Title: Polymorphism Pure Object Oriented Programming


1
PolymorphismPure Object Oriented Programming
Lecture 22
2
Announcements
LB
  • Office Hours next Tuesday, April 4, 2000 will be
    from 100 - 200 p.m. instead of 300 - 400 p.m.
  • On the homework thats due Friday
  • Problem 2 requires inheritance!

3
Polymorphism
4
Scenarios
  • A veterinarian's algorithm might have a list of
    animals, but each one needs different food or
    care we want ONE information system to track all
    of this without complex logic for each individual
    kind of animal.
  • A car dealership sells many different types of
    cars with different features, but each has a
    price and quantity in stock.
  • A registration system might treat in-state
    students differently from out-of-state students,
    graduate students differently from
    undergraduates, etc.
  • A graphical user interface (GUI) e.g. Windows
    needs to puts lots of simlar widgets on screen...

LB
5
Motivation
  • Wed like to be able to manage objects of
    different kinds of classes.
  • Since classes within a class hierarchy often
    share common methods and attributes, wed like to
    make use of this fact to make our algorithms
    simpler.

6
Polymorphism Defined
  • The ability to take on different forms.
  • Manipulate objects of various classes, and invoke
    methods on an object without knowing that
    objects type.

7
A Class Hierarchy
Animal
Dog
Cat
Fish
Mutt
Poodle
Gold
Beta
8
A Polymorphic Example
Animal
Dog
MyMutt isoftype Mutt MyAnimal isoftype
Animal MyDog isoftype Dog . . . MyDog lt-
MyMutt MyAnimal lt- MyMutt
Mutt
9
Polymorphism Explained
  • MyAnimal lt- MyMutt seems incorrect. The left
    and right hand side of the assignment seem to not
    match or do they?
  • Since Mutt inherits from Dog, and Dog inherits
    from Animal, then MyMutt is at all times a Mutt,
    a Dog, and an Animal. Thus the assignment
    statement is perfectly valid.
  • This makes logical (real world) sense.

10
An Illegal Example
  • We are able to assign an object of a sub-class
    into an object of a super-class as in
  • MyAnimal lt- MyMutt
  • But the reverse is not true. We cant assign a
    superclass object into a sub-class object.
  • MyMutt lt- MyAnimal // illegal

11
Method Calls and Polymorphism
  • Assume the Dog class inherits the Animal class,
    redefining the MakeNoise method.
  • Consider the following
  • MyAnimal lt- MyDog
  • MyAnimal.MakeNoise

12
Method Calls and Polymorphism
  • MyAnimal lt- MyDog
  • MyAnimal.MakeNoise
  • Different languages handle this differently.
  • For simplicity, well assume that MyAnimal
    remembers it is actually an object of the Dog
    class, so well execute the MakeNoise method in
    the Dog class.

13
Polymorphism vs. Inheritance
  • Inheritance is required in order to achieve
    polymorphism (we must have class hierarchies).
  • Re-using class definitions via extension and
    redefinition
  • Polymorphism is not required in order to achieve
    inheritance.
  • An object of class A acts as an object of class B
    (an ancestor to A).

14
Processing Collections
  • One of the main benefits of polymorphism is the
    ability to easily process collections.
  • We will consider a collection (queue) of bank
    accounts in the next example. . .

15
The Banking Class Hierarchy
16
A Collection of Bank Accounts
  • Imagine a bank needs to manage all of the
    accounts.
  • Rather than maintain seven separate queues, one
    each for Bank_Accounts, Savings_Accounts,
    Cool_Savings, CD_Accounts, Checking_Accounts,
    NOW_accounts, and Money_Market_Accounts
  • We can maintain only one queue of Bank Accounts.

17
Polymorphic Banking
  • Assume accounts of various kinds
  • john_account isoftype Checking_Account
  • paul_account isoftype Cool_Savings
  • paul_other_account isoftype CD_Account
  • george_account isoftype NOW_Account
  • ringo_account isoftype Money_Market
  • Then put them all in a single structure
  • account_queue isoftype Queue(Bank_Account)
  • account_queue.Enqueue(john_account)
  • account_queue.Enqueue(paul_account)
  • account_queue.Enqueue(paul_other_account)
  • account_queue.Enqueue(george_account)
  • account_queue.Enqueue(ringo_account)

18
Polymorphic Banking
  • account_queue is polymorphic
  • It is holding accounts of many forms.
  • Each of the accounts is within the family of
    the class hierarchy of bank accounts.
  • Each one will have its own set of capabilities
    via inheritance (extension, and/or redefinition).

19
Example of Polymorphic Banking
  • With polymorphism, our main algorithm doesnt
    care what kind of account it is processing
  • sum, amount isoftype Num
  • account isoftype Bank_Account
  • account_queue isoftype Queue(Bank_Account)
  • . . .
  • sum lt- 0
  • loop
  • exitif( account_queue.IsEmpty )
  • account_queue.Dequeue( account )
  • sum lt- sum account.Get_Balance
  • endloop
  • print( Sum of the balances is , sum )

20
Resolving Polymorphic Method Calls
  • Different languages do this differently.
  • The various kinds of Accounts, though all stored
    as a Bank_Account, remember the class (subclass)
    of which they are an instance.
  • So, calls to Get_Balance() will
  • use the method from class NOW_Account if the
    object is an instance of NOW_Account
  • use the method from class Money_Market if the
    object is an instance of Money_Market
  • and so on...

21
Polymorphism
  • This is the magic of polymorphismit keeps
    track of family members within the inheritance
    hierarchy for you.
  • Without it, wed have lots of code sprinkled
    through out our algorithm choosing among many
    options
  • if( its Checking_Account ) then
  • call Checking_Account Calc_Interest
  • elseif( its Super_Savings) then
  • call Super_Savings Calc_Interest
  • elseif( its CD_Account then
  • call CD_Account Calc_Interest
  • elseif( its NOW_Account ) then
  • call NOW_Account Calc_Interest
  • . . .

22
Summary
  • Polymorphism allows objects to represent
    instances of its own class and any of its
    sublcasses.
  • Polymorphic collections are useful for managing
    objects with common (ancestor) interfaces.
  • For our purposes, well assume objects remember
    what kind of class they really contain, so method
    calls are resolved to the original class.

23
Questions?
24
Pure Object Oriented Programming
25
What Have We Discussed?
  • Structured programming
  • Object-Oriented programming
  • Whats left?
  • Everything an object
  • Lets make a class coordinate activities

26
Structured Programming
  • Break down the problem.
  • Each module has a well-defined interface of
    parameters
  • A main algorithm calls and coordinates the
    various modules the main is in charge.
  • Persistent data (in the main algorithm) vs.
    module data (dies upon module completion).

27
An Example
  • Lets write an algorithm to simulate a
    veterinarians clinic
  • Maintain a collection of different animals
  • Feed, water, talk with and house animals
  • Allow owners to bring pets for treatment and
    boarding
  • Well present a menu of options to the user

28
A Structured Solution
  • Write many record types (cat, dog, rabbit)
  • Write the collection records and modules for each
    type of pet
  • Write many modules allowing for interactions with
    the collection
  • Write menu and processing modules
  • Write main algorithm

29
An Object-Oriented Solution
  • Write class hierarchy with inheritance (pet, cat,
    dog, rabbit)
  • Write the generic collection class
  • Write many modules allowing for interactions with
    the collection
  • Write menu and processing modules
  • Write main algorithm

30
Simulating a Veterinarian Clinic
LB
user interaction
has-a
Boarding Pens (Vector)
Vet Clinic
Owner (user)
has-a
Pet
is-a
is-a
is-a
Rabbit
Dog
Cat
31
The Vector Class
Vector
Initialize
InsertElementAt
RemoveElementAt
  • head


ElementAt
Size
Contains
IndexOf
IsEmpty
32
  • algorithm VetClinic
  • uses Vector, Pet, Cat, Dog, Rabbit
  • Pens isoftype Vector(Pet)
  • Pens.Initialize
  • choice isoftype string
  • loop
  • PrintMenu
  • GetChoice(choice)
  • exitif (choice QUIT)
  • ProcessChoice(choice, Pens)
  • endloop
  • print(The Vet Clinic has closed. Goodbye!)
  • endalgorithm // VetClinic

33
  • procedure PrintMenu
  • print(Please enter a choice)
  • print(ADD a pet)
  • print(REMOVE a pet)
  • print(FEED pets)
  • print(LIST pets)
  • ...
  • print(QUIT)
  • endprocedure // PrintMenu
  • procedure GetChoice(choice isoftype out string)
  • print(What would you like to do?)
  • read(choice)
  • endprocedure // GetChoice

LB
34
  • procedure ProcessChoice(choice iot in string,
  • Pens iot in/out Vector(Pet))
  • if (choice ADD) then
  • AddPet(Pens)
  • elseif (choice REMOVE) then
  • RemovePet(Pens)
  • elseif (choice FEED) then
  • FeedPets(Pens)
  • elseif (choice LIST) then
  • . . .
  • endif
  • endprocedure // ProcessChoice

LB
35
  • procedure RemovePet(Pens iot in/out Vector(Pet))
  • IndexToRemove isoftype num
  • print(What is the index of the pet to
    remove?)
  • read(IndexToRemove)
  • if (IndexToRemove lt Pens.SizeOf) then
  • Pens.RemoveElementAt(IndexToRemove)
  • else
  • print(ERROR That index is too high)
  • endif
  • endprocedure // RemovePet

36
  • procedure FeedPets(Pens iot in/out Vector(Pet))
  • count isoftype num
  • count lt- 1
  • loop
  • exitif(count gt Pens.SizeOf)
  • // get the next pet in the collection and
  • // polymorphically call the Eat method on
  • // that pet (whatever its class)
  • Pens.ElementAt(count).Eat
  • count lt- count 1
  • endloop
  • print(Pets all fed!)
  • endprocedure // FeedPets

37
  • . . . continue implementation
  • AddPet module, etc.

38
Vestiges of Structured Programming
  • In the previous example (and thus far), we have
    used classes and objects in the conventional
    structured approach to algorithms that we have
    used throughout.
  • We have done what is called Hybrid OO the use
    of OO constructs within the standard structured
    paradigm.
  • What is the difference?

39
Hybrid Object-Oriented Programming
  • Hybrid OO is like Structured in some ways
  • Break down the problem.
  • One module per sub-problem.
  • Each module has one task.
  • Each module has a interface of parameters.
  • A main algorithm is in charge of program.

40
Hybrid Object-Oriented Programming
  • Hybrid OO is not just like structured
  • Each object maintains its own persistent data.
  • Uses OO constructs (classes objects)
  • Encapsulate data and methods together
  • Support data integrity by protecting data
  • Reuse, minimizing recreating code
  • Inheritance to ease customization
  • Polymorphism to model the world
  • Our examples so far show Hybrid OO
  • Structured algorithms, main in charge.
  • Use of OO constructs (classes objects)

41
Whats Left?
  • The Object-Oriented paradigm is state of the art
  • Encapsulation
  • Reusability/Adaptability
  • Polymorphism
  • But whats left?
  • The algorithm itself
  • We still have a main algorithm in control

42
  • class VetClinic
  • uses Vector, Pet, Cat, Dog, Rabbit
  • public
  • procedure Initialize
  • // contract here
  • protected
  • Pens isoftype Vector(Pet)
  • procedure Initialize
  • Pens.Initialize
  • DoWork
  • endprocedure // Initialize

43
  • // Still in protected section
  • procedure DoWork
  • // contract here protected method
  • choice isoftype string
  • loop
  • PrintMenu
  • GetChoice(choice)
  • exitif (choice QUIT)
  • ProcessChoice(choice)
  • endloop
  • print(The Vet Clinic has closed.)
  • endprocedure // DoWork

44
  • // Still in protected section
  • procedure PrintMenu
  • // contract here protected method
  • print(Please enter a choice)
  • print(ADD a pet)
  • print(REMOVE a pet)
  • print(FEED pets)
  • . . .
  • print(QUIT)
  • endprocedure // PrintMenu
  • procedure GetChoice(choice iot out string)
  • // contract here protected method
  • print(What would you like to do?)
  • read(choice)
  • endprocedure // GetChoice

45
  • // Still in protected section
  • procedure ProcessChoice(choice iot in string)
  • // contract here protected method
  • if (choice ADD) then
  • AddPet
  • elseif (choice REMOVE) then
  • RemovePet
  • elseif (choice FEED) then
  • FeedPets
  • . . .
  • endif
  • endprocedure // ProcessChoice

46
  • // Still in protected section
  • procedure RemovePet
  • // contract here protected method
  • IndexToRemove isoftype num
  • print(What is index of the pet to
    remove?)
  • read(IndexToRemove)
  • if (IndexToRemove lt Pens.Size) then
  • Pens.RemoveElementAt(IndexToRemove)
  • else
  • print(ERROR That index is too high)
  • endif
  • endprocedure // RemovePet

47
  • // Still in protected section
  • procedure FeedPets
  • // contract here protected method
  • count isoftype num
  • count lt- 1
  • loop
  • exitif(count gt Pens.Size)
  • // get the next pet in the collection and
  • // polymorphically call the Eat method on
  • // that pet (whatever its class)
  • Pens.ElementAt(count).Eat
  • count lt- count 1
  • endloop
  • print(Pets all fed!)
  • endprocedure // FeedPets

48
  • // Still in protected section
  • . . . continue the protected methods
  • endclass // VetClinic
  • // --------------------------------------
  • algorithm VetExample
  • store isoftype VetClinic
  • store.Initialize
  • endalgorithm // VetExample

49
What Did We Do?
  • Everything is an object
  • The main algorithm (if it exists at all) simply
    creates a VetClinic and calls its Initialize
    method.
  • From there, the VetClinic object coordinates the
    system
  • Now were doing Pure OO Programming

50
Pure Object Oriented Programming
  • There is no main algorithm in charge.
  • Control is decentralized among various objects.
  • Everything in the program is an object.
  • A root class gets things started.
  • The root class is not in charge instead it
    invokes some method, beginning a chain reaction
    of objects calling methods provided by other
    objects.
  • Requires a slightly different way of thinking
    centralized control vs. distributed control.

51
Windowing with a Mouse
LB
SimpleCalculator
0
Add
0
Clear
0
52
Windowing with a Mouse
LB
SimpleCalculator
5
Add
0
Clear
0
53
Windowing with a Mouse
LB
SimpleCalculator
5
Add
12
Clear
0
54
Windowing with a Mouse
LB
SimpleCalculator
5
Add
12
Clear
0
55
Windowing with a Mouse
LB
SimpleCalculator
5
Add
12
Clear
17
56
Windowing with a Mouse
LB
SimpleCalculator
5
Add
12
Clear
17
57
Windowing with a Mouse
LB
SimpleCalculator
0
Add
0
Clear
0
58
Classes
LB
59
Typical Operations
LB
Class AddButton inherits Button ... Procedure
Listen // Activated when mouse button
pressed ResultBox.SetContents( TopBox.GetCont
ents BottomBox.GetContents) endprocedure

This type method listens for an event to occur
60
Typical Operations
LB
Class ClearButton inherits Button ... Procedure
Listen // Activated when mouse button
pressed TopBox.Clear BottomBox.Clear ResultB
ox.Clear endprocedure
61
Typical Operations
LB
Class CalcWindow inherits Window ... Procedure
Initialize // Starts everything
up super.Initialize AddIn(ClearButton) AddIn
(AddButton) AddIn(TopBox) AddIn(BottomBox) A
ddIn(ResultBox) endprocedure
Where the buttons and boxes are located is magic
62
Starting it all up
LB
theWindow isoftype CalcWindow theWindow.ShowAt(LOC
X, LOCY)
This code would appear in some kind of special
initiation construct A root class or a startup
main or whatever.
63
Windowing with a Mouse
LB
SimpleCalculator
0
Add
0
Clear
0
64
A Vehicle Dealership Example
Queue of Vehicles
Dealership
Car
Truck
User/Customer
65
Other Pure OO Examples
  • Interactive programs
  • Graphical, windowed interfaces
  • Mac OS, Windows, etc.
  • Event-driven programming
  • Complex database applications

66
Summary of Structured Programming
  • Break down the problem.
  • One module per sub-problem.
  • Each module has one task.
  • Each module has a interface of parameters.
  • A main algorithm is in charge of program.
  • Local data dies, must pass back to main.

67
Summary of Hybrid- vs. Pure-OO
  • Hybrid-OO programming means
  • Structured algorithms, main in charge.
  • Use of OO constructs (classes--objects)
  • Pure-OO or Real-OO programming means
  • No main in charge.
  • Decentralized, distributed control.
  • Everything is an object.

68
Questions?
69
Pseudocode to Java
LB
  • class Simple
  • public
  • Procedure Initialize()
  • // PPP
  • procedure setValue(newVal isoftype in Num)
  • // ppp
  • function getValue returnsa Num()
  • // PPP

70
Pseudocode to Java
LB
  • protected
  • value isoftype Num
  • Procedure Initialize()
  • value lt- 0
  • endprocedure
  • procedure setValue(newVal isoftype in Num)
  • value lt- newVal
  • endprocedure
  • function getValue returnsa Num()
  • getValue returns value
  • endfunction
  • endclass

71
Java version
LB
  • class Simple
  • private int value
  • // ppp
  • public void Simple()
  • value 0
  • // Constructor
  • // ppp
  • public setValue(int newVal)
  • value newVal
  • // setValue
  • // ppp
  • public int getValue()
  • return value
  • // getValue
  • // Simple

72
Questions?
73
(No Transcript)
Write a Comment
User Comments (0)
About PowerShow.com
