Title: ASP'NET 2'0 Black Belt


1
(No Transcript)
2
ASP.NET 2.0 Black Belt
  • Improving performance

3
Overview
  • Performance improvements with ASP.NET 2.0
  • Asynchronous request handling
  • SQL caching
  • Client callbacks (if time permits)
  • Summary
  • Questions and answers

4
Introducing
  • Class-A
  • Kennisprovider
  • Microsoft development
  • Training
  • Coaching
  • Alex Thissen
  • Trainer/coach
  • http//www.alexthissen.nl

5
Why this session?
  • Web Server performance is critical!
  • Determined by combination of hardware and
    software
  • Good or bad use of ASP.NET greatly influences
    performance
  • Achieve better performance by
  • Good programming practice
  • Taking advantage of features in ASP.NET 2.0

6
Asynchronous request handling
7
The need for asynchronous ASP.NET
  • Long running operations performed during handling
    of page request can degrade performance
  • Shorter requests will take much longer than
    necessary
  • On average throughput will be lower
  • Asynchronous ASP.NET to the rescue
  • Page request can be handled asynchronously
  • Do not wait for long running operations to
    complete
  • Spawn long operations on different threads

8
Thread pools in .NET and ASP.NET
  • .NET uses a pool of threads per process
  • Pool has two types of threads
  • Worker threads (default 100 in pool)
  • IO completion port threads (default 100 in pool)
  • Change defaults with calls to ThreadPool.SetMax/Mi
    nThreads
  • Several .NET classes use IO threads
  • Sockets, Web Service Proxies, WebRequest,
    FileStream

9
ASP.NET threads
  • ASP.NET uses 20 worker and 20 IO threads by
    default
  • A minimum number of threads is reserved to handle
    callbacks from async operations
  • Performance gain by switching from worker to IO
    threads
  • Avoid draining worker threads in pool

ltprocessModel maxWorkerThreads "20"
minWorkerThreads "1" maxIoThreads "20"
minIoThreads "1" /gt lthttpRuntime
minFreeThreads "threads" minFreeLocalRequestFre
eThreads "threads" ... /gt
10
ASP.NET architecture
worker processaspnet_wp.exe (IIS4,5) or w3wp.exe
(IIS6)
ASP.NET runtime in .NET CLR
inetinfo.exe (IIS 4 and 5)
HttpApplication\vdir1
aspnet_isapi.dll(native code)
HTTP pipeline
HttpApplication\vdir2
http.sys kernel mode driver(IIS 6)
aspnet_isapi.dll(native code)
11
IHttpAsyncHandler interface
  • Asynchronous web pages implement
    IHttpAsyncHandler interface
  • Request threads are returned to pool right after
    async operation is started on other thread
  • Implementing IHttpAsyncHandler is NOT a trivial
    or easy task

public interface IHttpAsyncHandler IHttpHandler
IAsyncResult BeginProcessRequest(HttpContext
context, AsyncCallback cb, object extraData)
void EndProcessRequest(IAsyncResult result)
12
Asynchronous pages in ASP.NET 2.0
  • Add asynctrue to _at_Page directive or ltpagesgt
    element in web.config
  • Pass delegates for start and completion of
    asynchronous operation in AddOnPreRenderCompleteAs
    ync method
  • Register event handler for PreRenderComplete

private void Page_Load(object sender, EventArgs
e) this.AddOnPreRenderCompleteAsync( new
BeginEventHandler(BeginAsynchronousOperation),
new EndEventHandler(EndAsynchronousOperation))
this.PreRenderComplete new
EventHandler(LongRunningAsync_PreRenderComplete)

13
Effects during page lifecycle
Client

request page

LoadComplete
PreRender
PreRenderComplete
Thread 1
SaveViewState
Render
send response

14
Effects during page lifecycle

Client
request page

Thread 1
LoadComplete
PreRender
IAsyncResult
PreRenderComplete
SaveViewState
Render
Thread 2
send response

15
Synchronous performance
100 concurrent users
20 concurrent users
50 concurrent users
10 concurrent users
16
Asynchronous performance
50 concurrent users
20 concurrent users
10 concurrent users
  • 100 concurrent users

17
Downside of async pages
  • Async pages have no timeout
  • Not really meant to perform several async
    operations
  • Does not flow impersonation information, current
    HttpContext or culture to end handlers
  • Hard to pass some form of state to async threads
  • Requires at least High trust

18
Asynchronous tasks
  • In ASP.NET 2.0 you can add async tasks to page
    request handling
  • Flow contextual information
  • Pass state to async handler
  • Have timeout value and timeout handler
  • Register tasks before PreRenderComplete
  • Registered tasks get executed automatically
  • Tasks are executed only once
  • ExecuteRegisteredAsyncTasks will only run tasks
    that have not executed before

19
Async tasks
  • Single unit of work encapsulated by PageAsyncTask
    class
  • Constructor takes three delegates
  • BeginEventHandler start async operation here
  • EndEventHandler complete async operation
  • TimeoutHandler called when task times out
  • Tasks can execute in parallel for better
    concurrency
  • Page execution halts until all tasks have
    completed or timed out

20
Configuration of async tasks
  • Default timeout of async tasks is 45 seconds
  • Change timeout in _at_Page directive or ltpagesgt
    element in web.config
  • Page itself does not have to be asynchronous
  • But sync page will block until all async tasks
    have completed or timed out

lt_at_Page Asynctrue AsyncTimeout60
gt ltsystem.webgtltpages asyncTimeout60 /gt
21
Things to remember
  • IIS 5.1 on Windows XP has default setting of 10
    concurrent requests
  • Gives 403.9 errors if exceeded
  • Increase by editing metabase key
    LM/W3SVC/MaxConnections (40 hardcoded limit)
  • BUG All requests are handled by IO threads
  • On IIS5 and in ASP.NET 1.0 and 1.1 (without SP1)
    install hotfix from KB 821156
  • ASP.NET 1.1SP1 and 2.0 require registry setting
    HKLM\Software\Microsoft\ASP.NET\UseWorkerThreadsO
    nIIS5 to 1 (DWORD)

22
Fixing IIS5.1ASP.NET bug
  • Before IO threads used

After worker threads used
23
SQL caching
24
Caching in ASP.NET
  • ASP.NET has rich caching mechanism
  • Automatic cache management
  • Scavenging of cache if necessary
  • Declarative caching in controls and directives
  • Programmatic caching with Cache API
  • ASP.NET 2.0 adds new features
  • SQL Cache support
  • Cache profiles
  • More declarative control over cache management

25
SQL Caching basics
  • Caching data retrieved from database can avoid
    lots of trips to database server
  • Putting data in cache is easy use Cache API
  • Determining when to get fresh data is hard part
  • Cached items should be invalidated when
    underlying data changes
  • Two mechanisms are available to determine
    changes
  • Polling mechanism periodically checking if data
    has changed
  • Query notifications (new in SQL Server 2005)

26
Polling mechanism
  • ASP.NET runtime polls for database changes on a
    specified interval
  • Can be used with SQL Server 7, 2000 and 2005
  • Triggers on table of interest react to changes by
    INSERT, UPDATE and DELETE
  • Trigger runs sproc to increase Change ID in a
    special table AspNet_SqlCacheTablesForChangeNotifi
    cation

27
Preparing database for polling
  • Enable polling on database
  • Creates poll table and stored procedures
  • Enable polling on specific table
  • Creates triggers and adds entry in poll table

aspnet_regsql.exe E d Northwind ed
aspnet_regsql.exe -E -d Northwind -t Categories
-et
28
SQL caching configuration
ltconfigurationgt ltconnectionStringsgt ltadd
name"NorthwindConnectionString"connectionString"
" providerName"System.Data.SqlClient" /gt
lt/connectionStringsgt ltsystem.webgt ltcachinggt
ltsqlCacheDependency enabled"true"
pollTime"1000"gt ltdatabasesgt ltadd
name"Northwind" connectionStringName"Nort
hwindConnectionString"/gt lt/databasesgt
lt/sqlCacheDependencygt lt/cachinggt
lt/system.webgt lt/configurationgt
29
SQL 2005 Notification architecture
ASP.NET
SQL Server
SqlCommand
Cache
Northwind
TCP Port 1433
Notification Delivery Service
30
Preparing for SQL2005 notifications
  • Enable Service Broker on database
  • Enable caching in web.config

ALTER DATABASE Northwind SET ENABLE_BROKER GO
ltconfigurationgt ltsystem.webgt ltcachinggt
ltsqlCacheDependency enabled"true" /gt
lt/cachinggt lt/system.webgt lt/configurationgt
31
Start listening to notifications
  • Call SqlDependency.Start with connection string
  • Creates a new queue and a new service with GUIDs
    in name
  • Once per connection string in lifetime of an
    application, typically global.asax
  • Remember to call SqlDependency.Stop

void Application_Start(object sender, EventArgs
e) SqlDependency.Start(connectionString) voi
d Application_End(object sender, EventArgs e)
SqlDependency.Stop(connectionString)
32
Output Caching with SQL dependencies
  • Page output cache can be dependent on query
    results retrieved from SQL Server
  • SqlDependency attribute specifies invalidation
    mechanism
  • CommandNotification for query notification
  • Semi-colon separated list for polling
  • Automatically adds dependency to SqlCommand
    objects used in code

33
Page output caching
  • Use _at_OutputCache directive to set up output
    caching with a dependency to command
  • SQL Server 2005
  • SQL Server 7 and 2000

lt_at_ OutputCache Duration"60" VaryByParam"None"
SqlDependency"CommandNotification" gt
lt_at_ OutputCache Duration"60" VaryByParam"None"
SqlDependency"NorthwindProductsPubsAuthors" gt
34
DataSource controls
  • SqlDataSource control offers SqlCacheDependency
    property
  • Only for SQL Server databases
  • Works same way as page output caching

ltaspSqlDataSource ID"SqlDataSource1"
runat"server" ConnectionString"lt
ConnectionStringsNorthwindConnection
gt" EnableCaching"True" CacheDuration"10"Cache
ExpirationPolicy"Sliding"SelectCommand"SELECT
ProductID, ProductName, QuantityPerUnit FROM
dbo.Products" SqlCacheDependency"CommandNotificat
ion"gt lt/aspSqlDataSourcegt
35
DataSource controls
  • ObjectDataSource control does not support
    notifications
  • Add caching logic with SqlCacheDependency inside
    of Select method
  • Resort to polling

36
SqlCacheDependency class
  • Output cache and data source controls create an
    instance of SqlCacheDependency
  • You can use SqlCacheDependency directly

SqlCommand command new SqlCommand(sql,
connection) SqlCacheDependency dependency new
SqlCacheDependency(command) Response.AddCacheDepe
ndency(dependency)-- or -- Cache.Insert("key",
someDataSet, dependency)
37
ADO.NET 2.0 and Query Notifications
  • SqlClient managed provider has support for Query
    Notifications in SQL Server 2005
  • Two important classes for Query Notifications
  • SqlDependency class for easy wiring
  • SqlNotificationRequest

SqlDependency dependency new SqlDependency(comma
nd) dependency.OnChanged new
OnChangedEventHandler(DataChanged) SqlDataReader
reader command.ExecuteReader( ) void
DataChanged(object sender, SqlNotificationEventArg
s args)
38
Troubleshooting
  • Special rules apply for SELECT statements
  • Must use explicit column names
  • You cannot use SELECT
  • Specify schema name for db objects
  • Example SELECT FROM dbo.Customers
  • More rules apply, see MSDN
  • Database compatibility level must be 90 or higher
    sp_dbcmptlevel Northwind, 90
  • SQL Server Service cannot run under Local System
    account
  • Add dependency to command before executing it

39
Troubleshooting
  • ASP.NET identity that is not dbo should have
    enough rights
  • Requires attached instance, not User Instance of
    SQL Server Express
  • SQL CLR must be enabled

40
SQL Caching recommendations
  • Use wisely infrequently changing data, e.g.
    read-mostly lookup tables
  • For middle tier scenarios you might want to
    specify your own service and queue
  • SqlNotificationRequest for more control and
    custom handling of notifications
  • Check out SqlCacheDependencyAdmin for
    administrative tasks related to polling

41
Client callbacks
42
Client callbacks
  • A client callback is a out-of-band call to the
    web server
  • Server round-trip "behind-the-scenes"
  • No page refresh or complete page round-trip
  • Can perform actions at the server and optionally
    retrieve data and update UI
  • Improves friendliness and responsiveness of the
    user interface
  • Callbacks are made asynchronously by default
  • Perceived (not actual) performance is improved

43
Client callbacks, AJAX and Atlas
  • AJAX Asynchronous JavaScript and XML
  • Atlas is Microsoft framework for Web 2.0
    applications
  • Browser compatible client-side libraries for
    object-orientation and
  • Web Server controls for declaratively emitting
    markup and script for client callbacks
  • ASP.NET Client callbacks is like light-weight
    AJAX
  • No XML is transferred between client and server
  • No script libraries or server controls

44
Callback flow of information
Server-side
Client-side
WebResource script
Web page
WebForm1.aspx
include
onClick
Page state
ltscriptgt lt/scriptgt
DoCallback
ltscriptgtlt/scriptgt
HTTP POST
RaiseCallbackEvent GetCallbackResult
MSXML3.XMLHTTP
Callback
ltscriptgtlt/scriptgt
onReadyStateChange
ltscriptgtlt/scriptgt
ltscriptgtlt/scriptgt
Timeout
45
Client-side script
  • Client-side JavaScript starts roundtrip to server
  • Three functions DoCallback, CallbackComplete,
    ExecuteCallback
  • ASP.NET callback script is included as a Web
    Resource
  • Embedded Resource made available for download
    through HTTP handler AssemblyResourceLoader
  • Special URL WebResource.axd?dt

46
Data exchange
  • Data is posted back as regular URL-encoded form
    data, not necessarily XML
  • Contains ViewState, Event validation data,
    callback ID and param
  • Response contains response and new Event
    validation data

__EVENTTARGET__EVENTARGUMENT__VIEWSTATE2FwEP
Ah4Hb25jbGljawUgR2V0SGVsbG9aXb3JabdcsxMiwgJ2w1__C
ALLBACKID__Page__CALLBACKPARAM12__EVENTVALIDA
TION2FwEWAwL2BraDpAgL72B4SRCAKM54rGBpFe3rPMr2H
7QsP2vv4x4ojYDdL2
14/wEWDgLh94yAQServer Time is 13035
AM LengthEventValidationDataResponse
47
Client callback enabled pages
  • Pages that can handler client callbacks implement
    System.Web.UI.ICallbackEventHandler
  • RaiseCallbackEvent receives client-side data
  • Response is generated in GetCallbackResult
  • Split into two methods to allow for asynchronous
    pages or tasks

public interface ICallbackEventHandler void
RaiseCallbackEvent(string eventArgument)
string GetCallbackResult( )
48
Altered page lifecycle
  • Page lifecycle is different for callbacks
  • Check withPage.IsCallback property

Client
Init
LoadState
request page
ProcessPostData
Load
2nd ProcessPostData
Change events
Postback events
PreRender/Complete
send response
Render
Unload
49
Altered page lifecycle
  • Page lifecycle is different for callbacks
  • Check withPage.IsCallback property

Client
Init
LoadState
request page
ProcessPostData
Load
2nd ProcessPostData
Change events
RaiseCallbackEvent
send response
GetCallbackResult
Unload
50
Putting callbacks together
  • Create JavaScript functions for
  • Firing callback
  • Use server-side code or include from .js file
  • Create call with a call to ClientScriptManager
    GetCallbackEventReference method
  • Handling callback
  • Error handling (optionally)
  • Register client script blocks or includes
  • Choose client-side event to call function
  • Wire up HTML DOM event handler

51
Passing arguments to server
  • Retrieve values of controls through HTML DOM
  • Choose an appropriate form of marshalling and/or
    encoding for complex data

ltselect name"ProvincieLijst" id"ProvincieLijst"
onchange"HaalFlitsers(GetListValue(ProvincieLijst
), null)"gt
ltscript type"text/javascript"gtlt!-- function
HaalFlitsers(args, context) WebForm_DoCallback('
__Page',args,HaalFlitsersCallback,"",HaalFlitsersE
rror,true)// --gt lt/scriptgt
52
Context of callback
  • Context does not travels back and forth between
    client and server
  • Maintained at client
  • Use context to
  • Keep track of multiple active async callbacks
  • Context can be null, simple datatype (e.g.
    string) or object

var context new Object() context.Param1
context.Param2 WebForm_DoCallback('__Page'
,args,OnCallBack,context,OnCallBackError,true)
53
Error handling
  • Exception thrown during page lifecycle will
    result in error scenario on client
  • Exception is caught and message is propagated to
    client (prefixed 'e')
  • Register a error function
  • Requires you to specify async behavior boolean in
    call to GetCallbackEventReference

54
Client callbacks from controls
  • Some controls in ASP.NET 2.0 use Client callbacks
  • GridView, TreeView and DetailsView
  • Controls that call back need to implement
    ICallbackEventHandler
  • Optionally ICallbackContainer
  • Provides a formalized way for controls to
    retrieve callback script for buttons

public interface ICallbackContainer string
GetCallbackScript(IButtonControl button,
string argument)
55
Event validation
  • ASP.NET 2.0 validates events on post/callback
  • Not just any control can cause postback and send
    arguments
  • Avoid setting lt_at_Page EnableEventValidation"Fals
    e" gt
  • Register values for event validation inside
    GetCallbackResult
  • Still cannot read directly from control. Use
    Request object instead.

ClientScript.RegisterForEventValidation("ListBox1"
, index.ToString( ))
56
Browser compatibility
  • Works with
  • Internet Explorer with MSXML 3.0
  • Mozilla and Opera style browsers
  • Non-IE browsers do not use XmlHttp object
  • Script determines XmlHttp does not exist
  • Creates a hidden IFrame for every request
  • Data is submitted to server via normal HTTP POST
    and form.submit()

57
Review
  • Performance of ASP.NET web applications can be
    drastically improved by using new ASP.NET 2.0
    features
  • Asynchronous pages and task relieve threads
    making overall response times better
  • SQL Caching avoids unnecessary roundtrips to
    database server and provides easy cache
    invalidation based on data changes
  • Client callback provides lightweight AJAX
    functionality and improves perceived performance

58
Questions
  • ?

59
SDC 2006
60
Question 1
  • What is the name of the property that was
    previously called SmartNavigation?

MaintainScrollPositionOnPostback
61
Question 2
  • How do you take a Web application offline with a
    single page?

Place app_offline.htm in root of application
62
Question 3
  • What is the hardcoded (!) limit of concurrent
    requests on IIS 5.1 in Windows XP?

40
Write a Comment
User Comments (0)
About PowerShow.com
