Windows 2000 Operating System -- Active Directory Service

1
Windows 2000 Operating System -- Active
Directory Service

• COSC 516
• Yuan YAO
• 08/29/2000

2
Windows 2000 Included Products

• Windows 2000 Professional
• Windows 2000 Server
• Windows 2000 Advanced Server
• Windows 2000 Datacenter Server

• Windows NT 4.0 Workstation
• Windows NT 4.0 Server
• Windows NT 4.0 Enterprise

3
Upgrade to Windows 2000

• 95 2000
• automatic setup will report incompatibility,
  some application have different components for
  two
• 98 2000
• tricky due to lots of hardware and software
  compatibility problems
• NT 4.0 2000
• easier but not without problems

4
What to expect if you

• are on the road (Remote users)
• work at home (Home office users)
• run a small business (Small business)
• run a larger network (Medium-size and large
  enterprise)
• provide internet services (Service provider)

5
Active Directory Service

• A true hierarchical, distributed directory
  service for managing resources across an
  enterprise or extranet.

6
ADS Terminology

• Directory and Directory Services
• Directory is an information store.
• Directory Services are a directory itself as well
  as the services it provides, such as security and
  replication.
• Workgroup and Domain
• A Windows 2000 workgroup is a logical grouping of
  networked computers that share resources, such as
  files and printers, and maintain a local security
  database, which is a list of user accounts and
  resource security information for the computer it
  is on.
• A Windows 2000 domain is a logical grouping of
  networked computers that share a central
  directory database, which contains user accounts
  and security information for the domain.

7
ADS Terminology

• Domain Tree and Forest
• A domain tree refers to a hierarchical grouping
  of domains that share a contiguous namespace, a
  common schema, and a common global catalog.
• A domain forest is a collection of two or more
  domain trees that do not share a contiguous
  namespace, but do share common schema and global
  catalog.
• Namespace
• A collection of unique domain names.

8
ADS Terminology

• Object and Organizational unit
• An object is a representation of a network
  resource, including users, computers, printers,
  and so forth.
• Organizational unit is an object that can hold
  other objects.
• Multimaster replication
• The process by which Active Directory domains
  replicate with each other and resolve conflicting
  updates.
• Lightweight Directory Access Protocol (LDAP)
• An Internet standard by which Active Directory
  clients and servers communicate.

9
Do you need Directory Service ?

• A central database that keeps track of every
  resource and user in an enterprise-wide network.
• If you don't need a full directory service yet,
  you should get ready by practicing the discipline
  of using a consistent naming scheme.

10
Importance of Directories

• Become the points of reference for applications
  and user services.
• Provide single sign-on.
• Become increasingly important as business
  networks expand to include connections with
  business partners and customers.

11
Existing Directory Services

• Bull, Computer Associates, Hewlett-Packard, IBM,
  Tivoli, and Unisys have offered directory
  solutions. But hefty price tags and lack of
  interoperability have limited their adoption.
• Active Directory brings a big buzz.
• Novell Directory Services (NDS) and the Novell
  ZenWorks software family have also made many
  administrators aware of the importance of
  directory services.

12
What is a hierarchical namespace?
13
Scalability Comparison

• Active Directory Service partitions can hold
  millions of objects and use indexed data stores
• Novell Domain Service partitions are limited to
  1,000 objects
• NT 4 Domain Service can only provide limited
  scalability, one NT 4 server stores the entire
  domain database

14
Transitive Kerberos Trusts

• If domain A trusts domain B, and domain B trusts
  domain C, then domain A trusts domain C and vice
  versa.
• Trusts give user and group rights to traverse
  domains and are essential for single sign-on.
• It reduces the complexity of maintenance.

15
A Distributed Directory Service

• Directory servers are typically distributed
  across a network so that they are easily
  reachable by clients and servers.
• Data relationships and naming
• Replication
• Caching

16
Data Relationships Naming

• For NT 4, administrative authority could only
  delegate to the domain level.
• ADS gives the administrative authority down to
  the Organizational Unit level.

• For NDS, user rights to other domain objects or
  common resources can be assigned to an
  Organizational Unit.
• For ADS, rights must always be configured for
  individual users and groups.

17
Replication

• Domain Controller, a server that contains
  directory information and responds to database
  requests or routing requests for resources.
• NT 4's Primary and Backup Domain Controllers have
  been replaced in 2000 by a peer model. Any server
  can be promoted to AD domain controller status.
• Multimaster Replication replicates changes made
  to any single controller to all other controllers.

18
Caching

• To improve response time for directory queries,
  directory servers can save a copy of frequently
  requested directory service information locally
  in Global Catalog (GC)

19
Migrating to Active Directory

• Domains to Active Directory
• Requires extensive planning and testing
• NDS to ADS
• No good reasons to switch to Active Directory,
  unless plan to abandon NetWare completely. Better
  create a test-bed first.

20
Domain Modes

• Mixed Mode
• Allows the domain controllers to interactive with
  any domain controllers running previous versions
  of Win 2000 Server.
• Native Mode
• All the domains are integrated with Active
  Directory, and all Windows NT 4 domain
  controllers are upgraded to Windows 2000 Server

21
Mixed Mode to Native Mode

• Upgrade all domain controllers.
• Reconfigure the domains by using Active Directory
  Migration Tool or FastLane, etc.
• Several points
• Support for down-level replication ceases.
• Can no longer add new down-level domain
  controllers to the domain.
• No more primary domain controller, all domain
  controllers are peers.
• The change is one way only.
