Title: PHOTOSYNTHESIS


1
PHOTOSYNTHESIS
2
IMPORTANCE OF PHOTOSYNTHESIS
  • Uses energy from sunlight to convert CO2 to
    sugars
  • Supplies usable chemical energy for life on Earth
  • CO2 H2O C6H12O6 O2

3
THE LEAF
  • The leaf is a food supply factory
  • Adapted to maximize light absorption and CO2
    diffusion
  • see page 159

4
PARTS OF THE LEAF
  • Upper Lower Epidermis
  • a single layer of cells covering the upper and
    lower leaf
  • Cuticle
  • a waxy secretion that forms a water repellent
    covering

5
  • Mesophyll
  • middle layer of cells
  • cells loaded with chloroplasts
  • Palisade layer single layer just below upper
    epidermis
  • Spongy Layer contains air spaces which act as
    CO2 and H2O reservoirs

6
  • Stomates
  • minute pores in epidermis
  • gases move in and out of the leaf through
    stomates
  • a pair of guard cells controls the opening and
    closing
  • when guard cells swell with water, the stomates
    open
  • stomates close when guard cells lose water

7
CHLOROPLAST
  • See page 161
  • Outer membrane regulates movement of materials
    into and out of the chloroplast

8
  • Internal Membrane System
  • Thylakoids
  • flattened disc
  • increase surface area
  • contains light absorbing pigments

9
  • Grana
  • stacked thylakoids
  • allows maximum absorption of sunlight

10
  • Stroma
  • pale, semifluid substance

11
PLANT PIGMENTS
  • Chlorophyll
  • green pigment
  • present in two forms - a and b
  • chlorophyll absorbs light
  • Accessory Pigments
  • carotene - orange
  • xanthophyll - yellow

12
RATE OF PHOTOSYNTHESIS
  • Light Intensity
  • increases photosynthesis
  • until saturation point
  • Temperature
  • increases photosynthesis
  • until enzymes become denatured

13
  • O2 and CO2 Concentration
  • increase CO2, increase rate
  • increase O2, decrease rate
