Title: Lecture 29 ECE743


1
Lecture 29 - ECE743
3-Phase Induction Machines Reference Frame Theory
Part IV
Professor Ali Keyhani
2
q-d Axis Voltage Equations
  • q-d axis voltage equations can be written by
    inspection of Fig.1
  • And flux linkage equations are

3
q-d Axis Voltage Equations
Fig.1 Axis of 2-pole, 3-phase
symmetrical induction.
4
q-d Axis Voltage Equations
Fig. 2. A 2-pole 3-phase symmetrical
induction machine.
5
q-d Axis Voltage Equations
Fig. 2. A 2-pole 3-phase symmetrical
induction machine.
6
q-d Axis Voltage Equations
Fig. 3. Equivalent circuits of a
3-phase, symmetrical induction machine with
rotating q-d axis at speed of ?.
7
q-d Axis Voltage Equations
Fig. 3. Equivalent circuits of a
3-phase, symmetrical induction machine with
rotating q-d axis at speed of ?.
8
q-d Axis Voltage Equations
Fig. 3. Equivalent circuits of a
3-phase, symmetrical induction machine with
rotating q-d axis at speed of ?.
9
q-d Axis Voltage Equations
  • When ?0 (stationary reference frame), voltage
    equations become,
  • When ? ?r (rotor reference frame) which is also
    referred to as Parks transformation, voltage
    equations become,

10
q-d Axis Voltage Equations
  • When ? ?e (synchronously rotating reference
    frame), the voltage equations become,
  • Synchronously rotating reference frame is used
    when incorporating the dynamic characteristics od
    an induction machine into a digital computer
    program used to study the transient and dynamic
    stability of large power systems.
  • Synchronously rotating reference frame is also
    used in variable frequency study of induction
    machines.

11
Per Unit System
  • Machine data,
  • - Stator line frequency f (Hz)
  • - Output horse power HP (hp)
  • - Line to line voltage V (rms V)
  • - Pole number P
  • Base values,

12
Per Unit System
  • Base electrical angular velocity ?b2?fb
    rad/sec,
  • Base mechanical angular velocity
    ?brm2?fb/(P/2)

Let
13
Per Unit System
  • Define
  • Machine voltage equations in p.u can be written
    as

14
Per Unit System
  • Torque base

15
Per Unit System
  • Per unit equation of motion is
  • Define quantity

16
Per Unit System
Therefore,
J kg.m2 Pb watts ?b rad/sec
17
Per Unit System
  • The quantity H is called the inertia constant and
    has units of seconds.

n rpm KVA base KVA J kg.m2 Wk2 Lb-ft2
18
Per Unit System
  • Example

rs 0.016 ? r?r 0.001 ? Xls 0.0706 ? X?lr
0.0903 ? X?m 2.8413 ?
HP 115 Poles 4 Vrated 210rms/phase f 50
Hz (rated) J 100 Lb-ft2
- Base values
Pb (746)(115) 85,800 watts Vb (210)?2 297
Volts peak Ib (2/3)(Pb/Vb) 193 Amp.peak Zb
(Vb/Ib) (297/193) 1.54 ?
19
Per Unit System
- Base angular frequency ?b 2?(50) 314
rad/sec
- Torque base Tb Pb(P/2)/?b 547 N-m
20
Per Unit System
