DNA

1
DNA

• Chapter 11

2
The main nucleic acids

• There are 2 main nucleic acids
• 1. DNA Deoxyribonucleic Acid
• 2. RNA Ribonucleic Acid

3
What is DNA?

• Deoxyribonucleic Acid (DNA) is the genetic
  enzymes that is critical for an organisms
  function because they control the chemical
  reactions needed for life

4
The structure of DNA

• DNA is a polymer made of repeating subunits
  called nucleotides
• Nucleotides have three parts 1. a simple sugar
  (deoxyribose), 2. a phosphate group, and 3. a
  nitrogenous base

Nitrogen base
Phosphate group
Sugar (deoxyribose)
5
Parts of the Nucleotide

• The simple sugar in DNA, called deoxyribose (dee
  ahk sih RI bos), gives DNA its namedeoxyribonucle
  ic acid.
• The phosphate group is composed of one atom of
  phosphorus surrounded by four oxygen atoms

6
Parts of the Nucleotide

• A nitrogenous base is a carbon ring structure
  that contains one or more atoms of nitrogen.
• In DNA, there are four possible nitrogenous
  bases adenine (A), guanine (G), cytosine (C),
  and thymine (T).

Adenine (A)
Guanine (G)
Cytosine (C)
Thymine (T)
7
Parts of the Nucleotide

• Nucleotides join together to form long chains,
  with the phosphate group of one nucleotide
  bonding to the deoxyribose sugar of an adjacent
  nucleotide
• The phosphate groups and deoxyribose molecules
  form the backbone of the chain, and the
  nitrogenous bases stick out like the teeth of a
  zipper
• Each nitrogen base is held together by a hydrogen
  bond

8
The structure of DNA
Because DNA is composed of two strands twisted
together, its shape is called double helix
9
Watson Crick

• In 1953, Watson and Crick proposed that DNA is
  made of two chains of nucleotides held together
  by nitrogenous bases
• Watson and Crick also proposed that DNA is shaped
  like a long zipper that is twisted into a coil
  like a spring

10
The importance of the nucleotide sequence

• The sequence of nucleotides forms the unique
  genetic information of an organism. The closer
  the relationship is between two organisms, the
  more similar their DNA nucleotide sequences will
  be.

Chromosome
11
DNA Replication

• Before a cell can divide by mitosis or meiosis,
  it must first make a copy of its chromosomes
• The DNA in the chromosomes is copied in a process
  called DNA replication
• Without DNA replication, new cells would have
  only half the DNA of their parents

12
Replication of DNA
DNA
Replication
Replication
13
Copying DNA

• DNA is copied during interphase prior to mitosis
  and meiosis.
• It is important that the new copies are exactly
  like the original molecules

14
Copying DNA
New DNA molecule
Original DNA Strand
New DNA molecule
Free Nucleotides
New DNA Strand
Original DNA Strand
Original DNA
15
The importance of DNA

• Scientists use nucleotide sequences to determine
• 1. evolutionary relationships among organisms
• 2. to determine whether two people are related
• 3. to identify bodies of crime victims.

16
RNA

• Section 2

17
3 Parts of the RNA nucleotide

• Ribose (sugar)
• Phosphate Acid
• 4 Nitrogen Bases
• 1. A- Adenine
• 2. U- Uracil (replaces Thymine)
• 3. C- Cytosine
• 4. G- Guanine

18
RNA vs DNA

• RNA like DNA, is a nucleic acid.
• RNA structure differs from DNA structure in three
  ways.
• RNA is single strandedDNA is double stranded

19
RNA vs DNA

• 2. The sugar in RNA is ribose - DNAs sugar is
  deoxyribose

20
RNA vs DNA

• Both DNA and RNA contain four nitrogenous bases,
  but rather than thymine, RNA contains a similar
  base called uracil (U).

Uracil forms a base pair with adenine in RNA,
just as thymine does in DNA.
21
RNA provides instruction for making protein

• RNA takes instructions from DNA on the assembly
  of proteins, thenamino acid by amino acidthey
  assemble the protein.
• There are three types of RNA that help build
  proteins.
• 1. mRNA messenger RNA
• 2. tRNA transfer RNA
• 3. rRNA ribosomal RNA

22
(No Transcript)
23
How it all works

• Messenger RNA (mRNA), brings instructions from
  DNA in the nucleus to the cells factory floor,
  the cytoplasm
• On the factory floor, mRNA moves to the assembly
  line, a ribosome.
• The ribosome, made of ribosomal RNA (rRNA), binds
  to the mRNA and uses the instructions to assemble
  the amino acids in the correct order

24
THEN

• Transfer RNA (tRNA) is the supplier. Transfer
  RNA delivers amino acids to the ribosome to be
  assembled into a protein
• In the nucleus, enzymes make an RNA copy of a
  portion of a DNA strand in a process called
  transcription.

25
Transcription vs Replication

• The main difference between transcription and DNA
  replication is that transcription results in the
  formation of one single-stranded RNA molecule
  rather than a double-stranded DNA molecule

26
The Genetic Code

• The nucleotide sequence transcribed from DNA to a
  strand of messenger RNA acts as a genetic
  message, the complete information for the
  building of a protein
• As you know, proteins contain chains of amino
  acids. You could say that the language of
  proteins uses an alphabet of amino acids
• A code is needed to convert the language of mRNA
  into the language of proteins

27
Codon

• Biochemists began to crack the genetic code when
  they discovered that a group of three nitrogenous
  bases in mRNA code for one amino acid. Each group
  is known as a codon
• Sixty-four combinations are possible when a
  sequence of three bases is used thus, 64
  different mRNA codons are in the genetic code

28
(No Transcript)
29
Facts about Codons

• Some codons do not code for amino acids they
  provide instructions for making the protein
• More than one codon can code for the same amino
  acid.
• For any one codon, there can be only one amino
  acid

30
The Genetic Code

• All organisms use the same genetic code
• This provides evidence that all life on Earth
  evolved from a common origin

31
Translation from mRNA to Protein

• The process of converting the information in a
  sequence of nitrogenous bases in mRNA into a
  sequence of amino acids in protein is known as
  translation
• Translation takes place at the ribosomes in the
  cytoplasm
• In prokaryotic cells, which have no nucleus, the
  mRNA is made in the cytoplasm
• In eukaryotic cells, mRNA is made in the nucleus
  and travels to the cytoplasm
• In cytoplasm, a ribosome attaches to the strand
  of mRNA

32
Role of Transfer RNA

• For proteins to be built, the 20 different amino
  acids dissolved in the cytoplasm must be brought
  to the ribosomes
• This is the role of transfer RNA

33
Amino acid
Each tRNA molecule attaches to only one type of
amino acid.
Chain of RNA nucleotides
Transfer RNA molecule
Anticondon
34
tRNA
35
The role of transfer RNA
Ribosome
mRNA codon
36
The role of tRNA

• Usually, the first codon on mRNA is AUG, which
  codes for the amino acid methionine
• AUG signals the start of protein synthesis
• When this signal is given, the ribosome slides
  along the mRNA to the next codon

37
The role of transfer RNA
Methionine
tRNA anticodon
38
The role of transfer RNA
A new tRNA molecule carrying an amino acid pairs
with the second mRNA codon.
Alanine
39
The role of transfer RNA
The amino acids are joined when a peptide bond is
formed between them.
Methionine
Alanine
Peptide bond
40
The role of transfer RNA
A chain of amino acids is formed until the stop
codon is reached on the mRNA strand.
Stop codon
41
Mutations

• Section 3

42
Mutations in reproductive cells

• By changing the sequence of nucleotides within a
  gene in a sperm or an egg cell
• The altered gene would become part of the genetic
  makeup of the offspring
• May produce a new trait or a protein that does
  not work correctly or a protein that is
  nonfunctional
• The embryo may not survive
• In some rare cases a gene mutation may have
  positive effects

43
Mutations in Body Cells

• If the cells DNA is changed, (by a gamma ray)
  this mutation would not be passed on to offspring
  but could cause problems for the individual
• Damage to a gene may impair the function of the
  cell
• When that cell divides, the new cells also will
  have the same mutation
• Some mutations of DNA in body cells affect genes
  that control cell division resulting in cancer

44
Point Mutation

• A point mutation is a change in a single base
  pair in DNA
• A change in a single nitrogenous base can change
  the entire structure of a protein because a
  change in a single amino acid can affect the
  shape of the protein.

45
example

• Normal
• THE DOG BIT THE CAT
• Mutation
• THE DOG BIT THE CAR

46
The effects of point mutations
mRNA
Normal
Protein
Stop
Replace G with A
Point mutation
mRNA
Protein
Stop
47
Frameshift Mutation

• What would happen if a single base were lost from
  a DNA strand?
• Frameshift mutation is an addition or deletion of
  a base in a DNA strand

48
Frameshift Mutation
Deletion of U
mRNA
Protein
49
Causes of Mutations

• Could be spontaneous, or caused from
  environmental factors
• Any agent that can cause a change in DNA is
  called a mutagen
• Radiations
• Chemicals
• High Temperatures
