Joints

1
Joints
2

• Articulations of bones
• Functions of joints
• Hold bones together
• Allow for mobility
• Ways joints are classified
• Functionally
• Structurally

3
Functional Classification of Joints

• Synarthroses (synarthrotic joints)
• immovable joints, most fibrous joints
• Amphiarthroses (amphiarthrotic joints)
• slightly movable, mostly cartilaginous joints
• Diarthroses (diarthrotic joints)
• freely movable joints
• Synovial joints

4
Synarthrosis (immovable)

• Sutures - Fibrous joint
• Ex. found between bone of the skull
• Gomphosis Fibrous joint
• Cone-shape peg fits into socket
• Ex. Roots of teeth in the alveoli (socket) of
  maxillae and mandible
• Synchondrosis Cartilaginous joint
• Hyaline cartilage is connecting material
• Joint eventually replaced by bone
• Ex. Epiphyseal plate and joints between the rib
  and the sternum

5
Gomphosis
6
Amphiarthroses

• Syndesmosis
• Like suture but has more fibrous tissue between
  the bones
• Joints are not as tight (permits more
  flexibility)
• Distal end of tibia and fibula
• Symphysis (growing together)
• Cartilaginous joint
• Connecting material is a broad, flat disc of
  fibrocartilage
• Intervetebral joints and pubic symphysis

7
Diarthrosis

• movable
• Has synovial cavity or joint separating bones
• Has articular cartilage covers the surface of
  articulating bones
• Reduces friction and helps absorb shock

8
Structural Classification of Joints

• Fibrous joints
• Generally immovable
• Cartilaginous joints
• Immovable or slightly movable
• Synovial joints
• Freely movable

9
Fibrous Joints

• Bones united by fibrous tissue
• Examples
• Sutures
• Synostosis bony joint synarthrosis
• Ex. Frontal suture
• Syndesmoses
• Allows more movement than sutures
  amphiarthrosis
• Ex distal end of tibia and fibula
• Gomphoses
• Fibrous joint synarthrosis
• Teeth in alveoli

Figure 5.27ab
10
Cartilaginous Joints

• Bones connected by cartilage
• Synchondroses (hyaline cartilage) synarthrosis
• Ex. costal cartilage and epiphyseal plate
• Symphyses (fibrocartilage sandwiched between
  hyaline cartilage) amphiarthrosis
• Ex. intervetebral disks and symphysis pubis

Figure 5.27de
11
Synovial Joints

• Articulating bones are separated by a joint
  cavity
• Synovial fluid is found in the joint cavity

Figure 5.24fh
12
Features of Synovial Joints

• Articular cartilage (hyaline cartilage) covers
  the ends of bones
• Joint surfaces are enclosed by a fibrous
  articular capsule
• Have a joint cavity filled with synovial fluid
• Ligaments reinforce the joint

13
(No Transcript)
14
Structures Associated with the Synovial Joint
(reduce friction)

• Bursae flattened fibrous sacs
• Lined with synovial membranes
• Filled with synovial fluid
• Not actually part of the joint
• Tendon sheath
• Elongated bursa that wraps around a tendon

15
The Synovial Joint
Figure 5.28
16
(No Transcript)
17
(No Transcript)
18
(No Transcript)
19
(No Transcript)
20
(No Transcript)
21
(No Transcript)
22
(No Transcript)
23
(No Transcript)
24
Supination and pronation only refers to the
movement of the hand.
25
(No Transcript)
26

• Condyloid and saddle joints
• Very similar but slightly different in shape
• Movements
• Flexion, extension, adduction, abduction,
  circumduction ( a combination of the four)

27
(No Transcript)
28
(No Transcript)
29
The axes for these movements run bilaterally
through the ankle.
30
(No Transcript)
31
Other movements

• Elevation to raise a part
• Depression to lower a part
• Protraction to move a part forward
• Retraction to move a part backward
• You can elevate and depress many parts
• Scapula, pelvis, jaws, etc.
• These can also protract and retract

32
The shoulder joint

• Humeroscapular or glenohumeral joint
• Multiple ligaments help to hold the humerus in
  place
• Primary structural support is the rotator cuff (a
  group of muscles)

33
Elbow Joint

• Humerus, ulna, and radius
• Has pivot joint between the capitulum of the
  humerus and the head of the radius
• A hinge joint whose axis runs bilaterally through
  the trochlea

34
(No Transcript)
35
(No Transcript)
36
The Hip Joint

• Coxal joint
• Ball and socket joint between the head of the
  femur and the acetabulum of the hip bone
• Has deep fossa which supports the tremendous
  force placed on it

37
(No Transcript)
38
The Knee Joint

• Most complex and the largest joint
• Has three joints within a single synovial cavity
• Laterally tibiofemoral joint (lateral condyle
  of femur, lateral meniscu, lateral condyle of
  tibia) modified hinge joint
• Medially tibiofemoral joint (medial condyle of
  femur, medial meniscus, medial condyle of tibia)
  modified hinge joint
• Intermediate patellofemoral joint planar joint

39
Inflammatory Conditions Associated with Joints

• Bursitis inflammation of a bursa usually caused
  by a blow or friction
• Tendonitis inflammation of tendon sheaths
• Arthritis inflammatory or degenerative diseases
  of joints
• Over 100 different types
• The most widespread crippling disease in the
  United States

40
Clinical Forms of Arthritis

• Osteoarthritis
• Most common chronic arthritis
• Probably related to normal aging processes
• Rheumatoid arthritis
• An autoimmune disease the immune system attacks
  the joints
• Symptoms begin with bilateral inflammation of
  certain joints
• Often leads to deformities

41
Clinical Forms of Arthritis

• Gouty Arthritis
• Inflammation of joints is caused by a deposition
  of urate crystals from the blood
• Can usually be controlled with diet

42
(No Transcript)
43
Other diseases

• Lyme disease
• Caused by deer ticks
• Afflicts the knee, ankle, hip, elbow, or wrist
• Arthritis is the main complication in advance
  stages of disease

44
Joint injuries

• Sprain - twisting of the joint, often with
  accompanying stretching and tearing of ligaments
• Strain pulling of a muscle tendon and other
  connective tissue in muscles, but not joint tissue

45
Joint injuries

• Luxation is a dislocation where a bone such as
  the humerus or femur pulls away from its position
  in the socket of the joint
• Separation occurs when fibrous tissue in a
  syndesmoses stretches or tears

46
Aging and Joints

• Results in decreased production of synovial fluid
• Articular cartilage thins down
• Ligaments shorten lose flexibility

47
Arthroplasty

• Surgical replacement of severely damaged joints
  with artificial joints
• Most commonly replaced hips, knees, shoulders
• Partial hip replacement involves the femur
• Total hip replacement involves both acetabulum
  and head of the femur

48

• http//www.edheads.org
