The Internet

1
The Internet
2
Overview

• An introduction to HTML
• Dynamic HTML
• Encryption
• Public Key Infrastructure
• Development of the Internet
• Web Browsers

3
Top 10 uses of Internet at Work (2000)

• 1. E-mail 73
• 2. Business related research 35
• 3. Academic Research 23
• 4. General browsing/surfing 17
• 5. IT information 11
• 6. Downloading Software 11
• 7. News information 10
• 8. Searching for personal information 9
• 9. Reading Magazines/Newspapers 7
• 10. Sports information 7

4
Overall Structure of Internet
5
(No Transcript)
6
How does the World Wide Web works?

• User must have a program called "browser" running
  on the computer Internet Explorer (IE) or
  Netscape
• User establishes a connection with an ISP
  (Internet Service Provider) via dial-up or LAN
  (local area network).
• User types in an URL (Uniform Resource Locator)
  as the target webpage address in browser's
  address field. For example, http//www.csd.uwo.ca/
  cs031

7

• (4-6 are behind the scene) Through ISPs, the
  English URL is translated into a numerical IP
  (Internet Protocol) address. Eg130.100.11.3
• User's browser uses the IP address to establish a
  connection via local, regional, and/or national
  ISPs, with the target computer (a web server).
• The web page that the user wants, HTML page, is
  sent back to user's browser.
• User's browser interprets HTML commands, and
  displays the page with nice format to the user.
  HTML pages can have
• Formatting information (text formatting, framing,
  etc.)
• Hyperlinks (user clicks on and browser repeats
  steps 3-6)
• Multimedia (pictures, audio, video, animations)

8
A Simple Example (simple.html)
A very simple web page My name is
Charles Ling

Here is a picture of
mine
width150

My favourite thing to do
is

• Adventurous travelling around the
  world
• Watching good movies
• Reading news
  at CNN

For
more info about me, click my href"http//www.csd.uwo.ca/faculty/ling"home
page at UWO.
9
(No Transcript)
10
Building Webpages

• Writing html files directly (using notepad or
  other text editors)
• Using MS Word and save as html
• Using specialized software MS Frontpage,
  Dreamwaver, etc.
• Adding animations, forms, java, javascript,
  database functionality,

11
Writing Simple html pages

• Start notepad and writing html code directly
• Save it as an html file (eg, my.html)
• Start browser (eg, Internet Explore)
• Click file open, click browse to locate and
  open the html file (eg, my.html).
• You will see how the html file is displayed!

12
HTML

• HTML HyperText Markup Language
• A language used to define the content of, and the
  presentation instructions for, a Web document

13

• When a browser presents a Web document, the
  browser scans the document and applies the
  presentation instructions to the content
• Content that does not have presentation
  instructions will be presented using default
  instructions built into the browser

14

• HTML documents must employ a simple format so
  anyone can create documents
• HTML documents are stored in text (ASCII) files
• This type of document can be created using any
  editor that allows you to save the document as a
  text file

15

• To combine the content and the presentation
  instructions in the same file, there must be a
  way to distinguish between these two components
• In HTML, the presentation instructions are
  inserted as tags
• Anything that isnt a presentation instruction is
  content

16

• HTML tags normally occur in pairs
• The pair of tags surround the content to which
  they apply
• A start tag is indicated with angle brackets
• An end tag is indicated with a slash after the
  opening angle bracket

17

• HTML has a set of predefined tags
• These tags can be used to
• Control how the text in the document is displayed
• Insert images into the document
• Insert links to other documents

18
Document Tags

• HTML documents are enclosed within and
  tags
• Every HTML document will have a head and a body
• The document head is enclosed within the
  and tags
• The body is enclosed within the and
  tags

19

• The basic structure of an HTML document is

• The within the is displayed in the
  title bar of the browser

20

• The of the document contains information
  used by the browser
• All of the content for the document and the
  associated presentation instructions are placed
  inside the tags

21
Formatting Tags

• HTML contains tag definitions that allow you to
  control
• Headings
• Style
• Ordered Lists
• Unordered Lists
• Definition Lists
• etc.

22
Heading Tags

• There are six heading levels
• The levels are named H1, H2, H3, H6 where H1 is
  the largest and H6 is the smallest
• To create a heading, you enclose the text of the
  heading inside the opening and closing tags for
  the heading level

23
Heading Examples
24
Physical Style Tags

• Used to control the display of text
• - bold
• - italics
• - underline
• - typewriter type face

25
Physical Style Tag Example
26
Logical Style Tags

• Examples of logical style tags
• - for emphasis
• - stronger emphasis
• - citation
• - computer code

27
Logical Style Tag Example
28
Layout Style Tags

• Used to control text layout
• - center the text
• - new paragraph
•
  - break, start a new line
• - horizontal rule, draw a line

29
Layout Style Tag Example
30
Lists

• Lists of data can be defined using
• Ordered List enumerated lists
• Unordered List bulleted lists
• Definition List lists that are made of terms
  and their associated definitions

31
Ordered List

• Use the
  and
  tags to start and end an
  ordered list
• Within the ordered list, the list item (
• ) tag
  is used to indicate the items on the list
• The VALUE tag can be used to set the value of a
  list item
• The START parameter is used to control the value
  of the first item

32

• The TYPE parameter controls what enumeration
  scheme is used
• The types are
• 1 numbers (default)
• a lower case letters
• A upper case letters
• i small Roman numerals
• I large Roman numerals

33
Ordered List
34
Ordered List
35
Ordered List
36
Unordered List

• Use the
  and
  tags to start and end an
  unordered list
• Within the unordered list, the list item (
• )
  tag is used to identify the items on the list

37

• The TYPE parameter can be used to control the
  look of the list
• The types are
• Disc a solid disc
• Circle a hollow circle
• Square a square symbol

38
Unordered List
39
Unordered List
40
Definition List

• The and tags define the Definition
  List
• The tag is used to indicate a definition
  term
• The tag is used to indicate a definition

41
Definition List
42
URL

• An URL is a Uniform Resource Locator
• An URL contains information about
• The address of a document on the Internet
• The protocol that will be used to access the
  document

43
Protocols

• HTTP HyperText Transfer Protocol
• Designed to transmit files on the World Wide Web
• FTP File Transfer Protocol
• Designed to transmit files over the Internet
  (before the Web developed)
• ftp//ftp.csd.uwo.ca
• Email mailtoling_at_csd.uwo.ca
• These protocols are sets of rules that dictate
  how files are transmitted between computers

44
URL Example

• In the following URL example, the protocol to be
  used is HTTP (before the //)

• The document is browse.html and it is located
  in the selected folder at the World Wide Web
  site for UWO in Canada

45
Images

• Images are added to documents using the tag
• A tag is not required
• The SRC parameter is used to indicate the SouRCe
  of the image

46
Image Formats

• Standard image formats are needed so images can
  be
• stored
• retrieved
• transmitted over the Web

47

• Examples of image formats used on the Web are
• GIF Graphics Interchange Format
• JPG ( JPEG ) Joint Photographic Experts Group
• PNG Portable Network Graphics
• BMP Windows Bitmap

48
Graphics Interchange Format

• Uses the Lempel-Ziv Welch (LZW) compression
  algorithm
• The algorithm searches the image for big blocks
  of the same color and then compresses these
  blocks
• This compression reduces the size of the image

49

• The algorithm also uses an indexed color scheme,
  in which a custom color palette for the image is
  selected using only 256 of the over 16 million
  available colors
• This format is used when the image does not
  contain a wide range of colors or color shades

50
Joint Photographic Experts Group

• Images can contain millions of colors
• Uses Lossy compression algorithm
• When the image is compressed it permanently loses
  some of its quality
• The algorithm looks for similar colors (like a
  range of reds) and chooses the same red for very
  close shades

51

• If the original image had 1,000 shades of red,
  the compressed image may have only 500 shades
• The human eye cannot detect all the shades so in
  general the lose will not be noticed
• This format is used when the image contains many
  colors and many color shades

52
Portable Network Graphics

• Portable Network Graphics format was designed to
  replace GIF
• Uses loss less compression like GIF
• Provides better resolution and more colors like
  JPG
• Generates smaller files like GIF
• Is not supported by all versions of browsers

53
Windows Bitmap

• Every pixel in the image is represented by a
  piece of data
• The data represents the color of the pixel
• Bitmap images are very large
• Rarely used on Web pages because of the time
  required to download the image

54
Image Tag
55
Anchors

• Anchor tags ( and ) are used to insert
  hyperlinks and bookmarks into HTML documents
• A hyperlink is a link to another document on the
  World Wide Web
• A bookmark is a named location within an HTML
  document

56
No. 1 use of AnchorsAnchors as Hyperlinks

• An example of a link to the UWO home page

• When the HTML is rendered the document will
  contain a link to UWO

57

• The Link Item is the text or image that you click
  on to activate the link
• The HREF parameter is the Hypertext REFerence
  parameter
• The HREF parameter is used to define the link
  destination

58
An Image as a Link
59
No. 2 useAnchors as Bookmarks(in the same
document)

• An example of the definition of an (invisible)
  bookmark using the NAME parameter (normally in a
  long html file)

.. .. NAMEConclusions_bookmark Conclusions/h2
60

• An example of a link to a bookmark within the
  same document (in the same html document)
• Note the use of

You can see conclusions markhere Back to
top
61
In a long html file (say papers.html)
. You can see conclusions ookmarkhere NAMEConclusions_bookmark Conclusions/h2 You can see conclusions hrefConclusions_bookmarkhere
62
No.3 use combining 1 and 2Anchors as
Hyperlinksto bookmark in a different document

• The form of the anchor tags used as a hypertext
  link is

Link Item
63

• An example of a link to a bookmark within another
  html document

Click usions_bookmark here to jump to conclusions
in that document.

• See a real example inhttp//www.csd.uwo.ca/facult
  y/ling/cs031/simple.html
• If linking to a bookmark in the same document,
  the URL is omitted

64
Web Page Example 1

• Create a Web page with
• My First Web Page as the title
• Your name as a level 2 heading
• An enumerated list of your three favorite
  University courses
• An image for the University. Try
  http//www.uwo.ca/gifs/uwologo4.gif as the
  source URL. If this URL doesnt work, look at
  the HTML source for the Universitys home page to
  find an URL

65
Web Page Example 2

• Create a Web Page with
• A TV show name as a level 1 heading at the top of
  the page
• A paragraph of text about the show
• Bold the stars names and italicize the night that
  the show is broadcast within this text
• A horizontal line
• A link to a Web page for the show. Use the name
  of the show as the link text
• A horizontal line
• A link to the heading at the top of the page,
  using Top as the link text

66
DHTML

• Dynamic HTML
• Supported by fourth generation and later browsers
  (Netscape and IE)
• DHTML allows the user to interact with a web page
• The user can enter values and select buttons

67

• The user of a DHTML page can enter data and then
  have the data sent (posted) to a web site
• The computer hosting the web site can then
  process the data
• DHTML Example 1
• DHTML Example 2

68
Encryption

• Encryption involves encoding a message to conceal
  the meaning
• Consider the name

NORMA JEAN BAKER

• The name has been encrypted as

OPSNB!KFBO!CBLFS

• What is the encryption algorithm?
• How would you decode the message?

69

• For encryption to work there must be an algorithm
  that is applied to the original message
• There must also be a way to decode the encrypted
  message to obtain the original message

70

• Encryption algorithms use a binary key to
  encrypt and decrypt messages
• There are two types of encryption algorithms used
  to secure Internet transmissions
• Symmetric Key Encryption
• Asymmetric (Public) Key Encryption

71
Symmetric Key Encryption

• Symmetric Key Encryption can use the same key for
  both encryption and decryption
• The sender and the receiver must both know the
  key
• Both must ensure that the key is kept secret
• If the key becomes public then others can decrypt
  valid messages and create fake messages

72
Key Length

• For Symmetric Key Encryption, the typical key
  lengths are 40, 56 and 128 bits
• Key length is one measure of encryption strength
• Longer keys provide stronger encryption
• An additional bit in the key doubles the strength
  of the key

73
Data Encryption Standard

• The Data Encryption Standard (DES) is the U.S.
  governments standard for data encryption
• Uses the Data Encryption Algorithm (DEA) to
  encrypt/decrypt the message
• An improvement on the Lucifer algorithm developed
  by IBM in the early 1970s
• Uses a 56 bit key

74
Triple DES

• Uses a key three times as long as Standard DES
• 168 bit key
• Used for banks and other organizations that
  transmit highly sensitive data

75
Public Key Encryption

• Asymmetric Key Encryption
• Uses a pair of keys, one public and one private
• Key length is a least 512 bits
• The public key is published so any sender can
  obtain it
• The private key is kept secret

76

• Messages encrypted using the public key can only
  be decrypted by using the private key
• There reverse is also true, messages encrypted
  using the private key can only be decrypted using
  the public key
• This is one way to generate a digital certificate
  (to sign a message)

77

• Rhonda wants to send an email to Rick
• Rhonda finds Ricks Public Key through a Public
  Key directory
• She encrypts the message using Ricks Public Key
  and sends the message
• Rick uses his Private Key to decrypt the message
  (his Public Key will NOT decrypt the message)
• For Rick to respond, he must use Rhondas Public
  Key to encrypt the message

78
Encryption Strength

• The strength of an encryption depends on the
  algorithm used and the length of the key
• The algorithms used in most implementations of
  Public Key Encryption are patented by RSA Data
  Security Inc.

79
RSA Algorithms

• The RSA Public Key Cryptosystem was developed in
  1977 by
• Ronald Rivest
• Adi Shamir
• Leonard Adleman
• They have created a number of 128 bit key
  algorithms
• For example, RC2 and RC4

80
Code Breaking

• For Symmetric Key Encryption, the typical key
  lengths are 40, 56 and 128 bits
• Tests have been conducted to determine how long
  it will take to break messages encoded using
  various key lengths

81

• The 128 bit encryption has not been broken yet!
• The sun will burn out first is a frequent
  estimate of how long it will take!

82
US vs International Security

• Under current U.S. policy, software manufacturers
  can only sell 40 bit key encryption systems
  overseas
• Some exceptions can use 56 bit keys
• International banks

83

• In the U.S., 128 bit keys are recommended to
  ensure secure communications
• Why would the U.S. want to restrict key length in
  software used in other countries?

84
Public Key Infrastructure

• A Public Key Infrastructure is an encryption and
  digital certificate delivery system which makes
  secure electronic transactions possible
• The X.509 Standard

85

• PKI uses Digital Certificates
• A digital signature
• Digital Certificates carry the same legal weight
  as a written signature
• Provides a way for others to verify your identity
• Uses Public Key Encryption

86

• A Digital Certificate relates you to a set of
  public and private keys
• Digital Certificates are used to provide secure
  transactions through the Secure Sockets Layer
  Protocol (SSL)

87
SSL Protocol

• Developed by Netscape
• Goal is to provide secure and reliable
  communication between applications
• For example, between a Web application (your
  browser) and a Web site

88

• Public Key Encryption is used by each application
  to establish the identity of the other
  application
• Symmetric Encryption is used for data encryption

89

• Public Key Encryption is used to exchange the key
  used by the Symmetric Encryption of the data
• The reliability of the message is ensured by
  including a Message Authentication Code (MAC) as
  part of the data

90

• SSL takes the message to be transmitted and
• fragments the data into manageable blocks
• optionally, compresses the data
• performs a message integrity check
• encrypts the data
• transmits the result

91

• Received data is
• decrypted
• verified
• decompressed
• reassembled
• delivered to the client

92
Digital Trust

• Public Key Infrastructure (PKI) manages all
  aspects of Digital Trust
• In the digital world, trust requires
• Privacy
• Integrity
• Non-repudiation
• Authentication

93
Privacy

• To ensure privacy, messages are encrypted
• Encryption ensures that the message cannot be
  read in transit or by anyone except the recipient

94
Integrity

• Verify the integrity of the message
• Ensure that the message that is received is
  exactly what was sent

95
Non-repudiation

• The sender cannot deny or repudiate a valid
  message
• For example, when a stock broker receives an
  order for stock trades, the client cannot later
  claim that they didnt send the message

96
Authentication

• Verify that the sender is who they claim to be

97
The Internet

• Networks of networks
• Tens of thousands of computer networks
• Reaches 100s of millions of people
• How did the Internet develop?

98

• Started with ARPANET, an experimental project of
  the U.S. Department of Defense Advanced Research
  Projects Agency (DARPA) in 1969
• The original purpose was to explore experimental
  networking technologies for the military

99

• How large is the Internet?
• Nobody knows for sure!
• According to the Internet Society (ISOC), a
  professional organization of Internet developers,
  influencers, and users, the Internet reaches more
  than 170 countries

100
Internet Growth
101

• One of the reasons the Internet has been so
  successful is the commitment of its developers to
  producing open standards
• The specifications or rules that computers need
  to communicate are publicly and freely available
  published so that everyone can obtain them

102
TCP/IP

• The standards that the Internet uses are known as
  TCP/IP
• Transmission Control Protocol/Internet Protocol
  suite
• Without open standards, only computers from the
  same vendor could talk to one another

103

• Computers and networks that conform to the same
  communications standards are able to
  interoperate, regardless of the manufacturer
• All of the networks and computers act as peers in
  the exchange of information and communication

104
Packets

• Communication on the Internet revolves around the
  concept of a packet, a basic building block
• All information and communications transmitted on
  the Internet are broken into packets, each of
  which is considered to be an independent entity

105

• The packets are individually routed from network
  to network until they reach their destination,
  where they are reassembled and presented to the
  user

106

• This method of networking is very flexible and
  robust
• It allows diverse computers and systems to
  communicate by means of network software, not
  proprietary hardware

107

• If a network goes down (breaks down), then the
  packets can be rerouted through other parts of
  the network of networks
• This dynamic alternate routing of information
  creates a very persistent means of communication

108
Internet Development

• There have been three generations of Internet
  development
• They characterize the evolution of the Internet

109
First Generation

• There were three main First Generation Tools
• Electronic mail
• Remote logon
• File transfer
• These tools are still available on all parts of
  the Internet

110
Electronic Mail

• Uses Simple Mail Transfer Protocol (SMTP)
• Standardized in 1983
• Originally designed to transmit plain text
• Printable characters
• NOT binary files, graphics or sound

111

• Current systems use Multipurpose Internet Mail
  Extensions (MIME)
• MIME allows the email system to transport
• Plain text, binary files, graphics and sound
• MIME encodes and decodes complex messages into a
  simpler form that SMTP can transport

112

• Characteristics of email programs
• Composition
• Response
• Read
• Delete
• Organize
• Filter

113
Email Address

• An email address consists of a local part and a
  host part
• For example,

csdept_at_csd.uwo.ca
114
csdept_at_csd.uwo.ca

• The local part is a user name, mailbox, login
  name or user id
• csdept
• The host part is the name of an email server on
  the Internet
• csd.uwo.ca

115
POP and IMAP

• Protocols like the Post Office Protocol (POP) and
  the Internet Message Access Protocol (IMAP) are
  used to transmit email from
• your computer to your email server
• your email server to your computer

116
Simple Mail Transfer Protocol

• The Simple Mail Transfer Protocol (SMTP) is used
  to transmit email between email servers

117

• To send an email
• Construct the message on your computer
• When you click on Send, the message is moved
  using POP or IMAP to your email server
• The email server uses the host part of the
  address to determine where to send the message

118

• When the message arrives at the destination email
  server, it is stored and the recipient is
  notified of its arrival
• When the recipient wants to read the message, it
  is moved using POP or IMAP to their computer

119
Remote Logon

• Allows you to logon to a computer over the
  Internet
• A utility that handles remote logon is Telnet
• To remotely connect to a computer, you must know
  the address of the computer
• For example, mccarthy.csd.uwo.ca

120

• On most host computers, you must have an account
  on the computer
• Some host computers allow you to logon as
  Anonymous or Guest with your email address as
  the password
• Anonymous logon

121
(No Transcript)
122
File Transfer

• The File Transfer Protocol (FTP)
• Used to copy (download) files over the Internet

123

• FTP was designed to copy plain text files
• HTTP was designed to transmit text files,
  graphics, sound, etc.
• FTP is faster than HTTP because FTP doesn't
  perform as many checks on the data during the
  download process

124

• FTP allows you to
• connect to another computer
• list the files in a folder on the other computer
• copy files back and forth between the two
  computers
• Anonymous FTP allows you to logon as Anonymous
  or Guest with your email address as the password

125
(No Transcript)
126
Second Generation

• The Second Generation saw large increases in
• The amount of data being made public
• The number of Internet users
• There was an increasing need for tools that would
  aid users in finding resources

127
Tools

• The first tool was Gopher
• Developed at the University of Minnesota, where
  the mascot is a Golden Gopher!

128

• Gopher was a hierarchical system of menus
• The top level menu contained general categories
• The information became more specific as you
  drilled down
• Looked a lot like Yahoo!

129
Veronica

• Very Easy Rodent-Oriented Net-wide Index to
  Computerized Archives
• The University of Nevada
• Gopher allowed you to search through the
  categories looking for interesting resources
• But it was a manual search
• Veronica allowed the user to submit keywords and
  the utility did a search of gopher space

130
Archie

• Archie is derived from the word archive
• Developed at the McGill University School of
  Computer Science
• Maintained a database of all the names of files
  stored at known public FTP sites
• Helped find files at FTP sites

131
Network News - USENET

• USENET is a network within the Internet
• Divided into newsgroups
• Each newsgroup is devoted to a topic
• To read or post to a newsgroup you need a news
  reader application

132
Newsgroups

• More than 80,000 newsgroups
• Newsgroups are divided into hierarchies
• alt 10,159 alternate groups
• microsoft 991 groups
• bionet 94 groups
• biz 48 groups
• Newsgroups are added daily so these numbers are
  out of date!

133
Third Generation

• The World Wide Web
• Tools
• Browsers
• Search engines
• Directories

134
World Wide Web

• Originally developed by the European Laboratory
  for Particle Physics (also known as CERN) by Tim
  Berners-Lee of Switzerland
• He developed a system to link together scholarly
  references
• The links from one document to another are
  imagined to form a web!

135

• The World Wide Web is a browsing and searching
  system
• Built on the concept of hypertext and hypermedia

136

• The Web is a continuous distributed information
  construction project
• Tens of thousands of people are adding knowledge
  to it daily by bringing up their own servers or
  posting documents on existing servers

137
Browsers

• A browser is application software
• Browsers use HTML documents as their input
• The HTML tags in the document are applied to the
  content and the result is displayed in the browser

138
Mosaic

• The first popular graphical browser
• It was developed at the National Center for
  Supercomputing Applications (NCSA) in Champaign,
  Illinois by Marc Andreessen
• Allows a user to click on text, graphics, buttons
  or icons that link to other resources

139
Netscape

• Developed by Netscape Communications Corporation
• The company was founded in April of 1994 by Marc
  Andreessen, creator of the NCSA Mosaic software
  and Dr. James H. Clark, the founder of Silicon
  Graphics, Inc.

140

• Microsofts Web browser is Internet Explorer
• All browsers have the same basic functionality,
  they just have a slightly different look and
  feel

141
Browser Functionality

• Typical functionality
• Display HTML documents
• Create bookmarks
• Send and read email
• Read news
• Display and create the source HTML for documents
• Debug script on DHTML pages

142
Search Engines

• One of the most difficult tasks for a Web browser
  is to make it easy for the user to find resources
• Search engines allow users to do keyword searches
• These searches are actually database searches
• Search engines keep databases that match keywords
  to document URLs

143
Directories

• The top level of directories indicate general
  categories
• As the user drills down into a category, they are
  presented with more specific categories

144

• Consider WebCrawler and Google
• These two are typical World Web Web tools
• They both provide basic and advanced search
  capabilities as well as directories

145
Advanced Searches

• Each search engine has its own syntax for
  describing a search
• Most engines AND together keywords
• The document must have all of the keywords
• The search engine should also support OR, NOT and
  exact phrases

146

• Check out the WebCrawler and Google advanced
  search pages for examples of typical advanced
  search strategies

147

• You can submit a page to be included in searches
  and directories
• WebCrawler
• Google
• Search engine databases also get information
  about documents from programs called robots that
  explore the Web looking for documents to add to
  their database
