SUPERPAVE

1
SUPERPAVE

• FOR
• LOCAL ROADS
• LOW VOLUME STATE HIGHWAYS

2
PROBLEM STATEMENT

• ROADS MUST ACCOMODATE
• Extreme Temperatures High - 110FLow - minus
  40F
• EnvironmentMountains Snow and RainDeserts
  High Temperature
• Traffic Types
• Forest, Agriculture, Mineral Hauling/Loads
• Recreational Traffic
• Buses and Heavy Trucks

3
FLEXIBLE PAVEMENTSGOVERNING DISTRESSES FOR

• STATE ROADS
• COUNTY ROADS
• CITY ROADS

4
Governing Distress TypesFor State Roads (ADT lt
5000)
5
Governing Distress TypesFor County Roads
6
Governing Distress Types
7
STUDY OBJECTIVE

• Implement SHRP Superpave technologies and
  evaluate use performance on local streets and
  low volume state and county roads.

8
STUDY TASKS

• Organize Technical Working Group
• Coordinate work with the Rocky Mountain Asphalt
  User/Producer Group
• Develop Standard Binder Asphalt mix design
  criteria for streets roads
• Evaluate mixes (SHRP protocol level 1)
• Construct Experimental Pavement Sections
  Evaluate Performance
• Prepare Design Construction Reports
• Conduct Periodic Condition Surveys Prepare
  Performance Reports

9
Expected Benefits

• Cost Savings
• Increased Pavement Life
• Improved Service to Road User

10
TWG- Technical Working Group

• State DOT

County
Asphalt Institute
City/Town
RMAUPG
Contractors
Materials/Suppliers
Consultants
11
Superpave Asphalt Mix Design Criteria(Level I
Mix Design)

• Residential Streets
• County Roads/ Low Volume State Roads
• Collector Arterial Streets (i.e. Buses)
• Industrial Areas

12
Selection of Materials

• Asphalt Cements (Hi - Low Temp Map for State)
• PG 64-28
• PG 64-34
• PG 64-40
• PG 70-28
• Aggregates (Max. Size)
• 19mm / ¾ inch
• 12mm / ½ inch

13
Mix Design Criteria
14
Ogden CITYSuperpave Projects

• FIRST PROJECT 1997
• OVERLAY PROJECTS 1998 - 2000

15
Ogden City - Projects

• RECONSTRUCTION
• Superpave Level I Mix Design
• PG-64-28 Asphalt Cement
• 3 inches of HMA
• 19mm (3/4 inch) max. size aggregate

• OVERLAYS
• Superpave Level I Mix Design
• PG-64-28 Asphalt Cement
• Partial roto-mill of existing surface.
• Non-woven fabric
• 2 inches HMA

16
Ogden - Reconstruction of 34 th Street

• Superpave Level I Mix Design Required.
• PG-64-28 Asphalt Cement selected.
• Mix design validated by UDOT.
• Pavement Structure
• 3 inch HMA surface
• 8 inch crushed aggregate base

17
34 th Street Jefferson to Washington
Reconstructed- 1997 3 in. HMA 19 mm max.
aggr. Asphalt PG-64-28

• Condition Rating

3459
18
Henderson Avenue
Costructed 1999 2 in. HMA Overlay 12.5 mm max.
aggr. Asphalt PG 64-28

• Condition Rating

dcp01427
19
25th Street from Taylor Avenue to Fillmore
Avenue constructed 1999
20
Comparison of PW Overlays Superpave Overlays
21
SALT LAKE CITY Superpave Projects
22
Salt Lake City - Projects

• RECONSTRUCTION
• Superpave Level I Mix Design
• PG-64-28 or PG-70-28 Asphalt Cement
• 7 inches of HMA
• 19mm (3/4 inch) max. size aggregate

• OVERLAYS
• Superpave Level I Mix Design
• PG-64-28 Asphalt Cement
• Partial roto-mill of existing surface.
• Non-woven fabric
• 2.5 inches HMA

23
2100 South - 1700 East to 2300 East
Reconstructed in two phases 1997 1998 7 in.
HMA 19 mm max. aggr. Asphalt Cement PG 70-28

• Condition Ratings

15,000 ADT 7 Trucks Buses 150 trips/day
24
2100 South, 940 East to 1100 East
Constructed 2000 3 in. Overlay of PCCP 12.5 mm
max. aggr. Asphalt Cement PG 64-28

• Condition Ratings

15000 ADT
25
9th Ave (E Street to F Street)
Constr. 2000 2.5 Overlay w fabric 12.5 mm max.
aggr. Asphalt Cement PG 64-28

• Condition Ratings

26
Cheyenne St.- Wasatch to 800 South
Constr. 2000 2.5 in. Overlay w fabric 12.5 mm
max. aggr. Asphalt Cement PG 64-28

• Condition Ratings

27
Concord - 300 South to 340 South
Constr. 2000 2.5 in. Overlay w fabric 12.5 mm
max. aggr. Asphalt PG 64-28

• Condition Ratings

600 ADT 60 bus trips per day
28
Salt Lake City Summary

• Comparison
• 900 East 7 in. HMA
• AC-20
• ADT 14000
• 2100 South 7 in. HMA
• PG 70-28
• ADT 15000
• 900 East has 4 times more rutting than 2100 South

• Cost
• 2000 AC-20, ¾ HMA
• 1.31/sq./in.
• 2002 AC-20, ¾ HMA
• 1.50/sq./in.
• 15 increase in cost.
• 2000 PG 64-28, ½ HMA
• 1.55/sq./in.
• 2002 PG 64-28, ½ HMA
• 1.70/sq./in.
• 10 increase in cost.

29
Other Experimental Projects

• Orem City
• 1200 South 400 West to Sandhill Road
• State Route 10
• Just North of Castledale between Reference Posts
  38.6 and 41.3
• State Route 30
• Park Valley

30
City of Orem 1200th South 400 West to Sandhill
Road
31
Orem Overview 0.5 Mile Section 1800 tons Close to
Utah Valley State College SHRP Level I Mix
Design 19mm PG 64-34
32
Orem CitySHRP Level I Mix Design

• UDOT Central Materials Bituminous Mix Design
  Laboratory
• AMRL Accredited
• FHWA approved gyratory compactor
• Atsers Asphalt-it 6.0 design software

33
Aggregate

• Geneva Rock Products
• Gradation modified to avoid restricted zone
• Fine aggregate angularity out of spec in one
  stockpile

34
(No Transcript)
35
(No Transcript)
36
Binder SelectionWhy PG 64-34?

• City Setting - Dynamic loading
• Minimize thermal cracking
• Safety factor

37
Paving Mixture

• 1 Lime - Antistrip
• Lower asphalt content longer mix times?

38
(No Transcript)
39
1200 South Sandhill Rd. Reconstructed August
1997
Condition 1-24-03
40
Condition Comparison
1-24-2003
1997
41
1200 South Sandhill Rd. Reconstructed August
1997
42
SR-10 Overview

• Project SP-0010(8)39
• Rotomill and Overlay - 1998
• Length 2.7 miles or 4.35 Kilometers
• 4,400 Metric Tons
• ADT 3235
• 19 mm PG 64-40 mix
• Average Remaining Service Life 3 years

43
Original Condition
State Route 10 Ref Posts 38.6 - 41.3 North of
Castledale
44
COAL TRUCK TRAFFIC SR- 10
45
(No Transcript)
46
(No Transcript)
47
(No Transcript)
48
(No Transcript)
49
SR 10 Ref. Post 38.6 to 41.3

• Condition Rating

50
(No Transcript)
51
SR-10 MP-38.67
July 2002
July2002
52
SR 10 MP 39.07
July 2002
53
Comparison
4-1-2000
10-9-02
54
SR-30 Overview

• Project SP-0030(22)42
• HMA Overlay
• 19mm max. aggr.
• PG 64-34 asphalt cement
• Constructed 1998

55
(No Transcript)
56
State Route 30 Park Valley
57
(No Transcript)
58
Oil Graph
59
(No Transcript)
60
Georgia Loaded Wheel Test
61
SR- 30 MP 30
October 2001
62
SR 30 MP 46
October 2001
63
Condition Comparison
2001
1998
64
Changes with Superpave

• Increased testing and specifications
• More coarse aggregate in mix
• Binders now engineered
• Binder specification based on temperature
  extremes

65
SUPERPAVE COSTS

66
Average Increase In Cost

• 2000 1.00/ton of mix(28.00 per ton)
• 2002 3.00/ton of mix
• (31.00 per ton)

67
Lessons Learned Construction

• Must have solid foundation
• Requires Quality Construction Procedures
• Requires Additional Compactive Effort
• Tender Zone
• QC/QA a must
• Excellent Joint Construction

68
Lessons Learned Performance

• On New or Total Reconstructed Pavements No
  Thermal Cracking After 5 Years
• Reduced Reflective Cracking for 2 inch Plus
  Overlays
• At Least 19mm(¾ inch) Maximum Size Aggregate
  Required for City Bus Traffic
• 12mm(½ inch) max. Size Aggregate Works Well for
  Overlays on Residential Streets
• Longitudinal Joint Construction has Been
  Excellent on Most All Projects.
