Title: Chapter 7 Water and Atmospheric Moisture


1
Chapter 7Water and Atmospheric Moisture
  • Geosystems 6e
  • An Introduction to Physical Geography

Robert W. Christopherson Charles E. Thomsen
2
Frontal Lifting
  • Fronts named after attacking air mass
  • Remember cold air is denser, heavier
  • Cold Fronts
  • Cold air forces warm air aloft
  • 400 km wide (250 mi)
  • Warm Fronts
  • Warm air moves up and over cold air
  • 1000 km wide (600 mi)

3
Frontal Lifting
  • Both cold and warm fronts cause air to be
    uplifted.
  • This causes adiabatic cooling, low pressure,
    cloud development, rainfall.
  • Keep in mind the properties of each type of air
    mass and their changes as the front passes.

4
Frontal Lifting
  • The BIG FIVE! These change depending on front
  • Humidity
  • Temperature
  • Pressure
  • Wind direction/speed
  • Cloud types
  • Cold front blue triangles
  • Warm front red/orange half circles

5
Cold Front
Figure 8.11
6
Warm Front
Figure 8.13
7
Midlatitude Cyclone
Figure 8.14
8
Violent Weather
  • Ice
  • Thunderstorms
  • Tornadoes
  • Tropical Cyclones
  • hurricanes
  • All of these are examples of ___ pressure
  • All operate on same principles, but occur on
    different spatial scales
  • All can bring devastating weather

9
Freezing Rain
  • Supercooled water that falls to the surface as
    rain but upon impact freezes
  • The weight of accumulated ice breaks power lines
    and tree limbs

10
Hail
  • Hail consists of ice pellets formed in roughly
    concentric layers
  • Formed when water is frozen in the atmosphere.
    The ice pellet falls and encounters water, which
    freezes to the ice pellet forming a second layer
  • The size of hail is determined by the strength of
    the updraft
  • Hail has more water volume, snowflakes have more
    air volume

11
Hailstones
12
  • Air mass thunderstorms (ordinary thunderstorms)
    self-extinguishing localized short lived
    phenomena limited vertical wind shear.

13
Severe Thunderstorms self-propagating
14
Supercell
15
  • Where moist air uplifting
  • ? Occurs frequently in the tropics, nearly daily
    in some locations
  • The U.S.s most frequent region the Gulf South
    absolute peak in Florida (land protrusion into
    warm waters)

16
Thunderstorms
Figure 8.20
17
Mesoscale Convective Complexes
A mesoscale convective complex over eastern South
Dakota
18
Squall Line Thunderstorms
19
Tornadoes
Figure 8.23
Figure 8.24
20
Tornadoes
  • A tornado is defined as a small, very rapid wind
    vortex with extremely low air pressure in its
    center, formed beneath dense cumulonimbus clouds
    in proximity to a passing cold front.
  • Known as waterspouts when they form over oceans.
    If the circulation remains aloft, it is known as
    a funnel cloud.

21
Tornadoes Characteristics Dimensions
  • A wide variety of shapes and sizes.
  • Diameters typical 100 yards, some 15 times as
    larger
  • Duration usually a short lived phenomena, only
    a few minutes some have lasted for hours
  • Movement is generally about 50km/hr (30 mph)
    over an areas about 3-4 km (2-2.5 mi) long
  • Wind speeds from 40mph to 280 mph

22
Tornadoes
  • The most damaging aspect of a tornado is wind
    speed.
  • Tornadoes are spawned by frontal boundaries,
    squall lines, MCCs, and tropical cyclones.
  • The most severe tornadoes are spawned by severe
    thunderstorm cells known as supercells.

23
Mesocyclone andTornado
Figure 8.23
24
Nonsupercell Tornado Formation
  • Related to strong convection along a convergence
    zone

25
(No Transcript)
26
  • Tornadoes predominate in North America,
    especially in south-central states of Texas,
    Oklahoma, Kansas, Nebraska, and Iowa, and
    throughout the Midwest.
  • This region is commonly called tornado alley.
  • A secondary concentration occurs in the
    southeastern U.S., especially Florida and
    Mississippi.

27
Tornadoes
Figure 8.25
28
  • In the U.S. alone, we can expect to have on
    average about 800 tornadoes, so this is a common
    phenomenon.
  • Most occur between 10 AM and 6 PM, and tornado
    season runs from March to July, with May seeing
    the heaviest occurrence.

29
(No Transcript)
30
  • Hurricanes Around the Globe
  • Atlantic and eastern Pacific hurricanes.
  • Western Pacific typhoons.
  • Indian Ocean and Australia cyclones

31
Hurricane Characteristics
  • Hurricanes winds gt 120 km/hr (gt 74 mph)
  • Compared with tornadoes lesser in intensity,
    much larger in size and longer life span ? much
    more devastating
  • Size Average diameters 600 km (350 mi) and
    central pressure averages 950 mb may be as low
    as 870 mb
  • Fuel from latent heat release in the cloud
    formation process
  • When Where
  • Where warm waters abound and during the times of
    highest SSTs
  • When August and September in the Northern
    Hemisphere January to March in the Southern
    Hemisphere

32
Hurricane Characteristics
  • Hurricanes consist of
  • A central eye surrounded by large cumulonimbus
    thunderstorms occupying the adjacent eye wall
  • Pressure differences into the center of the storm
    are about twice as great as the average
    mid-latitude cyclone, resulting in strong
    sustained winds

33
(No Transcript)
34
Eye and Eye Wall
  • Eye an area of descending air and light winds
    about 25 km (15 mi) in diameter on average air
    in the eye to be warmer than elsewhere
  • A shrinking eye indicates storm intensification
  • Eye wall comprised of the strongest winds, the
    largest clouds, and the heaviest precipitation
    with rainfall rates as high as 2500 mm/day (100
    in.)

35
Hurricane Formation
  • Start Tropical disturbances
  • Often begin in the eastern ocean basins as
    disorganized clusters of thunderstorms
  • Some form in association with mid-latitude
    troughs migrating toward lower latitudes
  • Some from ITCZ-related convection.
  • Most associated with easterly wave.

36
Hurricane Formation
  • Tropical depression below 37 mph
  • Tropical storm further intensification to wind
    speeds of 60 km/hr (37 mph)
  • Hurricane when winds reach or exceed 120 km/hr
    (74 mph)
  • A high percentage of depressions become tropical
    storms and an even higher percentage reach
    hurricane status

37
Conditions Necessary for Hurricane Formation
  • Hurricanes form only over deep water layers with
    surface temperatures in excess of 27 oC (81 oF)
  • Coriolis force is an important contributor, and
    as such, hurricanes do not form equatorward of 5o
  • Strong vertical shear must be absent

38
Destruction by Hurricanes
  • Winds
  • Heavy rainfall
  • Storm surge is responsible for a large
    percentage of damage along coastal regions (e.g.,
    hurricane Camille caused a storm surge of 7 m (23
    ft) along the Mississippi coast)
  • High surf occurs atop the surge, increasing
    damage

39
Destruction by Hurricanes
  • Winds and surge are typically most intense in
    the right front quadrant of the storm. Why?
    Combination of wind speeds and the speed of the
    storms movement.

40
Destruction by Hurricanes
  • The right front quadrant also produces the
    greatest frequency of tornadoes within the
    hurricane.
