Ambient Air Volatile Organic Compound Tube Method Sampling

1
Ambient AirVolatile Organic CompoundTube Method
Sampling
2
Enabling Learning Objectives

• Given a VOC tube sampling device, demonstrate the
  proper techniques for operating, maintaining the
  equipment IAW manufacturers operating
  instructions.
• Given a list, select the tube methods for
  detecting VOCs IAW EPA standard methods.
• Given a list, select the equipment needed to
  conduct VOC tube sampling IAW manufacturers
  operating instructions.
• Given a list, select the pump programming
  procedures for the VOC tube sampling device IAW
  manufacturers operating instructions.

3
Enabling Learning Objectives

• Given a list, select the sample collection
  procedures for the VOC tube sampling device IAW
  manufacturers operating instructions.
• Given a list, select the sample recovery
  procedures for the VOC tube sampling device IAW
  manufacturers operating instructions.
• Given a list, select the post-sampling site
  procedures for the VOC tube sampling device IAW
  manufacturers operating instructions.
• Given a list of calibration procedures for the
  VOC tube sampling device, select the appropriate
  steps IAW manufacturers operating instructions.

4
Outline

• VOC Tube Sampling Methods
• VOC Tube Sampler Equipment
• Pump Calibration Procedures
• Pump Programming Procedures
• Sample Collection Procedures
• Sample Recovery Procedures
• Post Sampling Procedures
• Field Datasheet and Instructions

5
VOC Tube Sampling Methods

• Toxic Organic - 1 (TO-1)
• TO-17
• DAMMS

6
(No Transcript)
7
TO-1

• Handling
• Hold the middle of the tube (DO NOT hold ends)
• Oils from fingers could cause contamination
• Storage/Shipping
• Keep tubes refrigerated
• DO NOT allow tubes to get wet
• Ship in cooler with ice
• seal in zip-lock bags
• Shipping Container
• No storage container
• Wrap in bubble wrap

8
TO-1

• Sampling
• Remove the Swage lock fittings
• Attach a pump tubing to one end of the tube
• Sample Volume
• Total volume range 18-20 liters
• Should NOT exceed 20 liters
• 19 liter corresponds to 40mL/min flow rate over
  an 8 hour sampling period
• Analytical
• Gas Chromatograph/Mass Spectrometry (GC/MS)

9
TO-17

• Handling
• Hold the middle of the tube (DO NOT hold ends)
• Oils from fingers could cause contamination
• Storage/Shipping
• Keep tubes refrigerated
• DO NOT allow tubes to get wet
• Ship in cooler with ice
• seal in zip-lock bags
• Shipping Container
• Each stainless steel tube is contained in a
  shipping container
• Label properly

10
TO-17

• Sampling
• Black arrow indicates direction of flow
• If NO arrow is visible, DO NOT USE
• Attach the pump tubing to the end the arrow is
  pointing
• Sample Volume
• Total volume range 18-20 liters
• Should NOT exceed 20 liters
• 19 liter corresponds to 40mL/min flow rate over
  an 8 hour sampling period
• Analytical
• Gas Chromatograph/Mass Spectrometry (GC/MS)

11
DAMMS

• Handling
• Hold the middle of the tube (DO NOT hold ends)
• Oils from fingers could cause contamination
• Storage/Shipping
• Keep tubes refrigerated
• DO NOT allow tubes to get wet
• Ship in cooler with ice
• seal in zip-lock bags
• Shipping Container
• Glass sampling tube is shipped in capped glass
  container
• Tubes must be packed to withstand breakage

12
DAMMS

• Sampling
• Black arrow indicates direction of flow
• If NO arrow is visible, DO NOT USE
• Attach the pump tubing to the end the arrow is
  pointing
• Sample Volume
• Total volume range 18-20 liters
• Should NOT exceed 20 liters
• 19 liter corresponds to 40mL/min flow rate over
  an 8 hour sampling period
• Analytical
• Gas Chromatograph/Mass Spectrometry (GC/MS)

13
Pump Calibration
14
Tygon Tubing
Calibrator
PUFF CalibrationTube
Flow Rate
Flow Rate
Tygon Tubing
Sampling Pump
Teflon - Preferred Tygon - UV breakdown
TO-10 Calibration Setup
15
Pump Calibration

• Introduction
• Should be conducted in controlled work area
• Should be conducted before and after each
  sampling episode
• Must use a calibration tube

16
Pump Calibration

• Pre-Sampling Calibration Procedure
• Record calibration data on the field data sheet
• Connect the calibration sampling tube
• Connect other end of sample calibration tube to
  the calibrator
• Insure sufficient level of bubble solution
• Turn pump on
• Depress and release the black button on the
  calibrator
• Observe the pump flow

17
Pump Calibration

• Pre-Sampling Calibration Procedure
• Turn the fine adjustment to achieve desired flow
  rate
• TO-1 Flow Rate - 39.5 ml/min
• TO-17 Flow Rate - 39.5 ml/min
• DAMMS Flow Rate - 39.5 ml/min
• Take 3 - 5 readings and record average as Flow
  Rate Pre
• Post Sampling Calibration procedure
• should be the same
• except with NO FLOW ADJUSTMENT
• Take 3 - 5 readings and record average as Flow
  Rate Post

18
SKC Pump Control Pad
19
Programming the Pump

• Introduction
• If unit is programmable, USE THE PROGRAMMER
• Pump can be programmed for a delayed start
• Ensures primary and co-located pumps start at
  same time
• Allows for programming to be conducted off-site
• Programming the SKC Pump
• Initializing Programming
• Turn pump on
• Press START/HOLD
• Press SET UP

20
Programming the Pump

• Programming the SKC Pump
• Programming Delayed Start
• Determine the delayed start time and duration of
  sampling
• Press MODE until Delayed Start is displayed
• Set DELAY START using the digit select and digit
  set buttons
• Programming Sample Period
• Determine sample period
• Press MODE until Pump Period is displayed
• Set PUMP PERIOD using the digit select and digit
  set buttons

21
Programming the Pump

• Programming the SKC Pump
• Toggle through the Delayed Start, Sample
  Period, and Pump Period to ensure correct
  times have been set
• Press START/HOLD
• Places unit in HOLD mode
• Once in HOLD mode, sampler will begin count
  down
• When delayed start has reached zero the sampler
  will start

22
Teflon - Preferred Tygon - UV breakdown
23
Sample Collection Procedures

• Take the following equipment to site
• 2 pumps
• 3 sampling tubes and containers
• Primary sample
• Co-located sample
• Field Blank
• Tygon or Teflon tubing
• Thermometer/barometer
• GPS

24
Sample Collection Procedures

• Record data on the field data sheet
• Place the following information on the sample
  label
• Sample ID
• Pump ID
• Start Date
• Tube ID

Sample ID
Pump ID Tube ID
Start Date End Date

25
Sampling Collection Procedures

• Attach the pumps to an appropriate structure
• 5 feet off of ground
• unobstructed area
• must determine location before sampling is
  initiated
• Insert tubes into tubing
• ensure flow is in correct direction
• Place pump in zip-lock bag if raining
• note rain on field data sheet
• Field blank
• Handle in same manner
• Return it to its container

26
Sampling Recovery Procedures

• At end of sampling period
• Bring field blank to sampling site
• Handle blank in identical fashion as samples
• Remove sampling tubes from pump
• ensure tube goes to correct container
• Record data on field data sheet

27
Post Sampling Procedures

• Retrieve sampling tubes and pumps
• Store sample tubes in refrigerator or cooler
• Conduct post-sampling calibration
• Record Flow Rate Post on field data sheet

28
Battery Maintenance

• Before charging a battery, ensure that it is
  totally discharged
• Charge battery for a minimum of 12 hours
• Only use a fully charged battery
• Battery will last for approximately 10 hours
  (when fully charged)

29
Charger
30
Quality Assurance/ Quality Control Procedures

• Note in the Invalid Sample field the
  appropriate code of sampler malfunction or filter
  damage
• Ensure all required fields on Field Data Sheet
  are complete and legible
• Enter Field Data Sheet information into
  Deployment Environmental Surveillance Database
  if applicable
• Complete data sheets for field blanks

31
Error Conditions

• If SKC pump doesnt work after you have tried
  everything in the book, send it back to CHPPM

32
Packing Samples for Shipment

• Filters should be replaced in their respective
  petri dishes and sealed.
• Include enough packing material in shipping box
  to ensure that filters do not move in shipping
  container.
• Tubes MUST NOT GET WET!
• Put tubes in sealed plastic bags
• Keep at 4oC

33
Sample Shipment

• Notify Laboratory POC of type, number, and
  collection dates of samples.
• Lab analysis request form, chain of custody form
  and soil importation permit placed inside cooler
• Soils importation form and chain of custody seal
  affixed to exterior of cooler.
• Packing materials
• Ice chest or other packing container
• mark Environmental Samples,
• This end up, "U.S. Government
• Property", etc.
• Freezer packs (4 degrees Celsius )

34
Sample Shipping

• Standard/Priority analysis samples can be sent by
  commercial carriers.
• Talk with the shipper before collecting the
  samples.
• Do not send Hazardous Materials by U.S. Mail.

35
Holding Times

• Holding Time To
• Parameter Preservation Extraction/Analysis
• Volatiles 4oC -Minimum Headspace ASAP/14 days
• Pesticides 4oC 7 days/30 days
• Herbicides 4oC 7 days/30 days
• Metals Cool 6 months
• Radioactivity
• Gross Alpha Beta None NA
• Oil and Grease 4oC 60 days

36
Field Data Sheet
37
Field Data Sheet (Pre-Sampling)

• Calibration
• Calibration Location
• Calibrator ID
• Calibration Operator
• Calibration Date
• Pump ID

38
Field Data Sheet (Sampling)

• Sample Collection
• Sample ID
• Sample Location
• Field Blank ID
• Sample Type
• Sample
• Field Blank
• Trip Blank
• Tube ID
• Operator

39
Field Data Sheet (Sampling)

• Sample Collection
• VOC Method
• Latitude (degrees)
• Latitude (minutes)
• Longitude (degrees)
• Longitude (minutes)
• Start Date
• Start Time

40
Field Data Sheet (Post-Sampling)

• Sample Recovery
• Start Date
• Start Time
• Sample Time
• Field Notes

41
Summary

• VOC Tube Sampling Methods
• VOC Tube Sampler Equipment
• Pump Calibration Procedures
• Pump Programming Procedures
• Sample Collection Procedures
• Sample Recovery Procedures
• Post Sampling Procedures
• Field Datasheet and Instructions

42
Questions

• ?
