Parallel Performance Wizard: Measurement Module

1
Parallel Performance WizardMeasurement Module

• Professor Alan D. George, Principal Investigator
• Mr. Hung-Hsun Su, Sr. Research Assistant
• Mr. Adam Leko, Sr. Research Assistant
• Mr. Bryan Golden, Research Assistant
• Mr. Hans Sherburne, Research Assistant
• Mr. Max Billingsley, Research Assistant
• Mr. Josh Hartman, Undergraduate Volunteer
• HCS Research Laboratory
• University of Florida

2
Measurement Topics Outline

• Measurement module overview
• Overview of measurement process
• I/O library overview (file formats)
• Clock synchronization algorithms
• Summary of PAPI support
• Preliminary overhead measurements
• Upcoming work

3
Measurement Module Overview

• Purpose of module
• Record performance information at runtime based
  upon analysis that the user requests
• Types of measurements
• Profiling
• Record statistical information about execution
  time or hardware counter values
• Relate information to basic blocks (functions,
  upc_forall loops) in source code
• Tracing
• Record full log of when events happen at runtime
  and how long
• Gives very complete information about what
  happened at runtime
• Sampling
• Special low-overhead mode of profiling that
  attributes performance information via indirect
  measurement (samples)
• Optional feature

4
Measurement Module Architecture
5
Measurement Data What is Recorded?

• Basic information for each run
• Command-line arguments (if available)
• Snapshot of environment variables
• Thread information rank, pid, hostname
• Region information filename, line, description
• Region is an abstraction of a code block such as
  function or upc_forall loop
• Regions are used to relate performance
  information to a particular block of user code
• Callsite information filename, line, col
• Relates performance information to a particular
  line of code
• Metric information name
• Used to signify the metric used for measurements
  (e.g., hardware counters such as of L2 misses,
  etc.)

6
Measurement Data Trace Records

• All trace records associated with a
• Time value (globally synchronized)
• Thread
• Event ID
• Begin/end flag
• Depending upon type of event, record also has
• Communication information
• Metric information (hardware counter values)
• Other language- and function-specific values
• Most of the SHMEM function type variants are
  mapped to a single event data size
• e.g., shmem_put_float, shmem_put_double, mapped
  to shmem_put with a size argument
• Significantly simplifies analysis code (200
  functions mapped down to a handful without losing
  information)

7
Measurement Data Profile Statistics

• Profile statistics are collected for regions only
• User regions handled normally
• For other language-specific statistics, stats are
  related to special regions
• upc_get
• shmem_get
• etc.
• Each statistic has
• of times that region was called
• of subroutine calls (another region was entered
  inside this region)
• Min/Max/Sum of inclusive time spent in region
• Sum of exclusive time spent in region
• Sum of (exclusive time)2 spent in region (for
  standard deviation calculations)
• Metric this statistic corresponds to
• A callpath it is associated with

8
Measurement Data Profile Statistics (2)

• Inclusive vs. exclusive time
• Inclusive time time spent inside a region,
  including any subroutine calls
• Exclusive time time spent inside a region,
  excluding any subroutine calls ( self time)
• Tracking both inclusive and exclusive time helps
  differentiate between
• Slow regions that do most of the work themselves
• Regions that call other regions that take a long
  time
• Min/max/average (derived from sum and count)
  inclusive time help determine if a regions time
  differs between invocations
• Standard deviation of exclusive time also helps
  determine

9
Measurement Data Callpaths for Stats

• Based upon our tool evaluations last year, we
  picked three different methods for relating stats
  to regions of code
• Flat callpaths
• Each statistic has a callpath of depth 1
• Results in one statistic per region
• e.g., will give user the average and total time
  for all upc_memgets in their program
• Can be efficiently recorded
• Parent callpaths
• Each statistic has a callpath of depth 2
  region, enclosing region
• Results in several statistics per region giving
  contextual information
• e.g., will give user the averages and total times
  for all upc_memgets in their program, including
  which region called that upc_memget
• Can be fairly efficiently recorded

10
Measurement Data Callpaths for Stats 2

• Full callpaths
• Callpaths are taken from root down, up to 10
  levels
• Gives user several statistical records per
  region, with a lot of contextual information
• Can result in a large volume of stat records, but
  size usage is very modest compared to tracing
• Naturally filters out deep function calls
• Much more expensive to record at runtime
• Have to do up to 10 comparison operations per
  timer struct lookup
• Increased memory usage due to larger possible
  of callpaths
• Different profile modes provided so user can
  balance amount of information recorded vs.
  runtime overhead
• Represents a wider spectrum of information vs.
  overhead possibilities than just profiling
  tracing

11
Measurement Data Visual Representation

• Simplified ER diagram (syntax severely abused for
  claritys sake)

12
Measurement Process Overview

• Goal keep runtime overhead as low as possible
• Tracing
• Each thread (execution unit) keeps a buffer of
  event records in raw format
• Buffer is flushed to disk when full
• On merge, raw data is sent to merge master, which
  outputs data in final (sorted) format
• Profiling
• Profile data is kept in memory inside timer
  structs
• Each timer struct is associated with a region of
  code (user or system) and a callpath
• Side note requirement of our project is to
  provide switching between tracing profiling
  without recompilation

13
Trace Implementation Details

• Importance of explicit buffering
• Disk behavior is similar to network overhead
• For small writes, seek time dominates data
  transfer time
• Even for modern (expensive) disks, seek times
  range in the milliseconds
• Cannot afford a seek on each trace entry
• Most OSs will buffer small reads if free RAM
• But, most HPC applications slurp up all available
  RAM
• Even a modest buffer size (64KB) will buffer
  over 1500 trace records _at_ 40 bytes / record
• Buffer size will be user-tunable
• Need to do extensive testing to determine effect
  of buffer size on tracing overhead
• Preliminary data seems to indicate that unless
  dealing with huge records, trace buffers of gt 1M
  have limited benefits
• Additional techniques for overhead reduction
  (will implement as needed)
• Use nonblocking io (aio_write, aio_read) with
  double buffering
• Alternatively use producer/consumer and circular
  buffer with pthreads

14
Profile Implementation Details

• As with tracing, low overhead is key
• On each region entry, need to look up associated
  timer object
• Need a very efficient data structure for lookups
  of a moderate (100s to 1000s) number of timer
  objects
• Hashing based upon region type (upc_get, upc_put,
  etc) is currently used
• Provides very efficient lookups when small number
  of timers per event type
• Separate hash used for user events
• Hash overflow buckets handled with a simple array
  using a modest number of pre-allocated buckets
• Further possible performance optimizations
• Use separate hash tables for very common events
  (UPC implicit communication region types)
• Use more efficient lookup structures for overflow
  buckets (AVL trees)
• Do cycle trimming on callpath matching code
• Need further testing with realistic applications
  to identify bottlenecks (premature optimization)

15
I/O Library File Formats

• We spent much time looking _at_ existing trace
  formats
• Trying to avoid reinventing the wheel!
• SLOG-2
• Native format used by Jumpshot
• Made to be very efficient for visualizing traces
• However, graphics-based format loses a lot of
  performance data
• Format is also expensive to write
• MPICH uses CLOG2 as intermediary file format
• Jumpshot viewer converts CLOG2 files
  semi-automatically when trace is opened for the
  first time

16
I/O Library File Formats (2)

• STF (Intel Trace Collector)
• Seems to be an efficient format but is not open
  (undocumented property of Intel)
• VTF3 (Vampirs format)
• VTF has free (but not open) library with support
  for many platforms
• VTF library is not designed to be used at runtime
• Rather, it is geared towards analysis
  conversion utilities
• OTF new trace library supported by Vampir-NG and
  TAU
• OTF trace format was created under contract with
  LLNL
• Open (documented) format, uses a lot of
  techniques to support massively parallel traces
  (1000s of processors)
• Library is open source (http//www.tu-dresden.de/z
  ih/otf)
• Format does not have specific support for
  one-sided memory operations
• Has become available only very recently (past few
  months)

17
I/O Library File Formats (3)

• Unnamed trace format for IBM SP systems
• Described in paper by Wu et al. in From Trace
  Generation to Visualization A Performance
  Framework for Distributed Parallel Systems
• No implementation available but has some good
  ideas (framing continuation records for
  efficient access)
• EPILOG
• Trace format used by KOJAK suite
• Open source documented
• Portable (support for many platforms)
• No explicit support for UPC operations
• Format survey findings
• OTF and EPILOG were most promising
• Neither has support for both UPC (EPILOG) and
  one-sided memory operations (OTF)
• Analysis module needs this information, so cannot
  use libraries as is
• Due to lack of perfect candidate, created own
  simple trace format that takes best ideas from
  each other library

18
I/O Library PPW Format

• File consists of two pieces (separate files)
• File header containing definition records and
  statistic information (filename.ppw)
• Trace file containing trace records very short
  header (filename.ppw.0)
• Trace definition records statistics kept
  separate from trace file
• Can easily transport the header file around for
  initial viewing by visualization tools
• Gory details of file format documented in PPW
  source code
• Very simple overall file format, basically a dump
  of information outlined on slides 5-11 in network
  byte-order format (big-Endian)
• File format is easily ported to other trace
  formats such as OTF, EPILOG, and VTF
• More featured trace conversion module are in the
  works
• Depending upon needs of analysis and presentation
  modules, will add more scalable features to
  format
• In particular, have strongly looked at trace file
  framing and continuation records to efficiently
  support reading portions of a trace file without
  losing information

19
Clock Synchronization Algorithms

• In order for analysis and visualization to be
  useful and accurate, need clocks to be globally
  synchronized
• PPW uses a simple linear drift model
• One clock is designated as the master clock
• Parameters recorded for slave clocks
• Local time 1 (t1), master time 1 (mt1)
• Local time 2 (t2), master time 2 (mt2)
• Based upon parameters, slave timestamps are
  mapped to masters time by linear equation
  globaltime mx b
• m (mt2 mt1) / (t2 t1)
• b mt1 m t1
• Timestamp values adjusted during merge phase
• F. Cristians algorithm is used to estimate
  remote clocks actual value
• Probabilistic remote clock reading algorithm,
  very popular straightforward to implement

20
Clock Synchronization Algorithms (2)

• Illustration of linear model

Thread 2
Thread 1
Offset (b)
Timer values
Different slopes (m)
Runtime
21
PAPI Basic Information

• Name
• Performance Application Programming Interface
  (PAPI)
• Developer
• University of Tennessee, Knoxville
• Current version
• PAPI 3.2.1
• Website
• http//icl.cs.utk.edu/papi/
• Contact
• Phil Mucci
• Collaborations
• TAU, SCALEA, vprof, SvPablo, PeformanceBench,
  DynaProf

22
PAPI Implementation
23
HW Support

• Excellent hardware support
• Heterogeneity support
• PAPI API code is highly portable, but needs to be
  cognizant of semantic differences

24
PPW/PAPI integration

• Not all metrics available on each platform
• More than 100 total PAPI metrics available
• 42 metrics available for Opteron processors in
  our open platforms
• PAPI does not support the Cray X1E
• Software multiplexing used to extend
  functionality (i.e. track more metrics than there
  are physical HW counters)
• Used for PPW modules
• A Unit Local delay analysis
• P Unit visualizations
• Profiling mode call tree, statistical
  visualizations
• Tracing mode timeline
• After call to PAPI_library_init
• PAPI_add_events defines what events PAPI should
  track
• PAPI_start/stop_counters starts/stops
  counting-specified hardware events
• PAPI_read_counters copy current counts to array
  reset counters

25
Measurement Future Work

• Performance tuning of measurement library
• Instrument record data for applications that
  exercise trace profile functions
• Identify inefficiencies via valgrind tool
• Proprietary platform support (Cray SHMEM, etc.)
• Add source callsite support for SHMEM wrappers
• Borrow code from mpiP
• Trace format improvements for efficient analysis
  / visualization
• Memory profiling minor mode
• Request from Berkeley UPC users
