Chapter 13 Part 3

1
Drug DesignOptimizing Target Interactions

• Chapter 13 Part 3

2
1. Drug design - optimizing binding interactions
Aim - To optimize binding interactions with target
Reasons

• To increase activity and reduce dose levels
• To increase selectivity and reduce side effects

Strategies

• Vary alkyl substituents
• Vary aryl substituents
• Extension
• Chain extensions / contractions
• Ring expansions / contractions
• Ring variation
• Isosteres
• Simplification
• Rigidification

3
2. Vary alkyl substituents

• Rationale
• Alkyl group in lead compound may interact with
  hydrophobic
• region in binding site
• Vary length and bulk of group to optimise
  interaction

4
2. Vary alkyl substituents
Rationale Vary length and bulk of alkyl group
to introduce selectivity
5
2. Vary alkyl substituents
Rationale Vary length and bulk of alkyl group
to introduce selectivity
Example Selectivity of adrenergic agents for
b-adrenoceptors over a-adrenoceptors
6
2. Vary alkyl substituents
7
a-Adrenoceptor
8
a-Adrenoceptor
9
a-Adrenoceptor
10
b-Adrenoceptor
11
b-Adrenoceptor
SALBUTAMOL
12
b-Adrenoceptor
13
a-Adrenoceptor
14
a-Adrenoceptor
15
a-Adrenoceptor
16
a-Adrenoceptor
17
a-Adrenoceptor
18
a-Adrenoceptor
19
a-Adrenoceptor
20
a-Adrenoceptor
21
2. Vary alkyl substituents

• Synthetic feasibility of analogues
• Feasible to replace alkyl substituents on
  heteroatoms with other alkyl substituents
• Difficult to modify alkyl substituents on the
  carbon skeleton of a lead compound.

22
2. Vary alkyl substituents
Methods
23
2. Vary alkyl substituents
Methods
24
3. Vary aryl substituents
Vary substituents Vary substitution pattern
25
3. Vary aryl substituents
Vary substituents Vary substitution pattern
Anti-arrhythmic activity best when substituent is
at 7-position
26
3. Vary aryl substituents
Vary substituents Vary substitution pattern
Meta substitution Inductive electron withdrawing
effect

• Notes
• Binding strength of NH2 as HBD affected by
  relative position of NO2
• Stronger when NO2 is at para position

27
4. Extension - extra functional groups
Rationale To explore target binding site for
further binding regions to achieve additional
binding interactions
28
4. Extension - extra functional groups
Example ACE Inhibitors
29
4. Extension - extra functional groups
Example Nerve gases and medicines

• Notes
• Extension - addition of quaternary nitrogen
• Extra ionic bonding interaction
• Increased selectivity for cholinergic receptor
• Mimics quaternary nitrogen of acetylcholine

30
4. Extension - extra functional groups
Example Second-generation anti-impotence drugs

• Notes
• Extension - addition of pyridine ring
• Extra van der Waals interactions and HBA
• Increased target selectivity

31
4. Extension - extra functional groups
Example Antagonists from agonists
32
5. Chain extension / contraction

• Rationale
• Useful if a chain is present connecting two
  binding groups
• Vary length of chain to optimise interactions

33
5. Chain extension / contraction
Example N-Phenethylmorphine
Optimum chain length 2
34
6. Ring expansion / contraction
Rationale To improve overlap of binding groups
with their binding regions
Better overlap with hydrophobic interactions
35
6. Ring expansion / contraction
Vary n to vary ring size
Example
Three interactions Increased binding
Two interactions Carboxylate ion out of range
36
7. Ring variations

• Rationale
• Replace aromatic/heterocyclic rings with other
  ring systems
• Often done for patent reasons

37
7. Ring variations
Rationale Sometimes results in improved
properties
Example
38
7. Ring variations
Example - Nevirapine (antiviral agent)
39
7. Ring variations
Example - Pronethalol (b-blocker)
40
8. Isosteres and bio-isosteres

• Rationale for isosteres
• Replace a functional group with a group of same
  valency (isostere)
• e.g. OH replaced by SH, NH2, CH3
• O replaced by S, NH, CH2
• Leads to more controlled changes in steric /
  electronic properties
• May affect binding and / or stability

41
8. Isosteres and bio-isosteres
Useful for SAR

• Notes
• Replacing OCH2 with CHCH, SCH2, CH2CH2
  eliminates activity
• Replacing OCH2 with NHCH2 retains activity
• Implies O involved in binding (HBA)

42
8. Isosteres and bio-isosteres

• Rationale for bio-isosteres
• Replace a functional group with another group
  which retains the same biological activity
• Not necessarily the same valency

Example Antipsychotics
Pyrrole ring bio-isostere for amide group
43
9. Simplification

• Rationale
• Lead compounds from natural sources are often
  complex and difficult to synthesize
• Simplifying the molecule makes the synthesis of
  analogues easier, quicker and cheaper
• Simpler structures may fit the binding site
  better and increase activity
• Simpler structures may be more selective and
  less toxic if excess functional groups are
  removed

44
9. Simplification

• Methods
• Retain pharmacophore
• Remove unnecessary functional groups

45
9. Simplification
Methods
Remove excess rings

• Example

46
9. Simplification
Methods
Remove asymmetric center
47
9. Simplification
Methods
Simplify in stages to avoid oversimplification

• Notes
• Simplification does not mean pruning groups
  off the lead compound
• Compounds usually made by total synthesis

48
(No Transcript)
49
(No Transcript)
50
(No Transcript)
51
(No Transcript)
52
(No Transcript)
53
9. Simplification
Example
54
9. Simplification

• Disadvantages
• Oversimplification may result in decreased
  activity and selectivity
• Simpler molecules have more conformations
• More likely to interact with more than one
  target binding site
• May result in increased side effects

55
Target binding site
56
Target binding site
57
Target binding site
58
Target binding site
59
Target binding site
60
Target binding site
61
Target binding site
62
Target binding site
63
Target binding site
64
Target binding site
65
Target binding site
66
Target binding site
67
Target binding site
68
Different binding site leading to side effects
69
9. Simplification
Oversimplification of opioids
70
MORPHINE
C
C
O
C
C
C
C
N
SIMPLIFICATION
71
LEVORPHANOL
C
C
O
C
C
C
C
N
SIMPLIFICATION
72
LEVORPHANOL
C
C
O
C
C
C
C
N
SIMPLIFICATION
73
METAZOCINE
C
C
O
C
C
C
C
N
SIMPLIFICATION
74
C
C
O
C
C
C
C
N
OVERSIMPLIFICATION
75
TYRAMINE
C
C
O
C
C
C
C
N
OVERSIMPLIFICATION
76
AMPHETAMINE
C
C
O
C
C
C
C
N
OVERSIMPLIFICATION
77
10. Rigidification

• Note
• Endogenous lead compounds are often simple and
  flexible
• Fit several targets due to different active
  conformations
• Results in side effects

• Strategy
• Rigidify molecule to limit conformations -
  conformational restraint
• Increases activity - more chance of desired
  active conformation being present
• Increases selectivity - less chance of undesired
  active conformations
• Disadvantage
• Molecule is more complex and may be more
  difficult to synthesise

78
10. Rigidification
79
10. Rigidification

• Methods - Introduce rings
• Bonds within ring systems are locked and cannot
  rotate freely
• Test rigid structures to see which ones have
  retained active conformation

80
10. Rigidification

• Methods - Introduce rings
• Bonds within ring systems are locked and cannot
  rotate freely
• Test rigid structures to see which ones have
  retained active conformation

81
10. Rigidification

• Methods - Introduce rings
• Bonds within ring systems are locked and cannot
  rotate freely
• Test rigid structures to see which ones have
  retained active conformation

82
Rotatable bond
83
Rotatable bond
Ring formation
84
Ring formation
85
10. Rigidification
Methods - Introduce rigid functional groups
86
10. Rigidification
Examples
Inhibits platelet aggregation
87
10. Rigidification
Examples - Combretastatin (anticancer agent)
Less active
More active
88
10. Rigidification
Methods - Steric Blockers
Flexible side chain
Coplanarity allowed
89
10. Rigidification
Methods - Steric Blockers
Serotonin antagonist
Increase in activity Active conformation retained
90
10. Rigidification
Methods Steric Blockers
Inactive - active conformation disallowed
D3 Antagonist
91
10. Rigidification
Identification of an active conformation by
rigidification
92
10. Rigidification
Identification of an active conformation by
rigidification
N
N
N
HN
O
93
10. Rigidification
Identification of an active conformation by
rigidification
N
N
N
HN
O
94
10. Rigidification
Identification of an active conformation by
rigidification
N
N
N
HN
O
95
10. Rigidification
Identification of an active conformation by
rigidification
N
N
N
HN
O
96
10. Rigidification
Identification of an active conformation by
rigidification
N
N
N
HN
O
97
10. Rigidification
Identification of an active conformation by
rigidification
N
N
N
HN
O
98
10. Rigidification
Identification of an active conformation by
rigidification
Planar conformation
99
10. Rigidification
Identification of an active conformation by
rigidification
Orthogonal conformation
100
10. Rigidification
Identification of an active conformation by
rigidification
CYCLISATION
101
10. Rigidification
Identification of an active conformation by
rigidification
CYCLISATION
102
10. Rigidification
Identification of an active conformation by
rigidification
CYCLISATION
Locked into planar conformation
103
10. Rigidification
Identification of an active conformation by
rigidification
STERIC HINDRANCE
104
10. Rigidification
Identification of an active conformation by
rigidification
STERIC HINDRANCE
105
10. Rigidification
Identification of an active conformation by
rigidification
STERIC HINDRANCE
106
10. Rigidification
Identification of an active conformation by
rigidification
STERIC HINDRANCE
107
10. Rigidification
Identification of an active conformation by
rigidification
STERIC HINDRANCE
Locked into orthogonal conformation
108
11. Structure-based drug design
Strategy Carry out drug design based on the
interactions between the lead compound and the
target binding site

• Procedure
• Crystallize target protein with bound ligand
• Acquire structure by X-ray crystallography
• Download to computer for molecular modelling
  studies
• Identify the binding site
• Identify the binding interactions between ligand
  and target
• Identify vacant regions for extra binding
  interactions
• Remove the ligand from the binding site in
  silico
• Fit analogues into the binding site in silico
  to test binding capability
• Identify the most promising analogues
• Synthesise and test for activity
• Crystallise a promising analogue with the target
  protein and repeat the process

109
(No Transcript)
110
(No Transcript)
111
(No Transcript)
112
(No Transcript)
113
(No Transcript)
114
(No Transcript)
115
(No Transcript)
116
(No Transcript)
117
(No Transcript)
118
(No Transcript)
119
(No Transcript)
120
(No Transcript)
121
(No Transcript)
122
12. De Novo Drug Design
The design of novel agents based on a knowledge
of the target binding site

• Procedure
• Crystallise target protein with bound ligand
• Acquire structure by X-ray crystallography
• Download to computer for molecular modelling
  studies
• Identify the binding site
• Remove the ligand in silico
• Identify potential binding regions in the
  binding site
• Design a lead compound to interact with the
  binding site
• Synthesise the lead compound and test it for
  activity
• Crystallise the lead compound with the target
  protein and identify the actual binding
  interactions
• Optimise by structure-based drug design
