Concurrent Auditing Techniques

1
Chapter 18

• Concurrent Auditing Techniques

2
Concurrent Auditing

• Techniques to collect audit evidence at the same
  time as an application system undertakes
  processing of its production

3
Basic Nature of Concurrent Auditing Techniques

• 2 bases for collecting audit evidence
• Special audit modules are embedded in application
  systems to collect, process, and print audit
  evidenced
• Audit records used to store the audit evidence
  collected so auditors can examine this evidence
  at a later stage

4
Concurrent Auditing
5
Need for Concurrent Auditing Techniques

• Disappearing Paper-Based Audit Trail
• Continuous Monitoring Required by Advance Systems
  (see next Figure)
• Increasing Difficulty of Performing Transaction
  Walkthroughs
• Presence of Entropy in Systems
• tendency of systems toward internal disorder and
  eventual collapse over time
• Problems Posed by Outsourced IT Systems
  (difficult for auditors to be there at the
  outsource)
• EDI and Inter- organizational Info systems

6
(No Transcript)
7
Concurrent Audit Techniques

• Integrated test facility (dummy company test data
  then analysis of authenticity, accuracy, and
  completeness)
• Snapshot/extended record
• System control audit review file (SCARF)
• Continuous and intermittent simulation (CIS)

8
Integrated Test Facility (ITF)

• Verifies authenticity, accuracy, and completeness

• Involves 2 major design decisions
• What method will be used to enter test data?
• What method will be used to remove the effects of
  ITF transactions?

9
Methods of Entering Test Data Using ITF

• 2 Methods
• (1) Involves tagging transactions submitted as
  production input to the application system to be
  tested
• (2) Involves designing new test transactions and
  entering them with the production input into the
  application system

10
Entering test data
11
Methods of Removing the Effects of ITF
Transactions

• 3 Methods
• (1) Modify the application system programs to
  recognize ITF transactions and to ignore them in
  terms of any processing that might affect users
• (2) Submit additional input that reverses the
  effects of the ITF transactions
• (3) Submit trivial entries so the effects of the
  ITF transaction on output are minimal

12
Snapshot/Extended Record

• Involves software taking pictures of a
  transaction as it flows through an application
  system.
• Major Implementation Decisions
• Where to locate the snapshot points?
• When to capture snapshots of transactions?
• Items needed for reporting of the snapshot data
  that is captured (timestamp, ID, time of each
  process)

13
(No Transcript)
14
(No Transcript)
15
System Control Audit Review File

• The most complex technique
• Involves embedding audit software modules within
  a host application system to provide continuous
  monitoring of the systems transactions
• 2 major design decisions
• What info. will be collected by SCARF?
• What reporting system will be used?

16
(No Transcript)
17
Information Collected by SCARF

• Application system errors
• Policy and procedural variances
• System exceptions (certain errors are allowed)
• Statistical samples
• Snapshots and extended records
• Profiling data (data to build profile of users)
• Performance measurement data

18
Structure of SCARF Reporting

• Design Decisions
• Determining how the SCARF file will be updated
  (e.g., small applications send data to the file
  once a day)
• Choosing sort codes and report formats to be used
• Choosing the timing of report preparation

19
(No Transcript)
20
Continuous Intermittent Simulation

• Primary advantages of CIS
• SCARF defines exceptions of interest but CIS
  traps exceptions for auditors using DBMS. It does
  not not require modifications to the application
  system
• Provides an online auditing capability
• Requires less programming instructions
• Less input/output overheads

21
(No Transcript)
