Gokul Varadhan

1
Accurate Minkowski Sum Approximation of
Polyhedral Models

• Gokul Varadhan
• Dinesh Manocha

University of North Carolina at Chapel Hill
http//gamma.cs.unc.edu/recons
2
Minkowski Sum
3
Minkowski Sum
4
Minkowski Sum
5
Minkowski Sum
6
Applications

• Motion planning
• Penetration depth computation dynamic
  simulation
• Packing
• CAD offsets
• Animation

7
Motion Planning
Workspace
Config Space
O
R
8
Dynamic Simulation

• Collision Detection
• Penetration Depth
• Computation

Kim et al. 2002
9
Packing
10
Offsetting
11
Morphing
A
B
Morph
12
Minkowski Sum Computation

• Difficult to compute the Minkowski sum exactly
• High complexity
• Minkowski sum of two nonconvex objects of size n
  can have O(n6) complexity

2D example Agarwal et al. 02
13
Minkowski Sum Computation

• Minkowski sum of two convex objects much easier
  to compute
• O(n2) complexity
• Common approach
• Decompose the two objects into convex pieces
• Compute pairwise Minkowski sums between
  all pairs of convex pieces
• Compute the union of pairwise Minkowski sums

14
Minkowski Sum Computation

• Main bottleneck
• Union computation
• Large number of primitives
• Given two objects with m and n convex pieces,
  perform a union of mn primitives
• Typically, mn very large (in the order of
  thousands)
• Exact union computation is prone to robustness
  problems and degeneracies

15
Previous Work

• 3D Minkowski sum
• Lozano-Perez 83
• Evans et al. 92
• Ghosh 93
• Special cases
• 2D Lee et al. 98 Flato Halperin 00
• Convex Guibas Seidel 87
• Slope monotone surfaces Seong et al. 02
• Superset of the Minkowski sum
• Kaul Rossignac 91, Basch et al. 96

16
Our Approach

• Do not compute exactly
• Approximate it using distance field based
  volumetric techniques

17
Volumetric Approach
A
M
Sampling
Reconstruction
Operation
18
Volumetric Approach

• Sampling
• Generate a volumetric grid
• At each grid point, compute
• Distance to the surface
• Sign i.e. inside ( ) /outside ( ) status

D Distance Sign
19
Volumetric Approach

• 2. Operation
• For each geometric operation (e.g.
  union/intersection), perform a min/max operation
  on the distance fields

D min (D1, D2)
20
Volumetric Approach

• 3. Reconstruction
• Perform isosurface extraction using Marching
  Cubes (MC) or its variant

A
21
Challenges

• 1. Accuracy
• Depends on rate of sampling, i.e., resolution of
  the underlying volumetric grid
• Undersampling can result in poor approximation

A
M
MC
22
Challenges

• 2. Efficiency
• Large number of primitives
• Inefficient to define sign and distance queries
  in terms of all the primitives
• Need culling techniques

23
Main Result

• An accurate and efficient Minkowski sum
  approximation algorithm

24
Main Result

• An accurate and efficient Minkowski sum
  approximation algorithm
• Geometric Error Bound
• Bound the two-sided Hausdorff distance between M
  A
• Topological Guarantee
• A has the same topology as M

Together these two guarantees ensure a good
quality of approximation
25
Main Result

• An accurate and efficient Minkowski sum
  approximation algorithm
• Culling techniques that improve performance

26
Outline

• Approximate Algorithm
• Culling Techniques
• Results
• Discussion

27
Approximate Algorithm

• Sampling
• Generate an adaptive volumetric grid satisfying a
  sampling condition
• Operation
• Compute a distance field on the grid by
  performing min/max operations
• Reconstruction
• Obtain an approximation by extracting an
  isosurface from the adaptive distance field

28
Approximate Algorithm

• Sampling
• Generate an adaptive volumetric grid satisfying a
  sampling condition
• Operation
• Compute a distance field on the grid by
  performing min/max operations
• Reconstruction
• Obtain an approximation by extracting an
  isosurface from the adaptive distance field

29
Main Idea

• Ensure that within each grid cell, M should be
  simple

• A cell that is intersected by the boundary of M
  should exhibit a sign change
• The boundary of M restricted to the cell should
  be a topological disk

30
Complex Cell Test

• M intersects the cell (volume) and the grid
  vertices belonging to the cell do not exhibit a
  sign change

No cell in the grid can be complex
31
Main Idea

• Ensure that within each grid cell, M is simple

• A cell that is intersected by the boundary of M
  should exhibit a sign change
• The boundary of M restricted to the cell should
  be a topological disk

32
Star-shapedness

• A primitive is star-shaped if there exists a
  point inside the primitive that can see every
  point in the primitive

33
Star-shaped Test

• M restricted to the cell should be star-shaped

Not star-shaped
Star-shaped
34
Topological Guarantee

• Theorem If every grid cell C satisfies the
  following criteria
• then the approximate Minkowski sum A has
  the same topology as the exact Minkowski sum M

• Complex cell test
• M must not be complex w.r.t C
• Star-shaped test
• M must be star-shaped w.r.t C

35
Adaptive Grid Generation

• Start with a grid cell that bounds M
• Perform adaptive subdivision
• Each grid cell must satisfy two criteria
• Complex cell test
• Star-shaped test
• Otherwise subdivide the grid cell

36
Adaptive Grid Generation
A
D
C
B
37
Adaptive Grid Generation

• Easy to implement these tests
• Complex cell test ? Max-norm distance computation
  Varadhan et al. 2003
• Star-shaped test ? Linear programming

38
Adaptive Grid Generation

• These tests do not require an explicit
  representation of the surface
• Applicable when the surface is defined as a
  Boolean expression
• Well suited to our problem as M is defined as a
  Boolean expression

39
Star-shaped Test

• For polyhedral primitives, it reduces to linear
  programming

Linear constraint
n (c - p) gt 0
n
c
p
40
Star-shaped Test

• Check if the linear program has a feasible
  solution

p
41
Star-shaped Test

• Booleans on primitives
• If both A and B are star-shaped w.r.t a common
  point p, then so is

• Combine the linear
• constraints
• Conservative

p
42
Geometric Error Bound

• We can bound the two-sided Hausdorff error to be
  less than ?
• Add an additional criterion
• Subdivide a cell if
• Hausdorff distance between the approximation and
  some primitive is greater than ?

43
Outline

• Approximate Algorithm
• Culling Techniques
• Results
• Discussion

44
Culling Techniques

• Cell culling
• Eliminate cells that do not contain a part of M
• Primitive culling
• When performing a query, disregard primitives
  that do not contribute to the answer

45
Cell Culling

• Eliminate cells do not contain a part of M

P2
A
B
P1
C
D
46
Primitive Culling

• The Minkowski sum is defined in terms of a large
  number of primitives
• Need to define the sign and distance queries in
  terms of fewer primitives

47
Primitive Culling

• A primitive influences the query only if its
  boundary intersects the cell (volume)

P
P
P
C
C
C
p
p
p
Disregard cell C (cell culling)
Disregard P
Consider P
48
Outline

• Approximate Algorithm
• Culling Techniques
• Results
• Discussion

49
Implementation

• 2 GHz Pentium IV PC, 1GB RAM
• Choice of isosurface extraction
• Dual Contouring Ju et al. 2002

50
Spoon (336 tris)
Anvil (144 tris)
Union of 4,446 primitives
1 min
15K tris
51
Rod (24 tris)
Brake Hub (4,736 tris)
Union of 1,777 primitives
2.3 mins
45K tris
52
Spiral (500 tris)
Wrench (772 tris)
Union of 38,703 primitives
5 mins
25K tris
53
Scissors (636 tris)
Knife (516 tris)
Union of 63,790 primitives
13 mins
26K tris
54
444 tris
1,134 tris
55
Union of 66,667 primitives
52 mins
358K tris
56
Offsetting
Cup Offset 33 secs 14K tris
Cup (1,000 tris)
Gear Offset 84 secs 22K tris
Gear 2,382 tris)
57
Motion Planning
A Simple Algorithm for Complete Motion Planning
of Translating Polyhedral Robots, WAFR 2004
58
Assembly Planning
A Simple Algorithm for Complete Motion Planning
of Translating Polyhedral Robots, WAFR 2004
59
Outline

• Approximate Algorithm
• Culling Techniques
• Results
• Discussion

60
Benefit of Culling

• Cell and primitive culling techniques improve
  performance by over two orders of magnitude
• More than 90 of the speedup comes from primitive
  culling
• Anvil Spoon example
• 7 hours without culling
• 1 minute with culling

61
Limitations

• Axis-aligned subdivision cannot handle degenerate
  cases where two primitives touch each other
• Use other subdivision strategies Sriram et al.
  2004
• Cannot handle all inputs
• Self intersections, non-manifolds
• Sampling condition is conservative

62
Main Result

• An accurate and efficient Minkowski sum
  approximation algorithm
• Good quality of approximation
• Guaranteed topology and a tight two-sided
  Hausdorff error bound

63
Main Result

• An accurate and efficient Minkowski sum
  approximation algorithm
• Good quality of Minkowski sum approximation
• Use of culling techniques significantly improves
  performance

64
Main Result

• An accurate and efficient Minkowski sum
  approximation algorithm
• Good quality of Minkowski sum approximation
• Use of culling techniques significantly improves
  performance
• Simple to implement and requires only two tests
• Complex cell test ? max-norm distance computation
• Star-shaped test ? linear programming

65
Conclusion

• Practical algorithm
• Applied it to complex polyhedral models
• Offset computation and motion planning

66
Ongoing Future Work

• Swept volume computation
• Approximate Voronoi diagram computation
• Less conservative scheme

67
Acknowledgement

• Danny Halperin for useful discussions on
  Minkowski sum
• Young Kim, Shankar Krishnan and TVN Sriram
• David Applegate for a modified dual LP code
• Joe Warren and Scot Schaefer for dual contouring
  code
• Members of UNC Gamma group

68
Acknowledgement

• ARO Contracts DAAD19-02-1-0390 and
  W911NF-04-1-0088
• NSF awards ACI 9876914 and ACR-0118743
• ONR Contracts N00014-01-1-0067 and
  N00014-01-1-0496
• DARPA Contract N61339-04-C-0043
• Intel

69
Thank you!
URL http//gamma.cs.unc.edu/recons
70
Performance

• 2 GHz Pentium IV PC, 1GB RAM

71
Star-shaped Test

• Need to enforce the topological disk property
• Obvious approach
• Test if the Euler characteristic is equal to 1
• Issue We do not have a polygonization of the
  boundary of M
• We use the star-shaped test to enforce this
  property

72
Performance

• Overall performance dominated by the sampling
  step
• More subdivision takes place in the vicinity of
  complex features such as thin sheets, needle like
  features, small holes

73
Level of Subdivision
Number of Voxels
Level of Subdivision
74
Intersection Test

• Calculate distance under max-norm
• Test if

d Max-norm distance at O L length of the cell
P
A
B
O
d
C
D
L
75
Cell Culling

• If the intersection test fails, do not consider
  the cell any further

Max-norm distance at O
P2
A
B
P1
O
C
D
76
Sign Query

• Strictly speaking, the sign query is a global
  query
• Sign of a point depends on all the primitives

• This definition results in a considerable
  overhead because the sign query is used
  frequently

77
Primitive Culling

• Transform it to a local query
• Suppose we wish to perform a sign query at point
  p contained in a grid cell C
• Consider only those primitives whose boundary
  intersects C
• This preserves correctness of the query

78
Primitive Culling

• Distance query can be handled similarly
• We care only for a local distance
