Microprogrammed Control Unit Design

1
Chapter 7

• Micro-programmed Control Unit Design

2
Micro-Programmed Control Unit

• A hard-wired control unit uses logic to generate
  the control signals needed to implement the
  different microoperations and their sequence.
• A Micro-Programmed control unit utilizes a memory
  (typically ROM) to store these signals in the
  form of a micro-program.

3
Micro-Program

• The micro-program consists of micro-instructions
  that specify the internal control signals for
  execution of microoperations.
• Each machine instruction initiates a sequence of
  micro-instructions in control memory.
• The micro-instructions generate the control
  signals needed to implement the different
  micro-operations of the machine instruction.
• The micro-instructions also control the
  sequencing of the operations.

4
Micro-Programmed Control Unit

• The set of micro-instructions are stored in the
  Control Memory
• The Control Address Register contains the address
  of the next micro-instruction to read
• When a micro-instruction is read, it is
  transferred to a Control Data Register.
• The Sequencing Logic determines the address of
  the next micro-instruction.

Sequencing Logic
Control Address Register
Control Memory
External inputs
Control Data Register
Control Word
5
Reason for Micro-programmed Control

• The implementation of a control unit as an
  interconnection of basic logic elements is no
  easy task
• The design must include logic for
• Sequencing through microoperations.
• Executing microoperations.
• Interpreting opcodes.
• Making decisions based on ALU flags.
• It is difficult to design and test such a system.
• The design is also quite inflexible.

6
Micro-Programming

• The number of different types of micro-operations
  in a given system is finite
• The complexity comes from the numerous sequences
  of micro-operations that are performed
• Micro-programming is an easier and more
  systematic way of generating the sequences of
  micro-operations for the execution of each
  instruction.

7
Micro-Programming

• In a micro-programmed control unit, each time
  cycle is represented by a bit pattern of 0s and
  1s for the different control signals generated in
  the control unit.
• Executing an instruction becomes simply going
  through the correct sequence of these bit
  patterns.
• The bit patterns representing the time cycles are
  stored in the control memory.

8
Control Word and Micro-Instruction

• For each micro-operation, the control unit simply
  generates a set of control signals.
• We can construct a Control Word in which each bit
  represents one control line.
• Each microoperation can be represented by a
  different pattern of 1s and 0s in the control
  word.
• Each control word forms a Micro-Instruction which
  specifies one or more microoperations.
• Each micro-instruction has an address in
  micro-memory.

9
The Micro-Instruction

• The micro-instruction needs to supply two pieces
  of information
• The control signals to control the hardware.
• Which micro-instruction to execute next.
• These two operations have a large effect on the
  size of the control memory as well as the
  complexity of the control unit as a whole.
• First, lets consider the second item, how to
  sequence the micro-instructions.

10
Micro-Instruction Sequencing

• Each machine instruction will be represented by a
  group of micro-instructions in the form of a
  routine.
• For example, the ADD to AC routine
• T0 AR ? PC
• T1 IR ? MAR, PC ? PC 1
• T2 Decode
• D7IT3 AR ? MAR
• D1T4 DR ? MAR
• D1T5 AC ? AC DR, E ? Cout, SC ? 0

11
Micro-Instruction Sequencing

• However, there are microoperations common to all
  instructions
• Fetch, decode, effective address calculation,
  etc.
• It does not make sense to repeat these for each
  different instruction.
• The control unit must allow for these common
  operations to be grouped together and accessed
  from the different instructions routines.
• Therefore, the instruction routines will include
  only micro-instructions unique to the specific
  instruction.

12
Overall View of Control Memory
. Jump to Indirect or Execute
Fetch cycle routine
. Jump to Execute
Indirect Cycle routine
. Jump to Fetch
Interrupt cycle routine
Jump to Op code routine
Execute cycle begin
. Jump to Fetch or Interrupt
AND routine
. Jump to Fetch or Interrupt
ADD routine
. . .
etc
13
Execution Micro-Cycle

• The address of the first micro-instruction of the
  fetch routine is loaded into the control address
  register.
• The micro-operations of the fetch cycle are
  sequenced by incrementing the control address
  register.
• By the end of the fetch routine, the instruction
  has been read into the Instruction Register (IR).
• The instruction may specify one of different
  addressing modes. The control unit must decide
  how to calculate the effective address based on
  the addressing mode.
• Conditional branch based on addressing mode

• After completing effective address calculation,
  the effective address of the operand is now in
  the Address Register (AR)
• The next step depends on the opcode stored in IR.
  The opcode must be mapped into a control memory
  address for the routine that implements the
  specific instruction.
• The micro-instructions of the routine are
  sequenced either through incrementing the control
  address register or through conditional branching
  based on values of status flags.
• At the end, an unconditional branch brings the
  execution back to the fetch routine.

14
Sequencing of Micro-Instructions

• After a certain micro-instruction is executed,
  the control unit needs to decide what
  micro-instruction to execute next
• It might be the next one.
• It might be somewhere else in micro-memory.
• Micro-Jump.
• It might depend on the value of external flags.
• Micro-Conditional Jump.
• The hardware that implements the sequencing must
  be capable of sequencing the micro-instructions
  within a routine as well as branching from one
  routine to another.

15
Determining Next Address

• Typically, each micro-instruction contains some
  bits that specify the method by which the next
  address is obtained.
• The micro-instruction can be divided into several
  fields
• Control signals.
• Conditions for conditional branching.
• Branch address field(s).

Control Signals
Address
Conditions for branching
16
Address Sequencing Logic
Instruction Code
Mapping Logic
Branch Logic
Multiplexer
MUX Select
Subroutine Register
Control Address Register
mProc. Status bits
Incrementer
Control Memory
Condition Bits
Microoperations
Branch Address
17
Mapping of Instructions

• It was mentioned that each machine instruction
  will be implemented using a routine of
  micro-instructions.
• How does the mapping between the instruction and
  the routine occur?
• Manipulating the OPCODE bits.
• Using a mapping memory.

18
Manipulating the OPCODE

• If most machine instructions require about the
  same number of micro-instructions to implement,
  we can use the OPCODE of the machine instruction
  plus some additional bits to form the address of
  the first micro-instruction in the routine.

Machine instruction OPCODE
1 0 1 1
Extra bits
0 0 0
Address of first micro-instruction In the machine
instructions routine
1 0 1 1 0 0 0
19
Using a Mapping Memory

• It is also possible to add a small address
  look-up memory inside the control unit.
• The OPCODE of the machine instruction is used to
  look-up the address of the first
  micro-instruction in its routine.

1 0 1 1 0 0 0
1 0 1 1
1 0 1 0 0 0 1 0 0 0 0 1 0 1 0
Instruction OPCODE
Lookup Memory
Control Memory
20
Using a Mapping Memory
Control Memory
1 0 1 0 0 0 1 0 0 0 0 1 0 1 0 1 1 1 0 0 0 0 0 0 1
0 0 0 0 1 0 0 0 0 0 0 0 1 1 0 0 0 0 0 0 1 1 0 0 0
0 1 0 0 1 1 0 0 0 0 1 1 1 0 0 0 0 1 0 0 0 1 1 0
0 0 0 0 0 0 0 0 1 1 0 0 0 0 0 0
1 0 1 1 0 0 0 1 0 1 1 0 0 1 1 0 1 1 0 1 0 1 0 1 1
0 1 1 1 0 1 1 1 0 0 1 0 1 1 1 0 1 1 0 1 1 1 1 0
ADD Routine
Lookup Memory
OR Routine
1 0 1 1 0 0 0
ADD
OR
1 0 1 1 0 1 1
AND
1 0 1 1 1 1 0
21
Control Unit Organization
Instruction Register
Sequencing Logic
Control Address Register
ALU Flags
Control Memory
Control Buffer Register
Control Logic
Control Signals
22
Vertical vs. Horizontal

• Horizontal Micro-Instruction
• A micro-instruction format that has a bit
  dedicated to each control signal being generated.
• Large number of bits, very wide format.
• Large (slow) control memory.
• Control signals immediately available in control
  word.
• Vertical Micro-Instruction
• A micro-instruction that combines multiple
  control signals into encoded fields.
• Smaller number of bits, narrower memory.
• Control memory is faster.
• Need additional hardware to decode the fields.

23
Micro-Instruction Encoding

• The control signals generated by the control unit
  form natural groups that are mutually exclusive.
• For example, the control signals for AR will
  never be active at the same time.
• It is possible to make use of this natural
  feature and encode these mutually exclusive
  signals into fields.
• Once the micro-instruction is read from the
  control memory, these fields will be decoded to
  retrieve the original signals.
• The advantage is a smaller control memory.

24
Micro-Instruction Encoding

• The micro-instruction is divided into fields of
  related and mutually exclusive operations.
• The bits of the fields are passed to decoders to
  generate the individual control signals.
• The different fields of the micro-instruction
  must specify operations that can occur
  simultaneously.

25
Rules for Encoding

• The signals grouped into a field must be mutually
  exclusive.
• No two signals in the group can occur at the same
  time.
• The group must include a none of the above
  case.
• To allow for none of the signals being active.
• The signals grouped into different fields may
  occur simultaneously.

26
Example

• Lets design a micro-programmed control unit for
  our example processor.
• We will use a vertical micro-instruction format
  with a single address field.
• Most common format.
• The format also must include a condition field
  and a branch field.

27
Determining the Control Signals

• First, we need to review the RTL description and
  group the operations according to the two rules
  mentioned earlier.
• We need to look at the control signal level, not
  just the micro-operation level.
• As an example, the following microoperation
• AC ? AC DR
• translates into the following three control
  signals
• AC_LD, ALU_ADD, and Bus control to select DR
  output.

28
Example

• The following is a list of all of the control
  signals

• ALU_AC_CCOMP
• ALU_E_COMP
• ALU_SHR
• ALU_SHL
• ALU_AND
• ALU_ADD
• Note There is no need for a sequence counter
  therefore, its signals are removed.

• DR_CLR
• IR_LD
• TR_LD
• TR_INC
• TR_CLR
• OUTR_LD
• R_SET
• R_RST
• IEN_RST
• IEN_SET
• E_RST
• S_RST
• FGI_RST
• FGO_RST

• S0, S1, S2
• MEM_RD
• MEM_WR
• AR_INC
• AR_LD
• AR_CLR
• PC_INC
• PC_LD
• PC_CLR
• AC_LD
• AC_INC
• AC_CLR
• DR_LD
• DR_INC

29
Example

• A total of 34 control signals
• They can be grouped based on resource
• The signals for the AC together, etc.
• They can be grouped based on exclusivity
• The signals that can never occur together in one
  group.
• For our example, if we use the first approach we
  will have 17 groups
• BUS MUX, memory, AR, PC, AC, DR, IR, TR, OUTR, R,
  IEN, AC, ALU, E, S, FGI, and FGO.

30
Example

• However, given the RTL code, we can group some of
  the smaller groups together to further reduce the
  size of the memory.
• For example, the OUTR_LD and FGO_CLR signals
  always occur together. They can be stored as one
  signal.
• The IR_LD occurs only once in the entire code. It
  can be coded with some other group.
• As long as the group does not contain PC_INC.

31
Control Signal Grouping

• We can reduce the groups to
• Group 1
• S0, S1, S2
• 3 bits
• Group 2
• AR_INC, AR_LD, AR_CLR
• PC_INC, PC_LD, PC_CLR
• E_RST
• NOP
• 3 bits

32
Control Signal Grouping

• Group 3
• AC_INC, AC_LD, AC_CLR
• DR_INC, DR_LD, DR_CLR
• IR_LD
• NOP
• 3 bits
• Group 4
• MEM_RD, MEM_WR
• TR_INC, TR_LD, TR_CLR
• R_RST, R_SET
• NOP
• 3 bits

33
Control Signal Grouping

• Group 5
• ALU_AC_COMP, ALU_E_COMP, ALU_SHR, ALU_SHL,
  ALU_AND, ALU_ADD
• OUT_LD
• NOP
• 3 bits
• Group 6
• IEN_RST, IEN_SET
• S_RST
• FGI_RST
• FGO_RST
• 2 NOP
• 3 bits

34
Control Signal Grouping

• The result now is 6 groups of 3 bits each.
• Total is 18 bits for the control signals.
• Compare this to a total of 34 bits for pure
  horizontal format
• Compare it with 17 groups for simple encoding.
• The next step is to assign a code for each of the
  signals in each of the groups.
• Simple, straight forward.

35
The Micro-Instruction Format

• So far, we can draw the following as the starting
  point of our micro-instruction
• As a result of this format, the control unit must
  include 6 3-to-8 decoders to decode the fields
  into the original individual signals.

GRP4
GRP5
GRP6
GRP1
GRP2
GRP3
Next Address Information
36
Example Microinstruction

• Using the previous format, the signal part of the
  following microinstruction
• IR ? MAR, PC ? PC 1
• is represented by
• 111 100 111 001 000 000 ------------
