SWIFTStandards (UNIFI

1
SWIFTStandards(UNIFI ISO 20022)MDA-like
approach

• Frank VandammeTools, Products
  MethodologySWIFTStandards

OMG, Montreal, August 2004
OMG_SWIFTMDA_200408_v2.ppt
2
Agenda
Introduction
Development methodology
Development infrastructure
Implementation infrastructure
3
IntroductionWhat is SWIFT?

• Society for Worldwide Interbank Financial
  Telecommunication
• Community of 7,000 financial institutions in
  200 countries
• Payments (e.g. cross-border, domestic, corporate)
• Securities (e.g. equity, fixed income, funds)
• Treasury (e.g. foreign exchange, swaptions)
• Trade Services (e.g. letters of credit)
• Mission To enable interoperability between our
  members, their market infrastructures and their
  end-user communities
• Concrete activities
• Establish secure and reliable network application
• Standardize information flows (messages)

4
IntroductionWhat is UNIFI (ISO 20022)

• Standard developed under ISO/TC68 (financial arm
  of ISO)
• Modelling-based approach to develop standardised
  messages
• Used in the financial industry
• Described in 5 parts
• Part 1 overview of the main components
• modelling-based approach
• repository
• Part 2 registration bodies
• Part 3 modelling guidelines
• Part 4 XML design rules
• Part 5 Reverse engineering approach

5
IntroductionDrivers for the MDA approach

• Stability
• Business-driven approach
• Interoperability and convergence
• End-to-end based on common semantics
• Neutrality
• Acceptable common description for existing
  standards
• Flexibility
• Cater more easily for market practices and market
  evolution
• Predictability, consistency and speed
• Foster reuse and automation capabilities

Note not used by SWIFT for application generation
6
Standards development methodologyOverview

• Three layered approach
• Business-oriented
• Communication needs
• End-to-end view
• Formal notation (UML)
• Representation-neutral
• Implementation-neutral
• Foster reuse (dictionary)
• Involve industry experts

7
Standards development methodology Business
analysis

• Understanding the business
• Processes what activities are happening
• Roles who (functionally) is involved
• Data what information is used
• Results of business analysis
• Business activity diagrams (roles activities)
• Business component diagram (data)

8
Standards development methodology Requirements
analysis

• Identifying communication requirements per
  activity
• Who owns the information
• Who can provide the information
• What are the required information flows
• Identifying additional requirements and
  constraints
• Which types of physical actors can play which
  roles
• Market specific information requirements
• Results of requirements analysis
• Activity diagrams with required information flows
• Requirement description documents
• Business test scenarios (high level)

9
Standards development methodology Logical
analysis

• Identifying the transactions (collaborations)
• Sequence of messages
• Pre- and post-conditions, triggers,
• Identifying the messages
• Message granularity guidelines
• Message content (based on business elements)
• Message usage authorisation / restrictions
• Business cases for variants
• Results of logical analysis
• Sequence diagrams
• Message scope content
• Business test scenarios (refined)

10
Standards development methodology Logical design

• Identifying the message structure
• Identify message components
• Include required technical elements
• Define structural message organisation
• Formalise required business rules
• Results of logical design
• Message definitions (structure)
• Message components
• Business technical test cases (detailed)

11
Standards development methodology Technical
design implementation

• Preparing the physical implementation
• Add syntax-specific information (e.g. tags)
• Applying the syntax-specific design rules
• UML-to-XML generation
• Results of technical design implementation
• XML Schemas
• XPL rules
• Message samples

12
Standards development infrastructureStandards
repository
ISO 20022 Standards Repository
DATA DICTIONARY
BUSINESS PROCESS CATALOGUE
13
Standards development infrastructure Data
Dictionary
DATA DICTIONARY
Business Concepts
Data Types
Message Concepts
14
Standards development infrastructure Business
Process Catalogue
Business Process Catalogue
15
Standards development infrastructureUML profile
used diagrams

• Which diagrams are used (business layer)?
• Business Analysis
• Use Case diagram highest level decomposition in
  business processes
• Activity diagram (swim lanes) details of
  business processes activities roles
• Class diagram dictionary (business components,
  data types, actors)
• Requirements Analysis
• Activity diagram (swim lanes) required
  information flows
• Complemented by textual information e.g. links
  with business components

16
Standards development infrastructureUML profile
used diagrams

• Which diagrams are used (logical layer)?
• Logical Analysis
• Sequence diagram description of message flow
  (business transactions)
• Class diagram messages
• Logical design
• Class diagram dictionary (message components,
  data types)
• Class diagram (hierarchical) message structure
• No additional diagrams used in technical/physical
  layer

17
Standards development infrastructureUML profile
stereotypes identify concepts

• Some examples of stereotyped concepts
• Classes
• ltltBusinessComponentgtgt
• ltltMessageComponentgtgt
• ltltChoiceComponentgtgt
• ltltDataTypeRepresentationgtgt (ltltTextgtgt,
  ltltIdentifiergtgt, )
• ltltMessagegtgt
• ltltActorgtgt
• Associations
• ltltIsVersiongtgt
• ltltIsVariantgtgt
• ltltIsAlternativeForgtgt

18
Standards development infrastructureUML profile
tagged values add information

• Some examples of tagged values
• Synonyms (business terms)
• Business components
• Business elements
• Messages
• Administrative information
• Requestor
• Registration status
• Supplementary information for data types
• Code list owner
• Format (facets)
• Traces between business layer and message
  layer
• Business components to Message components

19
Standards development infrastructureUML profile
platform specific information

• Through stereotypes, tagged values or properties
• Some examples
• Operations
• Injectable in validation engine (via export
  control property)
• SWIFTNet error code (tagged value)
• Message elements
• XML tags (tagged value)
• Data types
• ltltXMLAttirbutegtgt (to be included in Schema)
• ltltPropertygtgt (for documentation only)

20
Standards development infrastructureTool
(Standards Workstation)

• UML modeling tool for modeling activities
• Add-ins to support and enforce methodology
  guidelines
• Traceability between business layer and
  logical layer
• Formal rules
• Conformance checking
• Completeness checking
• Link with data dictionary
• Import and export of sample data

21
Standards development infrastructureGUI for
formal rules
22
Standards development infrastructureGUI for
formal rules
23
Standards development infrastructureSupporting
process

• Continuous quality control
• Check non-automated rules guidelines
• Check conformance with approval process
• Freeze models for audit purposes
• Check consistency across phases
• Are all requirements covered
• Are all messages based on approved requirements
• Mandatory review activities
• By registration authority
• By business experts
• Change log entries for dictionary components

24
Standards implementation infrastructureAutomated
generation overview
Internal Repository
Documentation
XML Schemas
Publication
Financial Dictionary
Business Process Catalogue
Standards Workstation
Message samples
Injection
Repository instance (XML)
More to come

• XML Schemas
• Validation rules
• Samples

25
Standards implementation infrastructureAutomated
generation documentation

• HTML (available) and PDF (in development)
• User view and implementer view
• Combines model information with auxiliary
  documents ( text)
• Click-able sequence diagrams
• Message tree structure (expand / collapse)
• Dictionary information (data types, )
• Delta documentation (for versions and variants)
• Generated sample messages

26
Standards implementation infrastructureAutomated
generation XML Schema

• Consistency in XML
• Business information ? XML element/value
• Metadata information ? XML attribute (usually not
  in instance)
• ComplexTypes are globally unique / elements are
  local
• Traceability from XML to repository (based on XML
  element name and/or XML type name)
• Message identifier aaaa.bbb.ccc.dd (business
  area - message number variant version)
• Character encoding UTF-8
• Data types Text, Code, Identifier, Amount, Rate,
  Quantity, Indicator, DateTime
• XML facets Pattern, Length, MinLength,
  MaxLength, TotalDigits, FractionDigits,
  MinInclusive, MaxInclusive, MinExclusive,
  MaxEclusive

27
Standards implementation infrastructureAutomated
generation repository

• UML repository is converted to
• Relational database
• Basis for web query tool on www.swift.com and
  on www.iso20022.org
• Also used for impact analysis
• XML instance
• Prototype

28
frank.vandamme_at_swift.com
