Query Optimization
2
Example
emp(name, age, sal, dno) dept(dno, dname, floor,
budget, mgr, ano) acnt(ano, type, balance,
bno) bank(bno, bname, address)
select name, floor from emp, dept where emp.dno
dept.dno and sal gt 100K
3
Example
Number of emp pages 20000 Number of emp
tuples 100000 Number of emp tuples gt
100K 10 Number of dept pages 10 Number of dept
tuples 100 Indices of emp clustered Btree on
emp.sal (3 levels deep) Indices of
dept clustered hashing on dept.dno (average
bucket length of 1.2 pages) Number of buffer
pages 3 Cost of one disk access 20ms
4
Example
Plan 1 Use the B tree to find all tuples of emp
that satisfy the selection For each one, use the
hashing index to fond the corresponding dept
tuples (nested loops, using the index on both
relations.
(3 1 10 1.2) blocks 20ms/block 0.32 sec
5
Example
Plan 2 For each dept page, scan the entire emp
relation, If an emp tuple agrees on the dno
attribute with the tuple on the dept page that
satisfies the selection on emp.sal then the
emp.dept tuple pairs appears in the
result (page-level nested loops, using no index
(10 10 20000) blocks 20ms/block 1h
6
Example
Plan 3 For each dept tuple, scan the entire emp
relation and store all emp-dept pairs Then, scan
this set, for each one check if it has the same
values in the two dno attributes and satisfy the
selection on emp.sal (tuple-level formation of
the cross product, with subsequent scan to test
the join and the
(3 100 20000) blocks 20ms/block 1 day
7
Overview
Query language (SQL)
Embedded queries
Query Parser
Relational Calculus
compile time
Query Optimizer
Relational and Physical Algebra
Code Generator/Interpreter
Record-at-a-time calls
Query Processor
run time
8
Overview of Query Optimizer
Applies transformation (static)
Rewriter
Rewriting Stage (declarative)
Specifies the arithmetic formulas used to
estimate the cost of execution plans
Planning Stage (procedural)
Cost Model
Planner
Algebraic Space
Examines all possible plans for each query
produced in the previous stage (through a search
strategy to examine the space of execution plans)
Execution orders to be consider by the planner
Size-Distribution Estimator
Method-structure space
Implementation choices for the execution of each
ordered series of actions
9
Overview of Query Optimizer
Rewriter
Cost Model
Planner
Algebraic Space
Size-Distribution Estimator
Method-structure space
10
Algebraic Space
Rewriter
Cost Model
Planner
Algebraic Space
Size-Distribution Estimator
select-project-join (SPJ) represented as a
tree Enormous number of trees
Method-structure space
11
Algebraic Space
select name, floor from emp, dept where emp.dno
dept.dno and sal gt 100K
Trees of Plan 1, Plan 2, Plan 3 (pg 10)
12
Algebraic Space
Restriction 1 Selections and projections are
processed on the fly and almost never generate
intermediate relations. Selections are processed
as relations are accessed for the first time.
Projections are processed as the results of other
operators are generated.
NOTE P1 satisfies R1 R1 eliminates only
suboptimal query trees, thus the algebraic space
module specifies only alternative query tees with
join operations only (selection and projection
being implicit)
13
Algebraic Space
R1 join R2 ? R2 join R1 which relations inner and
which outer (R1 join R2) join R3 ? R1 join (R2
join R3) order in which joins are executed
Large number gt need to further restrict
Restriction 2 Cross products are never formed,
unless the query itself asks for them. Relations
are combined always through joins in the query.
14
Algebraic Space
select name, floor, balance from emp, dept,
accnt where emp.dno dept.dno and dept.ano
acnt.ano
3 Trees (pg 11)
R2 almost always eliminates suboptimal query
trees, thus the algebraic space module specifies
only alternative query tees that do not involve
cross products
15
Algebraic Space
Restriction 3 The inner operand of each join is a
database relation, never an intermediate result
select name, floor, balance, address from emp,
dept, accnt, bank where emp.dno dept.dno and
dept.ano acnt.ano and act.bno bank.bno
3 Trees (pg 13) T1 satisfies R3
16
Algebraic Space
left-deep (inner being a database relation)
right-deep (outer being a database relation,
bushy (at least one join between two intermediate
results)

• Why left-deep
• Having original database relations as inners
  increases the use of any pre-existing indices
• Having intermediate relations as outers allows
  sequences of nested loops joins to be executed in
  a pipelined fashion (although right-deep favors
  sequence of hash joins)

17
Algebraic Space
R3 significantly reduces the number if
alternative join trees, thus the algebraic space
module of the typical query optimizer only
specifies join trees that are left-deep.
In summary, typical query optimizers make
restrictions R1, R2 and R3 to reduce the size of
the space they explore
18
Planner
Rewriter
Algebraic Space
Cost Model
Planner
Method-structure space
Explores the set of alternative execution plans
as specified by the algebraic space and the
method-structure space and find the cheapest one
as determined by the cost model and the size
distribution estimator
Size-Distribution Estimator
19
Planner
Dynamic Programming
A dynamically pruning exhaustive search
algorithm Constructs all alternative join trees
(that satisfy R1-R3) by iterating on the number
of relations joined so far, always pruning trees
that are known to be suboptimal
Merge scan - if one is sorted on its join
attribute the sorting step may be skipped gt take
into account the sorted order (if any) in which
the result comes out Interesting orders orders
of intermediate results on any relation
attributes that participate in joins
20
Planner dynamic programming
Step 1
For each relation in the query, all possible way
to access it (i.e., via all existing indices
sequential scan) are obtained Partition these
partial result (single-relation) into equivalence
classes based on any interesting order in which
they produce their result) Estimate the cost (by
the cost model module) and retain the cheapest
plan in each equivalence class (except of the
no-order class if it is not the cheaper one)
21
Planner dynamic programming
Step 2
For each pair of relations joined in the query,
all possible ways to evaluate their join using
the relation access paths retained after Step 1
are obtained. Partition and pruning of these
partial (two-relation) plans as above
22
Planner dynamic programming
Step i
For each set of i -1 relations joined in the
query, the cheapest plans to join them for each
interesting order are known from the previous
step. For each such set (of i- 1 relations
joined), all possible ways to join one more
relation with it without creating a cross product
are evaluated For each set of i relations joined,
all generated (partial) plans are partitioned and
pruned as before.
23
Planner dynamic programming
Step N
All possible plans to answer the query (the
unique set of N relations in the query) are
generated from the plans retained in the previous
step. The cheapest plan is the final output of
the optimizer, to be used to process the query.
24
Planner dynamic programming
Finds the optimal plan among those satisfying
restrictions R1-R3. In general, exponential with
the number of joins (N) since in the worst case
all viable partial plans must be stored in each
step. In practice, usually O(N3) Many systems
limit the number of joins (15)
See detailed example in the paper
25
Planner randomized algorithm
Randomized Algorithms (algorithms that flip coins
to make decisions) Operate by searching a graph
whose nodes are all the alternative execution
plans that can be used to answer a query. Each
node has a cost associated with it, and the goal
of the algorithm is to find a node with the
globally minimum cost Randomized algorithms
perform random walks in the graph via a series of
moves.
26
Planner randomized algorithm
Randomized algorithms perform random walks in the
graph via a series of moves. The nodes that can
be reached in one move from a node S are called
the neighbors of S. Uphill move (resp. downhill)
if the cost of the source node is lower (resp.
higher) than the cost of the destination node A
node is a global minimum if it has the lowest
cost among all nodes A node is a local minimum
if, in all paths starting at the node, any
downhill move comes after at one uphill move.
27
Planner randomized algorithm
Simulated Annealing performs a continous random
walk accepting downhill moves always ad uphill
moves with some probability trying to avoid being
caught in a high cost local minimum. Returns the
node with the lowest cost visited Iterative
Improvement performs a large number of local
optimizations. Each one starts at a random node
and repeatedly accepts random downhill moves
until it reaches a local minimum. Returns th
local minimum with the lowest cost found
28
Planner
For up to 10 joins dynamic programming works
better
29
Size-Distribution Estimator
Rewriter
Cost Model
Planner
Algebraic Space
Size-Distribution Estimator
Method-structure space
Given a query, it estimated the sizes of the
results of (sub) queries and the frequency
distributions of values in attributes of these
results
30
Size-Distribution Estimator Example
Name Salary Department Zeus 100K General
Manager Poseidon 80K Defense Pluto 80K Justice Ari
s 50K Defense Ermis 60K Commerce Apollo 60K Energy
Hefestus 50K Energy Hera 90K General
Manager Athena 70K Education Aphrodite 60K Domesti
c Affairs Demeter 60K Agriculture Hestia 50K Domes
tic Affairs Artemis 60K Energy
Department Frequency General Manager 2 Defense 2
Education 1 Domestic Affairs 2 Agriculture 1 Com
merce 1 Justice 1 Energy 3
Similarly discuss distribution of frequencies of
combinations of arbitrary number of
attributes Attribute value independence assumption
31
Size-Distribution Estimator Histograms
In a histogram on attribute a of relation R, the
domain of a is partitioned into buckets, and a
uniform distribution is assumed within each
bucket. That is, for any bucket b in the
histogram, if the value ui ? b, then the
frequency fi of ui is approximated by ?uj ? b fj/
b Trivial Any subset of the attributes domain
may form a bucket
32
Size-Distribution Estimator Histograms
Department Frequency in Bucket Approximate
Frequency General Manager 2 1.75 Defense 2
1.5 Education 1 1.75 Domestic
Affairs 2 1.5 Agriculture 1 1.5 Commerce 1
1.5 Justice 1 1.75 Energy 3 1.75
2 buckets
33
Size-Distribution Estimator Histograms
Department Frequency in Bucket Approximate
Frequency General Manager 2 1.33 Defense 2
1.33 Education 1 1.33 Domestic
Affairs 2 2.5 Agriculture 1 1.33 Commerce
1 1.33 Justice 1 1.33 Energy 3 2.5
2 buckets
34
Size-Distribution Estimator Histograms
Department Frequency in Bucket Approximate
Frequency General Manager 2 1.75 Defense 2
1.5 Education 1 1.75 Domestic
Affairs 2 1.5 Agriculture 1 1.5 Commerce 1
1.5 Justice 1 1.75 Energy 3 1.75
Equi-width the number of consecutive attribute
values or the size of the range of attributes
values associated with each bucket is the
same First bucket 4 values A D Second bucket 4
values E-Z
35
Size-Distribution Estimator Histograms
Department Frequency in Bucket Approximate
Frequency General Manager 2 1.33 Defense 2
1.33 Education 1 1.33 Domestic
Affairs 2 2.5 Agriculture 1 1.33 Commerce
1 1.33 Justice 1 1.33 Energy 3 2.5
Serial the frequencies of the attribute values
associated with each bucket are either all
greater or are all less than the frequencies of
the attribute values associated with any other
bucket
36
Parallel Databases

• Intra-operator parallelism
• Inter-operator parallelism (pipelining and
  independent parallelism)

37
Distributed Databases

• communication cost
• various forms of joins

38
Advanced Query Optimization
Semantic query optimization use integrity
constraints to rewrite a given query Global
query optimization multiple queries become
available for optimization at the same time
(queries with unions, multiple concurrent users,
etc) Derive a query plan optimal for the
execution of all of them as a group
