Reality Engine

• Anselmo Lastra
• COMP290-052

2
Topics

• Look at RE pipeline
• Examine the data that flows between stages
• Look at bandwidths

3
Reality Engine

• First OpenGL machine
• Change from proprietary IrisGL
• Fastest commercial machine of time
• Generations
• Akeleys definitions
• Begins at flat-shaded polygons

4
Design Goals

• ½ million textured tris/sec
• Mip-mapped textures
• Antialising
• High fill rate
• Work as well as VGX on 2nd gen work

5
Three types of Boards

• Geometry board
• 6, 8, 12 geometry processors
• Raster memory board
• 1, 2, 4 boards to increase fill rate
• Or antialiasing capability
• Display/video generator

6
Command Processor

• Controls work sent to geometry engines
• Broadcasts some state info
• Send tris to particular GE
• Round-robin assignment
• Static load balancing
• Sizes of primitives (t-strips) sent to GEs
  important
• Primitive ordering
• FIFOs between stages

7
Geometry Engines

• Intel i860
• RISC, pipelined FP
• All polygons converted to tris
• Single precision computation
• Typical
• Broadcasts data for rasterization
• Note also path to load code into DRAM

8
Fragment Generators

• Custom ASICs
• Each a portion of frame buffer
• Interleaved
• Pipeline with several fragments in flight
• Tasks z and color for center, coverage mask,
  texture addresses, texture lookup, final color
  computation (blend, fog)
• Care to keep color in triangle (not always
  center)
• Talk about fragment generation / rasterization
  later

9
Subpixel mask

• Fixed 8x8 grid
• Select 4, 8, or 16 samples on grid
• Computer coverage of samples
• Only one depth and texture coord chosen
• Depths expanded later from dX, dY
• Color at center also

10
Texturing

• Texture replicated at each fragment processor
• 5-20 times
• Eight DRAM chips
• One for each mipmap sample

11
Image Engine

• 16 per fragment generator
• One DRAM each
• Each computes depth at subpixel covered by
  fragment
• Bits/pixel depends on of boards and display
  resolution (256, 512, 1024)
• 12 bits / color component
• 32 bit depth

12
Display Board

• Display color computed by image engines every
  fragment
• OpenGL has no explicit end-of-frame
• 50MHz single bit paths to board from each image
  engine
• Color maps, etc.

13
Antialiasing

• Alpha
• Coverage on 8x8 grid computed
• Ordering must be observed

14
Multisample antialiasing

• Point sampling
• Including accurate edges
• Not always good representation of actual area
• Area sampling
• Can produce artifacts
• Screen-door transparency
• Alpha to coverage

15
Texturing

• Default is 16-bits / texel
• Because of bandwidth issues
• Can increase to 32 or 48 bits

16
Clipping

• FIFOs even out load
• MIMD better for clipping
• SIMD must execute wasted cycles to compute both
  if and else
• Far and near planes
• Also less clipping because rasterizers scissor
  the primitives

17
Antialiasing

• Single pass
• Multisample
• vs. A-Buffer
• Makes case for utility of supersampling as
  opposed to multi-pass
• Less overall hdw
• Transform/texture only once

18
Triangle Bus

• Argues that doing sort before fragment engines
  better than after
• Compares to ES
• Notes PixelFlow frame latency
• Lets defer discussion until we talk about
  sorting classification of parallel rendering

19
Commodity DRAM

• Many other machines used specialized video RAM
• RE stole memory cycles to refresh display
• Commodity parts lowered cost of RE

20
Data Flow of RE

• What flows between stages?

21
Bandwidths

• Compute bandwidths (at dots) required to render a
  million 50-pixel triangles
• Well make assumptions, such as all visible

22
Retained vs. Immediate

• Retained
• Potentially better performance when bandwidth to
  host a problem
• Difficult if much of model is edited
• Immediate
• Adds-ons to cache data on GPU
• Often have scene graph anyway

23
Geometry

• Often vertices treated independently
• Primitives reassembled
• Parallelism at fine or coarse scale
• Vertex 20-30 bytes
• About 50-100 Flops/vertex

24
Rasterization/Fragment

• Output is pixels triangles
• Standard then - 50-100 pixel tris
• Total about 50M fragments for our example

25
Texturing

• Per fragment cost is 8 32-bit texels
• About 1.6GB / million tris
• Can use compression here
• Modern systems use caching
• How fast a memory would we need for 10 M tris?

26
Frame Buffer Bandwidth

• Assume z of 32 bits, color 4 bytes
• Could go with z of 24 bits
• Must read Z for every fragment
• 200 MB/s for Z
• Must write some fraction
• Say ½
• 400 MB/s for Z and color
• Total 600 MB/s

27
Frame Buffer Clear

• Tricks to avoid clearing
• Example One indicator bit cleared at start of
  frame

28
Scanout Bandwidth

• 3 bytes/pixel
• 1024x1024, approx. 1M pixels
• 60 Hz
• About 180 MB/s
• 1280x1024, 72Hz, 280 MB/s
• Can go over 500 MB/s for HDTV at 72Hz

29
Modeling

• We have found spreadsheet performance model
  useful
• Can explore what-if
• Functional model in HLL
• Gate-level model in HLL or Verilog

30
Additional Reading

• The architecture of the pipeline
• Mark Segal and Kurt Akeley, The design of the
  OpenGL graphics interface

31
Next Time

• Rasterization
• Pineda, "A parallel algorithm for polygon
  rasterization", SIGGRAPH 88, and
• Olano, Marc and Trey Greer, "Triangle Scan
  Conversion Using 2D Homogeneous Coordinates",
  Proceedings of the 1997 SIGGRAPH/Eurographics
  Workshop on Graphics Hardware.
• Supplementary reading  Joel McCormack, Robert
  McNamara, "Tiled polygon traversal using
  half-plane edge functions", Graphics Hardware
  2000.  The Pineda paper presents a method to
  decide whether a fragment is in a triangle, but
  only sketches ways to fidn the candidate
  fragments.  This paper describes a method to
  traverse triangles in tile order (good for
  caching).
