Title: SNPs and Variation


1
SNPs and Variation
2
  • Most variation at the DNA level comes in the form
    of small insertions and deletions and single
    nucleotide polymorphisms (SNP).
  • A substitutional variation must occur in at least
    1 of the population to be considered as a SNP.
  • A haplotype is a cluster of SNPs.

3
High-throughput Sequencing
4
SNP
homozygous
A
C
A/C
A/C
A substitutional variation must occur in at least
1 of the population to be considered as a SNP.
heterozygous
5
Haplotype a cluster of SNPs
6
The Nature of Single Nucleotide Polymorphisms
  • Classification of SNPs
  • nucleotide change by way of transition (purine
    to purine, or pyrimidine to pyrimidine) and
    transversion (purine to pyrimidine, or pyrimidine
    to purine).
  • 1. Noncoding SNP
  • 2. Coding SNP

7
Noncoding SNP
Flanking region
Flanking region
5'
3'

GT
AG
GT
AG
GC box
Initiation codon
Stop codon
Poly(A)-addition site
CAAT box
TSS
AATAA
GC box
TATA box
8
Coding SNP
Flanking region
Flanking region
5'
3'

GT
AG
GT
AG
GC box
Initiation codon
Stop codon
Poly(A)-addition site
CAAT box
TSS
AATAA
GC box
TATA box
9
Coding SNP
10
3.1 (Part 1) Human promoter SNPs that affect
gene expression
11
3.1 (Part 2) Human promoter SNPs that affect
gene expression
12
SNP Database
13
(No Transcript)
14
(No Transcript)
15
SNP database of disease related loci.
http//pga.mbt.washington.edu/
16
Distribution of SNPs
  • Population genetics study the distribution of
    genetic variants.
  • Quantitative genetics study the relationship of
    variants and phenotypes.
  • Quantitative trait loci (QTL) a region of DNA
    that is associated with a particular phenotypic
    trait - these QTLs are often found on different
    chromosomes. Knowing the number of QTLs that
    explains variation in the phenotypic trait tells
    us about the genetic architecture of a trait.

17
  • Neutral theory most SNPs are maintained in
    natural populations as a result of a balance
    between mutation and genetic drift.
  • The dynamics of genotypic variation are described
    by the balance of mutation, drift, migration, and
    selection.
  • Neutral theory supplies the null hypothesis when
    the pattern of variants are assessed.

18
  • Three key concepts for characterizing SNP
    variation
  • 1. Allel frequency distribution
  • 2. Linkage disequilibrium
  • 3. Population stratification

19
3.2 (Part 1) Nucleotide diversity in natural
populations
874 SNPs from 75 candidate human hypertension
loci.
20
3.2 (Part 2) Nucleotide diversity in natural
populations
LD decays with time regarding recombination rate
r.
21
Linkage disequilibrium and Haplotype Maps
  • 1. Non-random assortment of alleles.
  • 2. Typically occurs over kbs.
  • 3. Measures based 2 SNPs system A/a B/b.

The probability of each haplotype (for two
allele)
chromosome recombination
  • PAB ? PAPB
  • PAb ? PAPb PA(1-PB)
  • PaB ? PaPB (1-PA) PB
  • Pab ? PaPb (1-PA) (1-PB)

A
b
There are 4 possible haplotypes for SNP sites A/a
and B/b.
22
D Coefficient
  • We can measure the non-randomness of two loci by
    means of a deviation, D, defined as follows
  • D PAB PAPB or PABPab PAbPaB
  • PAB PAPB D
  • PAb PA(1-PB) - D
  • PaB (1-PA) PB - D
  • Pab (1-PA) (1-PB) D
  • These two SNPs are linkage equilibrium iff D 0.

23
Let D PAB PAPB , and D D/Dmax, where Dmax
stands for the absolute maximal possible value of
D.
D
D
0
-PAPB
PAPB
  • D is independent of allele frequencies, 1 gt D
    gt -1.
  • D allow us to compare LD at different
    combination of loci.

24
  • D is constrained between -1 and 1.
  • D 1 (perfect positive LD between SNP alleles)
  • D 0 (linkage equilibrium between SNP alleles)
  • D -1 (perfect negative LD between SNP alleles)
  • D 0.87 (strong positive LD between SNP
    alleles)
  • D 0.12 (weak positive LD between SNP alleles)
  • Other measures of D coefficient
  • r2 or ?2
  • Chi-square Test.
  • Fisher exact test (for small samples).
  • P value.

25
  • A set of closely linked SNPs located on one
    chromosome.

SNP 1
SNP 2
SNP 3
GATATTCGTACGGA-T GATGTTCGTACTGAAT GATATTCGTACGGA-T
GATATTCGTACGGAAT GATGTTCGTACTGAAT GATGTTCGTACTGAA
T
Haplotypes
AG- 2/6 GTA 3/6 AGA 1/6
DNASequences
26
3.3 Distribution of linkage disequilibrium
across the human lipoprotein lipase (LPL) gene
The significance is inferred according to Fisher
exact test. Blue box significance,
p lt 0.001 Yellow box nonsignficance. White
unknown.
66 SNP sites in this genes
27
Haplotype Blocks in Human Genome
  • The human genome has been shown to contain
    regions of high LD interspersed by regions of low
    LD.
  • The recombination occurs frequently in low LD
    regions.
  • The high LD regions can form haplotype blocks.
  • The International HapMap Project aims to build
    the haplotype map across human genome.

Recombination hot spots(Low LD regions, D lt 0)
Haplotype blocks(High LD regions, D gt 0)
Chromosome
28
3.4 (Part 1) Distribution of LD in the human
genome
29
3.4 (Part 2) Distribution of LD in the human
genome
30
(No Transcript)
31
3.5 Tagging SNPs and the haplotype clusters
Tagging SNPs capture most of the nucleotide
variation included in haplotypes.
32
3.6 Haplotype structure in the human lipoprotein
lipase (LPL) gene
(82 unrelated humans)
Only 8 of all haplotypes are unique regarding
racial groups
33
3.7 Human diversity and population structure
Genotyping of 377 microsatellites in 1056
individuals.
34
Applications of SNP Technology
  • Population Genetics
  • Recombination Mapping
  • QTL Mapping
  • Linkage Disequilibrium Mapping

35
SNP Discovery
  • Resequencing
  • SNP identification
  • SNP verification
  • Sequence-free Polymorphism Detection

36
Resequencing
  • SNP are discovered by comparing sequences derived
    from different chromosomes.
  • The probability of detecting a SNP in the
    condition of two alleles is given by
  • P1-(1-p)2n
  • where p is the frequency of rare allele and n
    is the comparison number of individuals.

37
SNP identification
  • Two major methods can be used to identify SNPs.
  • 1. Comparison of whole genome sequence with
    cDNA (EST) sequences which from different
    strands.
  • 2. Comparison of genomic sequences derived
    from different individuals.
  • There is no way to determine whether a difference
    is the result of a sequencing error in original
    sequences.

38
(No Transcript)
39
SNP verification
  • PCR amplification of the specific fragment
    including SNP in a sample of at least 10
    individuals and resequencing.
  • Sequencing by hybridization use sequencing chip.

40
3.15 Sequencing by hybridization
One chip per individual
25-mer probe, N represent the variation site.
41
Sequence-free Polymorphism Detection
  • Denaturing High Performance Liquid Chromatography
    (DHPLC)
  • Denaturing Gradient Gel Electrophoresis (DGGE)
    and Single-Strand Conformation Polymorphism
    (SSCP)
  • Targeting Induced Local Lesion IN Genomes
    (TILLING)

42
DHPLC
43
DGGE and SSCP analysis
acrylamide gel
W and C are complementary strands
genotypes
Single-strand secondary structures
urea gradient
44
GC-clamp
45
AT, CG, AG, CT Four types of CG clamps
46
(No Transcript)
47
Tilling
EthylMethaneSulfonate
Pools of rows and columns
48
3.17 (Part 2) Tilling
49
SNP Genotyping
  • Low-Technology Methods
  • Minisequencing Methods
  • Homogeneous Fluorogenic Dye-Based Methods
  • Haplotype Phasing Methods

50
Low-Technology Methods
  • All current SNP genotyping methods except Invader
    assay depend on specific amplification of the DNA
    sequence surrounding the site to be genotyped,
    which is generally achieved using the PCR.
  • 1. PCR-RFLP method
  • 2. dCAPS method
  • 3. ASO method

51
3.18 (Part 1) Bulked segregant mapping of
mutations using Snip-SNPs
PCR-RFLP method
1/5 1/2 of all SNPs contained in palindromic
segments
52
3.18 (Part 2) Bulked segregant mapping of
mutations using Snip-SNPs
53
3.19 dCAPS
dCAPS method
54
ASO method
55
Minisequencing Methods
  • A philosophically different approach to
    genotyping is to actually resequence each allele
    only one or a few bases in a sample of
    individuals.
  • 1. Single-base extension
  • 2. Pyrosequencing

56
3.20 (Part 1) Single-base extension methods
Single-base extension
57
3.20 (Part 2) Single-base extension methods
58
3.21 Pyrosequencing
Pyrosequencing
59
Homogeneous Fluorogenic Dye-Based Methods
  • Homogeneous assays are those that are carried out
    in a single reaction in solution.
  • 1. TaqMan
  • 2. Molecular beacons
  • 3. Dye-labeled oligonucleotide ligation
  • 4. The Invader assay

60
3.22 (Part 1) Fluorogenic dye-based genotyping
methods
TaqMan
61
3.22 (Part 2) Fluorogenic dye-based genotyping
methods
Molecular beacons
62
3.22 (Part 3) Fluorogenic dye-based genotyping
methods
Dye-labeled oligonucleotide ligation
63
3.23 (Part 1) The Invader assay
The Invader assay
64
3.23 (Part 2) The Invader assay
65
3.23 (Part 3) The Invader assay
66
Haplotype Phasing Methods
  • Consider two adjacent SNPs A/T and A/C, the
    haplotypes could be AA and TC or TA and AC.
  • SNPs --------A/T--------- ----------A/C--------
    --
  • --------A-------------------------A---------
    ----
  • --------T-------------------------C---------
    ----
  • or
  • --------T-------------------------A---------
    ----
  • --------A-------------------------C---------
    ----
