Title: Receiver Structures


1
Receiver Structures
  • Jörgen Nordberg
  • (School of Engineering)
  • Blekinge Institute of Technology

2
Outline
  • Wireless Communication
  • ISI
  • Multipath Channel
  • Co-channel Interference
  • Receiver structures
  • Temporal Receivers
  • Spatial Receivers
  • Spatio-Temporal Receivers

3
Wireless Communication(Intersymbol Interference)
  • Strict system bandwidth requirements
  • Intersymbol Interference.

4
Wireless Communication(Multipath Propagation)
  • Reflections will cause the receiving antenna to
    receive multiple version of the transmitted
    signal, i.e. multipath propagation.

5
Wireless Communication(Multipath Propagation)
  • The multipath propagation is illustrated by the
    channel impulse response

6
Wireless Communication(Multipath Propagation)
  • Important channel characteristic
  • Coherence time
  • Coherence bandwidth
  • Doppler Spread
  • Delay Spread

7
Wireless Communication(Co-Channel Interference)
  • Co-Channel interference is caused by several
    users transmitting on the same frequency.

8
Wireless Communication(Co-Channel Interference)
  • Avoided or reduced by frequency planning in 1G
    and 2G systems (reuse distance)
  • Introduced on purpose in 3G systems, all users in
    each cell transmits on the same bandwidth
    (code-planning)

9
Wireless Communication(Interference)
  • Frequency leakage from other systems, that do not
    control their bandwidth usage, i.e. RF background
    noise, huge problem for radio-physics (deep space
    exploration)
  • Using a system operating in the unlicensed
    frequency bands, i.e. Bluetooth.

10
Receiver Structures
11
Receiver Structures(Contents)
  • Why?
  • Temporal Receivers
  • Spatial Receivers
  • Spatio-Temporal Receivers

12
Receiver Structures(Why?)
  • To reverse or reduce the effects of the wireless
    channel some kind of receiver structure must be
    used.

13
Receiver Structures(Temporal Receivers)
  • Using temporal information/diversity to recover
    the original transmitted signal
  • Channel Equalization
  • (Inverse filtering)
  • Rake Receivers
  • (Multipath alignment)

14
Receiver Structures(Channel Equalization)
  • In channel equalization the wireless-channel is
    modeled as a Finite Impulse Response (FIR) filter
    and the receiver tries to recover the original
    transmitted signal through inverse channel
    filtering.

15
Receiver Structures(Channel Equalization)
  • There are several inherit problems with inverse
    filtering
  • Noise amplifications (solved by doing FIR
    estimation)
  • Even a few multipath components results in
    estimations of high order filter, i.e. hundreds
    of taps.
  • Computationally complex
  • Convergence problems

16
Receiver Structures(Temporal Receivers)
  • Reducing the computationally complexity in the
    receiver by using multirate (or subband)
    techniques.
  • The received signal is split up into M different
    frequency bands and decimated with a factor D.
  • The inversing filtering problem is then solved in
    each subband.
  • There are two basically two multirate approaches

17
Receiver Structures(Temporal Receivers, Channel
Equalization, Subband Technique 1)
  • Complexity reduction
  • Straightforward implementation
  • Aliasing problems gt complicated filter bank
    design
  • Large processing delay

18
Receiver Structures(Temporal Receivers, Channel
Equalization, Subband Technique 2)
19
Receiver Structures(Temporal Receivers, Channel
Equalization, Subband Technique 2)
  • Complexity reduction
  • Complicated implementation
  • Parallel processing
  • Less aliasing problems gt moderate filter bank
    design complexity
  • Small processing delay

20
Receiver Structures(Temporal Receivers, Adaptive
Channel Equalization)
  • Adaptive Channel Equalization
  • (Time variant channel)
  • Non-blind Techniques, uses pilot/training
    sequences to estimated the channel.
  • (LMS, RLS)
  • Blind Techniques, using pre-know signal
    characteristics to restore the original
    transmitted signal.
  • (CMA)

21
Receiver Structures(Temporal receivers, Rake
Receivers)
  • Using multipath propagation to get diversity
    gain.
  • Each path is time aligned
  • The signal is multiplied with the complex
    conjugate of the channel coefficient .
  • The different paths are then summed together.
  • Require good estimates of the both path delay and
    amplitude attenuation, i.e. good channel
    estimation.

22
Receiver Structures(Temporal receivers, Rake
Receivers)
23
Receiver Structures(Spatial Receivers)
  • Spatial Receivers uses the fact that the target
    signal and interfering signals are transmitted
    from different spatial points.
  • Uses multiple receiving antennas in order to
    suppress interfering signals.
  • Spatial Diversity
  • Sector Antennas
  • Adaptive Antennas
  • Signal Separation (blind/non-blind)

24
Receiver Structures(Spatial Receivers, Spatial
Diversity)
  • The power of the received signal will vary with
    time (signal fading) due to reflections,
    shadowing etc.
  • The fading minima in the received signal can be
    avoided, by appropriate antenna separation.

Antenna 1
Antenna 2
25
Receiver Structures(Spatial Receivers, Sector
Antennas)
  • Another way to exploit the spatial domain is to
    weight the different received signals together, a
    beamforming approach.
  • By using beamforming the antenna array can be
    steered to listen in a certain direction and
    ignore signals from other directions.

26
Receiver Structures(Spatial Receivers, Sector
Antennas)
  • Each sector area is covered by a beam/lobe.
  • Beam/lobe handover

27
Receiver Structures(Spatial Receivers, Sector
Antennas, PIERS)
28
Receiver Structures(Spatial Receivers, Signal
Separation)
  • A signal separator is a unit that uses M antennas
    to separate a mixture of N independent signals (N
    lt M).
  • The signal separator can be viewed as a
    beamformer that creates a beam towards each
    source signal.
  • There exist both blind and non-blind signal
    separation
  • Least Squares, RLS, LMS using training
    sequences
  • ICA using higher order statistics

29
Receiver Structures(Spatial Receivers, Signal
Separation)
30
Sector Antennas combined with Signal Separation
Beam-former
31
Receiver Structures(Spatial Receivers, Adaptive
Antennas)
  • In Adaptive Antennas (or smart antennas)
    solution, the user is handled by one beam only
    during the users stay in the cell.
  • The beamformer must be able to track the user, in
    order to steer the beam towards the user, i.e.
    Direction Of Arrival (DOA) estimation.
  • NO beam-handoffs !!!
  • Signal separation can be viewed as a kind of
    smart antennas.

32
Receiver Structures(Spatio-Temporal Receivers)
  • Temporal receivers, can reverse the effect of
    multipath propagation but not the effects of
    co-channel interference.
  • Spatial Receivers can take care of co-channel
    interference but cannot handle the effects of
    multipath propagation.
  • By combining the two approaches in a Spatio
    Temporal Receiver both co-channel interference
    and multipath propagation effects can be dealt
    with.

33
Receiver Structures(Spatio-Temporal Receivers)
  • Combining spatial diversity and channel
    equalization results in a spatio-temporal channel
    equalizer.

Equalizer
Equalizer
34
Spatial Channel Equalization( The NEWTEST
project)
W1
W2
Estimation Algorithm
35
Spatial Channel Equalization (Results from the
NEWTEST project)
  • By using just one extra antenna at the receiver a
    6-7 dB gain was achieved in Symbol Error rate
    (SER) performance over the one antenna case.
  • By using a fractionally spaced (oversampled)
    spatial equalizer the SER performance was
    improved with 4 dB compared to the symbol rate
    case.

36
Receiver Structures(Spatio-Temporal Receivers)
  • Adding a temporal domain to the signals
    separation approach.

Signal Separation
37
Signal Separation using Multi-rate Signal
Processing (ICOTA)
38
Signal Separation using Multi-rate Signal
Processing (Results from ICOTA)
