The Massachusetts Concrete

1
(No Transcript)
2

The Massachusetts Concrete Aggregate Producers
Association

• Members Meeting
• Kens Stake house
• Framingham Ma
• January 29. 2009

3

Recycled Concrete
By David Gress Recycled Materials Resource
Center Department of Civil Engineering Univers
ity of New Hampshire

4
Acknowledgements

• Federal Highway Administration
• Recycled Materials Resource Center

5
Recycled ConcreteWhat is it?

• NCHRP 4-21
• Demolition by-product of old concrete structures
• Roadways
• Sidewalks
• Foundations
• Retaining Walls
• Concrete Pipe
• Roadway Medians
• Catch Basins
• etc
• Properly processed can be used as a substitute
  aggregate material
• ACI 116
• Hardened concrete that has been processed for
  reuse, usually as aggregate

6
Recycled Aggregate Products

• Road Base
• Dry Screened Rock
• Structural Backfill
• Landscape Stone
• Vehicle Tracking Rock
• Trail Surfacing

• Ready Mixed Concrete
• Top soil amendments
• Under Slab Bedding
• Drainage Rock
• Stackable Landscape Stone
• Pipe Bedding

7
Architectural Uses
8
Pavement Uses

• I 84 Waterbury Connecticut

9
Pavement Uses

• SR 59 Minnesota
• Doweled and Ground

10
Structural Use
Enterprise Park Building Denver 8,000- yd3
11
Where Do We Get It?

12
Does Source Matter?YES

• Aggregate size/properties
• Cement type, W/C
• Air entrained
• Distress (D cracking, ASR, freeze thaw damage,
  sulfate attack)
• Environmental exposure
• Type of structure
• May contain contaminants (soil and asphalt)

13

Opportunity or mess, where do you begin?
14

Conventional equipment works
15
RCA Stockpiles Ready for use
16
Denvers Stapleton International Airport

• Opened in 1929
• Closed 66 years later (1995)
• Concrete averaged 24 inches thick
• Covering 975 acres
• 6.5 million tons of aggregate recycled
• Worlds Largest Recycling Project
• Enough aggregate to build the Hoover Dam, and at
  no cost to the city of Denver!

17

A Recycling Pioneer
18
How did they do it? 13,000 Guillotine

Capable of Crushing gt30 of pavement
19
Crusher Feed Stock
20
Steel is magnetically removed and sold for scrap

21
RCA Base Course
22
Construction Materials Recycling Association
Estimates

• More than 140 million
• Tons per Year are produced in the US
• http//www.cdrecycling.org/

23
Physical Properties

• Grading (Same as conventional)
• Specific Gravity (increases with size 2.0-2.5)
• Shape (more angular, good)
• Texture (rougher, good)
• Moisture Content (higher due to absorption)
• Compacted Density (optimum w higher)
• Absorption (decreases with size, 8 to 2)

24
Mechanical Properties

• Strength (CBR 90 to 140) Equal
• Abrasion Loss (LAB 20 to 45) Increases
• Soundness (NaSO4 test not valid)

25
Chemical Properties

• pH gt 11 (no buffering capacity but corrodes
  aluminum)
• ASR (possible but can be mitigated)
• Tufa (white powdery precipitate)
• Salt (from deicing salts)

26
Deleterious Materials

• Soil
• Asphalt concrete
• Brick
• Solid waste and hazardous materials
• Wood, metal, plaster and gypsum

27
Application and Performance

• Portland Cement Concrete (equal)
• Hot Mix Asphalt (absorption of asphalt )
• Embankment or Fill (added value maybe too high
  for use)
• Miscellaneous Aggregate (equal to or better)
• Granular Base (equal to better)

28

Benefits

• Comparable to conventional aggregate
• Can be very cost effective (1/2 /-) especially
  in urban areas
• Increases life of landfills
• Preservation of natural aggregates
• Environmentally Green

29

Obstacles

• Need a specification for use
• Must recognize differences
• Q/C Q/A
• Education/learning curve
• Commitment to use must be made

30

Future Recycling of Concrete

• Increased quantity of RCA will come primarily
  from non-DOT sources
• 85 of PCC is owned by private, municipal or
  county agencies
• Need exists for standards and specifications to
  control quality of RCA obtained from multiple
  sources

31

RCA Web Sites

• Recycled Materials Resource Center
• http//www.rmrc.unh.edu
• Federal Highway Administration
• http//www.fhwa.dot.gov/pavement
• Environmental Council of Concrete Organizations
  (ECCO)
• http//www.ecco.org
• King County, Washington
• http//www.metrokc.gov/procure/green/concrete.htm

• Recycled Materials Company, Inc.
• http//www.rmci-usa.com
• Portland Cement Association
• http//cement.org

32

33
P

PaLATE
Pavement Life-cycle Assessment Tool for
Environmental and Economic Effects Developed by
the University of California, Berkley for RMRC
34
WWW.RMRC.unh.edu

• A computer based decision support tool to
• model economic costs and environmental
• effects of using traditional highway
  materials and recycle materials for highway
  applications.
• Audience Pavement designers and engineers,
  transportation agency decision-makers, civil
  engineers, and researchers

35
Environmental Output Data

• Energy MJ
• Water Consumption kg
• CO2 Mg emissions Global Warming Potential
  (GWP)
• NOx kg emissions
• PM10 kg particulate emissions
• SO2 kg emissions
• CO kg emissions
• Hg g emissions
• Pb g emissions
• RCRA Hazardous Waste Generated kg
• Human Toxicity Potential (Cancer)
• Human Toxicity Potential (Non-cancer)

36
Environmental Output Resultsfor Initial
Construction and Maintenance

• Materials
• Production
• Transportation
• Processing

37
Example for Carbon Footprint Comparison

• Interstate Highway 4 lanes separated with 4 and
  10 paved shoulders 1 mile long
• PCC 12 thick on 10 base
• PCC shoulders 6thick on 6 base

38
Cases evaluated

• Case 1 New construction
• Case 2 Recycle Case 1 as unbound base
• Case 3 Case 1 recycled into concrete

39
Case 1 New Construction

40
Case 1 New Construction

41
Case Comparison

42
CO2 Release New Construction vs. Unbound Base
and Recycled Concrete

43
Conclusions

• Recycling Concrete significantly reduces the
  Carbon Footprint
• Using RCA in Concrete reduces the Carbon
  Footprint more than when used as Unbound Base
