Construction of Polycrystalline Microstructures

1
Construction ofPolycrystalline Microstructures

• Dr. Dana Zöllner
• Fakultät für Naturwissenschaften
• Otto-von-Guericke-Universität
• Magdeburg

Workshop in Bad Helmstedt, 24.11.2006
2
Introduction
solid materials
crystalline
polycrystalline
amorphous
defects
line defects
point defects
planar defects
e.g. grain boundaries interfaces separating
two crystals of different orientations
grain structure
3
Introduction

• control of grain microstructure is key to improve
  materials properties in processing
• prediction of grain structures and their temporal
  evolution due to processes like recrystallization
  and grain growth
• microstructure influences properties in
  materials, like
• crystal plasticity, fracture, corrosion,
  strength or toughness
• different construction methods using

4
Using Real Microstructures
existing microstructures with physical
meaning many properties given (e.g. size,
topology, orientation)
- many materials to realistic e.g.
inclusions, two phases - large experimental
expense to get a single structure - limited
number of 2D samples yield uncertainties in
reconstruction of 3D structure!
5
ComparisonConstructed Structures vs.
Experimental Results
experimental results - low-carbon steel - by
Liu, Yu and Qin Mat. Sci. Eng. A326 (2002), p276
6
Using Mono-dispersive Grain Size Models
? size distribution (lognormal) ? delta
function ? replace grains of different shape and
size by regular hexagon-base columns, cubes or
other equi-sized polyhedra
simple handling fast procedure - discount
any real grain shapes and sizes ? far from reality
7
Using Voronoi Tessellations
blue dots initial seed in melt black circles
growing crystals
? crystals connect ? ideal grain ensemble
Poisson Voronoi tessellation
8
Using Voronoi Tessellations

• P is set of n distinct points (sites) in space
• Voronoi(P) is subdivision of space in n cells

9
Using Voronoi Tessellations

• P is set of n distinct points (sites) in space
• Voronoi(P) is subdivision of space in n cells
• point S is in the cell corresponding to Pi if
  distance(S, Pi) lt distance(S, Pj)

10
Using Voronoi Tessellations

• case 1 site
• trivial case
• Idea from http//nms.csail.mit.edu/aklmiu/6.838/
  L7.pdf

11
Using Voronoi Tessellations

• case 2 sites
• ? 2 half planes

12
Using Voronoi Tessellations

• case 2 sites
• ? 2 half planes

13
Using Voronoi Tessellations

• case n collinear sites
• ? n half planes

14
Using Voronoi Tessellations

• case 3 non-collinear sites
• ? 3 half edges meeting in a vertex

15
Using Voronoi Tessellations

• case 3 non-collinear sites
• ? 3 half edges meeting in a vertex

16
Using Voronoi Tessellations

• case 4 non-collinear sites
• ? simple Voronoi diagram

? 3 vertices ? 3 edges ? 3 half edges ? 1
bounded cell ? 3 unbounded cells
17
Using Voronoi Tessellations

• ?
• Which of the following statements is true for
• 2D Voronoi diagrams?
• Four non-collinear sites are
• sufficient to create a bounded cell.
• necessary to create a bounded cell.
• 1. and 2.
• none of above.

18
Using Voronoi Tessellations
very fast and simple procedure to construct in
2D and 3D many different grain structures
grains look statistically similar to experimental
results
- topological and statistical properties are far
from reality for example number of triple
junctions, triple junction angles, number of
neighbouring grains and grain size distribution
19
ComparisonConstructed Structures vs.
Experimental Results
Voronoi tessellation
scaling!
20
ComparisonConstructed Structures vs.
Experimental Results
Voronoi tessellation
21
Using Size-Distributed-Sphere-Packing

• algorithm
• 1. choice of grain size dis-tribution function f
• 2. calculation of N circles, which follow given
  size distribution f
• 2. arrangement of the cir-cles
• 3. filling of the gaps
• ? 3D works analogously

22
Using Size-Distributed-Sphere-Packing
fast and simple procedure to construct in 2D
and 3D many different grain structures grains
look statistically similar to experimental
results size distribution can be chosen, e.g.
from experiment ? nearer to reality than Voronoi
and MDGSM grain boundaries are slightly
curved only three grains meet in a vertex
(usually) triple junction angles near 120
number of neighbouring grains matches better
experimental results
23
ComparisonConstructed Structures vs.
Experimental Results
Size-Distributed-Sphere-Packing Rayleigh
Distribution
24
ComparisonConstructed Structures vs.
Experimental Results
Size-Distributed-Sphere-Packing Rayleigh
Distribution
25
ComparisonConstructed Structures vs.
Experimental Results
Size-Distributed-Sphere-Packing Log-normal
Distribution
26
ComparisonConstructed Structures vs.
Experimental Results
Size-Distributed-Sphere-Packing Log-normal
Distribution
27
ComparisonConstructed Structures vs.
Experimental Results
Size-Distributed-Sphere-Packing Normal
Distribution
28
ComparisonConstructed Structures vs.
Experimental Results
Size-Distributed-Sphere-Packing Normal
Distribution
29
Conclusions

• many different methods for constructing 3D grain
  microstructures
• Voronoi tessellation is widely used, but for
  creating polycrystalline structures topological
  and statistical properties are far from reality
• Size-Distributed-Sphere-Packing yields grain
  microstructures matching experimental results

30
Thank you for your attention!
