Geometrical optics

1
Geometrical optics
Physics 135 General Physics II 25/28 February
2005
2
Law of reflection
q angle of incidence
q angle of reflection
Planar reflecting surface (mirror)
3
Objects and images
Object
Reflected rays appear to come from a point
Rays from point on object reflect from mirror
4
Law of refraction
q1 angle of incidence
n1
q2 angle of refraction
n2
( n2 gt n1 in diagram )
5
Two simple effects
Total internal reflection
Object underwater appears to be at a shallower
depth
6
Thin lenses
7
Objects and images
x
y
Three easy rays for ray-tracing
Thin lens equation
magnification
8
Reading the signs

• In this diagram
• The object is upstream of the lens.
• The lens is a converging lens.
• The image is a real image through which light
  rays actually pass, and it is downstream of the
  lens.

i, f and o are all positive
9
A negative lens
o 50 cm
f -30 cm
i -18.75 cm
m 0.375
Upright, virtual image 37.5 as large as object
10
A compound lens system
50 cm
50 cm
150 cm
f 30 cm
f -30 cm
Total magnification
M m m (-1.5) (6.0) - 9.0
11
What is going on
Light rays diverge from object.
First lens causes rays to converge.
12
What is going on
Light rays diverge from object.
Diverging lens moves image to here.
First lens causes rays to converge.
13
Curved mirrors
1. Assume that mirror is a section of a sphere
of radius r
2. Assume that mirrors curve is shallow -- it
is essentially in one plane
14
Spherical mirrors
15
Spherical mirrors
16
x
y
17
o
r
x
r - i
y
o - r
i
18
(a little algebra)
19
Spherical mirror equation
20
f 10 cm
i 12.5 cm
21
o
r
x
y
i
magnification
22
f 10 cm
i 12.5 cm
m - 0.25
23
Limiting cases
f ? ? Flat mirror (infinite radius r) o ?
? Parallel incident rays
24
Two types of images
Real image i gt 0 , so light rays pass through
image point (in front of mirror) Inverted Virtua
l image i lt 0 , so light rays do not pass through
image point (behind mirror) Upright
