IPv6

1
IPv6 A Simplified Explanation

• Presented by
• Bryan Crisler
• Senior Network Engineer
• Time Warner Cable

2
Housekeeping

• Take this time to locate
• Emergency Exits
• Bathrooms
• Breakroom/Water Fountain
• Note taking utensils
• Put your Phones on Vibrate
• If you need to take a call, feel free to step out
  of the room.

3
About your Speaker

• Bryan Crisler
• Started in Cable _at_ Charter Communications,
  Riverside, CA in June 2005
• Currently a Senior Network Engineer at Time
  Warner Cable

4
About your Speaker

• Held following positions
• Broadband Technician I-IV (Charter)
• Network Operations Specialist (Charter)
• Network Technician (Charter)
• Network Engineer (Charter TWC)
• SR Network Engineer (TWC)

5
About your Speaker

• Email bryan.crisler_at_twcable.com
• LinkedIn linkedin.com/in/bcrisler

6
Todays Lesson Plan

• Session 1 So What About IPv6?
• Session 2 Every Day IPv6 and You

7
So What About IPv6?

• Session 1

8
Basic History of IP

• IP Internet Protocol
• Defined in RFC 791, dated 1981, written by
  Information Sciences Institute _at_ USC
• Written for DARPA (Defense Advanced Research
  Projects Agency)

9
Basic History of IP

• Internet Protocol is designed for use in
  interconnected systems of packet-switched
  computer communication networksprovides for
  transmitting blocks of data called datagrams from
  sources to destinations identified by fixed
  length addresses. (RFC 791, section 1.1)

10
Versions of IP

• IPv0 3 Experimental Only
• IPv4 Defined in 1981 by RFC 760 791. First
  version to implemented publically. Still in use
  today.
• IPv5 Also experimental, called Internet Stream
  Protocol.
• IPv6 Also called IP Next Generation (IPng),
  Defined in 1998 by RFC 2460-2467

11
IP Addressing

• Layer 3 (Network) form of Addressing
• Two different forms of IP Address
• IPv4
• Uses Dotted Decimal (192.168.0.1)
• Has 4,294,967,296 total address (public
  private)
• 32 bit address
• IPv6
• Uses Hexadecimal Notation (FE801)
• Has 3.41038 total address (public private)
• 128 bit address

12
IP Addressing cont.

• Both versions represent a real number
• For Instance
• 0.0.1.0 256
• 10.0.0.4 16,777,220
• 00000001 1
• 00001000 281,462,092,005,375

13
IP Addressing cont.

• IPv4 Address
• Dotted decimal notation
• x.x.x.x, where x is between 0 255
• IPv6 Address
• Hexadecimal Number system
• 00000000000000000000000000000000
• Leading Zeros can be removed
• Multiple blocks of zeros can be simplified using
  colon

14
IP Addressing cont.

• Blocks of IPs are called Subnets
• Each Subnet represents a network (either WAN or
  LAN)
• The range of each subnet is determined by the
  Subnet Mask
• Each Subnet has a Network (First IP address) and
  a Broadcast (Last IP Address, IPv4 only) IP
  Address
• Network Range is calculated Subtracting Subnet
  Mask and from 255.255.255.255 (IPv4) or by 2(128
  prefix) (IPv6).

15
IP Addressing cont.

• Network Address First IP in a Subnet used to
  identify the entire network
• Broadcast Address (IPv4 only) Last IP in a
  Subnet used to communicate any device on the
  Useable IP Range.
• Gateway IP Address The configured IP address on
  the next hop router, which contains a path
  towards a WAN/Internet
• Useable IP Range Any IP in a subnet except the
  Network and Broadcast (IPv4 only)

16
IPv4 Address Example

• A home wireless Router is configured with network
  address of 192.168.0.0 and a subnet mask of
  255.255.255.0
• 255.255.255.255 255.255.255.0 0.0.0.255 256
  total addresses
• 192.168.0.0 0.0.0.255 192.168.0.255
• Network Range 192.168.0.0 to 192.168.0.255
• Network Address 192.168.0.0
• Broadcast Address 192.168.0.255

17
IPv6 Address Example

• A home wireless router has received a prefix
  delegated scope from the ISP 2605e000160e816a
  /64.
• 2(128 - prefix) ? 264 -gt 18,446,744,073,709,551,
  616 hosts
• Approximately 18.4 Quintillion IP Addresses.
• If each IP address was the size of a quarter, you
  could cover the entire earth approximately 24
  times.

18
IPv6 Address Example cont.

• The network Range is
• 2605e000160e816a0000000000000000
  -2605e000160e816affffffffffffffff
• Network Address 2605e000160e816a00000000000
  00000
• Broadcast Address There is no broadcast address,
  since multicast is used instead.

19
IPv4 vs IPv6 Comparison
IPv4 IPv6
Address 32-bit 128-bit
Number of Addresses 4,294,967,296 340,282,366,920,938,463,463,374,607,431,768,211,456
Network Address X X
Broadcast Address X N/A
Link-Local Range 169.254.0.0/16 FE80/10
Multicast Range 224.0.0.0 239.255.255.255 FF00/8
Dynamic Addressing DHCP SLAAC or DHCPv6
Security Optional IPSec built-in, optional
Header Length Variable Fixed
20
IPv4 vs IPv6 Comparison cont.
IPv4 IPv6
Loopback Address 127.0.0.1/32 1/128
Default Gateway 0.0.0.0/0 /0
IGP Routing Protocols RIP (v1/v2), OSPF, ISIS, EIGRP RIPng, OSPFv3,ISIS
EBGP Routing Protocols BGP BGPv4
Other Protocols ICMP, DHCP, DNS ICMPv6, DHCPv6, DNS
21
IPv6 Features

• Larger Address Space
• Simplified header makes routing more efficient
• Private IP Space not required
• Manual configuration not required due to SLAAC
• Broadcasting of packets replaced with
  Multicast/Anycast

22
IPv6 Features cont.

• Security built into IPv6, but is optional
• Mobility allows for devices to use the same IPv6
  Address (from home network) regardless of what
  network they are connected to.
• Dual Stack / 6 to 4 tunneling is available to
  provide a smooth transition

23
(No Transcript)
24
ARP vs Neighbor Discovery Protocol

• ARP Address resolution protocol uses IPv4
  Broadcast address to map an IPv4 Address to a MAC
  address (ARP) or vise versa (rARP).
• Neighbor Discovery Protocol part of the ICMPv6
  protocol, uses multicast to establish
  communication with devices on the same network
  segment. Follows the following process
• Neighbor Solicitation sends a message to
  FF021/16 with all configured IPv6 addresses
• DAD (Duplicate Address Detection) If no message
  is received from LAN segment, configured IPv6
  Addresses are assumed not to be duplicates.
• Neighbor Assignment Message sent to confirm
  configuration of IPv6 addresses to LAN segment.

25
ARP vs Neighbor Discovery Protocol cont.

• NDP cont.
• Router Solicitation message sent to FF022/16
  to detect presence of routers on network segment.
  Determine the default gateway for host.
• Router Advertisement response from router
• Redirect message sent from router specifying
  that it is not the best gateway for the host.

26
SLAAC

• SLAAC StateLess Address AutoConfiguration
• Allows a host to automatically configure their
  own IPv6 Address
• Uses NDP to determine a valid Global IPv6 Address
• Uses EUI-64 method

27
(No Transcript)
28
Dynamic Host Configuration Protocol (DHCP)

• Allows a DHCP server to assign/configure an IP
  Address to an end device
• Will also configure Subnet Mask, Gateway IP, as
  well as DNS Servers
• When an end device is configured for DHCP, the
  DORA begins (IPv4) or SARR begins (IPv6).

29
DHCP cont.

• DORA (IPv4)
• Discover Client sends a broadcast message to
  DHCP Server
• Offer Server sends a message to client with an
  IP Address Offer
• Request Client formally request IP Address
  Offered, and sets Subnet Mask, gateway, DNS and
  lease time
• Acknowledge Server Acknowledges client Request
  and reserves IP.
• Once lease is at half-life, DORA process is
  repeated.

30
DHCP cont.

• SARR
• Solicit Client sends a multicast message to
  DHCPv6 Server
• Advertise DHCPv6 Server(s) replies to client
  with their IPv6 Address
• Request Client formally request IP Address
  Offered, and sets Prefix, DNS and lease time, but
  not gateway (learned from ICMPv6)
• Reply Server Acknowledges client Request and
  reserves IP.
• Once lease is at half-life, SARR process is
  repeated.

31
Domain Name Service (DNS)

• DNS Maps a domain name like google.com to an IP
  Address
• DNS Support for IPv6 has been added
• AAAA records are used to map a FQDN like google
  to an IPv6 Address
• A Records are used to map FQDN to an IPv4
  Address.

32
Session 1 Review

• How many bits are in an IPv6 Address?
• What method is used by DHCPv6?
• What does the double colon mean in
  hexadecimal numbering system for IPv6?
• Does ICMPv6 use broadcast or multicast messages?
• How is a default route or default gateway
  determined?

33
Session 1 QA

• Any Questions???

34
Break time

• 15 Minutes

35
Every Day IPv6 and You

• Session 2

36
Why did IPv6 become Necessary?

• We are out of IPv4 Space
• ARIN reports only 0.00374 of /8 left
• Only 245 /24s left (62,720 IPs left)
• Approximately 42.4 of the worlds population
  uses the internet as of Dec 2014, where as only
  12.7 used the internet in Dec 2004.
  (internetworldstats.com)

37
Where are we at with IPv6 Deployment?

• Since World IPv6 Launch day, on June 6th, 2012,
  many companies including Time Warner Cable and
  Comcast have committed to launching IPv6.
• Currently most companies are running both IPv4
  and IPv6 at the same time.
• Comcast, Charter, Cox and Time Warner Cable

38
What are the challenges to IPv6 deployment?

• End Device support (software and hardware)
• Windows 7 and 8 Support IPv6
• Mac OS X v10.1 and later Support IPv6
• End Device (Wireless Routers)
• Check your vendors website to see if IPv6 is
  supported.

39
Where are we at with IPv6 Deployment? cont.

• Most cable companies are providing IPv6 to
  customers
• Network Devices have already been configured
• Network Backbone already supports IPv6
• IPv6 Allocations have already been received and
  deployed

40
What are the challenges cont.

• Modem Support
• Not all modems have firmware that support IPv6.
• Each cable company has a list of supported IPv6
  enabled modems.
• Website Support
• Most websites are IPv4 only. Many bigger sites
  such as Google, Yahoo, Microsoft all support IPv6.

41
What are the challenges - cont.

• End User
• Training for Field Techs/CSR/Engineers
• Subscriber training

42
Is my computer IPv6 Ready?

• Here is how you can check
• Go to www.ipv6-test.com or www.test-ipv6.com
• Go to ipv6test.google.com

43
IPConfig

• Run cmd
• Type ipconfig /all
• Displays all IP Addresses
• Type ipconfig /release ipconfig /renew
• If you need to refresh the IP with the DHCP
  Server do a /release /renew
• Type ipconfig /flushdns
• If you are having problems reaching some
  websites, run a /flushdns

44
Tracert (Traceroute)

• Run cmd
• Shows latency and hopcount
• Each hop is a router interface
• Maximum hops on tracert is 30
• Type tracert -6 google.com
• To see if you can reach google or any other
  domain name.
• Type tracert -6 ltipv6 addressgt
• If you are unable to resolve any DNS, you can
  still traceroute using an IP Address
• Type tracert -6 ltipv6 gatewaygt
• If you are trying to reach your local routers
  gateway ip address
• Type tracert -6 ltcpe gateway ipgt
• If you are trying to reach your CPE gateway IP
  Address on the CMTS.

45
Ping

• Run cmd
• Great test for packet loss
• Type ping google.com
• To see if you can reach google or any other
  domain name
• Type ping -6 t ltip or domain namegt
• To test for packet loss on the internet. t will
  continuously ping until cntr-c is pressed.
• Type ping -6 n ltcountgt ltip or domain namegt
• To test for packet loss with a specific amount of
  packets.
• Type ping -6 l ltsize of packetgt ltip/domaingt
• To test for packet loss with a greater packet
  size.

46
NSLookup

• Run cmd
• Used to query DNS Server and perform DNS Lookups
• Can be used to determine if DNS server is down or
  not reachable
• Type nslookup google.com
• Performs a standard lookup
• Type nslookup ltip addressgt
• Performs a reverse dns lookup to find domain name
• Type nslookup ltip/domaingt ltserver ipgt
• Performs a lookup using a different server

47
Network-tools.com

• Go to www.network-tools.com
• Many different network tools
• Allows you to ping from outside cable network
• Can check DNS Records
• Can also check email spam blacklists
