Pest Management Approaches General Approaches

1
Insect Pests of Fruit Crops
Welcome to class!
2
MANAGEMENT OF FRUIT PESTS IN THE HOME GARDEN

• INSTRUCTOR
• Dan Mahr
• Extension Fruit Entomologist
• University of Wisconsin -- Madison

3
A Guide to Where We Are Going

• An overview of the general methods and approaches
  to pest management.
• Tree fruit pests.
• Biology and damage.
• Control.
• Strawberry pests.
• Biology and damage.
• Control.

4
Resources in Your Manuals
5
Pest Management ApproachesOverview of Control
Methods

• Chemical control (insecticides).
• Physical control (traps barriers).
• Mechanical control (hand picking).
• Biological control (beneficial natural enemies of
  the pests).
• Cultural controls (sanitation).
• Resistant crop varieties.
• Do nothing.
• Integrated pest management (IPM).

6
Pest Management ApproachesEveryone has
different needs!
7
Pest Management ApproachesGeneral Approaches to
Control

• Traditional, routine use of pesticides.
• Reduced pesticide use based on monitoring.
• True IPM.
• Organic gardening, including use of accepted
  pesticides.
• Non-chemical pest control.
• No controls applied.

8
Pest MonitoringAn Essential Key to Insect
Management

• Visual inspection.
• Trapping.
• Knowledge of pests.
• Dedication.

9
Insect Traps

• Odor traps (pheromone traps).
• Visual traps.
• Combination traps.

10
Insect Traps
11
End of overview of control
any questions?
12
Apple Pests
Apples are attacked by more types of insect pests
than any other Wisconsin fruit crop.
13
Apple Pests

• Key Pests
• Plum curculio
• Codling moth
• Apple maggot

• Secondary Pests
• Leafrollers
• Aphids
• Leafminers
• Spider mites

14
Plum curculio
15
Plum curculio
16
Plum curculio Control

• Visual monitoring for injury (no traps).
• Limb-tapping.
• Insecticides.
• Conventional or botanical (not Bt, oils, or
  soap).
• 1-2 applications (petal fall first cover) more
  often if using botanicals.
• Surround (clay barrier).

17
Surround Insecticide particle film
technology. kaolin clay. 50 lbs/acre per
application. Weekly application.
18
Plum curculio Summary

• One generation per year.
• Overwinter as adults.
• Enter orchard around petal fall.
• Produce crescent-shaped egg-laying scars.
• Result in misshapen fruit.
• Rarely larvae in fruit.
• Visual monitoring.
• Control by limb-tapping or insecticides
• Petal fall
• First cover

19
Codling moth
20
Codling moth
21
Codling moth
22
Codling moth Control

• Visual monitoring for injury pheromone traps.
• Sanitation (destroy dropped fruit).
• Insecticides.
• Conventional or botanical (not Bt, oils,
  Surround, or soap).
• 1-2 applications per generation (begin at first
  cover).

23
Codling moth Summary

• Two generations per year.
• Adults start egg laying around petal fall.
• Larvae feed in core of fruit.
• Usually one tunnel to outside may be frass.
• Second generation in July August.
• Visual monitoring for damage pheromone traps.
• Control by insecticides
• Petal fall
• First cover
• Destroy dropped fruit.

24
Apple maggot(railroad worm)
Apple maggot is the most serious home apple pest.
25
Apple maggot(railroad worm)
26
Apple maggot(railroad worm)
27
Apple maggot Trapping
28
Apple maggot Control

• Baited visual traps for monitoring and control.
• About 1 trap per 50 fruit.
• Hang July 1.
• Insecticides.
• Conventional or botanical (not Bt, oils, or
  soap).
• 1-3 applications (start about July 10, or based
  on trapping) more often if using botanicals.
• Surround provides some control.
• Pick up fallen fruit.

29
Apple maggot Summary

• One generation per year.
• Adults flying about July 1 Sept. 1.
• Adults must feed before laying eggs.
• Larvae tunnel throughout fruit, leaving trails.
• Fruit fall from tree and rot.
• Monitor using traps.
• Control by trapping or insecticides
• mid-July to late August.

30
Secondary pests Leafrollers
3-4 species of leafrollers are common on apple
and other fruit trees in Wisconsin.
31
Secondary pests Leafrollers
32
Secondary pests Leafrollers
33
Secondary pests Leafrollers

• 1-2 generations per year (depending on species).
• Primarily a problem immediately after bloom.
• Leaf feeding is not important.
• Feeding on fruit surface is mostly cosmetic.
• Control with conventional insecticides or Bt
• Immediately after bloom.

34
Secondary pests Aphids
35
Secondary pests Aphids

• Several types.
• Usually have no impact on established trees.
• Heavy infestations may retard young trees.
• Heavily attacked by beneficial insects.
• If needed, control with conventional insecticides
  or insecticidal soap.

36
Secondary pests Leafminers
37
Secondary pests Leafminers

• Usually only a curiosity on home trees.
• Usually controlled by beneficial insects.
• Damage occurs at numbers greater than 5/leaf.
• Three generations per year.

38
Secondary pests Spider mites
39
Secondary pests Spider mites

• Usually not a problem on home trees.
• High populations can cause stress and reduce tree
  vigor.
• A summer pest.
• Usually under good biological control.
• If necessary, use dormant oil or summer oil.

40
End of apple insects
any questions?
41
Pests of Stone Fruits
42
Stone Fruit Pests

• Key Pests
• Plum curculio
• Cherry fruit fly

• Secondary Pests
• Leafrollers
• Aphids
• Spider mites
• Wood borers

Plum curculio is the most serious pest of plums
and apricots. Cherry fruit flies are the most
serious pests of cherries.
43
Cherry fruit flies

• Black cherry fruit fly
• Cherry fruit fly

44
Cherry fruit flies
45
Cherry fruit flies
46
Cherry fruit flies Control

• Baited visual traps (yellow boards) for
  monitoring.
• Insecticides.
• Conventional or botanical (not Bt, oils, or
  soap).
• 1-3 applications (start about June 10, or based
  on trapping) more often if using botanicals.

47
Cherry fruit flies Summary

• Two species similar biology and damage.
• One generation per year.
• Adults flying about June 10 July 20.
• Larvae tunnel throughout fruit, causing rot.
• Monitor using traps.
• Control by insecticides
• mid-June to mid-July.

48
Secondary pests Wood borers

• American plum borer
• Lesser peachtree borer
• Peachtree borer

49
Secondary pests Wood borers
50
Secondary pests Wood borers
51
Secondary pests Wood borers

• Cultural controls
• Avoid injury.
• Remove tight mouse guards and wraps.
• Clean wounds and apply tree-wound compound.
• Chemical controls
• Difficult to kill larvae in wood.
• Aimed at killing young larvae as they hatch.
• Timing lengthy varies with insect species.

52
End of tree fruit pests
any questions?
53
Strawberry Pests
54
Strawberry Pests

• Key Pest
• Tarnished plant bug

• Secondary Pests
• Strawberry leafroller
• Strawberry bud weevil (clipper)
• Spittlebug

55
Tarnished plant bug
56
Tarnished plant bug
57
TPB Control

• Visual monitoring for injury tapping flower
  clusters.
• Control with insecticides.
• Conventional or botanical (not Bt, oils, or
  soap).
• 1-2 applications 1 prebloom and the second
  toward the end of flowering.

58
TPB Summary

• Two generations per year only the first is
  important.
• Nymphs (mostly) feed on flowers and young fruit.
• Cause cat-facing and apical seediness.
• Visual monitoring or flower-tapping.
• Control by insecticides
• Prebloom
• Toward the end of bloom.

59
Secondary pests Strawberry Leafroller
60
Secondary pests Strawberry Leafroller

• Relatively uncommon.
• Usually under good biological control.
• Outbreaks can be substantial.
• Plants are defoliated production is lost.
• Control with conventional insecticides or Bt.
• Pheromone traps available for timing sprays.

61
Secondary pests Strawberry Bud
Weevil

• Very common.
• Clips off flower buds.
• Plants may compensate.
• Insecticide application at flower bud development
  (before bloom).

62
Secondary pests Strawberry Bud
Weevil
63
Secondary pests Spittlebug
64
Secondary pests Spittlebug

• Very common.
• Attacks many kinds of plants, including weeds.
• Usually more noticeable than damaging.
• Control broadleaf weeds.
• If a major problem, control with conventional or
  botanical insecticides.

65
End of class
any last questions?
