Minerals

1
Minerals
2
So what is a mineral?What are the
characteristics of all minerals?
3
Do you Know?
4
Mineral Characteristics
5
1. A mineral occurs naturally.
6
2. A mineral is solid.
7
3. A mineral has a definite chemical composition.
8
4. A minerals atoms are arranged in an definite
crystaline structure.
9

• Of the almost 3000 known minerals, only about 30
  are common.
• The most common are quartz,feldspar,mica, and
  calcite.

10

• These minerals make up most of the rocks found in
  the Earths crust.

11

• In fact, over 60 of the Earths crust is made up
  of the family of minerals known as feldspar!

12

• To be able to identify these and other minerals,
  we need to look at the properties used to
  separate and distinguish these minerals.

13
Crystal Systems

• There are six main crystal system
• 1 Cubic or isometric (3 axes of equal length
  intersect at 90)
• 2 Tetragonal (2 axes of same length, all at 90 )

• 3 Orthorhombic (3 axes of different length at 90
  )
• 4 Hexagonal (3 horizontal axis at 60. Vertical
  axis at 90)
• 5 Monoclinic (3 axes of different length, 2
  intersect at 90 , the other is oblique to the
  others)
• 6 Triclinic (3 axes of different length are all
  oblique to one another)

14
six main crystal system
15
Crystallization by cooling from magma

• Whats magma?
• Molten or partially molten rock beneath the
  earths surface
• Magma is generated when rock deep underground
  melts due to the high temperatures and pressures
  inside the earth
• Magma is lighter than the surrounding rock, it
  tends to rise
• -encounters colder rock and begins to cool

16
Slow Cooling - bigger minerals with
distinctcrystal structure
17
Crystallization through precipitation
Atoms or ions left behind in an evaporating
solution bond with one another to form solids
Halite NaCl forms from evaporation of seawater
18

• CLASS Silicate ion SiO44-
• 14 ratio of Silicon to Oxygen and other elements
• most abundant of the minerals (96)
• most common silicates are feldspar and quartz

Both have conchoidal fracture and vitreous luster
19
Silicate structure
20
Silicate structure
21
Silicate structure
22
CLASS Carbonate ion CO32- -
contain carbon and oxygen in a 13 ratio and
other metallic elements... calcite and dolomite
are common carbonates
Most react with hydrochloric acid
23
(No Transcript)
24

• CLASS Oxide ion O22-
• contain oxygen and a metal atom... many
  common ores are oxides, such as hematite and
  magnetite

25
Oxide structure
26
CLASS Sulfide ion S2-
- contain sulfur and a metal atom... pyrite is
the most common sulfide
27
Pyrite (FeS2)
28
CLASS Sulfate ion SO42- -
contain sulfur and oxygen in a 14 ratio and a
metal atom
29
Sulfate Structure
30
CLASS Halides ions Cl-, F-, Br-,
I- - contains chloride or fluoride ions and a
metal atom...halite (table salt) is the most
common halide
31
(No Transcript)
32
CLASS Native elements ions none, no
charged ions
33
Copper (Cu)
34
Identifying Minerals

• Remember!
• Rarely is a mineral identified by a single
  property.
• These properties need to be considered together
  to correctly identify a mineral.

35
color

• Color is the most easily observed mineral
  property and the least useful!

36
color

• Some exceptions to the color rule would be
  cinnabar, which is always red, and malachite,
  which is green.

37
color

• Many minerals have a similar color.

38
color
39
Quiz Break!
40
Discuss the following!

• How many of the characteristics of minerals can
  you name?
• Why isnt color a very good property to identify
  most minerals?

41
luster

• Luster refers to the way a mineral shines in
  reflected light.
• Notice the difference between these two minerals?

42
luster

• There are several terms used to describe
  nonmetallic luster. Examples could be vitreous,
  like the quartz on the left, or pearly, like the
  gypsum on the right.

43

• Other terms that might be used include greasy,
  dull, and earthy.
• Can you tell which of these has an earthy luster
  and which has a vitreous luster?

Were you Right?
Vitreous
Earthy
44
streak

• Streak of a mineral is the color of its powder
  when rubbed on an unglazed white tile.

45
cleavage

• Mica is probably the best example as it splits
  into thin sheets. It is said to have one perfect
  cleavage.

46
cleavage

• Feldspar splits readily in two directions, always
  at or near right angles.

47
cleavage

• Calcite and galena cleave in three directions.
• They are said to have three good cleavages.

48
cleavage

• Not all minerals show cleavage.
• Those that dont break along cleavage surfaces
  are said to have fracture.

49
Quiz Break!
50
Discuss the following!

• There are four common minerals, how many can you
  name?
• Of the four common minerals, which one makes up
  over 60 of the Earths crust?

51
Discuss the following!

• Is the streak of a mineral identical to its
  color?
• What happens to quartz when broken?

52
Hardness

• The hardness of a mineral is its resistance to
  being scratched.

53
Hardness

• Friedrich Mohs devised a hardness scale.
• In this scale, 10 well known minerals that are
  found in nature and are easily recognizable, are
  given numbers from one to ten.
• We then compare an unknown mineral to those 10

54
Hardness

• Talc (left) is the softest and has a hardness of
  1
• Gypsum is a bit harder and has a hardness of 2

55
Hardness

• Calcite (left) has a hardness of 3
• Fluorite has a hardness of 4

56
Hardness

• Apatite (left) has a hardness of 5
• Feldspar has a hardness of 6

57
Hardness

• Quartz (left), with a hardness of 7
• Topaz has a hardness of 8

58
Hardness

• Corundum (left) has a hardness of 9
• Diamond with its hardness of 10

59
Quiz Break!
60
Discuss the following!

• Does this mineral show cleavage or fracture?
• Of the four most common minerals, which is the
  highest hardness?

61
crystal shapes

• Crystal shape can be a useful property to
  identify minerals

62
specific gravity

• Specific gravity tells you how many times as
  dense as water the mineral is.
• Pure gold can have a specific gravity as high as
  19.3!

63
acid test

• Calcite is calcium carbonate, CaCO3. If a drop of
  weak hydrochloric acid is placed on calcite, the
  acid bubbles as carbon dioxide is released.

64
Other Special Properties
Magnetic
Malleable
Radioactive
Fluorescence
Taste
65
Malleable or Ductile

• Minerals that can be hammered thin or shaped are
  said to show these properties.
• Can you think of a mineral that might be shaped
  or hammered?

66
Gold would be a perfect example!
67
Magnetic

• Some minerals that contain Iron, are magnetic and
  can be picked up by a magnet.

68
Fluorescence

• This is the state of glowing while under a
  ultraviolet light.
• Some minerals even glow once the light is turned
  off!

69
Radioactive

• Some minerals, such as this uraninite, are
  radioactive.
• They give off subatomic particles that will
  activate a Geiger counter.

70
Taste

• Halite (rock salt) can be identified by its
  taste.
• This practice is not recommended!

71
The End
