Mobile Internet 3G vs. 4G or both...

1
Mobile Internet3G vs. 4G or both...
Harri Kreus Senior Consultant Harri.Kreus_at_HMV.fi
358 40 7726525
2
Background

• There is a lot of discussion what 4G actually
  means...
• Will it be logical successor of 3G in timely
  fashion?
• We see at HMV that no, evolution of 3G 4G are
  parallel but starting from different paradigm,
  but possibly uniting in the Next Generation thus
  actually 5G
• 3G is evolving from Mobile Phone to Mobile
  Communicator to Mobile PDA (UMTS, WCDMA, i-Mode,
  WAP)
• 4G is evolving from PDA to Mobile Communicator to
  Mobile Phone (WLAN, GPRS, VoIP-client)
• Actually, we see that there is room for both in
  the market

3
Background

• At the same time there are two massive
  convergencies going on
• All IP
• Military-Commercial
• The Main Integrator will be Software Radio
• SoThank God for SWRADIO DSIG within OMG and
  Wireless CORBA (Telecom DTF) !

4
eEurope 2002 Internet everywhere, anytime, for
everybody
Information Society with eEurope
Cable modem
3G (UMTS)
EDGE GPRS
xDSL
Twisted pair
2G (GSM)
Internet Protocol
Mobile
Fixed
Commissioner Erkki Liikanen European Commission
5
Towards the personal Internet in EU

• Internet access increasingly based on mobile and
  interactive digital TV platforms
• By 2003, 65 of the EU population will have a
  mobile phone
• and 85 of mobile phones will be
  Internet-enabled

Commissioner Erkki Liikanen European Commission
6
Software radio

• Re-programmable radio of the future which can be
  configured (even in real time) to function in
  many radio systems and if necessary even
  simultaneously
• Dominant design principle in future
• All functions are to maximum extent software
  defined
• Includes also a smart multiband antenna system in
  the future

7
Main advantages of software radio

• The size, power consumption and complexity of
  radio will decrease---gt also cost of production
  is smaller
• Shorter development time
• Bridge or gateway function between different
  systems-gt makes interoperation possible
• Radio interface or communication protocol can be
  changed on the fly
• Adaptive radio interface possible
• Future proof
• compatibility with legacy and future waveforms

8
Military multiband multimode -basestation

• Basestations support both commercial and
  military waveforms
• Advantages
• No need for changes in terminals
• Drawbacks
• Basestation complicated and expensive
• different waveforms
• signalling
• etc
• does not support the principle of
  decentralisation

HF-radio
SR
SR
VHF CNR
SR
UHF-radio
SR
Commercial radio(GSM, TETRA etc.)
9
Commercial multiband multimode -basestation

• Advanced Communications Technologies released
  01/2001 SDR-basestation(SpectruCell), which
  includes GSM, CDMA, 3G,UMTS waveforms
• coming on the market this year
• 400 MHz2,9 GHz
• No application specific circuits
• for example CDMA function without specific
  circuit(like Qualcomm)
• 1024-QAM radiolinks can be used also to combine
  different basestations

GSM
SR BS
SR BS
UMTS
SR BS
GSM/EDGE
SR BS
IS 95
10
Military multiband multimode terminal

• Terminals will support both commercial and
  military waveforms
• Advantages
• Parallel use of existing networks ---gt supports
  the principle of decentralisation
• Terminal uses at same time only one waveform---gt
  implementation architecture simple
• Drawbacks
• Terminal more complicated compared to
  singlemode radio
• Commercial application 4G(3G)

11
Development of commercial mobile communication
networks

• 1G analog cellular networks
• NMT, AMPS, TACS etc
• Digital 2G networks
• GSM, through evolution path data rate increases
• HSCSD
• GPRS
• EDGE---gt over 384 kbit/s
• WAP
• wide range
• IS 95, IS-136 CDMA, IS-136 TDMA

12
Development of commercial mobile communication
networks

• 3G UMTS (WCDMA-techniques)
• Two versions UMTS_1999 and UMTS_ 2000
• core networks either enhanced GPRS or
• IP-network
• Handover GSM lt--gt UMTS---gt multimode radios
• Hotspot coverage
• max theoretical data rate 2 Mbit/s
• Offers for mobile user multimedia services and
  convergence between fixed, cellular and satellite
  networks

13
Development of commercial mobile communication
networks

• 4G
• Not a new waveform, butAs wide Integration as
  possible of all existing systems based on
  software radio and IP-technology
• all systems, all services, at low price
• private and public networks

Picture from Dr Pereira(EU commission), PIMRC 2000
14
Future All-IP network
15
Development of Tactical Radios (ground forces)

• 1. Generation
• Analog radios
• analog FM-modulation
• very slow data rate using typically
  FSK-modulation
• 2. Generation
• Digital radios
• deltamodulated voice and for example FSK-type
  modulation
• slow data rate (typically under 9.6 kbit/s)
• frequency hopping as ECCM-method
• Support of packet data
• for example Tactical Internet standard
  MIL-STD-188-220
• Ad Hoc type of network setup

• 3. Generation
• Multiband multimode radios
• same radio includes for instance HF, VHF and
  UHF waveforms
• Support of many waveforms (520)
• Enhanced packet data transfer
• Possibly includes also commercial or public
  safety waveforms(GSM, TETRA etc.)
• 4. Generation

16
Convergence of Commercial and Military Radio
Networks

• Strong encryption-, integrity- and authentication
  methods are used to guarantee secure data
  transfer
• Ad Hoc mode in the software radio enables
  automatic network management
• For longer range commu-nication the commercial
  or military networks are used as soon as they are
  available
• European cooperation would be necessary in order
  to develop 4G tactical software radio

• Both Commercial and Military Network will be
  IP-based
• Commercial and also tactical routers support
  Mobile IP and IPsec
• Untrusted Internet can be used to connect
  tactical intranets VPN(Virtual Private
  Network)
• In principle future military multimode
  software radio can be used seamlessly both in
  military and commercial radio networks
• core network is responsible of mobility (Mobile
  IP,Wireless CORBA)

17
Summary

• The convergence of commercial mobile systems (3G
  and especially 4G) is based on re-configurable
  radios (software radio)
• Future tactical radios will also be software
  radios
• the need for multiband multimode radios is
  obvious in future
• parallel use of commercial and military radio
  networks
• adaptive waveforms
• gateway-function possible
• interoperability between legacy and future
  waveforms
• Closer cooperation between commercial-military is
  needed
• OMG offers an excellent forum for this
