Title: Dermatoglyphics


1
Dermatoglyphics
  • Introduction to Fingerprint Identification

2
Fingerprints introduction
  • Start by lifting some of your own prints on a cue
    card. Do several fingers to get a representative
    sample. Consider the following questions
  • What do you notice about the types of
    fingerprints? Are the general patterns? Do all of
    your fingerprints have the same pattern? Can you
    categorize patterns looking at yours, and some
    prints from people sitting next to you? Any fine
    features stand out?
  • How do you think fingerprints are formed on your
    hands? What is their function? Do other animals
    have fingerprints? How are they transferred to
    other objects (i.e. what is being transferred?
    Why do your fingers leave prints?)

3
What Well Cover
  • A Brief History
  • Bertillon, Galton Will West
  • How Fingerprints Are Formed
  • Types of Prints and Minutiae
  • Loops, Whorls and Arches
  • Methods of Detecting, Visualizing and Lifting
    Prints
  • Databases
  • The Admissibility of Fingerprints

4
History
5
Alphonse Bertillon
  • 1883 Created the first systematic system of
    individual classification identification
  • Detailed description of subject, full-length
    profile photographs a system of precise body
    measurements (anthropometry)

http//www.spsmvbr.cz/cesky/os_stranky/jedlicka/mu
zeumzla/bertilon/bertilon.html
http//criminaljustice.state.ny.us/ojis/history/me
6
Sir Francis Galton - 1888
  • Sir Francis Galton, a British anthropologist and
    a cousin of Charles Darwin, began his
    observations of fingerprints as a means of
    identification in the 1880's.
  • In 1892, he published his book, "Fingerprints",
    establishing the individuality and permanence of
    fingerprints. The book included the first
    classification system for fingerprints.

http//en.wikipedia.org/wiki/Francis_Galton
7
Sir Francis Galton - 1888
  • Galton's primary interest in fingerprints was as
    an aid in determining heredity and racial
    background.
  • He soon discovered that fingerprints offered no
    firm clues to an individual's intelligence or
    genetic history
  • He demonstrated that fingerprints do not change
    over the course of an individual's lifetime, and
    that no two fingerprints are exactly the same
  • According to his calculations, the odds of two
    individual fingerprints being the same were 1 in
    64 billion.

8
Will West
  • 1903 William West incident
  • Fort Leavenworth prison
  • New prisoner William West couldnt be
    distinguished from unrelated inmate with same
    name by anthropometry
  • Discovered that their fingerprints differed

9
How Fingerprints Are Formed
10
Fingerprints
  • A fingerprint is an INDIVIDUAL CHARACTERISTIC
  • no two are alike and no two have yet been found
    to possess identical ridge characteristics.
  • Fingerprints are the product of your genes as
    well as the environment of the womb during
    development in the first trimester (nutrition,
    blood pressure, contact with the womb)
  • Once developed, fingerprints do not change over
    the course of your life, although they may be
    altered or scarred
  • They evolved in some primates and other animals
    (e.g. koalas) for firmer grasp and resistance to
    slippage
  • They are comprised of a series of lines
    corresponding to hills (ridges) and valleys
    (grooves).

11
Efforts to Remove Fingerprints are Unsuccessful
  • John Dillingers Prints Before and After
    Treatment with Acid

12
Anatomy of the Fingerprint
  • Skin is composed of layers of cells Epidermis
    (outer portion) and dermis as inner skin.
  • In a cross section- a boundary of cells
    separating the epidermis from the dermis is made
    up of dermal papillae- these determine the form
    and pattern of ridges on the surface.
  • Dermal papillae develop in the fetus and remain
    unchanged during life.
  • Sweat glands discharge and deposit perspiration
    to the surface of the skin sweat is vital to
    the formation of latent fingerprints

13
Latent Prints
  • Each skin ridge is populated with a single row of
    poresopenings for ducts leading from sweat
    glands
  • There are 2 types of sweat glands only those
    found on the surfaces of the hands and feet
    (eccrine glands) secrete perspiration that does
    not contain oil
  • Oil in fingerprints comes from the hand
    contacting other parts of the body (e.g. face) or
    other substances containing oil
  • Perspiration from eccrine glands discharges and
    deposits water (95), urea, salts and proteins
    on surface of skin.
  • When the finger comes into contact with another
    surface, the water and dissolved substances are
    transferred
  • This leaves an impression of the fingers ridge
    pattern (fingerprint)
  • These are typically invisible to the eye and
    referred to as latent fingerprints

14
Types of Prints and Minutiae
15
Types of Prints
16
Types of Prints
  • FINGERPRINTS HAVE GENERAL RIDGE PATTERNS FOR
    CLASSIFICATION
  • Divided into three classes
  • LOOP
  • WHORL
  • ARCH
  • 60-65 OF THE POPULATION HAS LOOPS
  • 30-35 WHORLS
  • AND 5 ARCHES

17
Dermatoglyphics
  • Individuality is not determined by general shape
    or pattern but by a careful study of its ridge
    characteristics
  • (also called minutiae)
  • Identity- number- and relative location of
    features that impart individuality.
  • The features should be in the same relative
    location to one another.
  • In court, a point-by-point comparison must be
    made to establish identity

http//cnx.rice.edu/content/m12574/latest/match.jp
g
18
Minutiae
19
Deltas and Cores
  • TYPE LINES are two diverging ridges usually
    coming into and splitting around an obstruction,
    such as a loop.
  • A DELTA is the ridge point nearest the type line
    divergence.
  • Triangular in shape.

20
Matching Minutiae
21
Making Comparisons
  • There are as many as 150 individual ridge
    characteristics on the average fingerprint.
  • a vast majority of prints recovered from crime
    scenes are partial impressions- showing only a
    segment of the print.
  • Expert has to compare a small number of ridge
    characteristics from the recovered print to the
    known recorded print.
  • Criteria of individuality in court generally
    requires 8-16 matching characteristics, but often
    this number is not as important as the expertise
    of the fingerprint examiner
  • 1973 International Association for Identification
    concluded it is the responsibility of the
    examiner- based upon experience and knowledge to
    establish positive identification.

22
Loops
  • A loop must have one or more ridges entering from
    one side of the print, recurring and exiting from
    the same side.
  • If loop opens toward little finger ulnar loop
  • Opens in the direction of the thumb radial loop
  • ALL LOOPS HAVE ONE DELTA

23
Whorls
  • All whorl patterns must have type lines and a
    minimum of two deltas.
  • A PLAIN WHORL and CENTRAL POCKET LOOP have at
    least one ridge that makes a complete circuit.
    This ridge may be in the form of a spiral, an
    oval, or any variant of a circular form.
  • The main difference between these two patterns
    can be shown if an imaginary line is drawn
    between the two deltas contained within the two
    patterns.
  • If the line touches any one of the spiral ridges,
    the pattern is determined to be a plain whorl, if
    no ridge is touched, the pattern is a central
    pocket loop.

24
Plain Whorl
  • In this plain whorl, the line between deltas
    touches and runs through the central pattern

25
Central Pocket Whorl
  • In this central pocket whorl, the line between
    the deltas does not touch any ridge formation in
    the inner part of the pattern.

26
Double Loops and Accidental
  • The DOUBLE LOOP is made up of any two loops
    combined into one fingerprint.
  • Any print classified as ACCIDENTAL either
    contains two or more patterns (not including the
    plain arch) or the pattern is not covered by
    other categories i.e., a combination loop and a
    plain whorl or a loop and tented arch.

27
Arches
  • Of the two types of arches, the PLAIN ARCH is the
    simplest of all fingerprint patterns. It is
    formed by ridges entering from one side of the
    print and exiting on the opposite side. These
    ridges tend to rise at the center of the pattern,
    forming a wavelike structure.
  • The TENTED ARCH is similar, but instead of rising
    smoothly at the center, there is either a sharp
    up thrust or spike, or the ridges meet at an
    angle that is less than 90 degrees.

28
Databases
29
IAFIS
  • INTEGRATED AUTOMATED FINGERPRINT IDENTIFICATION
    SYSTEM
  • Large database of fingerprint collections- using
    individual characteristics of fingerprints
    converted into DIGITAL MINUTIAE ridge endings,
    and branching.
  • Location and relationship of minutiae in a
    digitally recorded geometric pattern
  • A computer can make thousands of fingerprint
    comparisons in a second.
  • IAFIS does not make final verification of print
    identity, but rather flags prints with the
    closest correlation to the search prints.
  • ALLOWS CRIMINAL INVESTIGATORS TO SPEND LESS TIME
    DEVELOPING SUSPECT LISTS AND MORE TIME
    INVESTIGATING SUSPECTS GENERATED BY THE COMPUTER.
  • Fingerprints are voluntarily submitted to the FBI
    by local, state, and federal law enforcement
    agencies. These agencies acquire the fingerprints
    through criminal arrests or from non-criminal
    sources, such as employment background checks.
    The FBI then catalogs the fingerprints along with
    any criminal history linked with the subject.

30
Methods of Detection
31
Fingerprint visibility
  • Latent fingerprint- earlier stated was invisible
    to the eye since they are just perspiration and
    sometimes oil.
  • Composed mainly of water (95) and 5 other
    substances chemicals used to make these visible
    react with some of these substances
  • Visible Prints made by fingers touching a
    surface after ridges have been in contact with
    colored material BLOOD, PAINT, GREASE, INK
  • Plastic Prints are ridge impressions left in soft
    material- putty, wax, soap, or dust.
  • Locating visible prints are easier being visible
    and distinct to the eye.
  • Latent prints are more difficult and require use
    of technologies and techniques that will make the
    print visible.

32
METHODS OF DETECTING LATENT FINGERPRINTS
  • THE METHOD OF CHOICE WILL DEPEND ON THE SURFACE
    BEING LIFTED OR TESTED.
  • Hard and non-absorbent surfaces (glass, mirror,
    tile, and painted wood) require different
    approaches than soft and porous- paper, cloth, or
    cardboard.
  • The most challenging thing an examiner faces is
    location of latent prints.

33
Visualization of Latent Prints
  • On hard surfaces
  • Powder
  • Grey or black
  • Florescent
  • Magnetic
  • Superglue
  • Lighting Techniques
  • On soft surfaces
  • Iodine fuming
  • Nonpermanent visualization
  • Ninhydrin
  • Reacts with proteins
  • Gentian violet
  • Binds to cells and oils on tape

Ninhydrin
34
Ultraviolet Imaging Systems
  • Light sources can be used to locate prints which
    can then be enhanced and lifted using other
    methods. This saves time and energy by narrowing
    a search.
  • Reflected Ultraviolet Imaging System- locates
    prints on nonabsorbent surfaces without chemical
    or powder treatments.
  • When UV light strikes the fingerprint, light is
    reflected back to the viewer- differentiating the
    print from its background surface.

35
Ultraviolet Imaging Systems
Untreated Oily Print on sticky side of Duct
(Duck) tape. 35mm Black and White film.Scene
Scope excels at detecting prints on surfaces that
a forensic light source would find difficult or
impossible.
Latent fingerprint on Painted Wall. Illustration
of Contrast Effect due to variation of
illumination angle. Depending on what angle the
user holds the light, a print can either appear
white or black.
36
Ultraviolet Imaging Systems
  • Hand held Forensic Light Sources

37
Fingerprint Powders
  • Commercially available in a variety of colors and
    textures (photographing)
  • Lightly applied to nonabsorbent surfaces with
    camelhair brush will ADHERE TO PERSPIRATION
    RESIDUES AND BODY OILS.
  • Black and gray for photographing on surfaces-
    produce contrast.

38
Fluorescent Powders
  • Fluorescent powders that fluoresce under
    ultraviolet light- used when color or pattern of
    background obscures visibility of the print.
    (plaid, newsprint, etc).
  • Prints are typically not tape lifted, but
    photographed and digitized or transferred to a
    computer for analysis

39
CHEMICAL METHODS FOR VISUALIZING LATENT PRINTS
  • Iodine fuming
  • Iodine is a solid crystal that when heated, turns
    into a vapor without passing through a liquid
    phase
  • this transformation is called sublimation.
  • Suspect material is placed in an enclosed cabinet
    with iodine crystals
  • Once heated, vapors fill the chamber and combine
    with amino acids in the latent print to make it
    visible.
  • Iodine prints are not permanent and begin to fade
    once fuming is stopped. The print may be fixed
  • IT IS NECESSARY TO PHOTOGRAPH IMMEDIATELY
  • Can be fixed with 1 solution of starch in water
    applied by spraying- this will turn blue and last
    for several weeks or longer.

40
Super Glue Fuming
  • Super Glue fuming- works great on nonporous
    surfaces- metals, leather, plastic bags.
  • Created when superglue is placed on a hot plate.
  • Heating produces vapors that polymerize on the
    print.
  • Fumes and object contained within an enclosed
    chamber for up to 6 hrs.
  • Produces white latent print.
  • The print may be enhanced with a conventional
    powder

41
Gentian Violet
  • Once the standard for lifting latent prints on
    sticky surfaces like tape has now been replaced
    by a commercial product called Sticky-Side
    Powder
  • The dark purple dye stains sebaceous material
    (oil) and skin cells which have sloughed off of
    the person's fingers and palms and which have
    stuck to the adhesive side where the tape was
    touched.

42
Ninhydrin
  • One of the major components of fingerprints is
    amino acids. Several substances bind to them, but
    ninhydrin is particularly effective.
  • It is sprayed or poured onto the evidence, and a
    permanent pink and purple fingerprint results.
  • On the downside, it is toxic and causes blinding
    headaches if inhaled

43
Ninhydrin Reaction
44
Admissibility
45
Fingerprints and their use in court
  • The low probability of 2 unrelated prints
    matching is the foundation for its acceptance in
    court
  • Recall Galton said the probability that two
    fingerprints could match is one in 64 billion.
  • This is supported by the millions of individuals
    who have had prints taken over the past 90 years
    in the FBI central system- no two have ever been
    found to be identical

46
Fingerprints and their use in court
  • Which of the Daubert Standards does fingerprint
    analysis meet?
  • Subjected to peer review and publication
  • The theory or technique must be falsifiable,
    refutable, and testable.
  • Whether there are standards controlling the
    technique's operations.
  • Expert's qualifications.
  • Technique and its results be described with plain
    meaning.
  • Known or potential error rate.

47
Error Rate
  • A case being argued at the Supreme Court in
    Boston recently challenged the idea that
    fingerprint analysis has a zero error rate
  • While testifying, fingerprint examiners give
    all-or-nothing judgments.
  • The International Association for Identification,
    the oldest and largest professional forensic
    association in the world, states in a 1979
    resolution that any expert giving "testimony of
    possible, probable or likely fingerprint
    identification shall be deemed to be engaged in
    conduct unbecoming".
  • Is fingerprint analysis that robust? Consider the
    following studies

http//www.newscientist.com/article.ns?iddn8011
48
Error Rate
  • The FBI's Latent Fingerprint Section in Quantico,
    Virginia took a set of 50,000 pre-existing images
    of fingerprints and compared each one
    electronically against the whole of the data set,
    producing a grand total of 2.5 billion
    comparisons.
  • It concluded that the chances of each image being
    mistaken for any of the other 49,999 images were
    vanishingly small, at 1 in 1097
  • Critics say that showing an image is more like
    itself than other similar images is irrelevant.
    The study does not mimic what happens in real
    life, where messy, partial prints from a crime
    scene are compared with inked archive prints of
    known criminals.

http//www.newscientist.com/article.ns?iddn8011
49
Error Rate
  • One unpublished study may go some way to
    answering the critics. It documents the results
    of exercises in which 92 students with at least
    one year's training had to match archive and mock
    "crime scene" prints. Only two out of 5861 of
    these comparisons were incorrect, an error rate
    of 0.034 per cent.
  • But evidence from qualified fingerprint examiners
    suggests a higher error rate. These are the
    results of proficiency tests in the Journal of
    Criminal Law Criminology (vol 93, p 985).
  • These estimates that false matches occurred at a
    rate of 0.8 per cent on average, and in one year
    were as high as 4.4 per cent. Even if the lower
    figure is correct, this would equate to 1900
    mistaken fingerprint matches in the US in 2002
    alone.
  • How reliable are fingerprint analyses? You be the
    judge!

http//www.newscientist.com/article.ns?iddn8011
Write a Comment
User Comments (0)
About PowerShow.com
