A Brave New Frontier:

1
Presentation at AsiaSTAR2004, Canberra,
Australia, 7 Sep 2004

• A Brave New Frontier
• Testing Live Production Applications

Dr Kelvin Ross, Steve Woodyatt, Dr Steven
Butler SMART Testing Technologies Pty Ltd
2
Roadmap

• Avoiding Production Problems
• Testing for Service Level Management
• Case Study
• Considerations Unique to Production Testing
• Information for SLM
• Implementation Choices
• Wrap-Up

3
Why Test On Production

• Despite best efforts to test an application prior
  to deployment there are still post-deployment
  problems that frequently occur
• Server offline
• No response
• Functions not available
• Incorrect response
• Slow response
• Security breach
• Data out-of-date

4
The user experience

• What is it that the user will experience in
  dealing with our application
• E.g. Airline Reservation business process
• Search for flights
• Make a reservation
• Pay with credit card
• Obtain electronic ticket reservation code
• Confirmation by email with matching details
• Reservation details reported in frequent flyer

Information Flow
5
Distributed Architecture
Airline
External Systems
Remote Prices
Payment
PaymentGateway
Firewall
Email Gateway
Email
6
Roadmap

• Avoiding Production Problems
• Testing for Service Level Management
• Case Study
• Considerations Unique to Production Testing
• Information for SLM
• Implementation Choices
• Wrap-Up

7
Service Level Management

• Service Level Management (SLM)
• set of people and systems that allows the
  organisation to ensure that SLAs are being met
  and that the necessary resources are being
  provided efficiently
• Service Level Agreement (SLA)
• contracts between service providers and
  customers that define the services provided, the
  metrics associated with these services,
  acceptable and unacceptable service levels,
  liabilities on the part of the service provider
  and the customer, and actions to be taken in
  specific circumstances

Definitions from IEC, Service Level Management
tutorial, www.iec.org
8
SLM in the context of ITIL
9
SLA KPIs
10
Approaches
11
Business Process Auditing (BPA)
Business Process Auditing
Performance Availability Security Functionality Co
rrectness Accuracy Completion
? Automated
? Real-time
Fault Diagnosis Remedy
Reporting
Alerting
Service Level Management
12
Post-Deployment Testing and SLM

• Testing can be used to synthesise business
  transactions
• Interact with system through various interfaces
• Collect and report metrics
• Transfer of technology predominantly used
  pre-deployment

13

Problems Detected

• Problems detected
• End-To-End processes not available
• Responses slow
• Incorrect data
• Problems not detected
• Issues localised to individual clients
• Actual response times to all clients

14
Who Owns Production Testing

• The testing group?
• The support group?
• The operations group?
• The application owners?
• Marketing?
• Marriage of skills and technology required for
  efficiency

We dont call that testing syndrome
15
Which applications most benefit

• Those with real time dependence for completion of
  vital business processes
• High risk dependence
• Financial
• Market reputation
• Probity, Accountability and Liability
• Potentially unreliable or difficult to manage
  technology dependencies
• increasingly complex linkages
• distributed application architectures
• history of failure, problems
• Risk assessment
• SEVERITY X LIKELIHOOD

16
Roadmap

• Avoiding Production Problems
• Testing for Service Level Management
• Case Study
• Considerations Unique to Production Testing
• Information for SLM
• Implementation Choices
• Wrap-Up

17
Objectives

• BPA Planning checklist
• What are the critical business processes
• Who are the users
• What is the user experience
• How can success be determined
• How can the test be automated

18
Airline Reservation Case Study

• Critical business processes
• Search available flights
• Make online booking
• Change booking
• Cancel booking
• Etc.
• Users
• Consumers
• Travel agents
• Call centre

19
Airline Reservation Case Study

• What is the user experience
• Search for flights
• Available
• Function accessible
• Response returned
• Correct
• Correct flights, source and destination, time,
  etc.
• Complete
• No missing flights with available seats
• Responsive
• With tolerable response times
• How can success be determined
• What is the source of truth

20
Airline Reservation Case Study

• Choose what to monitor based on risk
• SEVERITY x LIKELIHOOD
• Previous operational reliability problems,
  complex dynamic behaviour
• What was previously tested and will continue to
  function
• Are there problems with distributed components
  continuing to run appropriately, e.g. tuxedo
  services, LDAP authentication, payment gateway
  not accessible
• Are there problems with timely propagation/retriev
  al of data, e.g. flight data not retrieved
  consistently, bookings not updated in timely
  manner

21
Test Frameworks

• Outcomes have to be reported at business level,
  not application object level
• Object level Too Low Level for Audience
• getURL search.jsp
• saveForm, submitflight
• setParam, submitflight, startime, 200412011100
• submitForm, submitflight
• Business level Appropriate for Audience
• searchFlight, return, 20041201110000, SYD,
• Action Word approaches recommended
• See Carl Nagle or Hans Buwaldas work

22
Dynamic behaviour

• searchFlight, return, 200412011100, SYD,
• Wont remain useful for long as production data
  is dynamic
• Dynamic input data
• searchFlight
• Type return
• DepartTime today()_at_10am 1 month
• ReturnTime today()_at_10am 1 month 5 days
• Depart Sydney
• Arrive Melbourne
• May even want to randomise data
• Vary depart and arrive on successive runs

23
The Test Oracle

• Mechanisms for determining correct response
• Get any response
• Get a response containing predefined expected
  values
• Expected values are checked using an oracle
• E.g. formula determining whether valid date
  returned
• Results are compared to reference data
• 3rd party data feed
• Trusted internal source, e.g. Mainframe

24
3rd Party Reference

• Trending against price data

25
Airline Reservation Case Study

• Verification failures for searchFlight response

26
Roadmap

• Avoiding Production Problems
• Testing for Service Level Management
• Case Study
• Considerations Unique to Production Testing
• Information for SLM
• Implementation Choices
• Wrap-Up

27
Scheduling the test

• How often
• 1 minutes, 5 minutes, hourly, daily, weekly
• Depends on how quickly support can respond
• What business hours
• 24x7, 9 to 5, higher frequency at certain events
• What about scheduled outages
• Planned outages, public holidays
• Coordinating tests
• Locking to prevent simultaneous tests
• E.g. dont check prices or submit orders unless
  logged in
• Semaphores

28
Sensitive Data

• Frequently there may be sensitive information
  stored in scripts and test logs
• Logins and passwords
• Credit card ids
• Personal details, e.g. phone numbers, ABNs, etc
• Where possible avoid
• Use dummy accounts
• Dont log sensitive information
• Can be difficult to control, eg. failure may save
  screen shot that then displays credentials
• Use encryption
• Sensitive data is stored in encrypted, but test
  engine still required key to send
• At least it is obfuscated

29
Where tests should be run from

• Many tools allow tests to be run from multiple
  locations
• Simulate users of different geographies
• Different connection speeds to report on a
  variety of user experiences
• Inside/outside firewall
• Probably the largest concern
• Consumer users outside, Corporate users inside
• To provide end-to-end scenarios, may need
  combination
• Scenario initiated internally, and end results
  are propagated to external, or vice-versa
• External view of web may be verified using Test
  Oracle data that is internal
• Agents may be deployed internal and external to
  run tests

30
Problems to Avoid

• Need to be aware of impact of testing
• Performance hits
• Volatile features
• Intrusive tests
• Biased results
• Compliance restrictions
• Impact on Business KPIs
• Taking measurements may distort the system being
  measured

31
Minimising the Effect of Transactions

• Cost of Transaction
• Financial purchase flight may incur credit card
  merchant fee
• Resource seats unavailable until refund
  provided, searching places additional load on
  resource pool
• Reversing the transaction
• Providing a refund, merchant fee may still apply
• What if the transaction is incomplete
• What happens if refund process doesnt
  occur/complete
• Compliance issues
• Corporate
• Legislative

32
Managing the Test Impact

• Modifications to the application under test to
  cleanup data or control test effects
• Manual fallback may be convenient option
• Test Objects
• Dummy frequent flyer accounts
• Dummy cost centres
• Testing the tests
• Access to test environment pre-deployment
• Endurance test that can be part of application
  test strategy
• Transfer of load, stress and endurance test
  scripts

33
Roadmap

• Avoiding Production Problems
• Testing for Service Level Management
• Case Study
• Considerations Unique to Production Testing
• Information for SLM
• Implementation Choices
• Wrap-Up

34
Effective Reporting

• Who are the users of the reports, different
  expectations on presentation/content
• Business/Application Manager
• Operations
• Development
• Support
• SLM
• How do they access reports?
• Web, email, Thick client
• Which reports are real-time or batched
• Is data summarised, or is original data accessible

35
Historic Reporting

• Service level reports
• Trends
• Progress
• Post Mortem Analysis

36
Realtime Reporting

• Alerts
• Current status
• Diagnosis

37
Diagnosing root cause and remedies

• Accessing fault and failure data for multiple
  components
• Pinpoint failures
• Correlation is a skill
• manual, expert analysis required
• Variety of support
• Saved actual results
• Unattended collection for debugging
• Correlation with component performance analysis
• Automated correlation with component failure
  modes
• Sophisticated expert system
• Rules that correlate tested events to arrive at
  diagnosis of root cause(s)

38
Fault Analysis
39
Roadmap

• Avoiding Production Problems
• Testing for Service Level Management
• Case Study
• Considerations Unique to Production Testing
• Information for SLM
• Implementation Choices
• Wrap-Up

40
Tool Requirements

• Evaluation Checklist
• Test script can interact with a variety of
  systems
• GUI, Terminal, APIs, HTTP, SOAP, POP/SMTP, etc.
• Test script can respond to dynamic behaviour
• Agents can be deployed internal/external of the
  WAN
• Ability to control frequency
• Time based functions can be used to control
  execution
• Functions available for data manipulation for
  dynamic responses (time, extraction, etc.)
• Inter-process coordination between tests using
  locking/semaphores
• Test steps can be reported on business process
  steps, object actions can be hidden in reports
• Test outcomes saved to repository for later
  analysis
• Ability to export data for other purposes, e.g.
  trending, visualisation, etc.
• Reporting capability on stored data
• Online ability to drill into test data for
  problem diagnosis
• Alerting mechanisms to email, SMS, online
  dashboards
• Alerting can be controlled, ie. escalation,
  filtering
• Apply weighting to each criteria according to need

41
Implementation Choices

• Available Commercial Tools/Services
• SmartTestTech - SMARTCat
• Mercury Topaz
• Compuware Vantage
• Keynote
• Lesser extent, enterprise monitoring tools
• BMC Patrol, Tivoli, HP Openview
• Home Brew Tools
• Extensive support for testing protocols in open
  source frameworks
• E.g. Java/Junit, .Net/Nunit, Perl/Ruby/Python
• Extend Existing In-house Regression Test Suites
• Automated scripts may be adapted
• Robot, QARun, WinRunner, Silk
• Post results to Database
• Provide reporting capability
• e.g. Crystal Reports, Cognos, etc

42
Roadmap

• Avoiding Production Problems
• Testing for Service Level Management
• Case Study
• Considerations Unique to Production Testing
• Information for SLM
• Implementation Choices
• Wrap-Up

43
Wrap-up

• Strong business case
• Benefit in bringing testing to the production
  world
• Small age availability increase translates to
  large
• Manages reputational risk with user base
• Large investment in SLM
• SLAs very ad-hoc and not measured
• Uses tests to provide SLM reports to Business /
  Application Managers
• Leveraging the investment in test resources
• Protects overall investment

44
Questions Answers

• Contact details
• Dr Kelvin Ross
• SMART Testing Technologies Pty Ltd
• PO Box 131, West Burleigh, Q4219
• AUSTRALIA
• Ph 61 7 5522 5131
• Email kelvinr_at_smarttesttech.com
