Title: Design for IDSS


1
Design for IDSS
  • Liam Page
  • CSE 435
  • 23 October 2006

2
What is design?
  • Construction of an artifact from single parts
    that may be either known and given or newly
    created for this particular effect (Börner 1998)
  • Design systems assist a user in producing better
    designs in shorter amount of time

3
What is design?
  • How does design help with
  • decreasing design times?
  • increasing design quality?
  • improving design predictability?

4
Classifying Design Task
  • Three classifications
  • Routine Design
  • Innovative Design
  • Creative Design

5
Routine Design
  • State space is well defined using potential
    designs
  • New designs can be derived entirely from existing
    designs
  • Outcomes known before hand
  • Final design agrees with configurable constraints
  • Used mostly in KB-systems

6
Innovative Design
  • Well defined state space of potential designs,
    non-routine design desired
  • Values for variables may change
  • Solution is similar to old designs, but also
    appears to be new due to variables

7
Complex Design
  • Non-routine design
  • New variables
  • Extends/moves state space of potential designs

8
Complex and Innovative Tasks (1)
  • Often unsure what the final design constraints
    will be
  • Typically ordered in accordance to preference
    criteria
  • Abstract -gt Concrete
  • Reduction of design space

9
Complex and Innovative Tasks (2)
  • Ideal system
  • Assists user, not automated
  • User interface logically constructed for type of
    design task
  • Learns from past solutions and users response to
    solutions (accept, correct, refuse)

10
Case Based Design
  • Themes of case based designed systems (Maher and
    Gomez de Silva Garza 1997)
  • representation and management of complex cases
  • case augmentation using generalized design
    knowledge
  • formalization of informal knowledge

11
Case Based Design
  • What can be a complex case?
  • Sample of larger data model
  • Data represented structurally (graphs)
  • Non-static variables
  • Flexible may have multiple interpretations
  • Adaptable to solve new problems

12
Case Based Design
  • Implications of complex cases
  • Must be able to reinterpret and reformulate new
    problems
  • Overlapping of problem and past cases must be
    identified
  • Parts must be chosen for transfer and combination
  • Similarity functions must be flexible
  • Joint consideration of case aspects is possible

13
Example of Complex Case Usage
  • Transformed Solution
  • Dimensions 30 x 30
  • Doors 1
  • Outlets 6
  • Deluxe Standing Shower yes
  • Case DeluxeBathroom2
  • Dimensions ( 30 50)x (30x50)
  • Doors 2 3
  • Outlets 6 10
  • Deluxe Standing Shower yes
  • Case DeluxeBathroom1
  • Dimensions (20-40)x (20-40)
  • Doors 1 2
  • Outlets 4 6
  • Hot tub yes

14
Case Based Design
  • Generalized design knowledge to augment cases
  • Includes causal models, state interactions,
    heuristic models/rules, geometric constraints
  • Typically not available for innovative and
    creative tasks

15
Case Based Design
  • Need formalization of knowledge for CBR
    automation
  • Problem human knowledge of design is difficult
    to formalize into rules and variables that the
    system can utilize
  • In cases where it is only possible to create an
    informal body of knowledge, system should be
    developed to merely support a human designer

16
Knowledge Representation
  • Four knowledge containers in CBR
  • Vocabulary
  • Case base
  • Similarity measure
  • Solution transformation

17
Vocabulary
  • Vocabulary task and domain dependent
  • Should capture all important features of design
  • Supports problem solving in relevant domain

18
Case Base
  • Represent past design experience
  • Usage abnormal/normal
  • Granularity grain size of cases is equal to
    grain size of design task
  • Level of Abstraction
  • Ossified cases general rules of thumb
  • Paradigmatic cases represent learned expertise
  • Stories complex, relate to large number of
    circumstance

19
Case Base (cont)
  • Perspective
  • State-oriented case represents problem and
    solution
  • Solution-path case refer to problem or operator
    that determines solution from problem description

20
Similarity Measure
  • Two different approaches to similarity assessment
  • Computational (similarity) approach
  • Representational approach

21
Computational Approach
  • Unstructured organization
  • Usefulness of cases based on presence or absence
    of features
  • Many cases Are Called candidate cases
  • Few Are Chosen structural comparison between
    problem and possible solutions

22
Representational Approach
  • Pre-structured case base (indexing structure)
  • Neighboring cases are assumed to be similar
  • Probes constraints in memory to determine
    possible solutions

23
CBR for Innovative and Creative Design
  • Flexible case retrieval
  • Retrieved cases show similar aspects to the
    problem
  • Different similarity measures have to be
    dynamically composed during retrieval
  • Fish and Shrink Algorithm
  • Structural similarity assessment
  • Structural cases are processed and represented as
    variables taking the role of problem or solution
    variables

24
Solution Transformation and Case Adaptation
  • New situations often different from old solutions
  • Solutions must be adapted to fit the constraints
    of the problem using parts from other past
    solutions

25
Solution Transformation and Case Adaptation
  • Three kinds of adaptation (Cunningham and
    Slattery 1993)
  • Parametric adaptation modifying parameters
  • Structural adaptation adaptation operators
    (grammar rules)
  • Generative Adaptation reuse and adaptation for
    derivations of past problem-solving episodes

26
Fish and Shrink
  • Algorithm for flexible case retrieval
  • Allows for rapid searching through case base
    (even if significant aspects are combined at
    query time)
  • Can be stopped at any time and still produce
    usable results (though not complete)

27
Fish and Shrink
original case ? aname ? Oname
T1
dname
Oname
distances
C1
  • Similarity measure of emphasized attributes
    between all cases and a set of test cases are
    retrieved and stored

28
Fish and Shrink (2)
Represents similarity distances between cases and
emphasized attributes
Reduce range of possible similarity of any case
to problem by utilizing the predetermined
similarity to test cases
  • Find similarity distance from test cases to
    problem
  • Use predetermined similarity of cases to test
    cases to derive the possible similarity of cases
    to problem
  • Reduce similarity range to a single estimate by
    overlaying similarity ranges to test case

29
Structural Similarity
  • Used to solve design problems involving a
    representative structure
  • Determines candidate solutions via maximal common
    subgraph (mcs)

30
Structural Similarity
  • Several functions are required
  • Compile translates attribute representations of
    objects and relations into graphs
  • Recompile converts graph back to attributes
    that may be depicted graphically
  • Retrieve gets candidate cases
  • Match finds mcs between graphs

31
Structural Similarity
  • Best mcs transferred to problem
  • Vertices and edges of other candidate cases may
    be used to augment solution

32
Structural Similarity
33
Structural Similarity
  • Arrows represent spatial relations (touches,
    overlaps, etc)

34
Case Study EADOCS
  • EADOCS
  • Interactive, multi-level, and hybrid expert
    system for aircraft sandwich panel structures
  • Structure of design defines the set of
    components, their configuration and parameter
    values

35
EADOCS (2)
  • Innovative design
  • Plans for designing components are not available
  • Only partial models for evaluating behavior are
    available

36
EADOCS (3)
  • Object Oriented class structure
  • Design cases are instances of design problems
    containing objects that define its behavior
  • For EADOCS, cases contain knowledge of the
    structural behavior of the design, such as an
    ability for a material to maintain its shape at a
    particular air pressure

37
EADOCS (4)
  • Retrieving a solution
  • Best solutions are selected and configured into
    prototype solutions
  • A best prototype defining an optimal design space
    is selected and a conceptual solution is
    retrieved
  • If no conceptual solution fitting the
    requirements can be retrieved, next best
    prototype is selected and 2 is repeated

38
EADOCS (5)
  • Case Combination
  • Sub-targets are identified within the conceptual
    solution that do not match the design
    requirements
  • New target for retrieval is defined
  • Cases are retrieved to satisfy the new target
  • Adaptations are retrieved based on differences in
    functionality between cases with a similar
    structure to the conceptual solution and the case
    satisfying the new target

39
EADOCS (6)
40
Final Remarks
  • IDSS can significantly help with design tasks by
  • Decreasing design times by automating aspects of
    the design process
  • Increasing design quality by insuring constraints
    of design are respected
  • Improving the predictability of designs by using
    learning algorithms to reduce design space

41
References
  • Arcos, J.L. and Enric Plaza. The ABC of
    adaptation Towards a Software Architecture for
    Adaptation-Centered CBR Systems. 12 November
    1999. 22 October 2006 lthttp//www.iiia.csic.es/Pr
    ojects/cbr/ABC/abc-report.htmlgt
  • Bergmann, Ralph. Experience Management for
    Electronic Design Reuse. Experience Management
    Foundations, Development Methodology, and
    Internet-Based Applications. Springer
    Berlin/Heidelberg, 2002. 2 August 2003. 6
    October 2006.
  • Börner, Katy. CBR for Design. Case-Based
    Reasoning Technology From Foundations to
    Applications. Springer Berlin/Heidelberg, 1998.
    Springer Link. 20 May 2003. 6 October 2006.
