THE STRUCTURE OF THE ATOM

1
THE STRUCTURE OF THE ATOM

• ATOMIC MODELS

2
PIONEERS OF THE ATOM

• DEMOCRITUS
• LAVOISIER
• DALTON
• THOMPSON
• MILLIKEN
• RUTHERFORD

3
THE EARLY ATOM
ITS ALL GREEK TO ME...

• DEMOCRITUS IS THE MAN!!!
• YOU KNOW IT!

4
DEMOCRITUS

• WAS A GREEK PHILOSOPHER THAT BEGAN WONDERING WHAT
  WAS THE UNIVERSE MADE UP OF.
• HE PROPOSED THAT ALL THE MATTER IN THE UNIVERSE
  IS COMPOSED OF TINY PARTICLES
• THESE PARTICLES ARE INDIVISABLE
• HE CALLED THESE PARTICLES ATOMOS (MEANS
  INDIVISABLE)
• BUT HE HAD AN OPPONENT

5
ARISTOTLE SCEPTIC
DEMOCRITUS IS AN IGNORAMUS!
ARISTOTLE WAS MUCH MORE POPULAR AND HE OPPOSED
THE IDEA OF ATOMS!
6
ARISTOTLE SCEPTIC
DEMOCRITUS IS AN IGNORAMUS!
ARISTOTLE BELIEVED THAT MATTER WAS CONTINUOUS.
7
DEMOCRITUS ATOMS
8
SO...CHEMISTRY DIED FOR ABOUT 1400 YEARS
UNTIL...
9
SO...CHEMISTRY DIED FOR ABOUT 1400 YEARS
IN THE 1700S
10
FOUNDATIONS OF ATOMIC THEORY

• THE PREDOMINATE BELIEF BY THE MID 1700S WAS THE
  MODERN DEFINITION OF AN ELEMENT AS A SUBSTANCE
  THAT CANNOT BE BROKEN DOWN BY ORDINARY CHEMICAL
  MEANS
• IT WAS ALSO BELIEVED THAT ELEMENTS COMBINE TO
  FORM COMPOUNDS THAT HAVE DIFFERENT PHYS AND CHEM
  PROPERTIES THAN THOSE OF THE ELEMENTS THAT FORM
  THEM.

11
FOUNDATIONS OF ATOMIC THEORY

• HOWEVER, THERE WAS CONTROVERSY AS TO WHETHER
  ELEMENTS ALWAYS COMBINE IN THE SAME RATIO WHEN
  FORMING A PARTICULAR COMPOUND.
• IN THE 1790S, THE STUDY OF MATTER WAS
  REVOLUTIONIZED BY A NEW EMPHASIS ON THE
  QUANTITATIVE ANALYSIS
• SCIENTISTS INVESTIGATIONS WERE MADE MORE
  ACCURATE BY NEW IMPROVED BALANCES

12
ANTOINNE LAVOISIER TOOK ADVANTAGE
MATTER CAN BE NEITHER CREATED NOR DESTROYED.
HE BEGAN TO GATHER EVIDENCE ABOUT HOW MATTER
BEHAVED BEFORE AND AFTER A REACTION.
13
ANTOINNE LAVOISIER TOOK ADVANTAGE
MATTER CAN BE NEITHER CREATED NOR DESTROYED.
HE DISCOVERED THAT THE TOTAL MASS OF THE
INGREDIENTS OF A CHEMICAL REACTION WAS THE SAME
AS THE TOTAL MASS OF THE RESULTS
14
2 OTHER FUNDAMENTAL IDEAS
WERE INVESTIGATED...
THE LAW OF DEFINITE PROPORTION
15
2 OTHER FUNDAMENTAL IDEAS
WERE INVESTIGATED...
THE LAW OF MULTIPLE PROPORTIONS
16
2 OTHER FUNDAMENTAL IDEAS
WERE INVESTIGATED...
IM BETTER LOOKING THAN PROUST!
17


CARBON MONOXIDE
C
O
CO


CARBON MONOXIDE
C
O
CO



CARBON DIOXIDE
O
C
O
CO2
18
DALTONS THOUGHTS

• IN 1808, JOHN DALTON PROPOSED AN EXPLANATION FOR
  THE LAW OF CONS OF MASS, THE LAW OF DEFINITE
  PROPORTIONS, FORMULATED THE LAW OF MULTIPLE
  PROPORTIONS.
• HE REASONED THAT ELEMENTS WERE COMPOSED OF ATOMS
  THAT ONLY WHOLE S OF ATOMS CAN COMBINE TO
  FORM COMPNDS
• HIS THEORY CAN BE SUMMARIZED IN 5 STATEMENTS.

19
(No Transcript)
20


21
DALTON AND HIS CONTEMPORARIES
THE EARLIEST THEORISTS THOUGHT THE ATOM WAS HARD
AND ROUND, MUCH LIKE TINY MARBLES OR BALL
BEARINGS.
22
STRUCTURE OF THE ATOM

• ALTHOUGH DALTON THOUGHT ATOMS WERE INDIVISIBLE,
  INVESTIGATORS IN THE LATE 1800S PROVED OTHERWISE
• IT SOON BECAME CLEAR THAT ATOMS ARE ACTUALLY
  COMPOSED OF SEVERAL BASIC TYPES OF SMALLER
  PARTICLES
• AND ITS THE NUMBERS AND ARRANGEMENTS OF THESE
  SUB-ATOMIC PARTICLES THAT DETERMINES THE IDENTITY
  OF THE ATOM.

23
STRUCTURE OF THE ATOM

• THE FIRST DISCOVERY OF A SUBATOMIC PARTICLE
  RESULTED FROM THE INVESTIGATIONS INTO THE
  RELATIONSHIP BETWEEN ELECTRICITY AND MATTER.
• IN THE LATE 1800S, MANY EXPERIMENTS WERE
  PERFORMED IN WHICH ELECTRIC CURRENT WAS PASSED
  THROUGH VARIOUS GASES AT LOW PRESS
• CARRIED OUT IN
  TUBES CALLED
  CATHODE-RAY TUBES

24
STRUCTURE OF THE ATOM

• INVESTIGATORS NOTICED THAT WHEN CURRENT WAS
  PASSED THROUGH A CATHODE RAY TUBE, THE SURFACE OF
  THE TUBE DIRECTLY OPPOSITE THE CATHODE GLOWED.

CATHODE RAY TUBE
25
STRUCTURE OF THE ATOM

• THEY HYPOTHESIZED THAT THE GLOW WAS CAUSED BY A
  STREAM OF PARTICLES
• THEY CALLED THE STREAM A CATHODE RAY

CATHODE RAY TUBE
26
STRUCTURE OF THE ATOM

• THE CATHODE RAY TRAVELED FROM THE CATHODE TO THE
  ANODE WHEN CURRENT WAS PASSED THROUGH THE TUBE.
• THE CATHODE RAY TUBE OPENED THE DOOR FOR J.J.
  THOMPSON

CATHODE
ANODE
CATHODE RAY TUBE
27
J. J. THOMPSON
I PLAY WITH ELECTRONS
28
J. J. THOMPSON

• THOMPSONS INVESTIGATIONS SUPPLIED EVIDENCE THAT
  THE CATHODE RAY COULD BE DEFLECTED BY APPLYING A
  POSITIVELY CHARGED ELECTRIC FIELD
• THIS HELPED THOMPSON
  DISC- OVER THAT THE
  CATHODE RAY WAS
  NEGATIVELY CHARGED.

29
(No Transcript)
30

• THOMPSON WAS ABLE TO MEASURE THE RATIO OF THE
  CHARGE OF CATHODE RAY PARTICLES TO THEIR MASS
• HE FOUND THAT THE RATIO WAS THE SAME REGARDLESS
  OF THE METAL USED AS THE CATHODE
• THOMPSON CONCLUDED THAT ALL CATHODE RAYS ARE
  COMPOSED OF IDENTICAL NEGATIVELY CHARGED
  PARTICLES
• WHICH WERE LATER CALLED ELECTRONS

31
THOMPSONS ATOMIC MODEL

• HE PROPOSED THAT THE ATOM LOOKS SOMETHING LIKE A
  CHOCOLATE CHIP COOKIE

THE CHIPS WOULD BE HIS ELECTRONS
THE COOKIE PART IS POS. MATTER TO CANCEL OUT THE
NEG. ELECTRONS
32

• THOMPSONS EXPERIMENTS REVEALED THAT THE ELECTRON
  HAS A VERY LARGE CHARGE IN RELATION TO ITS MASS
• IN 1909, ROBERT MILLIKAN, PERFORMED AN INGENIOUS
  EXPERIMENT TO CALCULATE THE MASS OF AN ELECTRON
• HE DISCOVERED THAT THE MASS OF THE ELECTRON IS
  ABOUT 1/2000TH THE MASS OF THE SIMPLEST ATOM
  (HYDRO.)

33
HELLO, MILLIKAN
DATS RIGHT! I SAVED THE DAY!
34

• HIS OIL DROP EXPERIMENT SHOWED THAT EVEN THOUGH
  THE ATOMS OF DIFFERENT ELEMENTS ARE VERY
  DIFFERENT, THEIR ELECTRONS ARE IDENTICAL.
• AN ELECTRON IS AN ELECTRON
• THE DIFFERENCE BETWEEN TWO DIFFERENT ATOMS IS
  THEIR NUMBER OF ELECTRONS NOT THEIR TYPE OF
  ELECTRON.
• HE ALSO CALCULATED THAT THE ELECTRONS MASS IS
  9.109x10-31kg

35
SO FAR WEVE LEARNED

• THOMPSONS MILLIKANS IDEAS
• ATOMS ARE IN FACT DIVISABLE
• ELECTRONS ARE PRESENT IN ATOMS OF ALL ELEM.
• ONE OF THE ATOMS FUNDMNTL PARTICLES IS NEG.
  CHARGED
• ATOMS ARE ELECTRICALLY NEUTRAL, SO THERE MUST BE
  A () CHARGE TO BALANCE OUT THE ()
• BECAUSE ELECTRONS ARE BASICALLY MASSLESS THERE
  MUST BE SOMETHING ELSE THAT ACCOUNTS FOR THE
  ATOMS MASS.

36
OTHER SIGNIFICANT DISCOVERIES

• IN 1886, WHEN E. GOLDSTEIN OBSERVED A CATHODE-RAY
  TUBE AND FOUND RAYS TRAVELLING IN THE OPPOSITE
  DIRECTION OF THAT OF THE CATHODE RAYS
• HE CALLED THE RAYS CANAL RAYS AND CONCLUDED THAT
  THEY WERE COMPOSED OF POS. PARTICLES
• IT WAS SOON DISCOVERED THAT THE POSITIVE
  PARTICLES MASS IS ABOUT 2000 TIMES THAT OF THE
  ELECTRON

37
OTHER SIGNIFICANT DISCOVERIES

• IN 1932, THE ENGLISH PHYSICIST JAMES CHADWICK
  CONFIRMED THE EXISTANCE OF YET ANOTHER SUBATOMIC
  PARTICLE.
• THE NEUTRON, WHICH IS A PARTICLE WITH NO CHARGE
• HAS A MASS NEARLY EQUAL TO THAT OF THE PROTON
• THEREFORE THE SUBATOMIC PARTICLES ARE THE
  ELECTRON, PROTON, AND NEUTRON.

38
(No Transcript)
39
Properties of Subatomic Particles
RELATIVE
RELATIVE
ACTUAL
SYMBOL
CHARGE
PARTICLE
MASS (g)
MASS
40
THE ATOMIC NUCLEUS

• WHEN SUBATOMIC PARTICLES WERE DISCOVERED,
  SCIENTISTS WONDERED HOW THESE PARTICLES WERE PUT
  TOGETHER IN AN ATOM.
• THIS WAS A DIFFICULT QUESTION TO ANSWER, GIVEN
  HOW TINY ATOMS ARE.
• MOST SCIENTISTS THOUGHT IT LIKELY THAT THE
  ELECTRONS WERE EVENLY DISTRIBUTED THROUGHOUT AN
  ATOM FILLED UNIFORMLY WITH POSITIVELY CHARGED
  MATERIAL.

41
ERNEST RUTHERFORD
HOW IS THE ATOM BUILT?
IN 1911, RUTHERFORD PERFORMED ONE OF THE MOST
BRILLIANT INVESTIGATIONS EVER CONCIEVED.
42
RUTHERFORDS FAMOUS EXPERIMENT

• RUTHERFORD SET OUT TO TEST THE THOMPSON MODEL OF
  THE ATOM
• THE TEST USED RELATIVELY MASSIVE RADIOACTIVE
  ALPHA PARTICLES
• ALPHA PARTICLES (?) ARE HELIUM ATOMS THAT HAVE
  LOST THEIR 2 ELECTRONS AND HAVE A DOUBLE
  POSITIVE CHARGE BECAUSE OF THE 2 REMAINING PROTONS

43

• IN THE EXPERIMENT, RUTHERFORD DIRECTED A NARROW
  BEAM OF ALPHA PARTICLES AT A VERY THIN SHEET OF
  GOLD FOIL.
• ACCORDING TO THE PREVAILING THEORY, THE ALPHA
  PARTICLES SHOULD HAVE PASSED EASILY THROUGH THE
  GOLD, WITH ONLY A SLIGHT DEFLECTION DUE TO THE
  POSITIVE CHARGE THOUGHT TO BE SPREAD OUT IN THE
  GOLD ATOMS.

44
(No Transcript)
45
(No Transcript)
46
(No Transcript)
47
WHAT HAPPENED?

• THE MAJORITY OF THE ? PARTICLES PASSED STRAIGHT
  THROUGH THE GOLD ATOMS, WITHOUT ANY DEFLECTION
• EVEN MORE SURPRISINGLY, A SMALL FRACTION OF THE ?
  PARTICLES BOUNCED OFF THE GOLD FOIL ATOMS AT VERY
  LARGE ANGLES
• SOME EVEN BOUNCED BACK AT THE SOURCE

48

• BASED ON THE RESULTS, RUTHERFORD SUGGESTED A NEW
  THEORY OF THE ATOM.
• HE PROPOSED THAT THE ATOM IS MOSTLY EMPTY SPACE
• THIS EXPLAINED THE LACK OF DEFLECTION OF SOME OF
  THE PARTICLES
• HE CONCLUDED THAT ALL THE POSITIVE CHARGE AND
  ALMOST ALL THE MASS IS CONCENTRATED IN A SMALL
  CORE
• HE CALLED THIS REGION THE NUCLEUS

49
(No Transcript)
50
WHAT DO WE KNOW?

• THERE ARE THREE FUNDAMENTAL PARTICLES THAT
  TOGETHER MAKE UP THE ATOM.
• COMPOSED OF ELECTRONS, PROTONS, AND NEUTRONS
• THE PROTONS AND THE NEUTRONS MAKE UP THE CENTER
  OF THE ATOM
• CENTER OF THE ATOM IS CALLED THE NUCLEUS
• THE PROTONS NEUTRONS OCC-UPY THE MASS OF THE
  ATOM

51

• THE ELECTRONS SURROUND THE NUCLEUS AND OCCUPY
  MOST OF THE ATOMS VOLUME
• HOW, THEN, ARE ATOMS OF HYDROGEN DIFFERENT FROM
  THOSE OF OXYGEN?
• A SUBATOMIC PARTICLES FROM ONE TYPE OF ATOM LOOKS
  LIKE PARTICLES FROM OTHER ATOMS

52

• ITS THE NUMBERS OF PROTONS IN AN ATOM THAT MAKES
  ATOMS DIFFERENT.
• AN OXYGEN ATOM HAS 8 PROTONS IN ITS NUCLEUS
• A HYDROGEN ATOM HAS 1 PROTON IN ITS NUCLEUS
• THE ATOMIC NUMBER OF AN ELEMENT IS THE NUMBER OF
  PROTONS IN THE NUCLEUS OF AN ATOM OF THAT ELEMENT
• SINCE OXYGENS NUCLEUS HAS 8 PROTONS ITS
  ATOMIC IS 8
• THE PROTONS IDENTIFY THE TYPE OF ATOM, THE ONLY
  ATOM WITH 8 PROTONS IS OXYGEN

53
(No Transcript)
54
SYMBOL
ATOMIC
PROTONS
NEUTRONS
MASS
ELECTRONS
NAME
55

• FOR EACH ELEMENT LISTED, THE NUMBER OF PROTONS
  EQUALS THE NUMBER OF ELECTRONS
• REMEMBER ATOMS ARE ELECTRICALLY NEUTRAL
• IN AN ATOM, THE NUMBER OF ELECTRONS MUST EQUAL
  THE NUMBER OF PROTONS
• A HYDROGEN ATOM HAS 1 ELECTRN
• AN OXYGEN ATOM HAS 8 ELECTRNS
• THE MASS OF AN ATOM IS CONCEN. IN ITS NUCLEUS AND
  DEPENDS ON THE NUMER OF PROTONS AND NEUTRONS

56

• THE TOTAL NUMBER OF PROTONS AND NEUTRONS IN AN
  ATOM IS CALLED THE MASS NUMBER
• A CARBON ATOM, WHICH HAS 6 PROTONS AND 6
  NEUTRONS, HAS A MASS NUMBER OF 12
• IF YOU KNOW THE ATOMIC NUMBER AND MASS NUMBER OF
  AN ATOM OF ANY ELEMENT, YOU CAN DETERMINE THE
  ATOMS COMPOSITION
• THE COMPOSITION OF ANY ATOM CAN BE REPRESENTED IN
  SHORTHAND NOTATION

57
CHEMICAL COMPOSITION SHORTHAND
OF PROTONS OF NEUTRONS
Cl
MASS NUMBER
35
ATOMIC NUMBER
17
NUMBER OF PROTONS
58
(No Transcript)
59
ISOTOPES

• EVERY CHLORINE ATOM HAS 17 PROTONS, WITHOUT
  EXCEPTION,
• HOWEVER, NOT EVERY CHLORINE ATOM HAS 18 NEUTRONS.
• ATOMS WITH THE SAME NUMBER OF PROTONS BUT CONTAIN
  DIFFERENT NUMBERS OF NEUTRONS ARE CALLED
  ISOTOPES.
• BECAUSE ISOTOPES OF AN ELEMENT HAVE DIFFERENT
  NUMBERS OF NEUTRONS THEY HAVE DIFFERENT MASS
  NUMBERS.

60

• ISOTOPES ARE CHEMICALLY ALIKE BECAUSE THEY HAVE
  IDENTICAL NUMBERS OF PROTONS AND ELECTRONS
• ITS THE ELECTRONS AND PROTONS THAT ARE
  RESPONSIBLE FOR CHEMICAL BEHAVIOR

BERYLLIUM ISOTOPES
proton
neutron
electron
61
(No Transcript)
62
EXAMPLE OF AN ISOTOPE
63
IONS

• AN ELEMENTS ATOMS ARE NOT ALWAYS NEUTRAL IN
  CHARGE.
• WHEN AN ATOM LOSES OR GAINS ONE OR MORE OF ITS
  ELECTRONS IT BECOMES ION.
• AN ION THAT HAS MORE ELECTRONS THAN PROTONS HAS A
  NEGATIVE ELECTRICAL CHARGE
• AN ION THAT HAS FEWER ELECTRONS THAN PROTONS HAS
  A POSITIVE ELECTRICAL CHARGE

NOTE ITS THE PROTONS THAT DEFINE THE TYPE OF
ATOM IT IS, BUT THE ELECTRONS DEFINE THE ATOMS
CHARGE.
64
(No Transcript)
65
SOME ATOMS GAIN ELECTRONS
ATOMS IONIC CHARGE PROTONS - ELECTRONS
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
O-2
O
66
ATOMIC MASS

• THE ACTUAL MASS OF A PROTON OR A NEUTRON IS VERY
  SMALL
• 1.67x10-24 g
• THE PROTONS NEUTRONS IS THE MASS OF THE ATOM
• THEREFORE THE MASS OF EVEN THE LARGEST ATOM IS
  INCREDIBALLY SMALL
• SCIENTISTS HAVE DETERMINED THE TINY MASSES OF
  ATOMS BY USING AN INSTRUMENT CALLED A MASS
  SPECTROMETER.

67

• FINDING THE MASS OF AN INDIVIDUAL ATOM CAN
  PROVIDE USEFUL INFO, BUT IN GENERAL, THESE VALUES
  ARE TOO SMALL AND IMPRACTICAL TO WORK WITH.
• INSTEAD SCIENTISTS COMPARE THE RELATIVE MASSES OF
  ATOMS TO A REFERENCE ATOM.
• A STANDARD HAS BEEN SET THAT DEFINES THE MASS OF
  ALL THE OTHER ATOMS
• THE ISOTOPE CHOSEN WAS THE CARBON-12 ATOM.

68

• THIS ISOTOPE OF CARBON WAS ASSIGNED A MASS OF
  EXACTLY 12 ATOMIC MASS UNITS
• 1 ATOMIC MASS UNIT (amu) IS DEFINED AS 1/12TH THE
  MASS OF AN CARBON-12 ATOM.
• USING THAT INFORMATION WE CAN SAY THAT A HELIUM-4
  ATOM HAS A MASS 1/3 THE MASS OF C-12
• A CARBON-12 ATOM HAS 6 PROTONS AND 6 NEUTRONS IN
  ITS NUCLEUS, AND ITS MASS IS SET AS 12 amu.

69

• THE 12 PROTONS AND NEUTRONS ACCOUNT FOR NEARLY
  ALL OF CARBONS MASS
• THEREFORE, THE MASS OF A SINGLE PROTON OR A
  SINGLE NEUTRON HAS A MASS OF 1amu.
• SINCE THE MASS OF AN ATOM IS BASED ON INDIVIDUAL
  PARTICLES OF MATTER, THE ATOMIC MASS OF AN ATOM
  SHOULD BE A WHOLE NUMBER
• YET ON THE PERIODIC TABLE THE MASSES ARENT WHOLE
  NUMBERS

70

• THE MASSES ON THE PERIODIC TABLE ARE WEIGHTED
  AVERAGES
• IN NATURE, MOST ELMNTS EXIST AS A MIXTURE OF
  ISOTOPES
• EACH ISOTOPE OF AN ELEMENT HAS A FIXED MASS AND A
  NATURAL ABUNDANCE.
• NATURAL ABUNDANCE IS AN INDICATION OF HOW OFTEN
  WE WOULD ENCOUNTER A PARTICULAR ISOTOPE
• ONE OF THE ISOTOPES IS ALMOST ALWAYS ENCOUNTERED
  MORE OFTEN SO IT GETS MORE WEIGHT

71

• RECALL THAT THE ELEMENT Cl HAS 2 ISOTOPES (Cl-35
  Cl-37)
• 75 OF THE CHLORINE ATOMS YOULL FIND IN NATURE
  ARE Cl-35
• WHICH HAS 17 PROTONS AND 18 NEUTRONS IN ITS
  NUCLEUS
• 25 OF THE CHLORINE ATOMS YOULL FIND IN NATURE
  ARE Cl-37
• WHICH HAS 17 PROTONS AND 20 NEUTRONS IN ITS
  NUCLEUS.
• SINCE WE ARE MORE LIKELY TO FIND A Cl-35 ATOM THE
  AVERAGE MASS OF Cl IS CLOSER TO 35 THAN TO THE
  TRUE AVERAGE OF 36.

72

• THEREFORE, THE ATOMIC MASS OF AN ATOM IS THE
  WEIGHTED AVERAGE MASS OF THE ATOMS IN A NATURALLY
  OCCURRING SAMPLE OF THE ELEMENT
• THE MASS NUMBER OF AN ATOM IS THE PROTONS
  NEUTRONS OF A PARTICULAR ATOM
• IF WE NEED THE MASS NUMBER FROM THE PERIODIC
  TABLE WE TAKE THE CLOSEST
  WHOLE NUMBER TO THE
  ATOMIC MASS FOUND ON
  THE PERIODIC TABLE.
