Title: Automatic Identification of Bug-Introducing Changes.


1
Automatic Identification of Bug-Introducing
Changes.
  • Presenter Haroon Malik

2
Abstract
  • Bug-fixes do not contain information about the
    change that initially introduced the bug.
  • Extraction of bug-introducing changes is
    challenging.
  • An algorithm to automatically and accurately
    identify a bug-introducing changes.
  • Algorithm can remove 3051 of false positive
    and 1415 of false negative to previous
    algorithm.

3
Introduction
  • Software project control their changes using SCM
    and capture bug reports using bug tracking
    software e.g Bugzilla.
  • Records which changed in SCM system fixes a
    Specific bug in the change tracking system.
  • Bug Progression
  • Programmer makes the change
  • Bug-introducing change
  • Bug manifest itself in some undesirable external
    behavior.
  • Recorded in bug tracking system
  • Developer modifies the code to fix bug
  • Bug-fix change

4
Introduction (Contd)
  • Wide spread use of SCM, data concerning bug fix
    changes in readily availble.
  • It is easy to mine SCM repository to mine changes
    that have repaired a bug
  • Linking key words with bug report refrence
  • E.g Bug or Fixed 902340

5
Major Problems with bug-fix data
  • It shed no light on when a bug was injected
  • Not always person who fixes a bug is one who
    caused
  • Can not determine where a bug occurred.

6
Background
  • SZZ Algoritham
  • Working
  • Firstly locates key words to mark bug-fixed
    changes
  • Secondly, running a diff tool what changed in
    bug-fix
  • Diff tool returns Hunk
  • Utilizes annotate feature of SCM to find the
    changes
  • Most recent revision
  • Who made the chage

7
Background (Contd)
  • Revision1 Origin of bug (Line 3).
  • Revision 2 Function name changed (bar foo).
  • Revision 3 Bug removal

8
SZZ Limitations
  • Blank spaces and Comments
  • Formatting changes (Line 3)
  • Name of function containing bug.

9
Proposed Approach
  • Applied of method level for two java open source
    projects
  • Columba and Eclipise
  • Two human judges manually verified all hunk in
    series of bug-fix to ensure the corresponding
    hunks are real bug fixes.

10
Proposed Approach
  • Steps(1-5) remove 3851 of false positive and
    1415 of false negatives as compared to SZZ.

11
Experimental setup
  • History Extraction
  • Used Kenyon to extract histories from SCM systems

12
Experimental setup (Contd)
  • Accuracy Measures
  • Bug-introducing change set consists of all the
    changes with in specific project revisions that
    have been identified as bug-introducing
  • Assuming R is the more accurate bug-introducing
    change set, then compute false positives and
    false negatives for the set P can be computed as
    follow

13
Annotation Graph
  • Annotation Graph
  • A graph which contains information on the
    cross-revision mappings of individual lines.
  • Major improvement over the SZZ

14
Experimental setup (Contd)
  • Non behavior changes
  • Code format, comments blank lines.
  • 1420 false positive
  • Format changes

15
Manual Verification
  • If a change log indicates the revisions is a
    bug-fix, it is assumed all the hunks in revision
    are bug fixes.
  • Two humans judges marked each bug-fix hunk for
    both projects.
  • Used bug-fix hunk verification tool

16
Real Bugs?
17
Validation Hurdles
  • Non representative systems.
  • Open Source.
  • Bug fix data is incomplete.
  • Manual Varicication

18
Bug-Introduction Statistics
Eclipse
Columba
19
Conclusion
  • Refined SSZ approach by introducing Annotation
    Graph.
  • Experiments showed the achievement of 3851 of
    false positive and 14 of false negative removal
    as compared to SSZ

20
Thank You
