Distributed Databases DDBs

1
Distributed Databases (DDBs)
2
Distributed Databases

• Distributed Systems goal
• to offer local DB autonomy at geographically
  distributed locations
• Multiple CPU's each has DBMS, but data
  distributed

3
Advantages of DDBs

• Distributed nature of some DB applications (bank
  branches)
• Increased reliability and availability if site
  failure - also replicate data at gt 1 site
• Data sharing but also local control
• Improved performance - smaller DBs exist at each
  site

4
Disadvantages Increased complexity

• Additional functions needed
• global vs. local queries
• access remote sites, transmit queries and data
• keep track of data and replication
• execution strategies if data at gt 1 site
• which copy to access
• maintain consistency of copies
• recover from site crashes

5
Architectures

• Parallel Systems goal  to construct a faster
  centralized computer
• Distributed Systems goal  to offer local DB
  autonomy at geographically distributed locations

6
Parallel DBSs

• Shared-memory multiprocessor
• get N times as much work with N CPU's access
• MIMD, SIMD - equal access to same data, massively
  parallel
• Parallel shared nothing
• data split among CPUs, each has own CPU, divide
  work for transactions, communicate over high
  speed networks                 LANs -
  homogeneous machines                 CPU
  memory - called a site

7
Distributed DBSs (DDBS)

• Distributed DB - share nothing
• lower communication rates
• WAN
• heterogeneous machines
• Homogeneous DDBS
• homogeneous same DBMSs
• Heterogeneous DDBS
• different DBMSs - need ODBC, standard SQL

8
   Heterogeneous distributed DBSs HDDBs

• Data distributed and each site has own DBMS
• ORACLE at one site, DB2 at another, etc.
• need ODBC, standard SQL
• usually transaction manager responsible for
  cooperation among sites
• must coordinate distributed transaction
• need data conversion and to access data at other
  sites

9
Multidatabase

• autonomous preexisting DBs form new database
• collection of cooperating DBSs that are
  heterogeneous
• Each DB has its own local users, local
  transparency and DBA
• very high degree of local autonomy
• need additional interface to allow users to
  access global data

10
Federated DB

• federated DB is a multidatabase that bridges
  heterogeneity fully integrated
• keeps a partial view of total schema
• Each DB specifies import/export schema (view)
• appears centralized for local autonomous users
• appears distributed for global users

11
DDBS

• Issues in DDBS in slides that follow

12
 To process a query

• Must use data dictionary that includes info on
  data distribution among servers
• Parse user query
• decomposed into independent site queries
• each site query sent to appropriate server site
• site processes local query, sends result to
  result site
• result site combines results of subqueries
• Ensure atomicity

13
Data fragments

• Can distribute a whole relation at a site
• or
• Data fragments
• logical units of the DB assigned for storage at
  various sites
• horizontal fragmentation - subset of tuples in
  the relation (select)
• vertical fragmentation - keeps only certain
  attributes of relation (project) need a PK

14
Fragments contd

• horizontal fragments
• complete - set of fragments whose conditions
  include every tuple
• disjoint - tuples only member of 1 fragment
          salary lt 5000 and dno4
• Complete vertical fragment        L1 U L2 U ...
  Ln - attributes of R                         Li
  intersect Lj PK(R)

15
Replication

• Full vs. partial replication
• Which copy to access
• Improves performance for global queries but
  updates a problem
• Ensure consistency of replicated copies of data

16
Example replication/fragmentation

• Example of fragments for company DB     site 1
  - company headquarters gets entire DB
      site 2, 3 horizontal fragments based on
  dept. no.

17
Concurrency Control and Recovery in Distributed
Databases

• Distributed transactions inherit ACID properties
• problems
• failure at individual sites and communication
  links
• distributed deadlock (usually timeout)
• distributed commit (use 2PC)
• concurrency control with multiple copies of data


18
Distributed Commit

• if updating data at different sites for same
  transaction, when to commit?
• difficult part - commit together so have
  atomicity
• Observation - 3 states of basic transactions
              active - can enter other 2 states
              committed - cannot leave this state
              aborted - cannot leave this state

19
States

• commit
• Active
• abort

20
Commit problems

• To commit a distributed transaction need a
  coordinator (originator) site (S1 in our example)
• Given transaction T with with components T1 and
  T2
• where T1 executes at site S1
• T2 executes at site S2
• a)  if S1 commits locally, sends commit message
  to S2
• BUT if S2 crashes, T2 aborts before completes
  subtask not atomic
• b)  if both T1 and T2 ready to commit S1 sends
  message to commit
• BUT if T2 crashes during commit, not atomic if
  cant recover

21
To solve problem

• How to solve these problems?
• Need an additional state
• prepare state
• when T is done and ready to commit, it goes to
  the prepare state
• in the prepare state, a transaction can go to
  the commit or abort state
• (place prepare log on log buffer, forced to log
  file - can reconstruct the transaction)

22
States

• commit
• Active Prepare to commit
• abort

23
Use Two-Phase Commit (2PC)

• Used by commercial DBS to achieve coordinated
  commit of distributed transactions
• Need a coordinator - usually a site that is
  participating in the transaction
• Only needed if updates

24
2PC

• Phase 1
• When each subquery concludes, signal coordinator

• If receive done from all, coordinator sends
  prepare to commit to all sites
• Else coordinate signals abort to all.
• Each site writes changes and Prepare to log
  file, send ready to commit, site enters
  prepared state
• if log fails or cannot commit for other reasons,
  send cannot commit, else can commit
• If dont hear from everyone within a time out
  interval assume not OK, send abort to all-
  rollback locally

25
2PC

• Phase 2
• If all prepare requests successful responses,
  coordinator sends commit
• Sites record Commit in log, update DB
• If any site response is unsuccessful, coordinator
  sends messages to all sites to abort -
  rollback locally
• If dont hear from everyone within a time out
  interval assume not OK, send abort to all-
  rollback locally
• subquery concluded     ready to commit
  (prepared state)
• commit record commit

26
Solved by 2PC?

• a)  if S1 commits locally, sends commit to S2
• BUT if S2 crashes, T2 aborts and it is not
  atomic
• With 2PC
• if T1 completes Transaction
• T1 is prepared
• If T2 crashes
• T2 is unsuccessful
• T1 can still abort from prepared state

27
Solved by 2PC?

• b) If both T1 and T2 ready to commit, S1 sends
  message to commit
• BUT if T2 crashes before commit completed, not
  atomic
• With 2PC
• if both T1 and T2 successfully complete
  Transaction
• T2 and T1 are both prepared
• If T2 crashes can recover prepared state and
  commit

28
Any problems with 2PC?

• A blocking protocol (block until commit or
  rollback received)
• In most practical applications, blocking caused
  by 2PC are rare
• Therefore, most systems use 2PC
• However, when could 2PC block?

29
2PC blocking

• However, when could 2PC block?
• Problem can occur when site in prepared state
• Site voted to commit
• Cannot commit until receive commit from
  coordinator
• Cannot change vote and abort
• Participant is blocked until receive message from
  coordinator
• (or coordinator can block while waiting for
  replies from participants what about time out?)
• Solution?

30
Three-phase commit

• 3PC
• Requires an extra round of messages
• Adds another state pre_commit in between ready
  to commit (prepared) state and commit state
• When in pre-commit state
• can still abort
• can contact other sites

31
3PC

• Phase 1 the same as 2PC
• Coordinator sends vote_req to all sites
• Sites respond commit or abort
• If one aborts, all abort
• Phase 2
• If all reply vote_commit, coordinator sends
  precommit (prepare_to_commit)
• Sites that responded commit, wait
• If receive precommit, send ack
• Else abort

32
3PC

• Phase 3
• Coordinator collects all acks
• Decides commit
• Broadcasts global_commit
• Site receiving global_commit, commits
• subquery concluded     ready to commit
• precommit
• commit record commit

33
3PC

• Eliminates blocking due to coordinator failure
  when
• Site sent vote_commit, but not received
  prepare_to_commit
• Site can abort if do not hear from coordinator
• Site received prepare_to_commit but not
  global_commit
• Knows everyone voted to commit, knows it will
  eventually commit, can act independently,
  communicate with other sites

34
3PC

• If in pre-commit state
• can elect new coordinator if it fails
• New coordinator collects states from sites and
  tries to resolve transaction
• Otherwise new coordinator tries to establish
  quorum

35
Quorum based 3PC establishing quorum

• Every site assigned a vote Vi
• Total votes V
• Abort and commit quorum are Va and Vc
• VaVcgt V
• Before commit, must obtain commit quorum
• At least one site in pre-commit and (sites in
  wait sites in pre_commit) form quorum
• Before abort, must obtain abort quorum
• (Sites in wait pre-abort) for quorum

36
Distributed concurrency control using locking

• Centralized vs. distributed solutions
• Definition distinguished copy
• Locks associated with this copy

37
Primary site technique

• Primary site technique
• Distinguished copy of all data at this site
• All locks kept at this site, all requests sent
  here
• Site acts as coordinator for all DB items
• If write lock, DBMS must update all copies
• If read lock from primary site, can access local
  copy
• disadv
• all locking requests sent to same site -
  bottleneck
• if failure at primary site?  must abort and
  restart all Ts

38
Primary site with backup

• Primary site with backup
• all lock information at both sites, so failure
  is less of a problem
• disadv
• slower - 2 sites to communicate with

39
Primary copy technique

• Primary copy technique - distribute
  responsibility
• distinguished copies of different items at
  different sites
• can also choose a new coordinator if a failure -
  election to choose self as new site

40
Voting

• Voting - no distinguished copy
• lock request sent to all sites with copy of data

• if granted lock by majority of copies, hold lock
  and inform sites with copies lock is granted
• if don't get a majority, timeout and cancel
  request sent to all sites
• disadv
• lots of message traffic

41
Additional Issues in DDBSs

• Distributed transaction if data distributed
• Transaction manager (TM) knows where data is
  stored
• TM decides which site starts local components of
  transaction
• Distributed query processing

42
Query Parallelism

• Decompose query into parts that can be executed
  in parallel at several sites
• Intra query parallelism
• If shared nothing horizontally fragmented
• Select name, phone from account where age gt 65
• Decompose into K different queries
• Result site accepts all and puts together (order
  by, count)

43
Query Parallelism

• What if a join?
• Difficult problem if table fragments at different
  sites
• Must get all values of joint attributes at one
  site
• Then broadcast to relevant sites value of join
  attribute
• If site 1 has values 1-10 and site 2 has 11-20,
  only set to those sites
• Result tuples returned, join performed
• Example A XB with tuples A1B1 A2B2
  A3B3 tuples A1,A2,A3 sent to S1 S1 sends FK to
  B1,B2,B3 sites B1,B2,B3 site send tuples where
  PKA1,A2,A3 join performed at S1

44
Distributed Query Processing

• If Query (read-only) - no 2PC needed
• If horizontally fragmented
• decompose query into subqueries that can be
  processed in parallel
• one site (result site) accepts all results and
  puts together
• Must also do order by, count

45
Distributed Query Processing

• If the data is not fragmented
• process whatever operations you can locally
  (select, project)
• Query can involve joins between data at multiple
  sites
• Must transfer data over network
• Transfer of data highest cost
• Algorithms to minimize amount of data transferred
  (NP-hard)

46
Distributed Query Processing

• Assume R1 X R2 -gt Site 3
• with R1 at S1 and R2 at S2
• Can do
• R1 -gt S3 and R2 -gt S3, do join at S3
• R1-gt S2, execute join at S2, result to S3
• R2-gt S1, execute join at S1, result to S3

47
Semi-join X

• p dname, lname Dept Xmgrssn Emp
• Assume Dept is R1 and Emp is R2
• 1) project join attribute of Emp at S2 resulting
  in E', send to S1. E' is (p ssn Emp)
• 2) E' X Dept at S1. Project result attributes
  and join attributes resulting in E'', send to S2

• E' is (p mgr, dname (Dept Xmgrssn E'))
• 3)  p dname, lname (E'' Xmgrssn Emp) and send
  result to S3

48
Distributed Query Processing

• Henver Yao
• Cost
• time to compute results
• time to transmit data
• Local data requires only processing time
• Assume transmission time is most costly
• Goal is to minimize transmission time

49
Distributed Query Processing

• Assume you have R3R1XattattR2
• R1 is at S1, R2 at S2 and result relation R3 sent
  to result site S
• Amount of data to transmit
• Assume R1 is 1M bytes
• R2 is 250K bytes
• R3 is 50k bytes
• Using semi-join
• pattR1 is 100K
• pattR2 is 50K
• pattR1XR2 is 10K
• pattR2XR1 is 25K

50
Distributed Query Processing

• Show all possibilities to previous problem and
  determine best distributed query processing
  strategy

51
FDBSs - Data Integration

• Fully-integrated, logical composite of all
  constituent databases
• Potential problems
• Incompatible data types or query syntax
• Semantically equivalent by differently named
  parts of schemas
• Use views for data integration
• reference
