IPPM REPORTING MIB

1
IPPM REPORTING MIB ISP measurement
infrastructure

• Emile STEPHAN- Jessie JEWITT
• France Telecom RD

2
Summary

• Standardization status
• Data model Architecture of the MIB
• Namespace IPPM Metrics Registry
• Measures sharing and control

• Result aggregation
• SLA monitoring

• Interdomain with IPPM MIB/ITU O.Iptest

• Intra/inter domain correlation issues
• Conclusion

3
Abbreviation Acronyms

• Acronyms
• VACM View Access-based Control Model
• MP measurement point or probe
• WG working group.
• Foo, Bar names of management applications
• Abbreviations
• E2e End to end QoS Quality of Service
• rootX Domain X network measures manager
• Net ippmNetMeasureTable
• Aggr ippmAggrMeasureTable
• Rpt ippmReportSetupTable
• IE information element

4
Standardization status

• IETF
• IPPM Reporting MIB
• Presented during 51st IETF
• WG Item after 53rd IETF
• Current version 04
• IPPM metrics Registry
• Requested by RMON WG
• WG last call done
• ITU
• O.Iptest
• SG4 draft of IP test packet

5
Data model

• PointOfMeasureTable
• NetMeasureTable
• SynchronizationTable
• HistoryTable
• MetricTable

Owners
MetricTable

• OwnersTable

• AggrMeasureTable
• ReportSetupTable

• ReportTable
• Notifications

6
Managing Heterogeneity

• Architecture of an IPPM Proxy

Measurement system
IPPM Reporting MIB proxy
C O N T R O L L E R
ReportSetupTable
READ/ CREATE
AggrMeasureSetupTable
SynchronisationTable
S N M P
probe
pointOfMeasureTable
probe
V A C M
probe
NetworkMeasureTable
probe
READ/ ONLY
History Table
Reportable
Notifications
Results
Control
7
Owner namespace

• Owner assigned indexes
• Owner Name
• Owner instance Index
• Distributed naming
• Same identifier for a measure on IPPM proxies
• For aggregated measure and setup
• Interdomain unambiguous naming

8
IPPM Metrics Registry

• IPPM Metrics Registry
• IPPM metrics
• RFC2678-2681
• RFC3148, RFC3357
• RFC3393 RFC3432
• Template for future IPPM metrics
• Distributed metric measure index

9
Measures sharing control VACM

• VACM Access list
• Who, from, session,action, object, instance
• Which sub tree an user can access ?
• Usage
• Aggregation
• Reporting
• Sharing results
• Measurement peering

10
Aggregation IppmAggrTable

• Aggregation of
• Network measures
• Aggregated measures
• Sharing measures
• Name spaces
• Fast reporting
• Maintenance
• Troubleshooting

11
SLA monitoring ippmReportTable

• Backgroup monitoring
• Metrics thresholds
• UpAndDown lt gt in out
• Exceeded Duration
• Errored periods
• Report
• Locally or remotely
• On event
• On Measure cycles

12
Interdomain measure ITU O.iptest

• Packet Signature
• Any Type-P IP, IPv6
• Sqce , Timestamp
• 3 optional IE
• CRC32,
• timestamp bar,
• Interdomain
• Interdomain IE
• IPPM Reporting MIB
• OwnerID MeasureID
• Carrier class results

13
Intra/inter domain correlation issues

• Need
• Correlate intra and interdomain results
• Report
• One solution
• Concatenation of intra domain measure
• Decomposition of e2e inter domain measure
• Missing
• Standard spatial metrics

Interdomain Net.Bar.5.6(AG) Intradomain
Net.rootX.9.6(AB)
Net.rootZ.7.6(HJ)
Net.rootY.5.6(FG) Concatenation AGAB HJ FG
Spatial.Foo.18.?(AG) rootX.9 rootY.5
rootZ.13 Decomposition AJ AG - FG
Spatial.Foo.19.?(AJ) Net.Bar.5.6 - Net.rootY.5.6
Management
Domain Z
Network
Domain Y
Domain X
A-G probes
O.iptest packet
Test packets
14
Conclusion

• Measure sharing security with SNMPv3/VACM
• Measurement peering with IPPM Proxies
• Statistical e2e interdomain QoS monitoring
• True e2e interdomain QoS monitoring with O.iptest
• Standardization of spatial metrics is required
• Concatenation of e2e intra domain measures
• Correlation of intra and interdomain e2e measures

15
References

• IPPM Reporting MIB IPPM metrics Registry
• http//www.ietf.org/html.charters/ippm-charter.htm
  l
• Spatial metric draft
• http//www.ietf.org/internet-drafts/draft-stephan-
  ippm-spatial-metrics-01.txt
• O.iptest
• http//www.itu.int/ITU-T/studygroups/com04/index.a
  sp
• IPPM proxy Implementation demo
• Implemented by FT RD
• 6QM IST project at IPv6 Global submit 2003
• http//www.ipv6-es.com/03/documents/demos_gis2003.
  pdf
• Industrialized in QosMetrix measurement system
