Title: Chapter 7 Water and Atmospheric Moisture


1
Chapter 7Water and Atmospheric Moisture
2
Water and Atmospheric Moisture
  • Water on Earth
  • Unique Properties of Water
  • Humidity
  • Atmospheric Stability
  • Clouds and Fog

3
Land and Water Hemispheres
Figure 7.2
4
Ocean and Freshwater Distribution
Figure 7.3
5
Unique Properties of Water
  • Heat Properties
  • Phase change
  • Sublimation
  • Latent heat
  • Vaporization
  • Condensation
  • Heat Properties of Water in Nature
  • Latent heat of sublimation

6
Basics about Water 2 atoms hydrogen 1 atom
oxygen make a covalent bond (very strong)
so water is very stable Molecule is shaped like
a bent paperclip
  • with the O side having a negative charge and the
    H side having a positive charge
  • the positive H side attracts the negative O side
    of a neighboring water molecule
  • called hydrogen bonding (weak)

7
  • Hydrogen bonding
  • Responsible for the surface tension of water
  • allows heavier things like bugs to stand on top
    of the surface of water
  • allows you to slightly overfill a glass of water
    without it spilling over.
  • Responsible for capillary action
  • what happens when you set the edge of a
    papertowel down on a puddle of water?
  • The water is pulled into the dry part of the
    towel because each molecule is drawing the next
    molecule in
  • Same thing happens in soils, which will become
    important when we talk about the hydrologic cycle

8
Phase changes
  • Sublimination
  • Condensation Evaporation
  • Freezing - Melting

Figure 7.4
9
Heat Transfer
Figure 4.10
10
Latent and sensible heat
11
Latent heat
Boiling
Water Vapor
100
Water
Temperature (oC)
0
Ice
Melting
Heat added
12
Water density
13
Humidity
  • Relative Humidity
  • Saturation
  • Dew point
  • Expressions of Relative Humidity
  • Vapor pressure
  • Specific humidity
  • Instruments

14
Relative Humidity
Actual water vapor content of air

x 100
Maximum water vapor capacity of air
Dew Point Temperature
Figure 7.7
15
Saturation Vapor Pressure
16
Water Vapor in the Atmosphere
Figure 7.9
17
Global Latent Heat
Figure 4.19
18
Daily Humidity Patterns
Figure 7.10
19
Seasonal Humidity Patterns
Winter
Summer
Figure 7.10
20
Humidity Instruments hair hygrometer
Figure 7.13
21
Humidity Instruments Sling Hygrometer
Rate of evaporation is faster (more heat loss)
when humidity is low
Figure 7.13
22
Atmospheric Stability
Will the Balloon float up or stay where it is (or
sink downward)? If the air in the balloon is
less dense than the air outside ? it floats
up If the air in the balloon is more dense than
the air outside ? it sinks
23
Atmospheric Stability
  • Adiabatic Processes
  • Environmental Lapse rate
  • Actual Lapse rate
  • Rate at which temperature decreases with
    altitude.
  • Dry adiabatic lapse rate
  • Lapse rate of dry air
  • Moist adiabatic lapse rate
  • Lapse rate of water vapor saturated air

24
Adiabatic Processes
Figure 7.16
25
Adiabatic Processes
  • Dry adiabatic rate (dry air)
  • 10 C/ 1000 m
  • 5.5 F/ 1000 ft
  • Moist adiabatic rate (saturated air)
  • 6 C/ 1000 m
  • 3.3 F/ 1000 ft

Figure 7.17
26
 Stable conditions
3000
MAR 6oC/km
DAR 10oC/km
2000
Altitude (m)
Environmental Lapse rate 5oC/km
1000
Temperature (oC)
  • Instructions
  • Take a balloon and fill it with air at ground
    level (note the humidity).
  • Move it up in the atmosphere
  • As the Pressure decreases the air in the balloon
    expands and becomes cooler
  • Is the air in the balloon at a lower temperature
    than the surrounding air?

27
 Stable conditions
Environmental Lapse rate 5oC/km
3000
MAR 6oC/km
DAR 10oC/km
2000
Altitude (m)
1000
Temperature (oC)
  • Is the air in the balloon at a lower temperature
    than the surrounding air?
  • If the air is DRY at ground level the temperature
    IN THE BALLOON at 2000 m is ? 5 oC
  • The temperature of the air outside the balloon is
    ? 16 oC
  • The air in the balloon is denser so the balloon
    WILL SINK!!!

28
 Stable conditions
Environmental Lapse rate 5oC/km
3000
MAR 6oC/km
DAR 10oC/km
2000
Altitude (m)
1000
Temperature (oC)
  • Is the air in the balloon at a lower temperature
    than the surrounding air?
  • If the air is MOIST (saturated) at ground level
    the temperature IN THE BALLOON at 2000 m is ?
    13 oC
  • The temperature of the air outside the balloon is
    ? 16 oC
  • The air in the balloon is denser so the balloon
    WILL SINK!!!

29
 Unstable conditions
3000
DAR 10oC/km
MAR 6oC/km
2000
Altitude (m)
1000
Temperature (oC)
  • Is the air in the balloon at a lower temperature
    than the surrounding air?
  • If the air is MOIST (saturated) at ground level
    the temperature IN THE BALLOON at 2000 m is ?
    13 oC
  • The temperature of the air outside the balloon is
    ? 2 oC
  • The air in the balloon is denser so the balloon
    WILL FLOAT!!!

30
 Unstable conditions
3000
DAR 10oC/km
MAR 6oC/km
2000
Altitude (m)
1000
Temperature (oC)
  • Is the air in the balloon at a lower temperature
    than the surrounding air?
  • If the air is DRY at ground level the temperature
    IN THE BALLOON at 2000 m is ? ? oC
  • The temperature of the air outside the balloon is
    ? ? oC
  • The air in the balloon is _______ so the balloon
    WILL _______!!!

31
 Conditionally Unstable
Environmental Lapse rate 7oC/km
3000
MAR 6oC/km
DAR 10oC/km
2000
Altitude (m)
1000
Temperature (oC)
  • Is the air in the balloon at a lower temperature
    than the surrounding air?
  • If the air is MOIST at ground level the
    temperature IN THE BALLOON at 2000 m is ?
    ? oC
  • The temperature of the air outside the balloon is
    ? ? oC
  • The air in the balloon is _______ so the balloon
    WILL _______!!!

32
 Conditionally Unstable
Environmental Lapse rate 7oC/km
3000
MAR 6oC/km
DAR 10oC/km
2000
Altitude (m)
1000
Temperature (oC)
  • Is the air in the balloon at a lower temperature
    than the surrounding air?
  • If the air is DRY at ground level the temperature
    IN THE BALLOON at 2000 m is ? ? oC
  • The temperature of the air outside the balloon is
    ? ? oC
  • The air in the balloon is _______ so the balloon
    WILL _______!!!

33
Stable and Unstable Atmospheric Conditions
Figure 7.18
34
If you warm the surface what happens to the
environmental lapse rate???
Figure 7.18
35
Clouds and Fog
  • Cloud Formation Processes
  • Cloud Types and Identification
  • Fog

36
Cloud Formation
  • Moisture droplet
  • Cloud-condensation nuclei

Figure 7.20
37
Cloud Types and Identification
Figure 7.22
38
Cumulonimbus Development
Figure 7.23
39
Fog
  • Advection fog
  • Evaporation fog
  • Upslope fog
  • Valley fog
  • Radiation fog

40
Advection Fog air migrates up or down and
becomes saturated with water vapor
Figure 7.24
41
Advection Fog Valley Fog
Figure 7.25
42
Advection Fog upslope Fog
43
Radiation Fog
Figure 7.26
44
Fog Harvesting
45
End of Chapter 7
  • Geosystems 5e
  • An Introduction to Physical Geography

Robert W. Christopherson Charlie Thomsen
46
