Using

1
SESSION 1317

• Using
• OPEN SOURCE software
• in a Shared ILS

2
Speakers

• Shann Leighton, CEOShelburne Public Library
• Agnes Rivers-Moore, CEOHanover Public Library
• Wilda Allen, CEOGrey Highlands Public Library
• Rose Dotten, CEOShelburne Public Library

3
Introduction

• SHANN LEIGHTON
• Selection, Consortium, RFP

4
THE MIGRATION PROCESS

• AGNES RIVERS-MOORE
• CEO / Chief Librarian,
• Hanover Public Library

5
KOHA DATA MIGRATIONor, How we got from A to B

• Make migration choices
• Study tables and data in Spectrum and in Koha
• Study local library procedures
• Match up similar functionality in both systems
• Extract tables data from Spectrum
• Clean up data (a little late)
• Manipulate data to fit Koha tables
• Create method to insert data into Koha tables
• Run, test, amend, run, test, amend repeat
• Insert all data to sandbox system and test
  again
• Turn over to library staff
• Repeat with new data and GO LIVE

6
Migration choices

• Critical decision what do you need to keep?
• Spectrum had about 60 tables, Koha about twice
  that many.
• Our vendor offered to transfer almost everything
  over.
• Most systems allow at least simple export and
  import of MARC and Patron records.
• Circulation, fines, holds, history can be very
  difficult.
• Statistics were not possible to migrate over.

7
Study Spectrum

• Know where you are coming from.
• A thorough understanding of how the old system
  works is needed.
• In our case we used in-house staff with systems
  experience.
• Remember, Garbage in, garbage out! Clean up the
  data first as far as possible.
• Extract and study the old system tables,
  relationships, data formats etc.

8
Study Koha

• Study the new system tables and relationships.
• Look for basic data elements
• Spectrum p_patron table is Koha borrowers
• Spectrum loclseq is Koha itemnumber
• Identify how tables are linked hidden system
  IDs
• A partial diagram of key Koha tables

9
(No Transcript)
10
Study library procedures

• Look at the basic library procedures.
• Study Koha system options and rules.
• Apply what the new system can do to what the
  staff and customers need.
• Just because the old system did it one way does
  not mean that is the best way prepare for
  change.
• We discovered that six libraries using the same
  system had six different ways of doing
  everything!

11
Match functionality

• Match up new functionality to old e.g. when a
  book is checked out, which tables are accessed,
  how are they linked?
• Check that each data element
• has a place in the new system.
• Make a clear map of which data goes where.
• Make sure your vendor/consultant understands.

12
Extract data

• Figure out how to extract the data you need.
• In Spectrum this required purchasing proprietary
  software from the database vendor the Spectrum
  system vendor did not have the tools we needed.

• some folks would have given up here.

• Convert the extracted data into a format you
  can work with.

13
Clean up

• Data out is only as good as what you put in.
• This stage is a good time to look at the mess and
  clean it up - reformat addresses to conform to
  Canada Post requirements, fix postcodes etc.
• Weed out the old. Every stage will take longer if
  you leave in ancient history and inactive
  accounts.

14
Manipulate to fit

• Modify, combine, split or edit to fit
• Koha needed datetime together - Spectrum stored
  them in separate fields.
• Spectrum split patron notes into
• different elements -
• Koha has a single text area.
• Yes/No flags were 0/1 or -1/0

15
Insert data

• Use import where possible (MARC records, patrons)
• Time to do some programming for the rest, write
  scripts to insert modified data, line by line,
  into the new Koha SQL database tables.
• Run a sample, check result, modify, check.
• Document every change carefully.
• Run full insert of each table, and CHECK AGAIN.

16
Set up Sandbox

• Set up a test system with all the rules and
  preferences
• Import every part of the data, as intended for
  the final system
• Test it does what you believe it should do due
  dates calculate correctly, fines accrue, overdue
  reminders are generated
• ( if using email reminders, dont connect to
  the outside world yet!)

17
Run, test, amend

• Check and double check
• Once all the basic patron, MARC and item tables
  are filled, check for functionality check out,
  check in, create hold, add patron, add item
• Add other data elements and check each works
  (holds, fines, checkout history match up with the
  correct patron and item)

18
Staff testing

• Turn it over to staff who know the data from
  their own library to test it intensively.
• They will spot errors in the data
• They will learn to watch the screen
• This is when good trainers will be discovered

Ask the Librarian!
19
Do it for real

• (Of course there is a lot of staff training and
  other preparation I am skipping over here.)
• Final data extraction back up, back up, back
  up!
• Repeat the data manipulation exactly as
  documented
• Insert the data to the new Koha system
• Test that everything works one more time
• Turn OFF the test system!
• GO LIVE !

20
KOHA GREAT FEATURES

• ROSE DOTTEN
• CEO / Chief Librarian,
• Shelburne Public Library

21
KOHA Great Features what we like

• Customizable add graphics, logos, hours, change
  for upcoming events etc.
• Access from home! a great feature for our
  patrons
• Links to Amazon, other catalogues and sources
  etc.
• Logistics- Print and design our own barcodes,
  uses Copy cataloguing and z39.50 protocols

22
OUR Library Home Page and access to KOHA
23
LOGIN SCREEN
24
Review your own file
25
What you can do
Your own information
Purchase Suggestions
26
What Andrew has checked out ALL or last 50
27
Current Title Checked Out Search sidebar
28
Sidebar Information during Search
29
Shelf Browse- a fun feature
30
Holds Queue
31
Holds Pending- date range
32
Holds awaiting pickup great feature to
quickly check when catalogue says AVAILABLE
33
KOHA MULTI-BRANCH ASPECTS

• WILDA ALLEN
• CEO / Chief Librarian,
• Grey Highlands Public Library

34
KOHA features for Multi-Branch Library
35
Financial

• Start-up costs (approx. ¼ cost of proprietary
  software)
• Costs for ongoing maintenance and yearly support
  (1/4 cost of proprietary software)

36
Circulation Features

• Patron Memberships registration at one branch
  is membership at all branches
• Patrons may
• Borrow from any branch with card
• Return items to any branch
• Reserve item from one/all branch(es) through
  online catalogue. May also indicate where they
  want to pick
• Online catalogue- provides option to search all
  branches or single branch

37
(No Transcript)
38
(No Transcript)
39
(No Transcript)
40
(No Transcript)
41
(No Transcript)
42
(No Transcript)
43
(No Transcript)
44
(No Transcript)
45
Circulation Features

• Staff may access
• Circulation Activity system-wide
• Staff have real time access to circulation
  activity of materials at the other branches-
  useful for checking on status of materials.
• Patron records-fines, messages, membership
  status
• Materials Check-in-  pop up "transfer" messages
  for materials belonging to other branches
• Interbranch loans- "transfer" feature allows for
  tracking of the item from time hold is placed to
  transfer of material until it is checked in by
  the borrowing library.   "waiting" feature- until
  patron picks up item.

46
(No Transcript)
47
(No Transcript)
48
(No Transcript)
49
Cataloguing and Acquisitions, Collection
Maintenance

• Importing of marc records- holdings for branches
  allows for unique call numbers at branches
• Donated materials- additional holdings can be
  added to records in database
• Weeding of materials-staff can check database for
  other copies.
• Bulk loans or blocks of materials can be moved to
  other branches by "transfer" feature.

50
(No Transcript)
51
Adminstration

• Web-based product- allows administrators to log
  in to any branch from any computer

52

• The SAUGEEN LIBRARY CONSORTIUM welcomes new
  members interested in using KOHA.
• Contact Shann Leighton
• shannleighton_at_primus.ca
• The support of the Government of Ontario through
  the Ministry of Tourism and Culture is
  acknowledged.

53
SAUGEEN LIBRARY CONSORTIUM

• COST TO IMPLEMENT SYSTEM IN
• SIX LIBRARIES

54
SAUGEEN LIBRARY CONSORTIUM

• Saugeen Library Consortium Feb. 2011
• Finances
• Grant Applicaton 133,107
• Actual Costs 180,983
• Difference -47,876

55
SAUGEEN LIBRARY CONSORTIUM

• BREAK DOWN OF EXPENSES
• GRANT ACTUAL DIFFERENCE
• Manag. Admin. 14,500 14,750 -250
• Data Migration 37,012 37,984 -972
• Hardware Set-up 26,385 35,335 -8,950
• Cust. Sup. Datbs Managmt 16,450 21,300
  -4,850
• Staff Training 5,700 6,908 -1,208
• Promotion to Public 15,000 5,731
  9,269

56

• DONATED SERVICES AND MATERIALS
• GRANT ACTUAL DIFFERENCE
• Library Staff Admin. 6,160 46,803 -
  40,642
• Computer Hardware 11,900 12,174
  -274
• Total 133,107 180,985 -47,878

57
SAUGEEN LIBRARY CONSORTIUM

• Revenue GRANT ACTUAL DIFFERENCE
• LSDF Grant 50,000 50,000
• Grand Valley Library 8,348 9,106
  -758
• West Grey Library 9,984 12,419
  -2,435
• Hanover Library 10,710 10,624 86
• North Perth Library 13,097 14,996
  -1,899
• Shelburne Library 9,836 11,089
  -1,253
• Grey Highlands Library13,072 14,072
  -1,000

58
SAUGEEN LIBRARY CONSORTIUM

• Donated Services and Material
• GRANT ACTUAL DIFFERENCE
• Library Staff Admin. 6,160 58,677
  (combined)
• Computer Hardware 11,900 -40,617
• Total 133,107 180,983 -47,876
