Machines

1
Machines

• Making Work Easier

2
What Is A Machine?

• A machine is a device that makes work easier

• Examples
• Doorknob
• Pencil Sharpener
• Knife
• Crow Bar
• Axe

3
Simple Machines

• Simple machines are devices that do work with
  only one movement
• There are six types of simple machines
• Levers
• Pulleys
• Wheel and axle
• Inclined plane
• Wedge
• Screw

4
Pictures
5
Advantages of Simple Machines

• They help us overcome friction and gravity
• A crowbar could help us move a heavy rock or pry
  the lid off a wooden crate
• Machines make work easier by changing the force
  you exert in size, direction or both

6
Effort and Resistance Forces

• The force applied to the machine is called the
  effort force (Fe)
• The force applied by the machine to overcome
  resistance is called the resistance force (Fr)

7
Forces cont.

• Sketch

8
Two Kinds of Work

• There is work done on the machine (Win)
• There is also work done by the machine (Wout)
• WinFexde
• WoutFrxdr

9
Ideal Machine

• If there was a perfect machine with out energy
  being lost to friction and heat then work input
  would equal work output
• perpetual machines - Google Search

10
The Lever

• A lever is a simple machine that consists of
  three parts
• An effort arm
• A Resistance arm
• A fulcrum

11
Sketch in Notes

• Fulcrum
• Effort Arm
• Resistance Arm

12
Levers

• There are three kinds of levers
• 1st class
• 2nd Class
• 3rd Class

13
1st Class Lever

• The 1st class lever has the fulcrum in the middle
  of the two arms
• Examples are the see-saw, can openers, and
  scissors

14
Sketch
15
2nd Class Levers

• 2nd class levers have the resistance and effort
  arms on one end, and the fulcrum on the other.
  The resistance is in the middle here

16
Sketch
17
3rd Class Levers

• The 3rd class has the fulcrum on one end and the
  arms on the other, except reversed. Now the
  effort arm is in the middle

18
Sketch
19
Pulleys

• A pulley is like a 1st class lever
• There is a fulcrum in the middle (the wheel) and
  a resistance rope and effort rope
• Pulleys can be fixed or movable

20
Fixed pulley
21
Movable Pulley
22
Block and Tackle
23
Compound Machines

• A machine made up of several simple machines make
  up a compound machine
• Examples are a bicycle, a lawnmower, or a pencil
  sharpener
