Enhance Features and Performance of Content Switches

1
Enhance Features and Performance of Content
Switches

• Chandra Prakash
• Department of Computer ScienceUniversity of
  Colorado at Colorado Springs

2
Outline of the Talk

• Introduction
• Existing Content Switch related
  products/techniques
• Basic Architecture of Content Switch (CS)
• TCP Delayed Binding and proposed improvements
• Performance results of various schemes for
  improving TCP Delayed Binding
• Handle multiple requests in HTTP Keep-Alive
  connection
• Enhancements to CS
• Handling muitlple packets of a HTTP request
• Handling different data encoding formats
• Improved XML rule matching
• High-Availability of Linux CS Cluster
• Conclusion
• Future Work

3
Content Switch-based Cluster
RIP1
Real Server1
RIP2
WAN/LAN
Internet
VIP
RIP3
CIP
Virtual Server/ Content Switch
Real Server3
Client
CIP Client IP Address VIP Virtual IP
Address RIP Real Server IP Address
4
Existing Content Switch Related Products

• Alteon's series (A180e/A184) products support
  URL-based Server load balancing
• F5's Big-IP product supports load balancing and
  contents switching
• Foundry network's ServerIron product supports
  URL, Cookie, and SSL Session ID-based switching
• Intels XML accelerator products can distribute
  Web load based on XML tag values

5
Existing Content Switch Related Techniques

• MAC address translation (MAT)
• MAC multicast
• Half network address translation (HNAT), also
  known as NAT in Linux Virtual Server Project
  (http//www.linuxvirtualserver.org)
• Full network address translation (FNAT)
• IP tunneling

6
MAC Address Translation
server to client traffic
client traffic
real server 1 ethernet IP128.198.192.1 loopback
IP128.198.192.182
LAN
client traffic
real server 2 ethernet IP128.198.192.2 loopback
IP128.198.192.182
virtual server VIP128.198.192.182
real server 3 ethernet IP128.198.192.3 loopback
IP128.198.192.182
7
MAC Multicast
server to client traffic
client traffic
client traffic
real server 1 IP1
LAN
client traffic
real server 2 IP2
switch
client traffic
real server 3 IP3
MAC Multicast group
8
Half NAT
client traffic
server to client traffic
client traffic
real server 1 ethernet IP128.198.192.1 Default
GW128.198.192.182
server to client traffic
real server 2 ethernet IP128.198.192.2 Default
GW 128.198.192.182
virtual server VIP128.198.192.182
LAN
real server 3 ethernet IP128.198.192.3 Default
GW 128.198.192.182
9
Full NAT
server to client traffic
server to client traffic
client traffic
real server 1 IP1
client traffic
real server 2 IP2
virtual server VIP
real server 3 IP3
10
IP Tunneling
server to client traffic
client traffic
real server 1 IP1
client traffic
real server 2 IP2
virtual server VIP
packet destined for real server
encapsulation at virtual server
RIP
client packet
real server 3 IP3
decapsulation at real server
11
Basic Operations of Content Switching
CS Content Switching
CS RuleEditor
CS Rules
Incoming Packets
Packet Classification
Header ContentExtraction
CS Rule Matching Algorithm
Packet Routing(Load Balancing)
Forward Packet To Servers
Network Path Info
Server Load Status
Load Balancing Repository
12
TCP Delayed Binding(Basic Scheme)
client

server

content switch


SYN(CSEQ)
step1


SYN(DSEQ)
step2



ACK(CSEQ1)
step4


SYN(CSEQ)

step5

SYN(SSEQ)

step6


ACK(CSEQ1)

step7

ACK(SSEQ1)


step8
DATA(CSEQ1)

ACK(SSEQ1)

DATA(SSEQ1)
DATA(DSEQ1)
step9



ACK(CSEQlenR1)
ACK(CSEQLenR1)
step10


ACK(DSEQ
lenD1)

ACK(SSEQlenD1)

lenR size of http request.

.

lenD size of return document
13
Pre-Allocate Scheme if Guess is Correct
Pre-allocated server
client


content switch


SYN(CSEQ)
SYN(CSEQ)

step1

SYN(SSEQ)
SYN(SSEQ)
step2




ACK(CSEQ1)

ACK(CSEQ1)

step4
DATA(CSEQ1)
DATA(CSEQ1)

• Guess routing decision based on IP/Port/History
• Advantage
• Faster than TCP delay binding.
• Possible direct route between client and server
• Reduce session processing overhead no need to
  convert server sequence

.
14
Pre-allocate Scheme if Guess is Wrong
Pre-allocated server
client


content switch


SYN(CSEQ)
SYN(CSEQ)
step1


SYN(SSEQ)/ ACK(CSEQ1)
step2
SYN(SSEQ)/ ACK(CSEQ1)








step4
DATA(CSEQ1)/ACK(SSEQ1)
DATA(CSEQ1)/ ACK(SSEQ1)

Server sent HTTP 404
RST
step6
Right server
step7
SYN(CSEQ)


SYN(RSEQ)/ ACK(CSEQ1)

step8


Sequence conversion needed for right server now
ACK(RSEQ1)

step9



step10

DATA(SSEQ1)/ACK(CSEQLenR1)
DATA(RSEQ1)/ACK(CSEQlenR1)
step11

step12
ACK(SSEQlenD1
ACK(RSEQlenD1)
15
Filter Process Scheme
Filter Processrun on server
client

server

content switch


SYN(CSEQ)
step1





step3


DATA(CSEQ1)/ACK(DSEQ1)
step4
step5b
SYN(CSEQ)
Migrate(Data, CSEQ, DSEQ)

step5
a

SYN(SSEQ)/ ACK(CSEQ1)

step6


step7

DATA(CSEQ1)/ACK(SSEQ1)

step8






ACK(DSEQ
lenD1)

ACK(SSEQlenD1)

step10
16
Performance Metrics

• Processing time vs document size for GET request
• Processing time vs document size for POST request
• Obtained results for individual schemes using
  Webbench by varying the delay and number of
  threads sending request
• Plot of max sustainable requests/sec vs. number
  of rules
• Plot of max throughput in bytes/sec vs. number of
  rules

17
Benchmark Configuration

• fladnag.uccs.edu - content switch -
  128.198.192.184 - Linux 2.2-16-3
• vinci.uccs.edu - real server 1 -
  128.198.192.193 - Linux 2.2-16-3
• gandalf.uccs.edu - real server 2 -
  128.198.192.194 - Linux 2.2-16-3
• dilbert.uccs.edu - client -
  128.198.192.195 - Windows NT 4.0
• For plot of processing time vs. document size.
• used a Perl script that sends GET and POST
  requests
• with varying request and response sizes.
• For response time and throughput measurement.
• used Webbench

18
Processing Time vs. Response Size for GET Request
19
Processing Time vs. Request Size for POST Request
20
Comparison of Overall Webbench Requests/Second
Metric
21
Comparison of Overall Webbench Throughput
(Bytes/Second) Metric
22
Request/Sec vs. Number of CS Rules
23
Throughput in Bytes/Sec vs. Number of CS Rules
24
Handling Multiple Requestsin a Keep-Alive
Connection

• Determine when new request arrives
• Verify that previous request has been completely
  received
• TCP payload size is gt 0
• Key assumption is only one outstanding request is
  sent at a time by client, i.e., requests are not
  pipelined.
• Reuse connections
• Store each connection control information in a
  hash table keyed by real server address, once it
  is established.

25
Keep-Alive Connection Hash Table

• For each real server, hash table entry stores
  following parameters
• rs_addr
• cli_str_seq
• cli_str_ack_seq
• rs_last_next_seq
• rs_last_ack_seq

26
Client to Real Server Sequence Translation in a
Keep-Alive Connection

• Sequence number of packet sent by client and
  forwarded to current real server
• rs_last_ack_seq (cli_cur_seq - cli_str_seq)
• Here cli_cur_seq is the sequence number of
  currently forwarded client packet.
• Acknowledgment number of packet sent by client
  and forwarded to current real server
• rs_last_next_seq (cli_cur_ack_seq -
  cli_str_ack_seq)

• Here cli_cur_ack_seq is the acknowledgment
  number of currently forwarded
• client packet.

27
Real Server to Client Sequence Translation in a
Keep-Alive Connection

• Sequence number of packet sent by real server and
  forwarded to client
• cli_str_ack_seq (rs_cur_seq -
  rs_last_next_seq)
• Here rs_cur_seq is the sequence number of
  currently forwarded real server packet.
• Acknowledgment number of packet sent by real
  server and forwarded to client
• cli_str_seq (rs_cur_ack_seq -
  rs_last_ack_seq)

• Here rs_cur_ack_seq is the acknowledgment
  number of currently forwarded
• real server packet

28
Handling Multiple Packets of a HTTP Request

• Request may span over multiple TCP segments which
  requires queuing of incoming packets
• Determine when request is completely received
  which requires parsing of HTTP header content,
  e.g., Content-Length tag in requests like PUT
  and POST
• Keeping in sync with client and server TCP
• HTTP request fragmentation example, where TCP
  Segment n contains
• POST /cgi-bin/cs622/purchase.pl HTTP/1.0\r\n
• Referer http//archie.uccs.edu/acsd/lcs/xmldemo.
  html\r\n
• Connection Keep-Alive\r\n
• Content-type application/x-www-form-urlencoded\r\
  n
• Content-length 7
• and TCP Segment n1 contains
• 53\r\n
• data (753 bytes)

29
Handling Different Data Encodings in XML Document

• Typically there are two encoding techniques
• text/xml
• consist of plain ascii text with no specical
  encoding
• x-www-form-urlencoded
• Consist of text where special characters are
  encoded as XX, where XX is the hexadecimal
  value of the special character.
• For example, newline and left anchor (lt)
  characters are encoded as "0A" and "3C
  respectively.

30
Improved Rule Specification

• ltpurchasegt
• ltcustomerIDgt111222333lt/customerIDgt
• ltitemgt
• ltproductIDgt309121544lt/productIDgt
• ltunitPricegt5000lt/unitPricegt
• lt/itemgt
• ltitemgt
• ltproductIDgt309121538lt/productIDgt
• ltunitPricegt200lt/unitPricegt
• lt/itemgt
• lt/purchasegt
• Many tags with the same name make rule
  specification ambiguous, e.g, the item tag in
  above XML sample document
• A rule specification like purchase1item2uniP
  rice1 gt 200 allows to access unitPrice tag
  of the second item

31
High-Availability of Linux Content Switch (HA-LCS)

• Address issues related to fault tolerance of
• Virtual server
• real servers or services on the real server
• high-availability of data files (e.g. HTML docs)
• The setup is based on existing configuration of
  high-availability of LVS with with following key
  software components
• Heartbeat (for fault tolerance of virtual server)
• Mon (for fault tolerance of services of real
  server)
• Coda (for high-availability of data files)

32
HA-LCS Architecture
user
real server 1
mon
heartbeat
Coda file system
primary
real server 2
mon
heartbeat
backup
virtual server cluster
LAN
real server 3
33
HA-LCS Configuration

• fladnag.uccs.edu - content switch (primary) -
  128.198.192.184 - Linux 2.2.16-3
• walden.uccs.edu - content switch(secondary) -
  128.198.192.203 - Linux 2.2.16-3
• vinci.uccs.edu - real server 1 (coda client)
  - 128.198.192.193 - Linux 2.4.2-2
• gandalf.uccs.edu - real server 2 (coda client) -
  128.198.192.194 - Linux 2.4.2-2
• wait.uccs.edu - coda server -
  128.198.192.202 - Linux 2.4.2-2

34
Unique Constraints Imposed in HA-LCS as Compared
to HA-LVS

• In LCS, switching rules based on application
  content are hard wired in kernel rule module. To
  change a switching rule requires
• modify rule module code to reflect changed rule
• compile modified rule module
• remove old rule module
• insert new old module
• In LVS, switching rules based a simple load
  balancing policy and can be changed via built in
  commands

35
HA-LCS Configuration Notes

• Heartbeat
• Setting up ha.cf and haresources file
• Note The IP address specified in the
  haresources file should not be configured via
  OS
• Mon
• Setting up mon.cf and real server
  failure/startup handler script wk_up.ksh
• Coda
• Setting up coda server using vice-setup and
  configuring client
• When creating coda volume on server the
  INSTALL.linux setup file says create volume as
• createvol_rep codaroot E0000100 /vicepa, where
  codaroot is root volume
• On the other hand, online coda help says root
  volume be set as coda.root.
• While creating coda admin, do not specify user id
  as 1, even though instructions say one can use
  coda admin user id as 1.

36
Performance of Different File Systems with HA-LCS
37
Conclusion

• Implemented three schemes to study improvement on
  TCP delayed binding. Pre-allocate scheme gave
  best results followed by basic and filter scheme.
• Implemented scheme to handle multiple requests in
  a given connection coming in a non-pipelined
  fashion.
• Proposed ways to handle request sent in a
  pipelined fashion in a Content Switch
• Addressed issues related to content switch
  processing
• handling multiple packets in a request,
• improving rule matching,
• handling different data encoding formats.
• Implemented a highly-available Linux Content
  Switch (LCS) system
• Identified key issues related to fault tolerance
  in LCS and implemented the solutions.

38
Future Work

• Improve the reliability of LCS by moving the
  content switch processing from IP layer to
  Transport layer.
• Enhance load balancing policies by considering
  network path status and server load.
• Improve performance by reusing connections in a
  connection pool to avoid setup overhead
• Utilize latest protocols, e.g., ASAP/ENRP, for
  managing fault-tolerant clusters.
