Thermodynamic Properties of Fluids

1
Thermodynamic Properties of Fluids

• Dr.Sininart Chongkhong A Dao
• ChE. PSU.

2
Purpose of this Chapter

• To develop from the first and second laws the
  fundamental property relations which underlie the
  mathematical structure of thermodynamics.
• Derive equations which allow calculation of
  enthalpy and entropy values from PVT and heat
  capacity data.
• Discuss diagrams and tables by which property
  values are presented for convenient use.
• Develop generalized correlations which provide
  estimated of property values in he absence of
  complete experimental information.

3
Property Relations for Homogeneous
PhasesFundamental Properties

• Although this equation is derived from the
  special case of a reversible process, it not
  restricted in application to reversible process.
• It applies to any process in a system of constant
  mass that results in a differential change form
  one equilibrium state to another.
• The system many consist of a single phase or
  several phases may be chemically inert or may
  undergo chemical reaction.

(6.1)
4

• Define
• H Enthalpy
• A Helmholtz energy
• G Gibbs energy

(2.11)
(6.2)
(6.3)
5

• Based on one mole (or to a unit mass) of a
  homogeneous fluid of constant composition, they
  simplified to

6

• Maxwells equaitons

7
Enthalpy and Entropy as Functions of T and P

• Temperature derivatives

• Pressure derivatives

8

• The most useful property relations for the
  enthalpy and entropy of a homogeneous phase
  result when these properties are expressed as
  functions of T and P (how H and S vary with T and
  P).

(6.20)
(6.21)
9
Property Relations for Homogeneous
PhasesInternal Energy as Function of P

• The pressure dependence of the internal energy is
  shown as

10
Property Relations for Homogeneous PhasesThe
Ideal Gas State

• For ideal gas, expressions of dH and dS
  (eq.6.20-6.21) as functions of T and P can be
  simplified to as follows

11
Property Relations for Homogeneous
PhasesAlternative Forms for Liquids

• Relations of liquids can be expressed in terms of
  ? and ? as follows

12
Property Relations for Homogeneous
PhasesAlternative Forms for Liquids

• Enthalpy and entropy as functions of T and P as
  follows
• ? and ? are weak functions of pressure for
  liquids, they are usually assumed constant at
  appropriate average values for integration.

13
Example 6.1

• Determine the enthalpy and entropy changes of
  liquid water for a change of stage from 1 bar
  25?C to 1,000 bar 50?C.

14
(No Transcript)
15
(No Transcript)
16
Note that the effect of ?P of almost 1,000 bar on
H and S of liquid water is less than that of ?T
of only 25?C.
17
Property Relations for Homogeneous
PhasesInternal Energy and Entropy as Function
of T and V

• Useful property relations for T and V as
  independent variables are

18

• The Partial derivatives dU and dS of homogeneous
  fluids of constant composition to temperature and
  volume are
• Alternative forms of the above equations are

19
Property Relations for Homogeneous PhasesThe
Gibbs Energy as a Generating Function

• An alternative form of a fundamental property
  relation as defined in dimensionless terms
• The Gibbs energy when given as a function of T
  and P therefore serves as a generating function
  for the other thermodynamic properties, and
  implicitly represents complete information.

20
Residual Properties

• The definition for the generic residual property
  is
• M is the molar value of any extensive
  thermodynamics property V, U, H, S, G.
• M, Mig the actual and ideal gas properties
  which are at the same temperature and pressure.

21

• Residual gibbs energy
• G, Gig the actual and ideal gas values of the
  Gibbs energy at the same temperature and
  pressure.
• Residual volume

22
Fundamental property relation for residual
properties

• The fundamental property relation for residual
  preperties applies to fluids of constant
  composition.

23
(No Transcript)
24
Enthalpy and Entropy from Residual Properties
25
The true worth of the Eq. for ideal gases is now
evident. They are important because they provide
a convenient base for the calculation of real-gas
properties.
26

• Example 6.3
• Calculate H and S of saturated isobutane vapor at
  630 K from the following information
• Table 6.1 gives compressibility-factor data
• The vapor pressure of isobutane at 630 K 15.46
  bar
• Set H0ig 18,115 Jmol-1 and S0ig 295.976
  Jmol-1K-1 for the ideal-gas reference state at
  300 K 1 bar
• Cpig/R 1.776533.037x10-3T (T/K)

27
(No Transcript)
28

• Solution 6.3
• Eqs. (6.46) and (6.48) are used to calculate HR
  and SR.
• Plot (?Z/?T)P/P and (Z-1)/P vs. P
• From the compressibility-factor data at 360 K ?
  (Z-1)/P
• The slope of a plot of Z vs. T ? (?Z/?T)P/P
• Data for the required plots are shown in Table
  6.2.

29
(No Transcript)
30
(No Transcript)
31
(No Transcript)
32
Residual Properties by Equations of State
Residual Properties from the Virial Equation of
State

• The two-term virial eq. gives Z-1 BP/RT.

33

• In application ? is a more convenient variable
  than V,
• PV ZRT is written in the alternative form.

34

• The three-term virial equation.

Application of these equations, useful for gases
up to moderate pressure, requires data for both
the second and third virial coefficients.
35
Residual Properties by Cubic Equations of State
36
The generic equation of state presents two cases.
37
(No Transcript)
38
Ex. 6.4

• Find values for the HR and SR for n-butane gas at
  500 K
• 50 bar as given by the Redlich/Kwong Eequation.
• Solution
• Tr 500/425.1 1.176, Pr 50/37.96 1.317
• From Table 3.1

39
(No Transcript)
40
(No Transcript)
41
These results are compared with those of other
calculation in Table 6.3.
42
TWO-PHASE SYSTEMS
The Clapeyron eq. for pure-species vaporization
43
Temperature Dependence of the Vapor Pressure of
Liquids
44
Corresponding-States Correlations for Vapor
Pressure
The reduced normal boiling point
The reduced vapor pressure corresponding to 1 atm
45

• Ex. 6.6
• Determine the vapor pressure for liquid n-hexane
  at 0, 30,
• 60 and 90?C (a) With constants from App. B.2.
• (b) From the Lee/Kesler correlation for Prsat
• Solution
• (a)
• (b) Eq.(6.78)
• From Table B.1,
• From Eq.(6.81) ? ? 0.298
• The average difference from the Antoine values is
  about 1.5.

46
(No Transcript)
47
(No Transcript)
48
Two-Phase Liquid/Vapor System
49
THERMODYNAMIC DIAGRAMS
50
GENERALIZED PROPERTY CORRELATION FOR GASES
51
Table E.5 - E.12
52
(No Transcript)
53
Analytical correlation of the residual properties
at low pressure
54
(No Transcript)
55
HR and SR with ideal-gas heat capacities

• For a change from state 1 to 2

• The enthalpy change for the process, ?H H2 H1

• Alternative form

56
(No Transcript)
57
A three-step calculational path

• Step 1?1ig A hypothetical process that
  transforms a real gas into an ideal gas at T1 and
  P1.
• Step 1ig ?2ig Changes in the ideal-gas state
  from (T1,P1) to (T2,P2).
• Step 2ig ?2 Another hypothetical process that
  transform the ideal gas back into a real gas at
  T2 and P2.

58

• Ex. 6.9
• Estimate V, U, H and S for 1-butane vapor at
  200?C, 70 bar
• if H and S are set equal to zero for saturated
  liquid at 0?C.
• Assume Tc420.0 K, Pc40.43 bar, Tn266.9 K,
  ?0.191
• Cpig/R1.96731.630x10-3T-9.837x10-6
  T2 (T/K)
• Solution

59
(No Transcript)
60
(No Transcript)
61

• Step (a) Vaporization of saturated liquid
  1-butane at 0?C
• The vapor pressure curve contains both
• The latent heat of vaporization, where
  Trn266.9/4200.636

62
(No Transcript)
63

• Step (b) Transformation of saturated vapor into
  an ideal gas at (T1, P1).
• Tr 0.650 and Pr 1.2771/40.43 0.0316

64

• Step (c) Changes in the ideal gas state
• Tam 373.15 K, Tlm 364.04 K,
• A 1.967, B 31.630x10-3, C -9.837x10-6
• ?Hig 20,564 J mol-1
• ?Sig 22.18 J mol-1 K-1

65

• Step (d) Transformation from the ideal gas to
  real gas state at T2 and P2.
• Tr 1.127 Pr 1.731
• At the higher P Eqs.(6.85) and (6.86) with
  interpolated values from Table E.7, E.8, E.11 and
  E.12.

66
Extension to Gas Mixtures
These replace Tr and Pr for reading entries from
the table of App. E, and lead to values of Z by
Eq.(3.57), and HR/RTpc by Eq.(6.85), and SR/R by
Eq.(6.86).
67

• Ex. 6.10
• Estimate V, HR, and SR for an equimolar mixture
  of
• carbon dioxide(1) and propane(2) at 450 K and 140
  bar by
• the Lee/Kesler correlations.
• Solution
• From Table B.1,

68
(No Transcript)
69
(No Transcript)
70
SEE YOU NEXT CHAPER
