Dredges

1
Dredges Barges
2
Dredges
3
Dredges

• Used in different mining applications
• Sand gravel are most commonly dredged materials
• Other minerals also mined with dredges

4
Dredge Types

• Suction pumps
• With or without cutter heads
• Clamshells draglines
• Bucket ladders

5
(No Transcript)
6
Mining Methods

• Suction material as slurry into pipe beneath
  water
• Slurry passes through pipe, separated from water
  transported to shore by various methods

7
Mining Methods

• Clamshells draglines scoop material load on
  belt or barge

8
Dredge Hazards

• Drowning
• Slips falls
• Electrocution
• High pressure pumps pipes
• Welding cutting
• Materials handling
• Pinch points

9
Remove Trip Hazards
10
Electrical Hazards Around Water
11
Material Loading
12
Material Loading

• Especially careful when loading materials.
• Never go under suspended loads

13
Other Hazards

• Cables
• High winds
• Lightning
• Fog
• Excessive noise

14
Hearing Protection

• Diesel Engines

15
PPE

• Life jackets
• Steel-toed boots with slip-resistant soles
• Safety glasses or goggles
• Hard hat

16
Stored Maintained
17
Hardhats
18
Hardhats

• Required for everyone on board
• If you dont have it on, its unlikely you will
  go get it when needed

19
Drowning

• Account for majority of dredge fatalities

20
Life Jackets
21
Life Jackets

• Wear at all times while working on or around
  small boats, barges, dredges tugboats
• Jackets that keep head above water preferred

22
Slip Trip Hazards

• many slip trip hazards
• Most serious is being caught between barge, dock
  or processing plant

23
Trip Hazards

• Oil, grease, water, ice, loose sand gravel
• Cables unsecured lines
• Good housekeeping reduces danger

24
Electricity Water

• Careful around electrical installations on
  dredges
• Provide maintain insulation grounding
• Lockout

25
Power Cables

• Floating cables power cables carried on
  pipelines properly insulated protected
• Mechanical bonding grounding maintained

26
Electrical Safety

• Dredges with on board power plants differ from
  those with shore power because vessels hull used
  as neutral or ground return
• Employee unfamiliar with marine electrical
  circuitry not allowed to work equipment

27
Light Bulbs Guarded
28
Electrical Safety

• Weatherproof lamp sockets
• Temporary lights guarded, with heavy duty cords
  grounded

29
Pipes Pumps

• High pressure pipes pumps isolated bled
  before any work performed
• System secured, blinded, locked tagged until
  work completed

30
Welding Cutting

• Pay particular attention to surroundings
• Welded objects tested to determine if water,
  flammable liquids or vapors present

31
Moving Heavy Objects
32
Moving Heavy Objects

• Use hoists or get help to handle heavy objects
• Rigging contains pinch points done by
  experienced people

33
Wire Rope
34
Wire Rope

• Broken cables can whip or backlash violently

35
Inspect Wire Rope
36
Inspect Wire Rope
37
Guard Drum Sheave
38
Dredge Fires
39
Dredge Fires

• Extremely dangerous
• Good housekeeping
• Keep oil, grease, waste rags, flammables
  combustibles in covered containers away from
  ignition sources

40
Fire Prevention

• Store paints, thinners solvents in fire
  cabinets
• Check for fire after welding cutting

41
Fire Extinguishers

• Inspected readily available.
• Trained in fire suppression techniques

42
Weather

• High winds lightning
• Stop work go ashore
• Create unstable work platforms
• Fog visibility

43
Wear Life Jacket
44
Rescue Equipment Maintained Accessible
45
Working Alone
46
Working Alone

• Not work alone in hazardous areas unless they can
  communicate, be seen or heard by others

47
Barges
48
Hazards

• Drowning
• Falling overboard
• Slips falls
• Crushed between barge dredge, dock or floating
  plant

49
PPE

• Life jackets
• Steel-toed boots with slip resistant soles
• Safety glasses or goggles
• Hardhat

50
Slips Falls
51
Trips Falls
52
Cables

• Pay attention around lines cables under tension
  they can break

53
Loading Hazards

• Slips falls
• Rope burns from being caught in lines
• Crushed between barge dredge
• Drowning
• Caught in conveyor

54
Unloading hazards

• Unloading equipment has pinch points blind
  spots
• Stay out of machine swing radius
• Falling material

55
Tow Boats
56
Tow Boat Hazards

• Slips falls
• Rope burns from being caught in lines
• Crushed between boat barge
• Drowning
• Excessive noise
