random variable

• Its often convenient to use the a different form
  of the variance which, applying the rules of
  expected value which we just learned and
  remembering the EX m, we derive in the
  following way.

11
The Bernoulli distribution

• Any random variable whose only two possible
  values are 0 and 1 is called a Bernoulli random
  variable.
• Example Suppose a set of buildings are examined
  in a western city for compliance with new
  stricter earthquake engineering specifications.
  After 25 of the cities buildings are examined at
  random and 12 are found to be out of code while
  88 are found to conform to the new
  specifications it is supposed that buildings in
  the region have a 12 likely hood of being out of
  code.
• Let X 1 if the next randomly selected building
  is within code and X 0 otherwise.
• The distribution of buildings in and out of code
  is a Bernoulli random variable with parameters p
  0.88 and 0.12.

12
The Bernoulli distribution

• We write this as follows

13
The Bernoulli distribution

• In general form, a is the parameter for the
  Bernoulli distribution but we usually refer to
  this parameter as p, the probability of success

• The mean of the Bernoulli distribution with
  parameter p is

• The variance of the Bernoulli distribution with
  parameter p is

14
The Binomial distribution

• Now consider a random variable that is made up of
  successive (independent) Bernoulli trials and
  define the random variable X as the number of
  successes among n trials.

• The Binomial distribution has the following
  probability mass function

• Remembering what we learned about combinations
  this makes intuitive sense. The binomial
  coefficient represents the number of ways to
  distribution the x successes among n trials. px
  represents the probability that we have x
  successes in the n trials, while (1-p)(n-x)
  represents the probability that we have n-x
  failures in the n trials.

15
The Binomial distribution

• Computing the mean and the variance of the
  binomial distribution is straightforward. First
  remember that the binomial random variable is the
  sum of the number of successes in n consecutive
  Bernoulli trials. Therefore

16
The Binomial distribution
17
The Binomial distribution
18
The Binomial distribution
19
Class exercise

• A software engineer has historically delivered
  completed code to clients on schedule, 40 of the
  time. If her performance record continues, the
  probability of the number of on schedule
  completions in the next 6 jobs can be described
  by the binomial distribution.

• Calculate the probability that exactly four jobs
  will be completed on schedule

• Calculate the probability that at most 5 jobs
  will be completed on schedule

• Calculate the probability that at least two jobs
  will be completed on schedule
• Calculate the probability that at most 5 jobs
  will be completed on schedule

20
The Hypergeometric distribution

• The binomial distribution is made up of
  independent trials in which the probability of
  success does not change.

• Another distribution in which the random variable
  X represents the number of successes among n
  trials is the hypergeometric distribution.

• The hypergeometric distribution assumes a fixed
  population in which the proportion or number of
  successes is known.

• We think of the hypergeometric distribution as
  involving trials without replacement and the
  binomial distribution involving trials with
  replacement.

• The classic illustration of the differences
  between the hypergeometric and the binomial
  distribution is that of black and white balls in
  a urn. Assume the proportion of black balls is
  p. The distribution of the number of black balls
  selected in n trials is binomial(xnp) if put
  the balls back in the urn after selection and
  hypergeometric(xnM,N) if we set them aside
  after selection. (engineering examples to come)

21
The Hypergeometric distribution

• The probability mass function of the
  hypergeometric distribution is given by the
  following, where M is the number of possible
  successes in the population, N is the total size
  of the population, x is number of successes in
  the n trials.

22
The Hypergeometric distribution

• Example Suppose out of 100 bridges in a region,
  30 have been recently retrofitted to be more
  secure during earthquakes. Ten bridges are
  selected randomly from the 100 for inspection.
  What is the probability that at least three of
  these bridges will be retrofitted?

23
The Hypergeometric distribution

• The mean and variance of the hypergeometric
  distribution is given below

24
The Hypergeometric and the Binomial distributions

• Note the following
• Sometimes we refer to M/N, the proportion of the
  population with a particular characteristic as p.

• This is very close to EX np and Var(x)
  pn(1-p) which are the mean and variance of the
  Binomial distribution. In fact we can think of
• as a correction term which accounts for the fact
  that in the hypergeometric distribution we sample
  without replacement.

• Question Should the variance of the
  Hypergeometric distribution with proportion p be
  greater than or less than the variance of the
  Binomial with parameter p? Can you give some
  intuitive reason why this is so?

25
The Hypergeometric and the Binomial distributions

• Example Binomial, p 0.40, three trials vs.
• Hypergeometric with M/N 2/5
  0.40, three trials

26
The Hypergeometric and the Binomial distributions

• If the ratio of the n, the number of trials is
  small and N, the number in the population is
  large then we can approximate the hypergeometric
  distribution with the binomial distribution in
  which p M/N.

• This used to be very important. As recently as
  five years ago computers and hand calculators
  could not calculate large factorials. The
  calculator I use can not calculate 70!. A few
  years ago 50! was out of the question.

• Despite improvements in calculators its still
  important to know that if the ratio of n to N is
  less than 5 (we are sampling 5 of the
  population) then we can approximate the
  hypergeometric distribution with the binomial.
• Check your calculators now -- what is the maximum
  factorial they can handle?

27
Class exercise

• The system administrator in charge of a campus
  computer lab has identified 9 machines out of 80
  with defective motherboards.
• While he is on vacation the lab is moved to a
  different room, in order to make room for
  graduate student offices.
• The administrator kept notes about which machines
  were bad, based on their location in the old lab.
  During the move the computers were places on
  their new desks in a random fashion so all of the
  machines must be checked again.
• If the administrator checks three of the machines
  for defects, what is the probability that one of
  the three will be defective?
• Calculate using both the hypergeometric
  distribution and the binomial approximation to
  the hypergeometric.

28
The Geometric distribution

• The geometric distribution refers to the random
  variable represented by the number of consecutive
  Bernoulli trials until a success is achieved.

• Suppose that independent trials, each having
  probability p,
• 0 lt p lt 1, of being a success are performed until
  a success occurs. If we let X equal the number
  of trials prior to the success, then
• The above definition is the one used in our
  textbook. A more common definition is the
  following Let X equal the number of trials
  including the last trial, which by definition is
  a success. Then we get the following

29
The geometric distribution

• The expected value and variance of the geometric
  distribution is given for the first form by

• For the second form, the expected value has more
  intuitive appeal. Can you convince yourself that
  the value is correct?

• Please note that the variance is the same in both
  cases.
• Explain why this is so.

30
The geometric distribution

• We can derive E(X) in the following way

31
The geometric distribution
These steps are so that we can work with the
geometric series 1xx2x31/(1-x)
so p(1qq2)p(1/1-q) Here we just substitute
p for 1-q
32
The geometric distribution
Try deriving the variance of the geometric
distribution by finding E(X2)
33
Poisson Distribution

• One of the most useful distributions for many
  branches of engineering is the Poisson
  Distribution
• The Poisson distribution is often used to model
  the number of occurrences during a given time
  interval or within a specified region.
• The time interval involved can have a variety of
  lengths, e.g., a second, minute, hour, day, year,
  and multiples thereof.

• Poisson processes may be temporal or spatial.
  The region in question can also be a line
  segment, an area, a volume, or some n-dimensional
  space.
• Poisson processes or experiments have the
  following characteristics

34
Poisson Distribution

• 1. The number of outcomes occurring in any given
  time interval or region is independent of the
  number of outcomes occurring in any other
  disjoint time interval or region.

• 2. The probability of a single outcome occurring
  in a very short time interval or very small
  region is proportional to the length of the time
  interval or the size of the region. This value is
  not affected by the number of outcomes occurring
  outside this particular time interval or region.


• 3. The probability of more than one outcome
  occurring in a very short time interval or very
  small region is negligible.
• Taken together, the first two characteristics are
  known as the memoryless property of Poisson
  processes.

• Transportation engineers often assume that the
  number of vehicles passing by a particular point
  on a road is approximately Poisson distributed.

• Do you think that this model is more appropriate
  for a rural hiqhway or a city street?

35
Poisson Distribution

• The pdf of the Poisson distribution is the
  following

• The parameter l is equal to a t, where a is the
  intensity of the process the average number of
  events per time unit and t is the number of time
  units in question. In a spatial Poisson process
  a represents the average number of events per
  unit of space and t represents the number of
  spatial units in question.
• For example, the number of vehicles crossing a
  bridge in a rural area might be modeled as a
  Poisson process. If the average number of
  vehicles per hour, during the hours of 1000 AM
  to 300 PM is 20 we might be interested in the
  probability that fewer than three vehicles cross
  on from 1230 to 1245 PM. In this case l (20
  per hour)(0.25hours) 5.
• The expected value and the variance of the
  Poisson distribution are identical and are equal
  to l.

36
Class exercise

• An urban planner believes that the number of gas
  stations in an urban area is approximately
  Poisson distributed with parameter a 3 per
  square mile. Lets assume she is correct in her
  assumption.

• Calculate the expected number of gas stations in
  a four square mile region of the urban area as
  well as the variance of this number.

• Calculate the probability that this region of
  four square miles has less than six gas stations.

• Calculate the probability that in four adjacent
  regions of one square mile each, that at least
  two of the four regions contains more than three
  gas stations.

• Do you think the situation is accurately modeled
  by a Poisson process?
• Why or why not?

37
Some random variables that typically obey the
Poisson probability law (Ross, p.130)

• The number of misprints on a page (or group of
  pages) of a book

• The number of people in a community living to 100
  years of age

• The number of wrong telephone numbers that are
  dialed in a day

• The number of packages of dog biscuits sold in a
  particular store each day

• The number of customers entering a post office
  (bank, store) in a give time period

• The number of vacancies occurring during a year
  in the supreme court

• The number of particles discharged in a fixed
  period of time from some radioactive material

• WHAT ABOUT ENGINEERING?
• Poisson processes are the heart of queueing
  theory --which is one of the most important
  topics in transportation and logistics. Lots of
  other applications too -- water, structures,
  geotech etc.

38
The Poisson Distribution as an approximation to
the Binomial

• When n is large and p is small, the Poisson
  distribution with parameter np is a very good
  approximation to the binomial (the number of
  successes in n independent trials when the
  probability of success is equal to p for each
  trial).

• Example --Suppose that the probability that an
  idem produced by a certain machine will be
  defective is 0.10. Find the probability that a
  sample of 10 items will contain at most one flaw.

np 0.10101.0
39
References

• Ross, S. (1988), A first course in probability,
  Macmillian Press.
