Chapter 3 Describing Syntax and Semantics

1
Chapter 3 Describing Syntax and Semantics

• CS 350 Programming Language Design
• Indiana University Purdue University Fort Wayne

2
Chapter 3 Topics

• Introduction
• The General Problem of Describing Syntax
• Formal Methods of Describing Syntax
• Attribute Grammars
• Describing the Meanings of Programs Dynamic
  Semantics

3
Introduction

• Who must use language definitions?
• Language designers
• Implementors
• Programmers (the users of the language)
• Syntax
• The form or structure of the expressions,
  statements, and program units
• Defines what is grammatically correct
• Semantics
• The meaning of the expressions, statements, and
  program units
• Describing syntax is easier than describing
  semantics

4
Some definitions

• A sentence is a string of characters over some
  alphabet
• A language is a set of valid sentences
• The syntax rules of the language specify which
  strings of characters are valid sentences
• A lexeme is the lowest level syntactic unit of a
  language
• For example sum, , 1234
• A token is a category of lexemes
• For example identifier, plus_op, int_literal
• Each token may be described by separate syntax
  rules
• Thus we may think of sentences as strings of
  lexemes rather than as strings of characters

5
Describing syntax

• Syntax may be formally described using
  recognition or generation
• Recognition involves a recognition device R
• Given an input string, R either accepts the
  string as valid or rejects it
• R is only used in trial-and-error mode
• A recognizer is not effective in enumerating all
  sentences in a language
• Languages are usually infinite
• The syntax analyzer part of a compiler (parser)
  is a recognizer

6
Describing syntax

• Generation
• A language generator generates the sentences of a
  language
• A grammar is a language generator
• One can determine if a string is a sentence by
  comparing it with the structure given by a
  generator

7
Formal methods for describing syntax

• Noam Chomsky and John Backus independently
  developed similar formalisms in the 1950s
• In the mid-1950s, Chomsky identified four classes
  of grammars for studying linguistics
• Regular grammars
• Recognizer Deterministic Finite Automaton (DFA)
• Context-free grammars
• Recognizer Push-down automaton
• Context-sensitive grammars
• Recognizer Linear-bounded automaton
• Phrase structure grammars
• Recognizer Turing machine
• The first is useful for describing tokens
• Most programming languages can be described by
  the second

8
Formal methods for describing syntax

• Context-Free Grammar (CFG)
• A language generator
• Not powerful enough to describe syntax of natural
  languages
• Defines a class of programming languages called
  context-free languages
• Backus-Naur Form (BNF)
• Presented in 1959 by John Backus to describe
  Algol 58
• Notation was slightly improved by Peter Naur
• BNF is equivalent to Chomskys context-free
  grammars

9
Formal methods for describing syntax

• A meta-language is a language used to describe
  another language
• BNF is a meta-language for programming languages
• In BNF . . .
• A terminal symbol is used to represent a lexeme
  or a token
• A nonterminal symbol is used to represent a
  syntactic class
• A production rule defines one nonterminal symbol
  in terms of terminal symbols and other
  nonterminal symbols

10
Production rule example

• The following production rule defines the
  syntactic class of a while statement
• ltwhile_stmtgt ? while ( ltlogic_exprgt )
  ltstmtgt
• The syntactic class being defined is on the
  left-hand side of the arrow (LHS)
• The text on the right-hand side (RHS) gives the
  definition of the LHS
• The RHS above consists of 3 terminals (tokens)
  and 2 nonterminals (syntactic classes)
• Terminals while, (, and )
• Nonterminals ltlogic_exprgt and ltstmtgt

11
Formal methods for describing syntax

• Nonterminal symbols may have multiple distinct
  definitions, as in . . .
• ltif_stmtgt ? if ltlogic_exprgt then ltstmtgt
• ltif_stmtgt ? if ltlogic_exprgt then ltstmtgt else
  ltstmtgt
• Alternative form
• ltif_stmtgt ? if ltlogic_exprgt then ltstmtgt
• ? if ltlogic_exprgt then ltstmtgt else ltstmtgt
• More compactly, . . .
• ltif_stmtgt ? if ltlogic_exprgt then ltstmtgt if
  ltlogic_exprgt then ltstmtgt else ltstmtgt
• The vertical bar is read or

12
Formal methods for describing syntax

• The nonterminal symbol being defined on the LHS
  may appear on the RHS
• Such a production rule is recursive
• Example
• Lists can be described using recursion

ltidentifier_listgt ? identifier ?
identifier , ltidentifier_listgt
13
Formal methods for describing syntax

• A grammar G ( T, N, P, S ), where
• T is a finite set of terminal symbols
• N is a finite set of nonterminal symbols
• P is a finite nonempty set of production rules
• S is a start symbol representing a complete
  sentence
• The start symbol is typically named ltprogramgt
• Generation of a sentence is called a derivation
• Beginning with the start symbol, a derivation
  applies production rules repeatedly until a
  complete sentence is generated (all terminal
  symbols)

14
Formal methods for describing syntax

• An example grammar
• Any nonterminal appearing on the RHS of a
  production rule needs to be defined with a
  production rule (and thus appear on the LHS)
• In the grammar, integer is a token representing
  any integer lexeme

ltprogramgt ? ltstmtsgt ltstmtsgt ? ltstmtgt
ltstmtgt ltstmtsgt ltstmtgt ? ltvargt
ltexprgt ltvargt ? a b c d
ltexprgt ? lttermgt lttermgt lttermgt -
lttermgt lttermgt ? ltvargt integer
15
Formal methods for describing syntax

• An example derivation
• The symbol gt is read derives

ltprogramgt gt ltstmtsgt gt ltstmtgt
gt ltvargt ltexprgt gt a
ltexprgt gt a lttermgt
lttermgt gt a ltvargt
lttermgt gt a b lttermgt
gt a b integer
16
Derivation

• Every string of symbols in the derivation is
  called a sentential form
• Including ltprogramgt
• A sentence is a sentential form that has only
  terminal symbols
• A leftmost derivation is one in which the
  leftmost nonterminal in each sentential form is
  the one that is expanded next
• A derivation may be leftmost or rightmost or
  neither
• Derivation order has no effect on the language
  generated by a grammar

17
Parse Tree

• A parse tree is a hierarchical representation of
  a derivation
• Each internal node is labeled with a nonterminal
  symbol and each leaf is labeled with a terminal
  symbol
• A grammar is ambiguous if and only if it
  generates a sentential form that has two or more
  distinct parse trees

ltprogramgt
ltstmtsgt
ltstmtgt
ltvargt

ltexprgt
a
lttermgt

lttermgt
integer
ltvargt
b
18
Ambiguous grammar example
ltexprgt ? ltexprgt ltopgt ltexprgt int ltopgt ?

ltexprgt
ltexprgt
ltexprgt
ltopgt
ltexprgt
ltexprgt
ltopgt
ltexprgt
ltexprgt
ltexprgt
ltexprgt
ltexprgt
ltopgt
ltopgt
int
int
int
int
int
int




19
Ambiguity

• The compiler decides what code to generate based
  on the structure of the parse tree
• The parse tree indicates precedence the operators
• Does it mean ( int int ) int or int (
  int int )
• Ambiguity cannot be tolerated
• In the case of operator precedence, ambiguity can
  be avoided by having separate nonterminals for
  operators of different precedence

20
A non-ambiguous grammar

• ltexprgt ? ltexprgt lttermgt lttermgt
• lttermgt ? lttermgt int int

ltexprgt
Derivation ltexprgt gt ltexprgt lttermgt
gt lttermgt lttermgt gt int lttermgt
gt int lttermgt int gt int int
int
ltexprgt
lttermgt

lttermgt

lttermgt
int
int
int
21
Associativity of operators

• Operator associativity can also be indicated by a
  grammar
• ltexprgt ? ltexprgt ltexprgt int
  (ambiguous)
• ltexprgt ? ltexprgt int int (unambiguous)
• Example a parse tree using the unambiguous
  grammar
• The unambiguous grammar is
• left recursive and produces
• a parse tree in which the order
• of addition is left associative
• Addition is performed in a
• left-to-right manner

ltexprgt
ltexprgt
ltexprgt

int
ltexprgt
int

int
22
Dangling-else problem

• Consider the grammar
• ltstmtgt ? ltif_stmtgt
• ltif_stmtgt ? if ltlogic_exprgt then ltstmtgt
• ? if ltlogic_exprgt then ltstmtgt else ltstmtgt
• This grammar is ambiguous since
• if ltlogic_exprgt then if ltlogic_exprgt then
  ltstmtgt else ltstmtgt
• has distinct parse trees represented by
• and

if ltlogic_exprgt then if ltlogic_exprgt then
ltstmtgt else ltstmtgt
if ltlogic_exprgt then if ltlogic_exprgt then
ltstmtgt else ltstmtgt
23
Dangling-else problem

• Most languages match each else with the nearest
  preceding elseless if
• The ambiguity can be eliminated by developing a
  grammar that distinguishes elseless ifs from ifs
  with else clauses
• See text, page 131

24
Extended BNF (denoted EBNF)

• Three abbreviations are added for convenience
• Optional parts on the RHS of a production rule
  can be placed in brackets
• ltoptionalgt
• Braces on the RHS indicate that the enclosed part
  may be repeated 0 or more times
• ltrepeatedgt
• When a single element must be chosen from a
  group, the options are placed in parentheses and
  separated by vertical bars
• ( a b c )

25
Extended BNF examples

• Brackets
• ltproc_callgt ? ident ( ltexpr_listgt )
• Generates myProcedure and myProcedure( a, b, c
  )
• Braces
• ltidentifier_listgt ? ident , ident
• Generates Larry, Curly, Moe
• Choice among options
• lttermgt ? int ( - ) int
• Generates 5 7 and 5 - 7

26
BNF and EBNF example

• BNF
• ltexprgt ? ltexprgt lttermgt
• ? ltexprgt - lttermgt
• ? lttermgt
• lttermgt ? lttermgt ltfactorgt
• ? lttermgt / ltfactorgt
• ? ltfactorgt
• EBNF
• ltexprgt ? lttermgt ( - ) lttermgt
• lttermgt ? ltfactorgt ( / ) ltfactorgt

27
Extended BNF

• EBNF uses metasymbols , , , (, ), , and
• When metasymbols are also terminal symbols in the
  language being defined, instances that are
  terminal symbols must be quoted
• ltproc_callgt ? ident ( ltexpr_listgt )
• When regular BNF indicates that an operator is
  left associative, the corresponding EBNF does not
• BNF ltsumgt ? ltsumgt int
• EBNF ltsumgt ? int int
• This must be overcome during syntax analysis

28
Extended BNF

• Sometimes a superscript is used as an
  additional metasymbol to indicate one or more
  repetitions
• Example The production rules
• ltcompound_stmtgt ? begin ltstmtgt ltstmtgt end
• and
• ltcompound_stmtgt ? begin ltstmtgt end
• are equivalent

29
BNF homework assignment

• Announced in class

30
Attribute grammars

• Context-free grammars (CFGs) cannot describe all
  of the syntax of programming languages
• Typical example a variable must be declared
  before it can be referenced
• Something like this is called a
  context-sensitive constraint
• Text refers to it as static semantics

31
Attribute grammars

• Static semantics refers to the legal form of a
  program
• This is actually syntax rather than semantics
• The term semantics is used because the syntax
  check is done during syntax analysis rather than
  during parsing
• The term static is used because the analysis
  required to check the constraint can be done at
  compile time

32
Attribute grammars (AGs)

• An attribute grammar is an extension to a CFG
• Concept developed by Donald Knuth in 1968
• The additional AG features describe static
  semantics
• These features carry some semantic info along
  through parse trees
• Additional features
• Attributes
• Can be assigned values like variables
• Attribute computation functions
• Specify how attribute values are calculated
• Predicate functions
• Do the checking

33
Attribute grammars defined

• Definition An attribute grammar is a
  context-free grammar G (T, N, P, S) with the
  following additions
• For each grammar symbol X there is a set A(X) of
  attributes
• Some of these are synthesized
• These pass information up the parse tree
• The remaining attributes are inherited
• These pass information down the parse tree
• Each production rule has a set of attribute
  computation functions that define certain
  attributes for the nonterminals in the rule
• Each production rule has a (possibly empty) set
  of predicate functions to check for attribute
  consistency

34
Attribute grammars defined

• Let X0 ? X1 ... Xn be a rule
• Synthesized attributes are computed with
  functions of the form
• S(X0) f(A(X1), ... , A(Xn))
• S(X0) depends only X0s child nodes
• Inherited attributes for symbols Xj on the RHS
  are computed with function of the form
• I(Xj) f(A(X0), ... , A(Xn))
• I(Xj) depends on Xj s parent as well as its
  siblings

35
Attribute grammars defined

• Initially, there are synthesized intrinsic
  attributes on the leaves
• When all attributes of a parse tree have been
  computed, the parse tree is fully attributed
• Predicate functions for X0 ? X1 ... Xn are
  Boolean functions defined over the attribute set
• A(X0), ... , A(Xn)
• For a program to be correct, every predicate
  function for every production rule must be true
• Any false predicate function value indicates a
  violation of the static semantics of the language

36
Attribute grammars

• Example expressions of the form id id
• id's can be either int_type or real_type
• types of the two id's must be the same
• type of the expression must match it's expected
  type
• BNF
• ltassigngt ? ltvargt ltexprgt
• ltexprgt ? ltvargt ltvargt
• ltvargt ? id
• Attributes
• actual_type
• Synthesized for ltvargt and ltexprgt
• Intrinsic for id
• expected_type
• Inherited for ltexprgt from ltvargt in ltassigngt ?
  ltvargt ltexprgt

37
The attribute grammar

• Syntax rule ltexprgt ? ltvargt1 ltvargt2
• Attribute computation functon
• ltexprgt.actual_type ? ltvargt1.actual_type
• Predicates
• ltvargt1.actual_type ltvargt2.actual_type
• ltexprgt.expected_type ltexprgt.actual_type
• Syntax rule ltvargt ? id
• Attribute computation functon
• ltvargt.actual_type ? lookup (id.type)

38
Attribute grammars

• In what order are attribute values computed?
• If all attributes were inherited, the tree could
  be decorated in top-down order
• If all attributes were synthesized, the tree
  could be decorated in bottom-up order
• In many cases, both kinds of attributes are used,
  and it is some combination of top-down and
  bottom-up that must be used
• Complex problem in general
• May require construction of a dependency graph
  showing all attribute dependencies

39
Computation of attributes

• For the generated expression sum increment
• ltexprgt.expected_type ? inherited from parent
• ltvargt1.actual_type ? lookup (sum.type)
• ltvargt2.actual_type ? lookup (increment.type)
• ltvargt1.actual_type ? ltvargt2.actual_type
• ltexprgt.actual_type ? ltvargt1.actual_type
• ltexprgt.actual_type ? ltexprgt.expected_type

40
Semantics

• The meaning of expressions, statements, and
  program units is known as dynamic semantics
• We consider three methods of describing dynamic
  semantics
• Operational semantics
• Axiomatic semantics
• Denotational semantics

41
Operational semantics

• Operational semantics describes the meaning of a
  language statement by executing the statement on
  a machine, either real or simulated
• The meaning of the statement is defined by the
  observed change in the state of the machine
• i.e., the change in memory, registers, etc.

42
Operational semantics

• The best approach is to use an idealized,
  low-level virtual computer, implemented as a
  software simulation
• Then, build a translator to translate source code
  to the machine code of the idealized computer
• The state changes in the virtual machine brought
  about by executing the code that results from
  translating a given statement defines the meaning
  of the statement
• In effect, this describes the meaning of a
  high-level language statement in terms of the
  statements of a simpler, low-level language

43
Operational semantics example

• The C statement for ( expr1 expr2 expr3 )

• is equivalent to
• The human reader can informally be considered to
  be the virtual computer
• Evaluation of operational semantics
• Good if used informally (language manuals, etc.)
• Based on lower-level languages, not mathematics
  and logic

expr1 loop if expr2 0 goto out
exp3 goto
loop out
44
Operational semantics homework

• Assigned in class

45
Axiomatic semantics

• Based on formal logic (predicate calculus)
• Original purpose formal program verification
• Each statement in a program is both preceded by
  and followed by an assertion about program
  variables
• Assertions are also known as predicates
• Assertions will be written with braces to
  distinguish them from program statements

46
Axiomatic semantics

• A precondition is an assertion immediately before
  a statement that describes the relationships and
  constraints among variables that are true at that
  point in execution
• A postcondition is an assertion immediately
  following a statement that describes the
  situation at that point
• Our point of view is to compute the preconditions
  for a given statement from the corresponding
  postconditions
• It is also possible to set things up in the
  opposite direction
• A weakest precondition is the least restrictive
  precondition that will guarantee the validity of
  the associated postcondition

47
Axiomatic semantics

• Notation P S Q
• P is the preconditon
• S is a statement
• Q is the postcondition
• Example
• Find the weakest precondition P for P a b
  1 a gt 1
• One possible precondition b gt 10
• Weakest precondition b gt 0

48
Axiomatic semantics

• If the weakest precondition can be computed for
  each statement in a program, then a correctness
  proof can be constructed for the program
• Start by using the desired result as the
  postcondition of the last statement and work
  backward
• The resulting precondition of the first statement
  defines the conditions under which the program
  will compute the desired result
• If this precondition is the same as the program
  specification, the program is correct

49
Axiomatic semantics

• Weakest preconditions can be computed using an
  axiom or using an inference rule
• An axiom is a logical statement assumed to be
  true
• An inference rule is a method of inferring the
  truth of one assertion on the basis of the values
  of other assertions
• Each statement type in the language must have an
  axiom or an inference rule
• We consider assignments, sequences, selection,
  and loops

50
Assignment statements

• Let xE be a generic assignment statement
• An axiom giving the precondition is sufficient in
  this case
• Q x ? E x E Q
• Here the weakest precondition P is given by Q x ?
  E
• In other words, P is the same as Q with all
  instances of x replaced by expression E
• For example, consider a a b 3 a gt 10
• Replace all instance of a in a gt10 by ab-3
• This gives ab-3gt10, or bgt13-a
• So, Q x ? E is bgt13-a

51
Inference rules

• The general form of an inference rule is
• This states that if S1, S2, S3, , and Sn are
  true, then the truth of S can be inferred

S1, S2, S3, , Sn S
52
The Rule of Consequence

• Here, gt means implies
• This says that a postcondition can always be
  weakened and a precondition can always be
  strengthened
• Thus in the earlier example
• the postcondition agt10 can be weakened to
  agt5
• the precondition bgt13-a can be strengthened
  to
• bgt15-a

53
Sequence statements

• Since a precondition for a sequence depends on
  the statements in the sequence, the weakest
  precondition cannot be described by an axiom
• An inference rule is needed for sequences
• Consider the sequence S1S2 of two statements
  with preconditions and postconditions as follows

• P1 S1 P2
• P2 S2 P3
• The inference rule is

54
Sequence statements example

• Consider the following sequence and postcondition
• y 3x 1 x y 3 x lt 10
• The weakest precondition for x y 3 is
  y lt 7
• Since this is the postcondition for y 3x 1,
  the weakest precondition for the sequence is
  x lt 2

55
Selection statements

• Consider only if-then-else statements
• The inference rule is
• Example if ( x gt 0 ) then y y - 5 else y y
  3 y gt 0
• The precondition for S2 is x lt 0 and y gt -3

• The precondition for S1 is x gt 0 and y gt 5
• What is P ?
• Note that y gt 5 gt y gt -3
• By the rule of consequence, P is y gt 5

B and P S1 Q , (not B) and P S2 Q
P if B then S1 else S2 Q
56
Loops

• We consider a logical pretest (while) loop
• P while B do S end Q
• Computing the weakest precondition is more
  difficult than for a sequence because the number
  of iterations is not predetermined
• An assertion called a loop invariant must be
  found
• A loop invariant corresponds to finding the
  inductive hypothesis when proving a mathematical
  theorem using induction

57
Loops

• The inference rule is
• where I is the loop invariant
• The loop invariant must satisfy each of the
  following
• P gt I (the loop invariant must be
  true initially)
• I and B S I (I is not changed by
  the body of the loop)
• (I and (not B)) gt Q (if I is true and B is
  false, Q is implied)
• The loop terminates (this can be difficult to
  prove)

I and B S I I while B do S end I
and (not B)
58
Example

• Consider the loop P while y ltgt x do y y
  1 end y x
• An appropriate loop invariant is I y lt x

• Let P yltx be the precondition for the while
  statement
• Then
• P gt I is true
• y lt x and y ltgt x y y 1 y lt x
• implies y lt x y y 1 y lt x ,
• which implies I and B S I
• (I and (not B)) gt Q is true because
• y lt x and not (y ltgt x) implies y x ,
  which is just Q
• The loop terminates since P guarantees that
  initially y lt x

59
Loops

• The loop invariant I is a weakened version of the
  loop postcondition, and it is also a
  precondition.
• I must be weak enough to be satisfied prior to
  the beginning of the loop
• When combined with the loop exit condition, I
  must be strong enough to force the truth of the
  postcondition

60
Axiomatic semantics

• Evaluation of axiomatic semantics
• Developing axioms or inference rules for all of
  the statements in a language can be difficult
• Axiomatic semantics is . . .
• a good tool for correctness proofs
• an excellent framework for reasoning about
  programs
• Axiomatic semantics is not as useful for language
  users and compiler writers

61
Axiomatic semantics homework

• Assigned in class

62
Denotational semantics

• Denotational semantics
• Is the most rigorous, widely known method for
  describing the meaning of programs
• Based on recursive function theory
• Fundamental concept
• Define a mathematical object for each language
  entity
• The mathematical objects can be rigorously
  defined and manipulated
• Define functions that map instances of the
  language entities onto instances of the
  corresponding mathematical objects

63
Denotational semantics

• As is the case with operational semantics, the
  meaning of a language construct is defined in
  terms of the state changes
• In denotational semantics, state is defined in
  terms of the various mathematical objects
• State is defined only in terms of the values of
  the program's variables
• The value of a variable is an instance of an
  appropriate mathematical object

64
Denotational semantics

• The state s of a program consists of the values
  of all its current variables
• s lti1, v1gt, lti2, v2gt, , ltin, vngt
• Here, ik is a variable and vk is the associated
  value
• Each vk is a mathematical object
• Most semantics mapping functions for program
  constructs map states to states
• The state change defines the meaning of the
  program construct
• Expression statements (among others) map states
  to values

65
Denotational semantics

• Let VARMAP be a function that, when given a
  variable name and a state, returns the current
  value of the variable
• VARMAP(ik, s) vk
• Any variable can have the special value undef
• i.e., currently undefined

66
Denotational semantics example

• The syntax of decimal numbers is described by the
  EBNF grammar
• ltdec_numgt ? 0 1 2 3 4 5 6 7 8
  9
• ? ltdec_numgt (0 1 2 3 4 5 6 7 8
  9)
• The denotational semantics of decimal numbers
  involves a semantic function that maps decimal
  numbers as strings of symbols into numeric values
  (mathematical objects)

67
Semantic function for decimal numbers

• Mdec('0') 0, Mdec ('1') 1, , Mdec ('9') 9
• Mdec (ltdec_numgt '0') 10 Mdec (ltdec_numgt)
• Mdec (ltdec_numgt '1) 10 Mdec (ltdec_numgt) 1
• Mdec (ltdec_numgt '9') 10 Mdec (ltdec_numgt) 9

68
Denotational semantics of expressions

• Assume expressions consist of decimal integer
  literals, variables, or binary expressions having
  one arithmetic operator and two operands, each of
  which can only be a variable or integer literal
• The value of an expression is an integer
• The value of an expression is error if it
  involves an undef value
• Thus, expressions map onto Z ? error

ltexprgt ? ltdec_numgt ltvargt ltbinary_exprgt ltbinary
_exprgt ? ltleft_exprgt ltoperatorgt
ltright_exprgt ltleft_exprgt ? ltdec_numgt
ltvargt ltright_exprgt ? ltdec_numgt ltvargt ltoperatorgt
?
69
Semantic function for expressions
Me(ltexprgt, s) ? case ltexprgt of
ltdec_numgt gt Mdec(ltdec_numgt) ltvargt gt
if VARMAP(ltvargt, s) undef
then error else VARMAP(ltvargt, s)
ltbinary_exprgt gt if
(Me(ltbinary_exprgt.ltleft_exprgt, s) undef
or Me(ltbinary_exprgt.ltright_exprgt, s)
undef) then error else if
(ltbinary_exprgt.ltoperatorgt then
Me(ltbinary_exprgt.ltleft_exprgt, s)
Me(ltbinary_exprgt.ltright_exprgt, s) else
Me(ltbinary_exprgt.ltleft_exprgt, s)
Me(ltbinary_exprgt.ltright_exprgt, s) end case

• An expression is mapped to a value

70
Denotational semantics of assignments

• Assignment statements map states to states

Ma(x E, s) ? if Me(E, s) error then
error else s
lti1,v1gt,lti2,v2gt,...,ltin,vngt, where,
for j 1, 2, ..., n, vj
VARMAP(ij, s) when ij ltgt x and vj
Me( E, s) when ij x
71
Denotational semantics of logical pretest loops

• Logical pretest
• loops map states
• to states
• Assume Msl maps
• a statement list to
• a state
• Assume Mb maps
• a Boolean expression
• to a Boolean value
• or to error

Ml( while B do L end, s ) ? if Mb(B, s)
undef then error else if Mb(B, s)
false then s else if Msl(L, s)
error then error else
Ml(while B do L end, Msl(L, s) )
72
Denotational semantics of loops

• The meaning of the loop is the value of the
  program variables after the statements in the
  loop have been executed the prescribed number of
  times (assuming there have been no errors)
• In essence, the loop has been converted from
  iteration to recursion, where the recursive
  control is mathematically defined by other
  recursive state mapping functions
• Recursion, when compared to iteration, is easier
  to describe with mathematical rigor

73
Denotational semantics

• Evaluation of denotational semantics
• Can be used to determine meaning of complete
  programs in a given language
• Provides a rigorous way to think about programs
• Can be an aid to language design
