Regional Intermodal Rail Project

1
Regional Intermodal Rail Project
2

• Regional Ports of Entry
• Santa Teresa New Mexico
• Paso del Norte Northbound
• Friendship Southbound
• Bridge of the Americas
• Zaragoza

3
Cross-Border Trains 3 trains / per
day Through-City Trains 50 trains / per day
4
Burlington Northern Santa Fe Rail Yard
5
Union Pacific Central Yard
6
Union Pacific Chamizal Yard
7
Union Pacific Paisano Yard
8
Union Pacific Alfalfa Yard
9
regional intermodalrail project
An integrated long-range transportation program
that enhances linkages, creates increased goods
movement and promotes economic growth in the
Region through a major alignment and improvement
of the rail and highway transport system and its
associated facilities.
10
regional intermodalrail project

• Strengthen cross-border effort to cooperatively
  address transportation issues vital to the
  region
• Allow for international network to
  capitalize on goods movement (55.6 million in
  commodities passed through El Paso in 2001)
• Provide for a safer, more efficient and
  multi- modal transport system

11
regional intermodalrail project

• Address air quality, drainage and transport
  connectivity
• Improve mobility and access management
• Allow for quality of life initiatives
  redevelopment opportunities

12
regional intermodalrail project
Conceptual Rail Options New loop rail access
New intermodal container transfer facilities
New interchange facilities New international
customs facility New border rail connections
New existing trackage depression
13
Regional Intermodal Rail Project January 2003
14
Union Pacific Central Rail Yard
15
Union Pacific Central Yard Redevelopment
16
Union Pacific Central Yard - Redevelopment
17
Near Piedras St. Bridge - Before
18
Near Piedras St. Bridge - After
19
regional intermodalrail project

• City Actions Taken
• Hiring of consultant for Feasibility Study
  Implementation Plan preparation Moffatt
  Nichol Engineers, December 2002
• Project Inclusion in Regions Metropolitan
  Transportation Plan, January 24, 2003
• Project support by regional legislators
  Transportation Policy Board
• Cross-border technical rail meetings held

20
regional intermodalrail project

• City Actions Taken
• Submission of 241 million Congressional
  funding request under TEA-21 Reauthorization
  Bill, February 28, 2003
• Submission of 1 million Federal Demonstration
  Project grant to cover planning feasibility
  studies, February 28, 2003
• Submissions sponsored by US Congressman
  Silvestre Reyes, endorsed by US Congressman
  Stevan Pearce

21
regional intermodalrail project

• Moffatt Nichol Engineers Report
• 3 Phase Project Scope
• - Federal funding submission
• - Technical economic evaluation studies,
  preliminary feasibility study
• - Final feasibility study and implementation
  plan
• Study driven by two primary factors
• - Initiatives in Mexico to mitigate rail impacts
  in downtown Ciudad Juarez
• - Transportation funding bill reauthorization

22
regional intermodalrail project

• Moffatt Nichol Engineers Report
• Submitted July 18, 2003 (Interim Draft)
• Briefings to El Paso City Council
  Transportation Policy Board, August 2003
• Conclusions
• - Current rail operations are reasonably
  efficient
• - BNSF UPRR have sufficient reserve capacity
  to meet current needs forecasted growth
  for near term

23
regional intermodalrail project

• Moffatt Nichol Engineers - Report
• - Local customer service would be degraded if
  rail operations were relocated to more
  distant locations
• - Proposed projects would provide a primary
  benefit in the future when growth has
  reduced service level requirements

24
regional intermodalrail project

• Moffatt Nichol Engineers - Report
• Most viable recommended projects for further
  study
• 1 New border crossing at Santa Teresa
• 199 million (US) 95 million (Mexico)
• 2 EPIA Intermodal Facility
• 58 million (US)
• 3 Dallas Yard (west) Redevelopment
• 35 million (US)
• TOTAL 292 million (US) 95 million (Mexico)

25
regional intermodalrail project

• Moffatt Nichol Engineers - Report
• Other long-term projects
• TOTAL 921 million (US) 80 million (Mexico)
• City cost through preliminary report
  submission 675,689
• Contract suspended, October 2003

26
