Title: 68402: Structural Design of Buildings II


1
68402 Structural Design of Buildings II
Design of Connections
  • Monther Dwaikat
  • Assistant Professor
  • Department of Building Engineering
  • An-Najah National University

2
Bolted Connections
  • Types of Connections
  • Simple Bolted Shear Connections
  • Bearing and Slip Critical Connections
  • Eccentric Bolted Connections
  • Moment Resisting Bolted Connections
  • Simple Welded Connections
  • Eccentric Welded Connections
  • Moment Resisting Welded Connections

3
Types of Connections
Simple Connections
Eccentric Connections
Bolted Connections
Welded Connections
Common Bolts
High Strength Bolts
Filet Weld
Slip Critical
Groove Weld
Bearing Type
4
Types of Connections
Simple Connections
Eccentric Connections
Bolted Connections
Welded Connections
Elastic Analysis
Ultimate Analysis
Moment Resisting
Elastic Analysis
Ultimate Analysis
Moment Resisting
5
Simple Bolted Connections
  • There are different types of bolted connections.
    They can be categorized based on the type of
    loading.
  • Tension member connection and splice. It subjects
    the bolts to forces that tend to shear the shank.
  • Beam end simple connection. It subjects the bolts
    to forces that tend to shear the shank.
  • Hanger connection. The hanger connection puts the
    bolts in tension

6
Simple Bolted Connections
P
P
Tension member Connection/ splice
P
P
Beam end Simple shear connection
7
Simple Bolted Connections
P
P
P
Hanger connection (Tension)
Moment resisting connection
8
Simple Bolted Connections
  • The bolts are subjected to shear or tension
    loading.
  • In most bolted connection, the bolts are
    subjected to shear.
  • Bolts can fail in shear or in tension.
  • You can calculate the shear strength or the
    tensile strength of a bolt
  • Simple connection If the line of action of the
    force acting on the connection passes through the
    center of gravity of the connection, then each
    bolt can be assumed to resist an equal share of
    the load.
  • The strength of the simple connection will be
    equal to the sum of the strengths of the
    individual bolts in the connection.

9
Bolt Types Materials
  • A307 - Unfinished (Ordinary or Common) bolts
    low carbon steel A36, Fu 413 MPa,
  • for light structures under static load
  • A325 - High strength bolts, heat-treated medium
    carbon steel, Fu 827 MPa,
  • for structural joints
  • A490 - High strength bolts, Quenched and
    Tempered Alloy steel, Fu 1033 MPa
  • for structural joints
  • A449 - High strength bolts with diameter gt 1 ½,
    anchor bolts, lifting hooks, tie-downs

10
Common Bolts
  • ASTM A307 bolts
  • Common bolts are no longer common for current
    structural design but are still available

11
High Strength Bolts
  • High strength bolts (HSB) are available as ASTM A
    325 and ASTM A490

Courtesy of Kao Wang Screw Co., Ltd.
  • Advantages of HSB over A307 bolts
  • Fewer bolts will be used compared to 307 è
    cheaper connection!
  • Smaller workman force required compared to 307
  • Higher fatigue strength
  • Ease of bolt removal è changing connection

12
High Strength Bolts
  • Snug tight
  • All plies of the connection are in firm contact
    to each other No pretension is used.
  • Easer to install and to inspect
  • Pre-tensioned
  • Bolts are first brought to snug tight status
  • Bolts are then tensioned to 70 of their tensile
    stresses

Courtesy of www.halfpricesurplus.com
  • Bolts are tensioned using direct tension
    indicator, calibrated wrench or other methods
    (see AISC)
  • Slip critical
  • Bolts are pre-tensioned but surfaces shall be
    treated to develop specific friction.
  • The main difference is in design, not
    installation. Load must be limited not to exceed
    friction capacity of the connection (Strength Vs.
    Serviceability!)
  • Necessary when no slip is needed to prevent
    failure due to fatigue in bridges.

13
HSB Bearing Type Connections
  • The shear strength of bolts shall be determined
    as follows

AISC Table J3.2
The table bellow shows the values of fv (MPa) for
different types of bolts
  • If the level of threads is not known, it is
    conservative to assume that the threads are type
    N.

14
Bolted Shear Connections
  • We want to design the bolted shear connections so
    that the factored design strength (?Rn) is
    greater than or equal to the factored load. ? Rn
    ? Pu
  • So, we need to examine the various possible
    failure modes and calculate the corresponding
    design strengths.
  • Possible failure modes are
  • Shear failure of the bolts
  • Failure of member being connected due to fracture
    or yielding or .
  • Edge tearing or fracture of the connected plate
  • Tearing or fracture of the connected plate
    between two bolt holes
  • Excessive bearing deformation at the bolt hole

15
Failure Modes of Bolted Connections
  • Bolt Shearing
  • Tension Fracture
  • Plate Bearing
  • Block Shear

16
Actions on Bolt
  • Shear, bearing, bending

Bearing and single plane Shear
Lap Joint
Bending
Bearing and double plane Shear
Butt Joint
17
Bolted Shear Connections
  • Possible failure modes
  • Failure of bolts single or double shear
  • Failure of connected elements
  • Shear, tension or bending failure of the
    connected elements (e.g. block shear)
  • Bearing failure at bolt location

18
Bolted Shear Connections
  • Shear failure of bolts
  • Average shearing stress in the bolt fv P/A
    P/(?db2/4)
  • P is the load acting on an individual bolt
  • A is the area of the bolt and db is its diameter
  • Strength of the bolt P fv x (?db2/4) where fv
    shear yield stress 0.6Fy
  • Bolts can be in single shear or double shear as
    shown above.
  • When the bolt is in double shear, two
    cross-sections are effective in resisting the
    load. The bolt in double shear will have the
    twice the shear strength of a bolt in single
    shear.

19
Bolted Shear Connections
20
Bolted Shear Connections
  • Failure of connected member
  • We have covered this in detail in this course on
    tension members
  • Member can fail due to tension fracture or
    yielding.
  • Bearing failure of connected/connecting part due
    to bearing from bolt holes
  • Hole is slightly larger than the fastener and the
    fastener is loosely placed in hole
  • Contact between the fastener and the connected
    part over approximately half the circumference of
    the fastener
  • As such the stress will be highest at the radial
    contact point (A). However, the average stress
    can be calculated as the applied force divided by
    the projected area of contact

21
Bolted Shear Connections
  • Average bearing stress fp P/(db t), where P is
    the force applied to the fastener.
  • The bearing stress state can be complicated by
    the presence of nearby bolt or edge. The bolt
    spacing and edge distance will have an effect on
    the bearing strength.
  • Bearing stress effects are independent of the
    bolt type because the bearing stress acts on the
    connected plate not the bolt.
  • A possible failure mode resulting from excessive
    bearing close to the edge of the connected
    element is shear tear-out as shown below. This
    type of shear tear-out can also occur between two
    holes in the direction of the bearing load.
  • Rn 2 x 0.6 Fu Lc t 1.2 Fu Lc t

22
Bolted Shear Connections
  • The bearing strength is independent of the bolt
    material as it is failure in the connected metal
  • The other possible common failure is shear end
    failure known as shear tear-out at the
    connection end

Shear limitation
Bearing limitation
23
Bolted Shear Connections
24
Bolted Shear Connections
25
Spacing and Edge-distance requirements
  • The AISC code gives guidance for edge distance
    and spacing to avoid tear out shear

AISC Table J3.4
NOTE The actual hole diameter is 1.6 mm bigger
than the bolt, we use another 1.6 mm for
tolerance when we calculate net area. Here use
1.6 mm only not 3.2
  • Bolt spacing is a function of the bolt diameter
  • Common we assume
  • The AISC minimum spacing is

26
Bolt Spacings Edge Distances
  • Bolt Spacings
  • - Painted members or members not subject to
    corrosion
  • 2 2/3d Bolt
    Spacings 24t or 305 mm
  • (LRFD J3.3) (LRFD
    J3.5)
  • - Unpainted members subject to corrosion
  • 3d Bolt
    Spacings 14t or 178 mm
  • Edge Distance
  • Values in Table J3.4M Edge Distance 12t or
    152 mm
  • (LRFD J3.4) (LRFD J3.5)
  • d - bolt diameter
  • t - thickness of thinner plate

27
Bolted Shear Connections
  • To prevent excessive deformation of the hole, an
    upper limit is placed on the bearing load. This
    upper limit is proportional to the fracture
    stress times the projected bearing area
  • Rn C x Fu x bearing area C Fu db t
  • If deformation is not a concern then C 3, If
    deformation is a concern then C 2.4
  • C 2.4 corresponds to a deformation of 6.3 mm.
  • Finally, the equation for the bearing strength of
    a single bolts is ?Rn
  • where, ? 0.75 and Rn 1.2 Lc t Fu lt 2.4 db t
    Fu
  • Lc is the clear distance in the load direction,
    from the edge of the bolt hole to the edge of the
    adjacent hole or to the edge of the material

28
Bolted Shear Connections
  • This relationship can be simplified as follows
  • The upper limit will become effective when 1.2
    Lc t Fu gt 2.4 db t Fu
  • i.e., the upper limit will become effective when
    Lc gt 2 db
  • If Lc lt 2 db, Rn 1.2 Lc t Fu
  • If Lc gt 2 db, Rn 2.4 db t Fu
  • Fu - specified tensile strength of the connected
    material
  • Lc - clear distance, in the direction of the
    force, between the edge of the hole and the edge
    of the adjacent hole or edge of the material.
  • t - thickness of connected material

29
Important Notes
Lc Clear distance
30
Design Provisions for Bolted Shear Connections
  • In a simple connection, all bolts share the load
    equally.

31
Design Provisions for Bolted Shear Connections
  • In a bolted shear connection, the bolts are
    subjected to shear and the connecting/connected
    plates are subjected to bearing stresses.

32
Design Provisions for Bolted Shear Connections
  • The shear strength of all bolts shear strength
    of one bolt x number of bolts
  • The bearing strength of the connecting /
    connected plates can be calculated using
    equations given by AISC specifications.
  • The tension strength of the connecting /
    connected plates can be calculated as discussed
    in tension members.

33
AISC Design Provisions
  • Chapter J of the AISC Specifications focuses on
    connections.
  • Section J3 focuses on bolts and threaded parts
  • AISC Specification J3.3 indicates that the
    minimum distance (s) between the centers of bolt
    holes is 2.67. A distance of 3db is preferred.
  • AISC Specification J3.4 indicates that the
    minimum edge distance (Le) from the center of the
    bolt to the edge of the connected part is given
    in Table J3.4. Table J3.4 specifies minimum edge
    distances for sheared edges, edges of rolled
    shapes, and gas cut edges.

34
AISC Design Provisions
  • AISC Specification indicates that the maximum
    edge distance for bolt holes is 12 times the
    thickness of the connected part (but not more
    than 152 mm). The maximum spacing for bolt holes
    is 24 times the thickness of the thinner part
    (but not more than 305 mm).
  • Specification J3.6 indicates that the design
    tension or shear strength of bolts is ?FnAb
  • ? 0.75
  • Table J3.2, gives the values of Fn
  • Ab is the unthreaded area of bolt.
  • In Table J3.2, there are different types of bolts
    A325 and A490.

35
AISC Design Provisions
  • The shear strength of the bolts depends on
    whether threads are included or excluded from the
    shear planes. If threads are included in the
    shear planes then the strength is lower.
  • We will always assume that threads are included
    in the shear plane, therefore less strength to be
    conservative.
  • We will look at specifications J3.7 J3.9 later.
  • AISC Specification J3.10 indicates the bearing
    strength of plates at bolt holes.
  • The design bearing strength at bolt holes is ?Rn
  • Rn 1.2 Lc t Fu 2.4 db t Fu -
    deformation at the bolt holes is a design
    consideration

36
Common bolt terminologies
  • A325-SC slip-critical A325 bolts
  • A325-N snug-tight or bearing A325 bolts with
    thread included in the shear planes.
  • A325-X - snug-tight or bearing A325 bolts with
    thread excluded in the shear planes.
  • Gage center-to-center distance of bolts in
    direction perpendicular to
  • members axis
  • Pitch ...parallel to members axis
  • Edge Distance Distance from
  • center of bolt to adjacent
  • edge of a member

p
37
Ex. 6.1 - Design Strength
  • Calculate and check the design strength of the
    simple connection shown below. Is the connection
    adequate for carrying the factored load of 300
    kN.

10 mm
120x15 mm
30 mm
60 mm
63 k
300 kN
30 mm
20 mm A325-N bolts
30 mm
60 mm
30 mm
38
Ex. 6.1 - Design Strength
  • Step I. Shear strength of bolts
  • The design shear strength of one bolt in shear
    ?Fn Ab 0.75 x 330 x p x 202/4000 77.8 kN
  • ? Fn Ab 77.8 kN per bolt (See Table J3.2)
  • Shear strength of connection 4 x 77.8 311.2
    kN

39
Ex. 6.1 - Design Strength
  • Step II. Minimum edge distance and spacing
    requirements
  • See Table J3.4M, minimum edge distance 26 mm
    for rolled edges of plates
  • The given edge distances (30 mm) gt 26 mm.
    Therefore, minimum edge distance requirements are
    satisfied.
  • Minimum spacing 2.67 db 2.67 x 20 53.4 mm.
  • (AISC Specifications J3.3)
  • Preferred spacing 3.0 db 3.0 x 20 60 mm.
  • The given spacing (60 mm) 60 mm. Therefore,
    spacing requirements are satisfied.

40
Ex. 6.1 - Design Strength
  • Step III. Bearing strength at bolt holes.
  • Bearing strength at bolt holes in connected part
    (120x15 mm plate)
  • At edges, Lc 30 hole diameter/2 30 (20
    1.6)/2 19.2
  • ?Rn 0.75 x (1.2 Lc t Fu) 0.75 x (1.2 x19.2
    x15x400)/1000 103.7 kN
  • But, ?Rn 0.75 (2.4 db t Fu) 0.75 x (2.4 x
    20x15x400)/1000 216 kN
  • Therefore, ?Rn 103.7 kN at edge holes.
  • At other holes, s 60 mm, Lc 60 (20 1.6)
    38.4 mm.
  • ?Rn 0.75 x (1.2 Lc t Fu) 0.75x(1.2 x 38.4 x15
    x400)/1000 207.4 kN
  • But, ?Rn 0.75 (2.4 db t Fu) 216 kN. Therefore
    ?Rn 207.4 kN

41
Ex. 6.1 - Design Strength
  • Therefore, ?Rn 216 kN at other holes
  • Therefore, bearing strength at holes 2 x 103.7
    2 x 207.4 622.2 kN
  • Bearing strength at bolt holes in gusset plate
    (10 mm plate)
  • At edges, Lc 30 hole diameter/2 30 (20
    1.6)/2 19.2 mm.
  • ?Rn 0.75 x (1.2 Lc t Fu) 0.75 x (1.2 x 19.2 x
    10 x 400)/1000 69.1 kN
  • But, ?Rn 0.75 (2.4 db t Fu) 0.75 x (2.4 x 20
    x 10 x 400)/1000 144 kN.
  • Therefore, ?Rn 69.1 kN at edge holes.

42
Ex. 6.1 - Design Strength
  • At other holes, s 60 mm, Lc 60 (20 1.6)
    38.4 mm.
  • ?Rn 0.75 x (1.2 Lc t Fu) 0.75 x (1.2 x 38.4 x
    10x 400)/1000 138.2 kN
  • But, ?Rn 0.75 (2.4 db t Fu) 144 kN
  • Therefore, ?Rn 138.2 kN at other holes
  • Therefore, bearing strength at holes 2 x 69.1
    2 x 138.2 414.6 kN
  • Bearing strength of the connection is the smaller
    of the bearing strengths 414.6 kN

43
Ex. 6.1 - Design Strength
Connection Strength
Shear strength 311.2
Bearing strength (plate) 622.2 kN
Bearing strength (gusset) 414.6 kN
Connection strength (fRn) gt applied factored
loads (gQ). 311.2 gt 300 Therefore ok.
  • Only connections is designed here
  • Need to design tension member and gusset plate

44
Eccentrically-Loaded Bolted Connections
CG
CG
  • Eccentricity in the plane of the faying surface
  • Direct Shear Additional Shear due to moment Pe

Eccentricity normal to the plane of the faying
surface Direct Shear Tension and Compression
(above and below neutral axis)
45
Forces on Eccentrically-Loaded Bolts
  • Eccentricity in the plane of the faying surface
  • LRFD Spec. presents values for computing design
    strengths of individual bolt only. To compute
    forces on group of bolts that are eccentrically
    loaded, there are two common methods
  • Elastic Method Conservative. Connected parts
    assumed rigid. Slip resistance between
    connected parts neglected.
  • Ultimate Strength Method (or Instantaneous Center
    of Gravity Method) Most realistic but tedious to
    apply

46
Forces on Eccentrically-Loaded Bolts with
Eccentricity on the Faying Surface
  • Elastic Method
  • Assume plates are perfectly rigid and bolts
    perfectly elastic ? rotational displacement at
    each bolt is proportional to its distance from
    the CG ? stress is greatest at bolt farthest from
    CG

47
Forces on Eccentrically-Loaded Bolts with
Eccentricity on the Faying Surface
  • MCG Pe r1d1 r2d2 r3d3
  • Since the force on each bolt is proportional to
    its distance from the CG
  • Substitute into eqn. for MCG

48
Forces on Eccentrically-Loaded Bolts with
Eccentricity on the Faying Surface
  • Total Forces in Bolt i
  • Horizontal Component
  • Vertical Component

49
Ex. 6.3 Eccentric Connections Elastic Method
  • Determine the force in the most stressed bolt of
    the group using elastic method

P140 kN
e
125 mm

Eccentricity wrt CG e 125 50 175
mm Direct Shear in each bolt P/n 140/8
17.5 kN Note that the upper right-hand and the
lower right-hand bolts are the most stressed
(farthest from CG and consider direction of
forces)
100 mm
100 mm
100 mm
100 mm
50
Ex. 6.3 Eccentric Connections Elastic Method
  • Additional Shear in the upper and lower
    right-hand bolts due to moment M Pe 140x175
    24500 kN.mm
  • The forces acting on the upper right-hand bolt
    are as follows
  • The resultant force on this bolt is

30.6 kN
10.2 kN
17.5 kN
51
Forces on Eccentrically-Loaded Bolts
  • Eccentricity Normal to Plane of Faying Surface
  • (a) Neutral Axis at CG

Shear force per bolt due to concentric force
Pu ruv Pu/n n of bolts Bolts above NA
are in tension. Bolts below NA are in
compression. Tension force per bolt rut
(Pue)/ndm n of bolts above NA dm moment arm
between resultant tensile and compressive forces
52
Forces on Eccentrically-Loaded Bolts
  • Eccentricity Normal to Plane of Faying Surface
  • (b) Neutral Axis Not at CG

Bolts above NA resist tension Bearing stress
below NA resist compression
  • Shear per bolt due to concentric force Pu
  • ruv Pu/n
  • Select first trial location of NA as 1/6 of the
    total bracket depth.
  • Effective width of the compression block
  • beff 8tf bf (for W-shapes, S-shapes, welded
    plates and angles)

2rut
NA
53
Forces on Eccentrically-Loaded Bolts
  • Check location of NA by equating the moment of
    the bolt area above the NA with the moment of the
    compression block area below the NA
  • ?Ab x y beff x d x d/2
  • ?Ab sum of areas of bolts above the NA
  • y distance from X-X to the CG of bolts above
    NA
  • d depth of compression block (adjust until
    satisfy)
  • Once the NA has been located, the tensile force
    per bolt
  • rut (PuecAb)/Ix
  • c distance from NA to most remote bolt in
    group
  • Ix combined moment of inertia of bolt group
    and compression block
  • about NA

54
Bolts Subjected to Shear and Tension
  • Nominal Tension Stress Ft of a bolt subjected to
    combined factored shear stress (fv Vu/NbAb) and
    factored tension stress (ft Tu/NbAb) can be
    computed as functions of fv as
  • ? 0.75
  • Fnt nominal tensile strength modified to
    include the effect of shear
  • Fnt nominal tensile strength from Table J3.2 in
    (AISC Spec.)
  • Fnv nominal shear strength from Table J3.2 in
    (AISC Spec.)
  • fv the required shear stress

Fnt (MPa)
Bolt Type
620
A325
780
A490
55
Ex. 6.5 Combined Tension shear
  • Is the bearing-type connection below
    satisfactory for the combined tension and shear
    loads shown?
  • Shear stress per bolt fv Vu/NbAb537000/(8x38
    0) 176.6 MPa
  • ?Fnv(0.75)(413)310 MPagt fv 176.6 MPa (OK)

  • Tension stress per bolt
  • ft
    Tu/NbAb1073000/(8x380) 353 MPa

  • Nominal Tension Strength Ft (Table J3.5)
  • ?Ft 0.75(1.3x620
    (620/310)x176.6) 620
  • 496 MPa 620
  • 496 MPa gt ft 353 MPa (OK)

1
2
56
Simple Welded Connections
  • Structural welding is a process by which the
    parts that are to be connected are heated and
    fused, with supplementary molten metal at the
    joint.
  • A relatively small depth of material will become
    molten, and upon cooling, the structural steel
    and weld metal will act as one continuous part
    where they are joined.

P
P
P
P
57
Introductory Concepts
Welding Process Fillet Weld
58
Introductory Concepts
  • The additional metal is deposited from a special
    electrode, which is part of the electric circuit
    that includes the connected part.
  • In the shielded metal arc welding (SMAW) process,
    current arcs across a gap between the electrode
    and the base metal, heating the connected parts
    and depositing part of the electrode into the
    molten base metal.
  • A special coating on the electrode vaporizes and
    forms a protective gaseous shield, preventing the
    molten weld metal from oxidizing before it
    solidifies.
  • The electrode is moved across the joint, and a
    weld bead is deposited, its size depending on the
    rate of travel of the electrode.

59
Introductory Concepts
  • As the weld cools, impurities rise to the
    surface, forming a coating called slag that must
    be removed before the member is painted or
    another pass is made with the electrode.
  • Shielded metal arc welding is usually done
    manually and is the process universally used for
    field welds.
  • For shop welding, an automatic or semi automatic
    process is usually used. Foremost among these is
    the submerged arc welding (SAW),
  • In this process, the end of the electrode and the
    arc are submerged in a granular flux that melts
    and forms a gaseous shield. There is more
    penetration into the base metal than with
    shielded metal arc welding, and higher strength
    results.

60
Introductory Concepts
  • Other commonly used processes for shop welding
    are gas shielded metal arc, flux cored arc, and
    electro-slag welding.
  • Quality control of welded connections is
    particularly difficult, because defects below the
    surface, or even minor flaws at the surface, will
    escape visual detection. Welders must be properly
    certified, and for critical work, special
    inspection techniques such as radiography or
    ultrasonic testing must be used.

61
Introductory Concepts
  • The two most common types of welds are the fillet
    weld and the groove weld. Fillet weld examples
    lap joint fillet welds placed in the corner
    formed by two plates
  • Tee joint fillet welds placed at the
    intersection of two plates.
  • Groove welds deposited in a gap or groove
    between two parts to be connected
  • e.g., butt, tee, and corner joints with beveled
    (prepared) edges
  • Partial penetration groove welds can be made from
    one or both sides with or without edge
    preparation.

62
Welded Connections
  • Classification of welds
  • According to type of weld
  • According to weld position
  • According to type of joint
  • Butt, lap, tee, edge or corner
  • According to the weld process
  • SMAW, SAW

Groove weld
Fillet weld
Flat, Horizontal, vertical or overhead weld
63
Introductory Concepts
64
Weld Limit States
  • The only limit state of the weld metal in a
    connection is that of fracture
  • Yielding is not a factor since any deformation
    that might take place will occur over such a
    short distance that it will not influence the
    performance of the structure

65
Design of Welded Connections
  • Fillet welds are most common and used in all
    structures.
  • Weld sizes are specified in 1 mm increments
  • A fillet weld can be loaded in any direction in
    shear, compression, or tension. However, it
    always fails in shear.
  • The shear failure of the fillet weld occurs along
    a plane through the throat of the weld, as shown
    in the Figure below.

66
Design of Welded Connections
hypotenuse
root
L length of the weld a size of the weld
67
Design of Welded Connections
  • Shear stress in fillet weld of length L subjected
    to load P
  • fv If the ultimate shear
    strength of the weld fw
  • Rn
  • ?Rn i.e., ? factor 0.75
  • fw shear strength of the weld metal is a
    function of the electrode used in the SMAW
    process.
  • The tensile strength of the weld electrode can be
    413, 482, 551, 620, 688, 758, or 827 MPa.
  • The corresponding electrodes are specified using
    the nomenclature E60XX, E70XX, E80XX, and so on.
    This is the standard terminology for weld
    electrodes.

68
Design of Welded Connections
  • The two digits "XX" denote the type of coating.
  • The strength of the electrode should match the
    strength of the base metal.
  • If yield stress (?y) of the base metal is ? 413 -
    448 MPa, use E70XX electrode.
  • If yield stress (?y) of the base metal is ? 413 -
    448 MPa, use E80XX electrode.
  • E70XX is the most popular electrode used for
    fillet welds made by the SMAW method.

E electrode 70 tensile strength of electrode
(ksi) 482 MPa XX type of coating
69
Fillet Weld
  • Stronger in tension and compression than in shear
  • Fillet weld designations
  • 12 mm SMAW E70XX fillet weld with equal leg
    size of 12 mm, formed using Shielded Metal Arc
    Welding Process, with filler metal electrodes
    having a minimum weld tensile strength of 70 ksi.
  • 9 mm-by-12 mm SAW E110XX fillet weld with
    unequal leg sizes, formed by using Submerged Arc
    Metal process, with filler metal electrodes
    having a minimum weld tensile strength of 758 MPa.

Unequal leg fillet weld
70
Fillet Weld Strength
  • Stress in fillet weld factored load/eff. throat
    area
  • Limit state of Fillet Weld is shear fracture
    through the throat, regardless of how it is
    loaded
  • Design Strength
  • For equal leg fillet weld

71
Design of Welded Connections
  • Table J2.5 in the AISC Specifications gives the
    weld design strength
  • fw 0.60 FEXX
  • For E70XX, ?fw 0.75 x 0.60 x 482 217 MPa
  • Additionally, the shear strength of the base
    metal must also be considered
  • ?Rn 0.9 x 0.6 Fy x area of base metal subjected
    to shear
  • where, Fy is the yield strength of the base metal.

72
Design of Welded Connections
  • For example
  • Strength of weld in shear 0.75 x 0.707 x a x
    Lw x fw
  • In weld design problems it is advantageous to
    work with strength per unit length of the weld or
    base metal.

73
Limitations on Weld Dimensions
  • Minimum size (amin)
  • Function of the thickness of the thinnest
    connected plate
  • Given in Table J2.4 in the AISC specifications
  • Maximum size (amax)
  • function of the thickness of the thinnest
    connected plate
  • for plates with thickness ? 6 mm, amax 6 mm.
  • for plates with thickness ? 6 mm, amax t 2
    mm.
  • Minimum length (Lw)
  • Length (Lw) ? 4 a otherwise, aeff Lw / 4 a
    weld size
  • Read J2.2 b page 16.1-95
  • Intermittent fillet welds Lw-min 4 a and 38
    mm.

74
Limitations on Weld Size AISC Specifications
J2.2b Page 16.1-95
  • The minimum length of fillet weld may not be less
    than 4 x the weld leg size. If it is, the
    effective weld size must be reduced to ¼ of the
    weld length
  • The maximum size of a fillet weld along edges of
    material less than 6 mm thick equals the material
    thickness. For material thicker than 6 mm, the
    maximum size may not exceed the material
    thickness less 2 mm. (to prevent melting of base
    material)
  • The minimum weld size of fillet welds and minimum
    effective throat thickness for partial-penetration
    groove welds are given in LRFD Tables J2.4 and
    J2.3 based on the thickness of the base materials
    (to ensure fusion and minimize distortion)
  • Minimum end return of fillet weld ? 2 x weld size

75
Limitations on Weld Dimensions
  • Maximum effective length - read AISC J2.2b
  • If weld length Lw lt 100 a, then effective weld
    length (Lw-eff) Lw
  • If Lw lt 300 a, then effective weld length
    (Lw-eff) Lw (1.2 0.002 Lw/a)
  • If Lw gt 300 a, the effective weld length (Lw-eff)
    0.6 Lw
  • Weld Terminations - read AISC J2.2b
  • Lap joint fillet welds terminate at a distance
    gt a from edge.
  • Weld returns around corners must be gt 2 a

76
Guidelines for Fillet Weld design
  • Two types of fillet welds can be used
  • Shielded Metal Arc Welding (SMAW)
  • Automatic Submerged Arc Welding (SAW)

Shear failure plane
AISC Section J2.2
77
Weld Symbols (American Welding Society AWS)
  • Fillet weld on arrow side. Welds leg size is 10
    mm. Weld size is given to the left of the weld
    symbol. Weld length (200 mm) is given to the
    right of the symbol
  • Fillet weld, 12 mm size and 75 mm long
    intermitten welds 125 on center, on the far side
  • Field fillet welds, 6 mm in size and 200 mm
    long, both sides.
  • Fillet welds on both sides, staggered
    intermitten 10 mm in size, 50 mm long and 150 mm
    on center
  • Weld all around joint
  • Tail used to reference certain specification or
    process

10
200
12
75_at_125
6
200
10
50_at_150
78
Guidelines for Fillet Weld design
  • Fillet weld design can be governed by the smaller
    value of
  • Weld material strength
  • Base Metal Strength


Yield Limit State
AISC Table J2.5
79
Guidelines for Fillet Weld design
  • The weld strength will increase if the force is
    not parallel to the weld

  • Maximum weld size
  • Minimum weld size

AISC Table J2.4
80
Capacity of Fillet Weld
  • The weld strength is a function of the angle q

Strength
w weld size
Angle (q)
81
Ex. 7.6 Design Strength of Welded Connection
  • Determine the design strength of the tension
    member and connection system shown below. The
    tension member is a 100 mm x 10 mm thick
    rectangular bar. It is welded to a 15 mm thick
    gusset plate using E70XX electrode. Consider the
    yielding and fracture of the tension member.
    Consider the shear strength of the weld metal and
    the surrounding base metal.

t 15 mm
a 6 mm
100 mm x 10 mm
125 mm
12 mm
12 mm
125 mm
82
Ex. 7.6 Design Strength of Welded Connection
  • Step I. Check for the limitations on the weld
    geometry
  • tmin 10 mm (member)
  • tmax 15 mm (gusset)
  • Therefore, amin 5 mm - AISC Table J2.4
  • amax 10 mm 2 mm 8 mm - AISC J2.2b page
    16.1-95
  • Fillet weld size a 6 mm - Therefore, OK!
  • Lw-min 4 x 6 24 mm and 38 mm - OK.
  • Lw-min for each length of the weld 100 mm
    (transverse distance between welds, see J2.2b)
  • Given length 125 mm, which is gt Lmin.
    Therefore, OK!

83
Ex. 7.6 Design Strength of Welded Connection
84
Ex. 7.6 Design Strength of Welded Connection
  • Length/weld size 125/6 20.8 - Therefore,
    maximum effective length J2.2 b satisfied.
  • End returns at the edge corner size - minimum 2
    a 12 mm -Therefore, OK!
  • Step II. Design strength of the weld
  • Weld strength ?x 0.707 x a x 0.60 x FEXX x Lw
  • 0.75 x 0.707 x 6 x 0.60 x 482 x
    250/1000
  • 230 kN
  • Step III. Tension strength of the member
  • ?Rn 0.9 x 344 x 100 x 10/1000 310 kN -
    tension yield

85
Ex. 7.6 Design Strength of Welded Connection
  • ?Rn 0.75 x Ae x 448 - tension fracture
  • Ae U A
  • Ae Ag 100 x 10 1000 mm
  • Therefore, ?Rn 336 kN
  • The design strength of the member-connection
    system 230 kN. Weld strength governs. The end
    returns at the corners were not included in the
    calculations.

86
Elastic Analysis of Eccentric Welded Connections
  • It is assumed here that the rotation of the weld
    at failure occur around the elastic centre (EC)
    of the weld. The only difference from bolts is we
    are dealing with unit length of weld instead of a
    bolt
  • The shear stress in weld due to torsion moment M
    is
  • M is the moment, d is the distance from the
    centroid of the weld to the weld point where we
    evaluate the stress, J is the polar moment of
    inertia of the weld

AISC Manual Part 8
87
Elastic Analysis of Eccentric Welded Connections
Shear Torsion
  • stresses due to torsional moment M is

- Calculation shall be done for teff
- Or for teff 1 mm
88
Elastic Analysis of Eccentric Welded Connections
Shear Torsion
  • Forces due to direct applied force is
  • Total stress in the weld is

89
Ex. 7.7 Design Strength of Welded Connection
Shear and Torsion
250 mm
  • Determine the size of weld required for the
    bracket connection in the figure. The service
    dead load is 50 kN, and the service live load is
    120 kN. A36 steel is used for the bracket, and
    A992 steel is used for the column.

D 50 kN L 120 kN
300 mm
15 mm PL
200 mm
Calculations are done for teff 25 mm
90
Ex. 7.7 Design Strength of Welded Connection
Shear and Torsion
  • Step I Calculate the ultimate load
  • Pu 1.2D 1.6L 1.2(50)1.6(120) 252 kN
  • Step II Calculate the direct shear stress
  • Step III Compute the location of the centroid
  • Step IV Compute the torsional moment
  • e 250 200 57.1 392.9 ? M Pe
    252(392.9)99011 kN-mm.

91
Ex. 7.7 Design Strength of Welded Connection
Shear and Torsion
  • Step V Compute the moments of inertia of the
    total weld area
  • Ix 1(300)3 (1/12)2(200)(150)211.25106 mm4
  • Iy 2 (200)3 (1/12)(200)(100-57.1)2
    300(57.1)23.05106 mm4
  • J Ix Iy (11.25 3.05)106 14.3106 mm4
  • Step VI Compute stresses at critical location

92
Ex. 7.7 Design Strength of Welded Connection
Shear and Torsion
  • Step VII Check the shear strength of the base
    metal
  • The shear yield strength of the angle leg is
  • FRn (0.9)0.6Fyt 0.9(0.6)(248)(15) 2009
    N/mm
  • The base metal shear strength is therefore
  • 2009 N/mm gt 1703 N/mm (OK).
  • Step VIII Calculate the weld size, assuming Fw
    0.6FEXX
  • ? Use 12 mm
  • Answer Use a 12-mm fillet weld, E70 electrode.

93
Elastic Analysis of Eccentric Welded Connections
Shear Tension
94
Elastic Analysis of Eccentric Welded Connections
Shear Tension
  • stresses due to torsion moment M is

- Calculation shall be done for teff
- Or for teff 1 mm
  • F applied force
  • e eccentricity of load
  • Ix moment of inertia around x-axis
  • c distance from neutral axis of weld to the
    farthest weld point

95
Ex. 7.8 Design Strength of Welded Connection
Shear Tension
  • An L6x4x1/2 is used in a seated beam connection,
    as shown in the figure. It must support a service
    load reaction of 25 kN dead load and a 50 kN
    live load. The angles are A36 and the columns in
    A992. E70XX electrodes are to be used. What size
    fillet weld are required for the connection to
    the column flange?

152 mm
20 mm
20 mm
82 mm
96
Ex. 7.8 Design Strength of Welded Connection
Shear Tension
  • Step I calculate the eccentricity of the
    reaction with respect to the weld is
  • e 20 82/2 61 mm
  • Step II Calculate the moment of inertia for the
    weld configuration
  • I 2(1)(152)3 / 12 585300 mm4 c 152/2
    76 mm
  • Step III Calculate the factored-load reaction
    is
  • Pu 1.2D 1.6L 1.2(25)1.6(50) 110 kN
  • Mu Pue 110(61) 6710 kN-mm

97
Ex. 7.8 Design Strength of Welded Connection
Shear Tension
  • Step III Calculate the factored-load reaction
    is
  • Step IV The required weld size a
  • a 943/(0.9x0.707x0.6x482) 6.2 mm

98
Ex. 7.8 Design Strength of Welded Connection
Shear Tension
  • The required size is therefore a 7 mm
  • Step V Check minimum and maximum weld size
  • From AISC Table J2.4 ? Minimum weld size 5 mm
  • From AISC Table J2.2b ? Maximum weld size 13 -
    2 11 mm
  • Try a 7 mm
  • Step VI Check the shear capacity of the base
    metal (the angle controls)
  • Applied direct shear fv 362 N/mm
  • The shear yield strength of the angle leg is
  • FRn 0.90.6Fyt (0.9)0.6(248)(13) 1741
    N/mm
  • The base metal shear strength is therefore
  • 1741 N/mm gt 362 N/mm (OK).

99
Ultimate Strength Analysis of Eccentric Welded
Connections
  • When comparing elastic analysis to experimental
    on eccentric welded connections, it becomes
    obvious that elastic analysis is over
    conservative.

100
Ultimate Strength Analysis of Eccentric Welded
Connections
  • Similar to bolts, weld can be divided into
    segments which rotate about an instantaneous
    centre (IC)
  • Instead of summing the forces we can integrate
    over the length of the weld to get the basic
    equations of equilibrium

Thus
101
Ultimate Strength Analysis of Eccentric Welded
Connections
  • However, in weld The force in each segment R
    is also function of the angle q between the force
    direction and the weld.

Deformation of the segment
Deformation of the segment at max stress
- Similar to bolts, the far weld element might
have a higher proportion of force.
102
Ultimate Strength Analysis of Eccentric Welded
Connections
However, the critical weld is that of the
smallest Dm/rs
Determine the segment that has
The ultimate deformation Du happens for the
segment with smallest Dm/rs
103
Ultimate Strength Analysis of Eccentric Welded
Connections
In all equations q is in radian ranges from
zero to p/2
104
Ultimate Strength Analysis of Eccentric Welded
Connections
  • Thus to estimate the force in the critical
    segment we do the following steps
  • 1- Divide the weld into segments and assume an
    IC
  • 2- Calculate the deformation of each element
  • 3- Compute the ratio Dm/r and determine rcrit
  • 4- For this critical segment compute the ultimate
    deformation Du
  • 5- Compute the deformation of each other segment

105
Ultimate Strength Analysis of Eccentric Welded
Connections
  • Steps continued
  • 6- Compute the stress in each segment
  • 7- Check equilibrium equations

106
Extra Slides
107
Slip-critical Bolted Connections
  • High strength (A325 and A490) bolts can be
    installed with such a degree of tightness that
    they are subject to large tensile forces.
  • These large tensile forces in the bolt clamp the
    connected plates together. The shear force
    applied to such a tightened connection will be
    resisted by friction as shown in the Figure below.

108
Slip-critical Bolted Connections
109
Slip-critical Bolted Connections
  • Thus, slip-critical bolted connections can be
    designed to resist the applied shear forces using
    friction. If the applied shear force is less than
    the friction that develops between the two
    surfaces, then no slip will occur between them.
  • However, slip will occur when the friction force
    is less than the applied shear force. After slip
    occurs, the connection will behave similar to the
    bearing-type bolted connections designed earlier.
  • Table J3.1 summarizes the minimum bolt tension
    that must be applied to develop a slip-critical
    connection.

110
Slip-Critical Connections
  • Loads to be transferred ? Frictional Resistance
    (tension force in bolt x coefficient of friction
    ?) ? No slippage between members
  • ? No bearing and shear stresses in bolt
  • LRFD J3.10 requires bearing strength to be
    checked for both Bearing-Type connections and
    Slip-Critical connections (even though there is
    supposed to be little or no bearing stresses on
    the bolts in Slip-Critical connections)

111
Slip-critical Bolted Connections
  • The shear resistance of fully tensioned bolts to
    slip at factored loads service loads is given
    by AISC Specification J3.8
  • Shear resistance at factored load ?Rn ?(1.13
    ?hscTb Ns)
  • ? - 0.85 for factored loads 1.00 for service
    loads
  • ? - friction coefficient
  • Tb - minimum bolt tension given in Table J3.1
  • hsc hole factor determined as
  • For standrad size holes hsc 1.0
  • For oversized and short-slotted holes hsc
    0.85
  • For long-slotted holes hsc 0.7
  • Ns - number of slip planes

112
Slip-Critical Connections
  • Slip Coefficients (LRFD J3.8)

Surface ?
Class A (unpainted clean mill scale or surfaces with class A coating on blast-cleaned steel) Class B (unpainted blast-cleaned surfaces or surfaces with Class B coating on blast-cleaned steel 0.35 0.50
113
Slip-critical Bolted Connections
  • When the applied shear force exceeds the ?Rn
    value stated above, slip will occur in the
    connection.
  • The final strength of the connection will depend
    on the shear strength of the bolts and on the
    bearing strength of the bolts. This is the same
    strength as that of a bearing type connection.
  • Slip critical connections shall still be checked
    as bearing type in case slip occurs as a result
    of overload.

114
Ex. 6.2 - Slip-critical Connections
  • Design a slip-critical splice for a tension
    member subjected to 600 kN of tension loading.
    The tension member is a W8 x 28 section made from
    A36 material. The unfactored dead load is equal
    to 100 kN and the unfactored live load is equal
    to 300 kN. Use A325 bolts. The splice should be
    slip-critical at service loads.

115
Ex. 6.2 - Slip-critical Connections
  • Step I. Service and factored loads
  • Service Load D L 400 kN.
  • Factored design load 1.2 D 1.6 L 600 kN
  • Tension member is W8 x 28 section made from A36
    steel. The tension splice must be slip critical
    (i.e., it must not slip) at service loads.
  • Step II. Slip-critical splice connection (service
    load)
  • ?Rn of one fully-tensioned slip-critical bolt
    ?(1.13 ?hscTb Ns)
  • (See Spec. J3.8)

116
Ex. 6.2 - Slip-critical Connections
  • Assume db 20 mm.
  • ?Rn of one bolt 1.0 x 1.13 x 0.35 x 1.0x142x1
    56.2 kN
  • Note, Tb 142 kN from Table J3.1M
  • ?Rn of n bolts 56.2 x n gt 400 kN (splice must
    be slip-critical at service)
  • Therefore, n gt 7.12

117
Ex. 6.2 - Slip-critical Connections
  • Step III. Layout of splice connection
  • Flange-plate splice connection

118
Ex. 6.2 - Slip-critical Connections
  • To be symmetric about the centerline, need the
    number of bolts to be a multiple of 8.
  • Therefore, choose 16 fully tensioned 20 mm A325
    bolts with layout as shown above.
  • Minimum edge distance (Le) 34 mm from Table
    J3.4M
  • Design edge distance Le 40 mm.
  • Minimum spacing s (22/3) db 2.67 x 20
    53.4 mm. (Spec. J3.3)
  • Preferred spacing s 3.0 db 3.0 x 20 60 mm
    (Spec. J3.3)
  • Design s 60 mm.
  • Assume 10 mm thick splice plate

119
Ex. 6.2 - Slip-critical Connections
  • Step IV. Connection strength at factored loads
  • The splice connection should be designed as a
    normal shear/bearing connection beyond this point
    for the factored load of 600 kN.
  • Shear strength of a bolt 77.8 kN (see Example
    7.1)
  • The shear strength of bolts 77.8 kN/bolt x 8
    622.4 kN
  • Bearing strength of 20 mm bolts at edge holes (Le
    30 mm) 69.1 kN (see Example 7.1)
  • Bearing strength of 20 mm bolts at non-edge holes
    (s 60 mm) 138.2 kN (see Example 7.1)
  • Bearing strength of bolt holes in flanges of wide
    flange section
  • 4 x 69.1 4 x 138.2 829.2 kN gt 600 kN OK

120
Ex. 6.2 - Slip-critical Connections
  • Step V. Design the splice plate
  • Tension yielding 0.9 Ag Fy gt 300 kN Therefore,
    Ag gt 1344 mm2
  • Tension fracture 0.75 An Fu gt 300 kN
  • Therefore, An Ag - 2 x (20 3.2) x 10 gt 1000
    mm2
  • Beam flange width 166 mm
  • Assume plate width 160 mm x 10 mm which has Ag
    1660 mm2
  • Step VI. Check member strength
  • Student on his/her own.

121
Ultimate Strength Analysis of Eccentric Bolted
Connections
  • Experimental study by Crawford and Kulak (1971)
    showed

- The load-deformation relationship of any bolt
is non-linear
AISC Manual Part 7
122
Ultimate Strength Analysis of Eccentric Bolted
Connections
  • The following conclusions were also shown
  • Failure rotation does not happen around the
    elastic center but around an instantaneous centre
    (IC)
  • The IC does not coincide with the EC
  • The deformation of each bolt is proportional to
    its distance from the IC
  • Similar to the elastic analysis, the connection
    capacity is governed by the force in the farthest
    bolt


123
Ultimate Strength Analysis of Eccentric Bolted
Connections
Measured at the elastic centroid
  • At failure


Eqn (1)

Eqn (2)

Eqn (3)
124
Ultimate Strength Analysis of Eccentric Bolted
Connections
  • Therefore, getting the maximum force in the
    farthest bolt requires determining the unknown
    e
  • Because of the non-linear relationship, e can be
    determined by trial and error
  • A spreadsheet can be used to determine e

125
Forces on Eccentrically-Loaded Bolts with
Eccentricity on the Faying Surface
  • Ultimate Strength Method (Instantaneous Center of
    Rotation Method)
  • R Rult(1
    e-0.394?)0.55
  • R Nominal shear strength of 1 bolt at a
    deformation ?, k
  • Rult Ultimate shear strength of 1 bolt, kN
  • Total deformation, including shear, bearing and
    bending deformation in the bolt and bearing
    deformation of the connected elements, in. (?max
    8.6 mm for 20 mm ASTM A325 bolt)
  • ?1/d1 ?2/d2 ?max/dmax
  • e 2.718base of the natural logarithm

126
Ultimate Strength Method (Instantaneous Center of
Rotation Method)
  • Trial and error
  • Assume e
  • Compute ?i di?max/dmax (?max is assumed for
    bolt at farthest distance from IC)
  • Compute RiRult(1- e-0.394?i)0.55
  • Check for Pu(? Rd)/(ee)
  • If not satisfied, repeat with another e

127
Ex. 6.4 Eccentric Connections Ultimate Method
  • Determine the largest eccentric force Pu for
    which the design shear strength of the bolts in
    the connection is adequate using the IC method.
    Use bearing-type 20 mm A325X bolts

Pu
e 100 mm
e60 mm
  • - Design shear strength per bolt (Ex. 7-1)
  • Ru ? Rn 77.8 kN
  • After several trials, assume e 60 mm. Bolts 2
    and 4 are furthest from the IC, therefore ?2 ?4
    ?max 8.6 mm
  • Compute ?i and Ri in tabulated form

75 mm
d1
d2
75 mm
d4
d3
75 mm
128
Ex. 6.4 Eccentric Connections Ultimate Method
Bolt h (mm) v (mm) d (mm) ? (mm) R (kN) Ry (kN) Rd (kN.mm)
1 22.5 75 78.3 5.47 72.7 20.9 5692
2 97.5 75 123 8.6 77.8 61.67 7585
3 22.5 75 78.3 5.47 72.7 20.9 5692
4 97.5 75 123 8.6 77.8 61.67 7585
? 165.14 ? 26554
Check Pu (?Rd)/(ee) (26554/(60100))
166 kN ?Ry 165.14 kN (OK)
Write a Comment
User Comments (0)
About PowerShow.com
