Towards efficient matching with random hashing methods

1
Towards efficient matching with random hashing
methodsKristen GraumanGregory Shakhnarovich
Trevor Darrell
2
Motivation Content-based image retrieval

• Features
• Harris-Affine detector
• (max m3,595)
• MSER detector
• (max m1,707)
• SIFT-PCA descriptors

• Data set of 30 scenes in Boston
• 1,079 database images
• 89 query images

3
Content-based image retrieval
Even this is far too slow for any web-scale
application!
Accuracy
Number top retrievals
4
Sub-linear time image search
Randomized hashing techniques useful for
sub-linear query time of very large image
databases
N
5
Pyramid match hashing

• For fixed-size sets, Locality-Sensitive Hashing
  Indyk Motwani 1998 provides bounded
  approximate similarity search over bijective
  matching Indyk Thaper 2003 Grauman
  Darrell CVPR 2004, 2005
• For varying set sizes, embedding of pyramid match
  (with product normalization) makes random
  hyperplane hashing possible under set
  intersection hash family of Charikar 2002.
  Grauman PhD 2006

6
(No Transcript)
7
(No Transcript)
8
(No Transcript)
9
(No Transcript)
10
Single Frame Pose Estimation via Approximate
Nearest Neighbor regression

• Obtain large DB of pose-appearance mappings
• Exploit fast methods for approximate nearest
  neighbor search in high dim. spaces. (e.g., LSH
  Indyk and Motwani 98-00.)

11
Approximate nearest neighbor techniques
Hash fcns.
input
similar examples fall into same bucket in one or
more hash table
12
Single Frame Pose Estimation via Approximate
Nearest Neighbor regression

• Render large DB of pose-appearance mappings
• Exploit fast methods for approximate nearest
  neighbor search in high dim. spaces. (e.g., LSH
  Indyk and Motwani 98-00.)
• Problem signal distance dominated by nuisance
  variables
• Idea find embedding (i.e., hash functions for
  LSH) most relevant to parameter (pose)
  similarity
  Shakhnarovich et. al 03,
  Shakhnarovich 05

13
Pose estimation and Similarity-sensitive hashing

Rendered ( hashed) Pose DB
Pose- sensitive Hash fcns.
input
NN similar in pose, not image
Shakhnarovich et. al 03, Shakhnarovich 05
14
SSE / BoostPro

• Similarity Sensitive Embedding
• Compute embedding H I ? 0, 1N such that
• H(I(?1)) - H(I(?2)) is small if ?1 is close
  to ?2
• H(I(?1)) - H(I(?2)) is large otherwise
• Use the embedding with approximate nearest
  neighbors retrieval (LSH)
• Find H by training boosted classifier to learn
  same-pair and concatenate resulting weak
  learners

Shakhnarovich 2005
15
PSH results
200,000 examples in DB 2 sec
Shakhnarovich et al. 2003, 2005
16
Conclusions

• Random Hashing techniques allow broad search
  well suited for very high dimensional spaces
• Useful in domains where there is no prior
  knowledge about how to cluster or model data
• Similarity (parameter) sensitive hashing can find
  distance related to taskeffectively learn
  problem dependent distance measure and efficient
  means to index.
